Frigidaire FRT18IS6C User manual

Product No. FRT18IS6CBF FRT18IS6CQF FRT18IS6CWF
Series R134a R134a R134a
Color black bisque white
Volts 115 115 115
Wiring Diagram 240398801 240398801 240398801
Owner's Guide 240400112 240400112 240400112
Market North America North America North America
Energy Guide 240572138 240572138 240572138
Service Data Sheet 240379017 240379017 240379017
Installation Instructions 240568301 240568301 240568301
N05L00003.eps N05DCDBCA1.eps N05BBAAAA12.eps N05SACAFI17.eps
N05CAAAAA8.eps 115-1.eps 240398801.eps 240398601.eps
u x Major Appliances
North & Latin America
P.O. BOX 212378
AUGUSTA, GA 30917
Publication No.
5995451696
05/10/18
(EN/SERVICE/WC)
390
TOP-MOUNT
REFRIGERATOR WITH
ICE-MAKER
Model No.
FRT18IS6C
Copyright ©2005 Home Pr oducts, Inc.
All rights reserved.

Publication No: 5995451696 FRT18IS6C
10/05 2
DOOR
14
14
48
48A
48B
10
22
22
11
12
22
22
22
13A
13
21C
21C
10
22
14
22
1
7
2
22
N05DCDBCA1
15
21 14B
21
14B
18
21
18A
49
49

FRT18IS6C Publication No: 5995451696
# Functional Parts 3 10/05
* Non-Illustrated Parts
DOOR
Model Index: AFRT18IS6C (FRT18IS6CBF)
BFRT18IS6C (FRT18IS6CQF)
CFRT18IS6C (FRT18IS6CWF)
POS. NO PART NO. DESCRIPTION
1 240542121 A - - Gasket-frzr door, black, magnetic
1 240542115 - B C Gasket-frzr door, white, magnetic
2 240542124 A - - Gasket-refr door, black, magnetic
2 240542118 - B C Gasket-refr door, white, magnetic
7 240337703 A B C Door-dairy, w/o graphics, clear
10 240381303 A - - Plug-button, black, hinge brg hole
10 240381302 - B - Plug-button, bisque, hinge brg hole, (2)
10 240381301 - - C Plug-button, white, hinge brg hole, (2)
11 240409919 A - - Door, frzr, black
11 240409902 - B - Door-frzr, bisque, complete assy
11 240409901 - - C Door-frzr, white, complete assy
12 240416304 A - - Nameplate, black
12 240416303 - B - Label-nameplate, bisque
12 240416301 - - C Label-nameplate, white
13 240312405 A - - Door Stop, black, refr
13 240312407 - B - Door Stop, bisque, ref
13 240312403 - - C Door Stop, white, ref
13A 240312406 A - - Door Stop, black, frzr
13A 240312408 - B - Door Stop, bisque, frzr
13A 240312404 - - C Door Stop, white, frzr
14 240494003 A - - Plug-button, black
14 240494002 - B - Plug-button, bisque
14 240494001 - - C Plug-button, white
14B 240383603 A - - Plug-button, black, door handle
14B 240383602 - B - Plug-button, bisque, door handle
14B 240383601 - - C Plug-button, white, door handle
15 240410125 A - - Door, refr, black
15 240410002 - B - Door-refr, bisque, complete assy
15 240410001 - - C Door-refr, white, complete assy
18 240339203 A - - Handle-door, black, refr-LH/frzr-RH
18 240339204 - B - Handle-door, bisque, refr-LH/frzr-RH
18 240339201 - - C Handle-door, white, refr-LH/frzr-RH
18A 240339208 A - - Handle-door, black, refr-RH/frzr-LH
18A 240339209 - B - Handle-door, bisque, refr-RH/frzr-LH
18A 240339206 - - C Handle-door, white, refr-RH/frzr-LH
21 240383401 A B C Screw, truss hd quad, #10-16 x .500
21C 218252200 A B C Screw, #8 truss hd, 10-32CA x 0.500
22 240527102 A - - Bearing-hinge, black
22 240527101 - B C Bearing-hinge, natural color
48 240338101 A B C Bin-door, pseudo, bottom
48A 240337901 A B C Bin-door, refr
48B 240338001 A B C Bin-door, pseudo, gallon, refr
49 240495804 A B C Bin-door, pseudo, frzr

