Frigidaire PLHV42P8K User manual

PRODUCT NO. BASE MODEL NO. MARKET COLOR
PLHV42P8KC PLHV42P8KC North America stainless steel
Publication No.
5995360012
011017
-EN/SERVICE /KC
099
RANGE HOOD
Model No.
PLHV42P8K
©2001 White Consolidated Industries, Inc.
All rights reserved
FACTORY PARTS CATALOG
RANGE HOOD
WIRING DIAGRAM - # 5995360012
OWNER’S GUIDE - # 316137200
INSTALLATION INSTRUCTIONS - # 316137200
ELECTROLUX HOME PRODUCTS NORTH AMERICA
P.O. BOX 212378, Augusta, GA 30917

10/01 2
Publication No. PLHV42P8KC
5995360012
Exploded No. $1346
38
23
32
31
19
348
514
14
6
7
49
92
8
41
44
463
56
57
87
98 48
125
34
36
REPLACEMENT PARTS

# = Functional Parts 3 10/01
* = Non-Illustrated Parts
PLHV42P8KC Publication No.
5995360012
REPLACEMENT PARTS
POS. NO PART NO DESCRIPTION
6 # 5304425236 Blower Wheel,fan
7 # 5304425237 Motor,blower fan
8 5304425238 Support,motor
14 5304425239 Housing,blower fan
19 # 5304425240 Capacitor
23 # 5304425283 Filter,range hood ,framed grid
31 5304425150 Lamp,Philips PL-S ,9 Watt ,fluorescent
32 # 5304425151 Lamp Holder
34 # 5304425152 Ballast,lamp ,transformer
36 5304425284 Housing,lamp support
38 5304425285 Cover,lamp lens
40 5304425243 Housing,controls
41 5304425266 Panel,control
44 5304425267 Button,control
48 # 5304425268 Switch,control circuit
49 # 5304425269 Control,printed circuit ,pcb
56 5304425286 Chimney,exhaust duct ,lower extension ,fixed
57 5304425287 Chimney,exhaust duct ,upper extension ,sliding
87 5304425288 Duct,air exhaust ,connector
92 5304425274 Control Box
98 5304425276 Cover,switch
125 5304425277 Cover,plaque ,glass
348 5304425289 Cover,capacitor
463 5304425290 Chimney,exhaust duct ,center section
514 5304425291 Housing,capacitor box
* 218395401 Nameplate

10/01 4
Publication No. PLHV42P8KC
5995360012
WIRING DIAGRAM
