Frigidaire FRT17HB3C User manual

N05L00004.eps N05DBDCKA0.eps N05BBAABA25.eps N05SADDCA21.eps
N05CAAAAA18.eps 240398801.eps 240398601.eps
Product No. FRT17HB3CW3 FRT17HB3CW4
Series R134a R134a
Color white white
Volts 115 115
Wiring Diagram 240398801 240398801
Owner's Guide 240400113 240400113
Market North America North America
Energy Guide 240592273 240592273
Service Data Sheet 240379017 240379017
Installation Instructions 240568301 240568301
North & Latin America
P.O. BOX 212378
AUGUSTA, GA 30917
Publication No.
5995455556
05/12/07
(EN/SERVICE/KHB)
390
TOP-MOUNT
REFRIGERATOR
Model No.
FRT17HB3C
Copyright ©All rights reserved.

Publication No: 5995455556 FRT17HB3C
12/05 2
DOOR
10
22
22
11
12
73
74
21A
18A
21
22
14
22
22
13A
13
21C
21C
10
22 18A
14
22
1
2
22
15
73
74
21A
N05DBDCKA0
8
4
4
4B
7

FRT17HB3C Publication No: 5995455556
# Functional Parts 3 12/05
* Non-Illustrated Parts
DOOR
Model Index: AFRT17HB3C (FRT17HB3CW3)
BFRT17HB3C (FRT17HB3CW4)
POS. NO PART NO. DESCRIPTION
1 # 240554101 A B Gasket-frzr door, white, magnetic
2 # 240542104 A B Gasket-refr door, white, magnetic
4 240535101 A B Rack-door
4B 240535201 A B Rack-door
7 240337701 A B Door-dairy, w/o graphics, white
8 240535001 A B Rack-door
10 240381301 A B Plug-button, white, hinge brg hole, (2)
11 240420101 A B Door, frzr, white
12 240415201 A B Label-nameplate, white
13 240312403 A B Door Stop, white, ref
13A 240312404 A B Door Stop, white, frzr
14 240494001 A B Plug-button, white
15 240420201 A B Door, refr, white
18A 218428101 A B Handle-door, white, w/block & screw
21 240383401 A B Screw, truss hd quad, #10-16 x .500
21A 240521301 A B Screw, #10-16 x 1/2
21C 218252200 A B Screw, #8 truss hd, 10-32CA x 0.500
22 240527101 A B Bearing-hinge, natural color
73 218396700 A B Block-handle mtg, dovetail
74 215503200 A B Screw, cr pan hd, 10-16 x 0.500

Publication No: 5995455556 FRT17HB3C
12/05 4
CABINET
83
82
11
10
1
12
12A
81
4
58
2
3
92
38
37
13
5
58
35A 36
34
35
59
59
56
42
30
72
N05BBAABA25
43 21C
41
41
41
8
8
9
14
81
34
22
21C
89

FRT17HB3C Publication No: 5995455556
# Functional Parts 5 12/05
* Non-Illustrated Parts
CABINET
Model Index: AFRT17HB3C (FRT17HB3CW3)
BFRT17HB3C (FRT17HB3CW4)
POS. NO PART NO. DESCRIPTION
1 241652301 A B Cover-fan
2 240367001 A B Knob-damper control
3 5303001028 A B Nut, push-on
4 241523701 A B Damper-fan cover
5 # 5308000010 A B Fan Blade, red, evaporator fan
8 5300157666 A B Bushing-motor mtg, (2)
9 5303292396 A B Bracket-motor mtg, front
10 241652211 A B Cover-evap coil
10* 240568601 A B Seal-coil cover
10*# 241520701 A B Harness-wiring, freezer
11 5303208309 A B Plug-hole, factory test
12 241557601 A B Plug-ice maker harness, rectangular
12A 240374401 A B Plug-wtr inlet tube, round, 1"
12A* 241586701 A B Plug-foam-wtr-inlet, round
13 # 240369702 A B Motor-evap fan
13* 215474201 A B Washer, "slinger", nylon, evap fan shaft
13* 218931001 A B Clamp-motor wiring, nylon, w/adhesive tape
14 5303292397 A B Bracket-motor mtg, rear
14* 5303274237 A B Screw, hex washer head, 8-32CA x 0.500, motor bracket
21C 218252200 A B Screw, #8 truss hd, 10-32CA x 0.500
22 215774901 A B Plug-button, white, upr hinge holes
30 240357101 A B Bracket-lower hinge, zinc chromate
34 240311303 A B Washer, hinge, nylon, (2)
35 240357001 A B Bracket-ctr hinge, zinc
35A 240336802 A B Spacer-hinge, center
36 240516401 A B Pin-center hinge
37 241611301 A B Trim-cabinet corner, white, (2)
38 241622501 A B up-hinge, plastic, white
41 5308009759 A B Grommet, shelf mtg, 1.25", LH, (4)
42 240578901 A B Screw-hinge mtg, hex head, 1/4-20 x 5/8
43 241559602 A B Roller Assy, fixed, front LH
43* 241559601 A B Roller Assy, fixed, front RH
56 240516501 A B Pin-lower hinge
58 5303001343 A B Screw, hex washer head, 8-15A x 0.500
59 240442701 A B Screw-#10-32 X 3/4, zinc
72 240368301 A B Grille/Kickplate, white
81 5308016566 A B Screw, hex washer head, 8-15A x 0.625, low profile
82 5304418225 A B Roller, compressor base, rear, (2)
83 5303316859 A B Rivet, flat head, 1/4 OD x 1-3/4, roller pin
89 241574606 A B Cover-access, w/label
89* 241500302 A B Screw, hex washer head, 8-18AB x 0.625
92 241624301 A B Screw-hinge mtg, hex head, 1/4-20 x 1.00
* 240479601 A B Plug, button, cab liner holes, (2)
* 5303305324 A B Paint, touch-up, white

