Frigidaire F42WC19E User manual

Product No. F42WC19EB F42WC19EQ F42WC19ES
Market North America North America North America
Color black bisque white
Exhaust-CFM 160 CFM 160 CFM 160 CFM
Volts 120 120 120
Owner's Guide 99043806 99043806 99043806
Installation Instructions 99043806 99043806 99043806
Wiring Diagram 5995459111 5995459111 5995459111
CF30WC.eps F30WC.tif Economy Wiring.eps
Electrolux Major Appliances
North & Latin America
P.O. BOX 212378
AUGUSTA, GA 30917
Publication No.
5995459111
06/02/03
(EN/SERVICE/KC)
099
RANGE HOOD
Model No.
F42WC19E
Copyright ©2006 Electrolux Home Products, Inc.
All rights reserved.

Publication No: 5995459111 F42WC19E
02/06 2
REPLACEMENT PARTS

F42WC19E Publication No: 5995459111
# Functional Parts 3 02/06
* Non-Illustrated Parts
REPLACEMENT PARTS
Model Index: AF42WC19E (F42WC19EB)
BF42WC19E (F42WC19EQ)
CF42WC19E (F42WC19ES)
POS. NO PART NO. DESCRIPTION
1 5304452355 A B C Cover, outlet box(Optional Accessory)
2 5303281950 A B C Screw, sheet metal, 8-18 x 0.375
3 # 5304452356 A B C Receptacle, Lamp holder, w/wires
4 3051767 A B C Lens, lamp, glass
5 5304452357 A B C Fastener Kit, 2-screw & 2-nut
6 # 5304452390 A B C Fan Blade
7 5304452359 A B C Nut, locking, 6-32, (2)
8 3051766 A B C Bracket, motor mount
9 # 5304452360 A B C Motor Assy, fan, includes 6, 7, 8
10 # 5304452031 A B C Filter, aluminum
10 # 5304454054 A B C Filter, duct-free, charcoal, 6-pk(Optional Accessory)
11 5304413743 A B C Clip, filter retainer
12 5303282121 A B C Screw, 8-18B x 0.250, (2)
13 5303281952 A B C Flap, damper door
14 5303281953 A B C Bushing, damper
15 # 5304452361 A B C Damper Assy, incl. 13, 14, 21
16 5304452370 A - - Nameplate, black
16 5304452681 - B - Nameplate, bisque
16 5304452371 - - C Nameplate, white
17 # 5304452392 A - - Switch, motor, black, 2 speed
17 # 5304452394 - B - Switch, motor, bisque, 2 speed
17 # 5304452393 - - C Switch, motor, white, 2 speed
18 # 5304452395 A - - Switch, lamp, black
18 # 5304452397 - B - Switch, lamp, bisque
18 # 5304452396 - - C Switch, lamp, white
19 # 5304452366 A B C Receptacle, motor, with wires
20 5304452398 A - - Cover, louver, black
20 5304452400 - B - Cover, louver, bisque
20 5304452399 - - C Cover, louver, white
21 5304452401 A B C Plate, round duct, 7 inch dia.

Publication No: 5995459111 F42WC19E
02/06 4
WIRING DIAGRAM
