Frigidaire GLTF2940ES3 User manual

Product No. GLTF2940ES3
Series Gallery
Market North America
Color white
Volts 120
Wiring Diagram 134730700
Owner's Guide 134667900
Energy Guide 134454400
Installation Instructions 134678000
Operating Instructions 134726400
P12L0052.eps P12C0361.eps P12V0085.eps P12T0088.eps 134730700.eps
Electrolux Major Appliances
North & Latin America
P.O. BOX 212378
AUGUSTA, GA 30917
Publication No.
5995463998
06/03/23
(EN/SERVICE/KC)
361
FRONT-LOAD
WASHING MACHINE
Model No.
GLTF2940E
Copyright ©2006 Electrolux Home Products, Inc.
All rights reserved.

Publication No: 5995463998 GLTF2940ES3
03/06 2
CONTROL PANEL

GLTF2940ES3 Publication No: 5995463998
# Functional Parts 3 03/06
* Non-Illustrated Parts
CONTROL PANEL
POS. NO PART NO. DESCRIPTION
1 # 134732003 Control Board, pc, with housing
3 134471500 Knob, program
4 134347700 Pin, program knob
6 134429100 Light Pipe, array, 1 row of 5
7 134429300 Light Pipe, array, 3 row of 3
8 134429200 Light Pipe, array, 2 row of 4
9 134429400 Light Pipe, array, 4 start group
10 134447100 Push Button, #1
11 134447500 Push Button, #5
12 134447400 Push Button, #4
13 134349400 Spring, push button
14 134447201 Push Button, #2
16 134364800 Bracket, top front
17 # 134407800 Switch, pressure, analog
18 131302800 Screw, 10-16AB x 0.375
19 134402900 Screw, phillips, 6-19 x 0.650
20 134452600 Cover, hole plug
21 134407900 Dampener, vibration
23 # 134436600 Wiring Harness, controls
23*# 134543100 Wiring Harness, main
26 131205100 Screw, #8 pan head, 10-10B x 0.500, cr/sq drive
27 134442700 Panel, control console
28 131205300 Screw, 10-16 x 0.750
31 134441300 Bezel, knob flange
32 134371700 Hose, disp-to-bellows
33 131306216 Clamp
34 134446300 Clamp, hose, bellows
35 134371800 Gasket, disp hose seal
36 # 134371220 Valve, dispenser, NTC/short tube
36* 131311900 Screw, quadrex ph, 8-18AB x 0.500
37 134372300 Hose, disp-to-tub
38 134372400 Clamp, tub hose
39 134446120 Housing, dispenser, w/valve, cover
39* 134371300 Gasket, disp-to-valve
40 134372100 Tube, disp-to-overflo
41 134372200 O-ring, overflow tube
42 131168200 Screw, pan head, 8-18B x 0.31
44 134370200 Cover, dispenser
45 134370000 Drawer, dispenser
46 134349500 Spring, door latch
47 134386500 Latch, dispenser, slider lock
48 134465800 Handle, dispenser, front
49 134386200 Frame, drawer handle
50 134370100 Conveyor, dispenser, lower
53 134447301 Push Button, #3
55 134428900 Lens, digital display
56 134503400 Light Pipe, digital display
57 # 134503300 Display, digital