Publication No: 5995451696 FRT18IS6C
10/05 4
CABINET
83
82
89
11
10
1
81
4
58
2
3
92
38
37
13
5
58
35A 36
34
35
59
59
56
42
30
72
N05BBAAAA12
43
28
21C
21C
41
41
41
8
8
9
14
81
34
22
37

FRT18IS6C Publication No: 5995451696
# Functional Parts 5 10/05
* Non-Illustrated Parts
CABINET
Model Index: AFRT18IS6C (FRT18IS6CBF)
BFRT18IS6C (FRT18IS6CQF)
CFRT18IS6C (FRT18IS6CWF)
POS. NO PART NO. DESCRIPTION
1 241652301 A B C Cover-fan
2 240367001 A B C Knob-damper control
3 5303001028 A B C Nut, push-on
4 241523701 A B C Damper-fan cover
5 # 5308000010 A B C Fan Blade, red, evaporator fan
8 5300157666 A B C Bushing-motor mtg, (2)
9 5303292396 A B C Bracket-motor mtg, front
10 241652210 A B C Cover-evap coil
10* 240568601 A B C Seal-coil cover
10* 241520701 A B C Harness-wiring, freezer
11 5303208309 A B C Plug-hole, factory test
13 # 240369702 A B C Motor-evap fan
13* 215474201 A B C Washer, "slinger", nylon, evap fan shaft
13* 218931001 A B C Clamp-motor wiring, nylon, w/adhesive tape
14 5303292397 A B C Bracket-motor mtg, rear
14* 240433201 A B C Screw, hex washer head, 8-18 x 0.375
21C 218252200 A B C Screw, #8 truss hd, 10-32CA x 0.500
22 215774918 A - - Plug-button, black, upr hinge holes
22 215774919 - B - Plug-button, bisque, upr hinge holes
22 215774901 - - C Plug-button, white, upr hinge holes
28 240335501 A B C Bolt-roller adj, hex washer head, 1/4-20 x 4.020, (2), special
30 240314003 A - - Bracket-lower hinge, black
30 240314001 - B C Bracket-lower hinge, zinc
34 240311303 A B C Washer, hinge, nylon, (2)
35 240313803 A - - Bracket-ctr hinge, black
35 240313801 - B C Bracket-ctr hinge, zinc
35A 240336802 A B C Spacer-hinge, center
36 240516401 A B C Pin-center hinge
37 241611303 A - - Trim-cabinet corner, black, (2)
37 241611304 - B - Trim-cabinet corner, bisque, (2)
37 241611301 - - C Trim-cabinet corner, white, (2)
38 241622603 A - - Hinge-up-plastic-blk, plastic, black
38 241622604 - B - Hinge-up-plastic-bis, plastic, bisque
38 241622601 - - C Hinge-up-plastc-wht, plastic, white
41 5308009759 A B C Grommet, shelf mtg, 1.25", LH, (4)
42 240578901 A B C Screw-hinge mtg, hex head, 1/4-20 x 5/8
43 240335003 A B C Roller Assy, adjustable, front, (2)
56 240516501 A B C Pin-lower hinge
58 240433202 A B C Screw, hex washer head, 8-18 x 5/16
59 240442703 A - - Screw-#10-32 X 3/4, black
59 240442701 - B C Screw-#10-32 X 3/4, zinc
72 240368207 A - - Grille/Kickplate, black
72 240368206 - B - Grille/Kickplate, bisque
72 240368205 - - C Grille/Kickplate, white
81 5308016566 A B C Screw, hex washer head, 8-15A x 0.625, low profile
82 5304418225 A B C Roller, compressor base, rear, (2)
83 5303316859 A B C Rivet, flat head, 1/4 OD x 1-3/4, roller pin
89 241574607 A B C Cover-access, w/label
89* 241500302 A B C Screw, hex washer head, 8-18AB x 0.625
92 241624301 A B C Screw-hinge mtg, hex head, 1/4-20 x 1.00
* 5303321321 A - - Paint, touch-up, black
* 5304414035 - B - Paint, touch-up, bisque
* 5303305324 - - C Paint, touch-up, white
* 218515401 A B C Clip

