FROGGYS FOG Titan H2 User manual

1"
Froggy’s(Fog(Titan(H2(Haze(Machine(-(User(Manual( (
!
Specifications!
!
Model!
Heater!Core!
CFM!
Warm!up!time!
Titan"H2"Haze"Machine"
1200"Watts"
4,000"
3"Min"
"
Fluid"Consumption"Rate"@"100%:" 16"hrs"/"gal"
Tank"Capacity:"" " " 0.8"Gal"
N.W.:""""""13.2"lbs"
G.W.:"""""15.5"lbs"
DMX"Channel:""""""""""""" " " 2"
"
Empty"Fluid"Circuitry"and"Pump"Protection"Technology"
"
Compatible"Fluids"–"" Froggys"Fog"Faze"Hazeä"Professional"Haze"Fluid"
"""Froggys"Fog"Beam"Splitterä"Premium"Haze"Fluid"
!
Important!
!
• Always"use"a"grounded"electrical"outlet."Turn"off"or"unplug"the"machine"when"not"using"it."
• This"Machine"can"be"used"indoors"and"outdoors,"but"it"is"not"water-proof."Please"keep"it"away"from"
moisture"and"water."If"moisture,"water"or"fluid"gets"inside"the"housing,"stop"using"it."
• No"user"serviceable"or"modifiable"parts"inside."Do"not"disassemble"the"housing"and"do"any"
modification,"otherwise"it"might"cause"damage"to"the"unit"or"hot"components"may"cause"burns."
• For"adult"use"only."Fixture"must"be"installed"out"of"the"reach"of"children."Never"leave"the"unit"
running"unattended."Keep"it"away"from"fire"as"well"as"combustible"and"flammable"materials."
• Position"the"machine"in"well-ventilated"area."
• Please"do"not"use"the"fixture"under"high"temperatures."
• Only"specifically"designed"water"based"scent"additives"may"be"added"to"the"haze"fluid."Never"add"
flammable"liquids"of"any"kind"(oil,"gas,"non-application"specific"perfumes)."""Pay"attention"to"all"
warning"labels"and"instructions"printed"on"the"exterior"of"your"machine."
"
• Use"only"Froggys"Fog"Haze"Liquids."The"fluid’s"optimal"vaporization"temperature"coincides"with"the"
machine’s"heater"core"to"give"you"efficient"haze"production"and"minimize"incomplete"vaporization."
• Never"drink"Haze"liquid."If"it"is"ingested,"call"a"doctor"immediately"for"any"discomfort."If"liquid"comes"
in"contact"with"skin"or"eyes,"rinse"thoroughly"with"water."
!

2"
!
!
SETUP!
"
Unpacking!and!inspection!
Immediately"upon"receiving"the"machine,"carefully"unpack"the"carton,"check"all"content"to"ensure"that"all"
parts"are"present"and"have"been"received"in"good"condition."If"any"parts"appear"damaged"or"mishandled"
from"shipping,"please"do"not"power"on"the"machine."Contact"the"manufacturer"for"further"instruction."
"
What!is!included:!
1."1"x"H2"Haze"machine"and"Hanging"Bracket"
2."1"x"Power"Cord"
3."1"x"W-4"Wireless"Remote"Controller"
4."1"x"User"Manual"
"
Installation!
1."After"ensuring"all"the"accessories"are"intact,"position"the"machine"on"a"flat""
2."Press"the"fluid"tank’s"quick"connector"by"thumb"and"forefinger,"and"take"it"out"quickly"to"disconnect"the"
tube"and"the"fluid"tank."Take"out"the"tank"and"uncover"the"cap."Pour"water"based"haze"machine"liquid"into"
the"tank"carefully,"then"tighten"the"cap."Put"the"tank"into"the"machine"and"push"the"connector"lightly"to"
connect"the"tube"and"fluid"tank.""
3."Connect"the"Neutrik"power"cord"to"the"machine."Please"make"sure"the"required"and"provided"electricity"
voltage"and"the"electricity"outlet"is"grounded.""
4."Upon"activating"the"power"switch,"the"unit"will"immediately"start"heating"up"in"the"standby"mode,"during"
this"time,"the"LCD"panel"will"display"“HEAT”"
!
"
!
!
!
!
!
!
!
!
!
!
!
!
"
!
!