Publication No: 5995463998 GLTF2940ES3
03/06 4
CABINET/TOP

GLTF2940ES3 Publication No: 5995463998
# Functional Parts 5 03/06
* Non-Illustrated Parts
CABINET/TOP
POS. NO PART NO. DESCRIPTION
1 131454100 Hose, water inlet, 4 ft., hose & washer
2 131168200 Screw, pan head, 8-18B x 0.31
4 # 134409902 Control Board, motor
4* # 134547600 Wiring Harness, motor control
5 134522900 Bracket, angle, motor control
8 # 131763200 Door Lock/Switch Assy
8* # 134606800 Wiring Harness, door switch
9 131303300 Screw, pan head, 10-16AB x 0.500, locking
11 134366400 Panel, door glass
12 134507301 Panel, inner door, with bumper
13 131302901 Screw, 10-16 x 0.750
14 131763310 Striker, door/lock/sw
15 134412400 Hinge, door
16 134178901 Screw, 8-18AB x 0.455
17 134408700 Clip, assembly
18 134321702 Panel, front service, white
19 131258400 Screw, 10-16AB x 0.500
20 134434901 Bracket, LS panel, reinforcement
20* 134434900 Bracket, RS panel, reinforcement
21 134424700 Screw, comb flat head, 8-18AB x 0.75
22 134364700 Retainer, spring steel
23 134522100 Screw, #12 flat head, 10-14P, quad drive
24 134365000 Panel, work top, white
26 134521600 Screw, hex washer head, M5 0.8 x 15
28 134364300 Panel, service access, rear
29 134363300 Panel, cabinet front, white
31 # 134501000 Power Cord, electric svce
32 5303209428 Bushing, power cord
35 134365100 Bracket, top support, rear
36 134548800 Leveling Leg, screw, plastic
42 134156200 Screw, flat head, 8-18AB x 0.44, quad drive
45 # 134369400 Hose, drain, external
46 134472202 Handle, door
48 134412103 Panel, outer door, white
50 134364600 Bracket, tub suspension
51 134562100 Protector, tub brkt, spring hook, (2)
52 131931202 Dampener, vibration, foam
53 134507403 Adapter, door glass ring
54 134364900 Fastener, wire harn clip
60 134372000 Grommet, dispenser, back panel
66 134366500 Bumper, door
* 134596200 Shipping Support Kit
* 134591500 Plug Assy, shippingholes, back

Publication No: 5995463998 GLTF2940ES3
03/06 6
MOTOR/TUB

GLTF2940ES3 Publication No: 5995463998
# Functional Parts 7 03/06
* Non-Illustrated Parts
MOTOR/TUB
POS. NO PART NO. DESCRIPTION
3 131793303 Bolt, carriage, 1/4-20 x 2.60
6 134362200 Counterweight, front, one piece
7 134365300 Spring, bellows clamp, retainer
8 134365200 Bellows, door boot
10 131304700 Nut, hex, 1/4-20 UNC-2B, (2)
11 131276900 Washer, Bellville, spring steel
12 134430600 Plate, counterweight
13 134362000 Shell, tub, front
14 # 134362800 Spring Assy, suspension
15 134408300 Screw, hex head, 6.5 x 51 mm
16 134360900 Drum Assy, spin basket
17 134509600 Vane Kit, drum
18 131302800 Screw, 10-16AB x 0.375
19 # 134362500 Motor, 120 V
20 131303500 Screw, 12-14AB x 1.50, motor mtg.
21 134361900 O-ring, tub
22 134509510 Shell, outer tub, rear, w/bearing, seal
25 # 134051001 Belt, drive, poly-V, 6-rib
26 # 134362600 Pulley, drum drive, large, rear
29 134408400 Screw, 10.9 class, M10 x 25 mm
30 134560400 Shock Absorber, dual stage
31 131268300 Pin, shock mtg.
32 134363200 Bracket, shock mtg.
33 134160900 Screw, quadrex, 10-16AB X 0.750
34 134446300 Clamp, hose, bellows
35 # 134051200 Pump, drain
40 134565200 Filter, pump
41 134455900 Hose, drain, tub>pump, coin trap
42 131333101 Clamp
43 134369000 Chamber, air
44 134369900 Hose, air pressure
48 131306234 Clamp, hose, wire
49 134527100 Clamp, bellows, spring held
52 131202300 Screw, 10-16AB x 0.625
55 # 134679000 Hose, internal drain
56 134369800 Fastener, hose clip, (3)
56* 134261300 Clip, drain hose, push-mount
* 134454400 Energy Guide

Publication No: 5995463998 GLTF2940ES3
03/06 8
WIRING DIAGRAM