Publication No: 5995451696 FRT18IS6C
10/05 6
SHELVES
11
24A
24
25
47
26
26
23
21
22A
13
12
14
18
17
15
16
58
58
31
25B
25C
N05SACAFI17
34

FRT18IS6C Publication No: 5995451696
# Functional Parts 7 10/05
* Non-Illustrated Parts
SHELVES
Model Index: AFRT18IS6C (FRT18IS6CBF)
BFRT18IS6C (FRT18IS6CQF)
CFRT18IS6C (FRT18IS6CWF)
POS. NO PART NO. DESCRIPTION
11 240358005 A B C Shelf, freezer, full-width, wire
11* 5303299664 A B C Spacer, shelf
12 241542001 A B C Diffuser, air, top
13 240362601 A B C Diffuser, air, bottom
13* 240568607 A B C Seal
14 # 241554901 A B C Switch-light/lamp
15 240436702 A B C Light Bulb/Lamp, A-15, clear, 40 W, 120 V, miniature
16 241559801 A B C Socket-light
17 240352701 A B C Control Box
17*# 240388701 A B C Wiring Harness, control box
18 240360801 A B C Knob, temp control
21 # 5304421256 A B C Control, temperature
22A 240468201 A B C Tube, sensor sleeve, 31 inch, plastic, white
23 # 241621501 A B C Timer-defrost
23* 5303001259 A B C Screw-timer mtg, pan hd, 6-20 x 0.438, (2)
24 240358905 A B C Shelf-"Spill-Safe", sliding
24A 240358906 A B C Shelf-"Spill-Safe", sliding, w/pan hanger
25 240364714 A B C Cover-crisper pan
25B 241613501 A B C Control-humidity, RH
25C 241613502 A B C Control-humidity, LH
26 240337107 A B C Pan-crisper, clear, (2), no graphics
31 240530810 A B C Pan, meat bin
34 240385201 A B C Container, ice bin
47 240350643 A B C Insert-pan cover, glass
58 5308016566 A B C Screw, hex washer head, 8-15A x 0.625, low profile

Publication No: 5995451696 FRT18IS6C
10/05 8
SYSTEM

FRT18IS6C Publication No: 5995451696
# Functional Parts 9 10/05
* Non-Illustrated Parts
SYSTEM
Model Index: AFRT18IS6C (FRT18IS6CBF)
BFRT18IS6C (FRT18IS6CQF)
CFRT18IS6C (FRT18IS6CWF)
POS. NO PART NO. DESCRIPTION
1 # 241666601 A B C Condenser, dynamic
4 # 218944001 A B C Drier-filter, R134a System
6 # 241607001 A B C Harness-wiring, machine compt
6* 241520701 A B C Harness-wiring, freezer
6* # 240388701 A B C Wiring Harness, control box
14 # 240356214 A B C Heater-defrost
15 # 5303918274 A B C Evaporator Kit
16 5308000110 A B C Strap-evap/heater, aluminum, (2)
17 241551801 A B C Trough-drain
20 241551901 A B C Insulation Block
21 # 5303918202 A B C Thermostat-defrost, kit
22 241602001 A B C Base-compressor
22* 218252200 A B C Screw, #8 truss hd, 10-32CA x 0.500
23 218513300 A B C Grommet-compr mtg, (4)
25 240491501 A B C Screw-compressor mtg, 1/4-28 x 1.16, shoulder, typ CF
26 240332608 A B C Pan-defrost drain
29 # 5303918325 A B C Compressor, w/electricals
30 216954201 A B C Controller, compressor
32 216954300 A B C Clip, controller
34 240405201 A B C Grommet, rubber, black, cond tube/wire
41 240433202 A B C Screw, hex washer head, 8-18 x 5/16
44 5303001199 A B C Clamp-wiring harness, strain relief, galv steel
45 5308016566 A B C Screw, hex washer head, 8-15A x 0.625, low profile
55 218909913 A B C Capacitor, run, 220 VAC, 15 microfarad
57 240542601 A B C Clip-wiring harness
58 218897002 A B C Screw, hex washer head, 8-32 x 0.375
59 5304430246 A B C Bracket-cond motor assy
59* 240346701 A B C Tape-foam seal, shroud
59* 240359401 A B C Screw-fan shroud, (2)
60 # 240525402 A B C Motor, condensor fan
61 # 240524101 A B C Fan Blade, galv steel, condenser fan
82 5304418225 A B C Roller, compressor base, rear, (2)
83 5303316859 A B C Rivet, flat head, 1/4 OD x 1-3/4, roller pin
84 240500801 A B C Tube-drain, rubber, lower
85 241665801 A B C Tube-connector, suction
* 240396801 A B C Clamp, tube/wiring, nylon, black/natural
* 5303918263 A B C Heat Exchanger Kit, suction line
* 5303918222 A B C Hot Tube Repair Kit, service