3"
!
OPERATION!
"
MENU"button:"Different"pages"can"be"chosen,"there"are"4"pages"in"total."
"
UP:""""""""Increase"value"set"for"subpages."
DOWN:"""""""Decrease"value"set"for"subpages."
Enter:""""""Confirm"or"exit."
"
!
!
!
Digital!display!!
!
1) Machine"is"heating."After"finishing"heating,"output"page"will"show"as"
default.""
"
2) Haze"output"volume"can"be"adjusted"by"the"knob"on"the"operation"
panel."And"the"display"shows"value"of"output,"0"for"off,100"for"max.""
"
3) The"fan"speed"volume"can"be"adjusted"by"the"knob"on"the"operation"
panel."And"the"display"shows"value"of"output,0"for"off,100"for"max.""
"
"
"
4) DMX"Addresses"
"
Press"ENTER"then"UP"or"DOWN"to"change"address."
After"setting,"press"ENTER"button"again"to"exit."
"
5) Wireless"Remote"controller"page""
"
"Press"ENTER"then"UP"or"DOWN"to"turn"Wireless"On"or"Off"
" After"setting,"press"ENTER"button"again"to"exit."
"
!
!
!
!
!
!
!

4"
Wireless!remote!control!function!!
!
• Transmitter"
• Use"battery:"DC"12V"
• Working"distance:"30meters"(the"distance"can"be"influenced"by"
signal"interference)"
"
• Receiver:"
• The"receiver"was"fixed"in"the"machine"body,"and"tested"one"by"one"before"shipping.""
"
Wireless!controller!(W-4)!function!and!setting:!
!
• W-4"can"be"used"directly"to"control"the"machine."Press"“ON”,"start"working;"Press"“OFF”,"stop"
working."
• A"maximum"of"5"transmitters"can"be"remembered"and"stored"by"the"receiver.!
• After"turning"on"the"machine,"within"15"seconds,"press"the"transmitter"ON"button.!
• When"the"digital"display"twinkling"twice,"that"means"the"transmitter"matches"the"machine!
successfully.!
• If"no"transmitter"matched"the"machine"after"power"in,"the"receiver"will"recognize"the"last"one.!
If"new"transmitter"matched"the"machine"after"power"in,"the"receiver"will"only"recognize"the"new"
one,"all"the"previous"setting"will"be"cleared"away."
!
DMX!Function!
!
• Channel"1:"Fan"output:"0~5"Off;"11~255"increase""
• Channel"2:"Haze"output:0~10"Off;"11~255"increase""
• When"the"unit"is"connected"to"DMX,"the"digital"display"will"show"the"DMX"address"value.""
• Pressing"UP"and"DOWN"button"will"change"the"DMX"address."
!
!
OTHER!FUNCTIONS!
!
• For"the"channel"of"haze"output,"timing"function"of"continuous"and"interval"time"can"use"DMX"
console"programming"to"achieve,"or"DMX"control"software"used"by"dimmer"to"realize."!
"
• Fluid"Sensor"Protection"Function"-"In"this"machine,"use"the"program"control"to"detect"whether"there"
is"fluid"in"the"tubing"to"protect"the"pump.""
"
• Start"Fluid"sensor"-"When"the"smoke"output"is"more"than"50%,"and"the"fluid"tubing"runs"dry,"the"
machine"will"start"fluid"sensor"in"5"minutes."The"pump"will"stop"working"and"the"LCD"display"will"be"
flashing."
"
• Remove"the"fluid"Sensor"Status"-"In"the"status"of"fluid"sensor,"there"is"2"ways"to"remove"the"fluid"
sensor"after"full"of"the"fluid"tank.""
"

