Frigidaire PLHV36W6K User manual

PRODUCT NO. BASE MODEL NO. MARKET COLOR
PLHV36W6KC PLHV36W6K North America stainless steel
Publication No.
5995359998
011017
-EN/SERVICE /KC
099
RANGE HOOD
Model No.
PLHV36W6K
©2001 White Consolidated Industries, Inc.
All rights reserved
FACTORY PARTS CATALOG
RANGE HOOD
WIRING DIAGRAM - # 5995359998
OWNER’S GUIDE - # 316137202
INSTALLATION INSTRUCTIONS - # 316137202
ELECTROLUX HOME PRODUCTS NORTH AMERICA
P.O. BOX 212378, Augusta, GA 30917

10/01 2
Publication No. PLHV36W6KC
5995359998
Exploded No. $1349
87
461
56
57
97
348
19
514
14
470
508
510
84
6
7511
509
48
8
46
47
42
43
40
41
31
23
85
REPLACEMENT PARTS

# = Functional Parts 3 10/01
* = Non-Illustrated Parts
PLHV36W6KC Publication No.
5995359998
REPLACEMENT PARTS
POS. NO PART NO DESCRIPTION
6 # 5304425236 Blower Wheel,fan
7 # 5304425237 Motor,blower fan
8 5304425238 Support,motor
14 5304425239 Housing,blower fan
19 # 5304425240 Capacitor
23 # 5304425241 Filter,range hood ,framed grid
31 # 5304425242 Lamp,halogen ,with holder
40 5304425243 Housing,controls
41 5304425244 Panel,control
42 5304425245 Actuator,light key
43 5304425246 Actuator,motor key
46 # 5304425247 Switch,light
47 # 5304425248 Switch,fan motor
48 # 5304425249 Circuit Board,printed ,control
56 5304425250 Chimney,exhaust duct ,lower extension ,fixed
57 5304425251 Chimney,exhaust duct ,upper extension ,sliding
84 # 5304425252 Ballast,lamp
85 5304425253 Bracket,hood support ,rear ,U-hook
87 5304425254 Duct,air exhaust ,connector
97 5304425255 Bracket,chimney support ,rear
348 5304425256 Cover,capacitor
461 5304425257 Plug,with screw
470# 5304425258 Fuse
508 5304425259 Cover,fuse
509 5304425260 Plate,fuse mounting
510 5304425261 Housing,transformer box
511 5304425262 Channel,xfmr box canal
514 5304425263 Housing,capacitor box
* 218395401 Nameplate

10/01 4
Publication No. PLHV36W6KC
5995359998
WIRING DIAGRAM