Publication No: 5995451696 FRT18IS6C
10/05 10
ICE MAKER

FRT18IS6C Publication No: 5995451696
# Functional Parts 11 10/05
* Non-Illustrated Parts
ICE MAKER
Model Index: AFRT18IS6C (FRT18IS6CBF)
BFRT18IS6C (FRT18IS6CQF)
CFRT18IS6C (FRT18IS6CWF)
POS. NO PART NO. DESCRIPTION
1 218976901 A B C Tube-water inlet, inlet valve, to ice maker
1* 240561701 A B C Seal-water inlet, inlet valve, to ice maker
2 5304420650 A B C Spring, shut-off arm
3 3206299 A B C Label, ID plate
4 3206301 A B C Gear
5 3206303 A B C Plate-mounting
6 3206305 A B C Screw-ground wire, 8-32 x 0.250
7 # 3206306 A B C Motor-ice maker
8 3206312 A B C Spacer-hold switch
9 3206313 A B C Cam
10 3206315 A B C Clamp
11 3206319 A B C Thermal Cutoff, ICE MAKER, complete assy
12 # 5304420651 A B C Wiring Harness, ICE MAKER, internal, with plug
12* 218843800 A B C Screw, hex wshr hd, 8-15A x 0.500
13 3206322 A B C Thermostat Assy, ICE MAKER
14 5304420652 A B C Screw, 4 x 0.750, switch mtg.
15 # 3206324 A B C Switch, (3)
16 5304420653 A B C Support, phenolic
17 # 5303320545 A B C Mold-ice maker, Radius Cube, with heater
18 3206328 A B C Ejector-ice
19 3206330 A B C Bearing & Inlet
20 5304408581 A B C Screw, 8-32 x 0.375
21 3206332 A B C Ice Stripper
22 3206333 A B C Shut-off Arm
23 5304408582 A B C Screw, 8-32 x 0.875, mold-to-support, (3)
24 3206335 A B C Lever Arm
25 3206336 A B C Screw, 8-18 x 0.562, lever arm/sprt
26 5304420654 A B C Screw-thermo/sprt, 4-24 x 0.375, (4)
27 3206338 A B C Screw, 4-40 x 1.000, hold switch mtg, (2)
28 3206339 A B C Screw-timing stop, 4-40 x 0.375
29 3206323 A B C Screw, 4-24 x 0.750, (6)
30 3206341 A B C Screw-timing adj, 8-32 x 1.000
31 3206342 A B C Insulator
32 3206343 A B C Plate-valve switch
33 5304408583 A B C Spring-timing adj
34 5304420655 A B C Screw, plazscrew, 8-10, (3)
35 5304408585 A B C Screw
36 3206347 A B C Cover-ice maker
45 5303001343 A B C Screw, hex washer head, 8-15A x 0.500
51 241523501 A B C Tube-water, ice mold fill, extension
55 # 240519601 A B C Valve-water, single solenoid, 60 Hz, 105/120 V
60 218362500 A B C Screw, hex washer head, 8-18AB x 1.250, spacer, (2)
61 218721500 A B C Bracket-leveling, ICE MAKER
62 218737900 A B C Screw-IM brkt mtg, hex washer head, 8-32D x 0.375
64 5303001549 A B C Clamp, 0.31 ID, steel, copper wtr line
* 218888001 A B C Adapter-water supply, nut & sleeve, compression ftg
* 240352409 A B C Ice Maker, Radius Cube, 115 V, no instl parts

Publication No: 5995451696 FRT18IS6C
10/05 12
WIRING SCHEMATIC

FRT18IS6C Publication No: 5995451696
# Functional Parts 13 10/05
* Non-Illustrated Parts
WIRING DIAGRAM