5"
OTHER!FUNCTIONS!(Continued)!
!
• When"controlling"the"volume"output"with"the"knob"switch,"first"to"adjust"the"output"to"0,"then"
adjust"to"100."The"machine"resume"output"and"exit"the"fluid"sensor"in"2"minutes."
• When"controlling"via"DMX,"first"push"channel"2"low"(OFF),"then"push"up"(ON)."The"machine"resume"
output"and"exit"the"fluid"sensor"in"2"minutes."
"
Attention："
If"the"machine"has"little"or"no"output"or"the"pump"excessively"buzzes,"please"disconnect"the"power."Check"
the"fluid"tank,"fuse"and"power,"if"all"above"are"fine,"resume"power"and"hold"the"wireless"controller"“ON”"for"
30"seconds"and"see"if"haze"is"emitted."In"the"case"of"no"haze"output,"check"the"tube"connected"to"the"fluid"
tank"and"make"sure"fluid"is"present."If"the"issue"still"persists,"please"contact"the"manufacturer"for"further"
instruction.""
"
"
Product!Overview!
!
1."Hanging"Bracket"
2."Safty"ring"
3."Nozzle"
4."Fluid"container"
5."Bracket"Knob"
6."Fluid"level"indicator"
7."Antenna"
8."Digital"display"
9."Fan"adjustment"
10."Haze"adjustment"
11."Power"Socket"
12."Power"switch"
13."3-pin"DMX"socket"
14."Fan"
"
"
"
!
!
!
!
!
!
!
!
!
!
!

6"
MAINTENANCE!
Cleaning!your!Haze!machine!regularly!will!help!reduce!costly!parts!replacement!and!repair!charges.!
Please"follow"these"instructions"for"safely"cleaning"your"haze"machine"if"output"become"noticeably"
decreased."High"Quality"fluid"recommended"by"the"manufacturer"lengthens"the"amount"of"time"between"
periods"of"maintenance"as"described"below."
"
Tools:"Clean"lint"free"cloth,"coffee"filter"or"similar"fine"mesh"filter"cloth,"plastic"or"glass"container"larger"than"
the"reservoir"size"(do"not"use"metal),"distilled"water"and"Froggys"Haze"fluid."
1. Allow"the"machine"to"cool"down"before"handling."
2. Drain"any"Haze"solution"that"remains"in"the"tank"into"a"container"through"the"filter"mesh"for"reuse."
3. Add"distilled"water"to"fill"the"Haze"fluid"reservoir"approximately"1/3."
4. Run"machine"for"10"minutes."Haze"will"come"out"the"first"few"cycles,"followed"by"distilled"water"
vapor."
5. Turn"off"the"machine"and"allow"to"cool"down,"then"drain"the"distilled"water"from"the"reservoir."
6. Refill"the"reservoir"approximately"1/3"with"good"quality"haze"solution."
7. Turn"the"machine"on,"run"for"10-15"minutes."Water"vapor"steam"will"come"out"the"first"few"cycles,"
followed"by"Haze.""Continue"steaming"the"machine"for"5-10"cycles."
8. Turn"off"the"machine"and"allow"to"cool,"then"wipe"machine"clean"with"clean"lint"free"cloth."
9. Leave"the"haze"solution"in"the"reservoir.""The"solution"acts"a"lubricant"and"conditioner"for"the"plastic"
and"rubber"parts"in"the"fluid"pump."""
10. Store"the"machine"in"a"cool,"dry"place"when"not"in"use.""Avoid"freezing"temperatures,"high"heat"
above"120"degrees"and"humid/damp"locations"which"may"cause"control"board"failure."
11. If"possible,"remove"from"storage"after"6"months"and"operate"the"machine"for"15"minutes"or"more,"
then"repeat"step"8"–"10."
"
Save"these"instructions.""2"Year"Limited"Warranty:"Valid"from"the"date"of"purchase."Warranty"covers"
manufacturing"defects"only"and"does"not"cover"misuse"or"abuse"of"the"machine."Serial"number,"place"of"
purchase"with"dated"valid"receipt"must"be"submitted"at"time"of"service."Warranty"is"only"valid"with-in"the"
United"States."Buyer"may"be"responsible"for"shipping"fees"associated"with"repairs."