Publication No: 5995455556 FRT17HB3C
12/05 6
SHELVES

FRT17HB3C Publication No: 5995455556
# Functional Parts 7 12/05
* Non-Illustrated Parts
SHELVES
Model Index: AFRT17HB3C (FRT17HB3CW3)
BFRT17HB3C (FRT17HB3CW4)
POS. NO PART NO. DESCRIPTION
11 5303282284 A B Shelf-freezer, "table type"
12 241542001 A B Diffuser, air, top
13 240362601 A B Diffuser, air, bottom
14 # 241554901 A B Switch-light/lamp
15 241555401 A B Light Bulb
16 241559801 A B Socket-light
17 240368001 A B Control Box
17* 240568607 A B Seal
17*# 240388701 A B Wiring Harness, control box
18 240360801 A B Knob, temp control
21 # 5304421256 A B Control, temperature
22A 240468201 A B Tube, sensor sleeve, 31 inch, plastic, white
23 # 241621501 A B Timer-defrost
23* 5303001259 A B Screw-timer mtg, pan hd, 6-20 x 0.438, (2)
24 240360902 A B Shelf, sliding, wire
25 240364706 A B Cover, crisper pan
26 240364501 A B Pan, crisper, (2)
81 5308016566 A B Screw, hex washer head, 8-15A x 0.625, low profile

Publication No: 5995455556 FRT17HB3C
12/05 8
SYSTEM
17 21
15
20
14
20
16
60
59
61
58
1
34
34
83
44
41
82
83
82
N05CAAAAA18
22
23
23
30
32
85
55
4
6
29
26
84
45
57
25
25

FRT17HB3C Publication No: 5995455556
# Functional Parts 9 12/05
* Non-Illustrated Parts
SYSTEM
Model Index: AFRT17HB3C (FRT17HB3CW3)
BFRT17HB3C (FRT17HB3CW4)
POS. NO PART NO. DESCRIPTION
1 # 240444401 A - Condenser, dynamic
1 # 241665701 - B Condenser, dynamic
4 # 218944001 A B Drier-filter, R134a System
6 240496101 A B Wiring Harness, machine compt, w/electric cord
6* 241520701 A B Harness-wiring, freezer
6* 240388701 A B Wiring Harness, control box
14 # 240356213 A B Heater-defrost
15 # 5303918275 A B Evaporator Kit
16 5308000110 A B Strap-evap/heater, aluminum, (2)
17 241551802 A B Trough-drain
20 241551901 A B Insulation Block
21 # 5303918202 A B Thermostat-defrost, kit
22 241602005 A - Base-compressor
22 241665401 - B Base-compressor
22* 218252200 A B Screw, #8 truss hd, 10-32CA x 0.500
23 218513300 A B Grommet-compr mtg, (4)
25 240491501 A B Screw-compressor mtg, 1/4-28 x 1.16, shoulder, typ CF
26 240332608 A B Pan-defrost drain
29 5303918299 A B Compressor, w/electricals
30 # 241527802 A B Starter
32 241544101 A B Clamp, elec cont mtg, compressor, bale wire
34 240405201 A B Grommet, rubber, black, cond tube/wire
41 240433202 A B Screw, hex washer head, 8-18 x 5/16
44 5303001199 A B Clamp-wiring harness, strain relief, galv steel
45 5308016566 A B Screw, hex washer head, 8-15A x 0.625, low profile
55 218909915 A B Capacitor, run, 220 VAC, 15 microfarad
57 240542601 A B Clip-wiring harness
58 218897002 A B Screw, hex washer head, 8-32 x 0.375
59 5304430246 A B Bracket-cond motor assy
59* 240346701 A B Tape-foam seal, shroud
59* 240359401 A B Screw-fan shroud, (2)
60 240525402 A B Motor, condensor fan
61 # 240524101 A B Fan Blade, galv steel, condenser fan
61* 240397201 A B Connector-shaft
82 5304418225 A B Roller, compressor base, rear, (2)
83 5303316859 A B Rivet, flat head, 1/4 OD x 1-3/4, roller pin
84 240500801 A B Tube-drain, rubber, lower
85 240553501 A B Tube-connector, suction
* 218843800 A B Screw, hex wshr hd, 8-15A x 0.500
* 240396801 A B Clamp, tube/wiring, nylon, black/natural
* # 5303918263 A B Heat Exchanger Kit, suction line
* 5303918222 A B Hot Tube Repair Kit, service
