SUPPLEMENTARY INSTALLATION INSTRUCTIONS FOR THE UK MARKET
TO BE READ IN CONJUNCTION WITH THOSE IN THE MAIN INSTRUCTION MANUAL
These instructions together with those in the instruction manual cover the basic principles
to ensure the satisfactory installation of the boiler, although detail may need slight
modification to suit particular local site conditions.
In all cases the installation must comply with current Building Regulations, Local Authority
Byelaws and other specifications or regulations as they affect the installation of the boiler.
It should be noted that the Building Regulations requirements may be met by adopting the
relevant recommendations given in British Standards BS 8303, BS EN15287-1:2007 as an
alternative means to achieve an equivalent level of performance to that obtained following
the guidance given in Approved Document J.
Please note that it is a legal requirement under England and Wales Building Regulations
that the installation of the boiler is either carried out under Local Authority Building Control
approval or is installed by a Competent Person registered with a Government approved
Competent Persons Scheme. HETAS Ltd operate such a Scheme and a listing of their
Registered Competent Persons can be found on their website at www.hetas.co.uk.
CO Alarms:-
Building regulations require that when ever a new or replacement fixed solid fuel or
wood/biomass appliance is installed in a dwelling a carbon monoxide alarm must be fitted
in the same room as the appliance. Further guidance on the installation of the carbon
monoxide alarm is available in BS EN 50292:2002 and from the alarm manufacturer’s
instructions. Provision of an alarm must not be considered a substitute for either installing
the appliance correctly or ensuring regular servicing and maintenance of the appliance and
chimney system.
HEALTH AND SAFETY PRECAUTIONS
Special care must be taken when installing the boiler such that the requirements of the Health and Safety at
Work Act are met.
Handling
Adequate facilities must be available for loading, unloading and site handling.
Fire Cement
Some types of fire cement are caustic and should not be allowed to come into contact with the skin. In case
of contact wash immediately with plenty of water.
Asbestos
This boiler contains no asbestos. If there is a possibility of disturbing any asbestos in the course of installation
then please seek specialist guidance and use appropriate protective equipment.
Metal Parts
When installing or servicing this boiler care should be taken to avoid the possibility of personal injury.

Version of 27 Oct 2011
Page 2 of 7
BOILER PERFORMANCE
The nominal heat outputs for the various boilers are detailed in the main instruction manual:
PREPARATORY WORK AND SAFETY CHECKS
IMPORTANT WARNING
This boiler must not be installed into a chimney that serves any other heating appliance.
There must not be an extractor fan fitted in the same room as the boiler as this can cause the boiler to emit
fumes into the room.
Chimney
In order for the boiler to perform satisfactorily the chimney height must be sufficient to ensure an adequate
draught of approximately 15 Pa so as to clear the products of combustion and prevent smoke problems into
the room.
NOTE: A chimney height of not less than 4.5 metres measured vertically from the outlet of the boiler to the top
of the chimney should be satisfactory. Alternatively the calculation procedure given in BS EN 13384-1 may be
used as the basis for deciding whether a particular chimney design will provide sufficient draught.
The outlet from the chimney should be above the roof of the building in accordance with the provisions of
Building Regulations Approved Document J.
Because these boilers run at high efficiencies the temperature of the flue gases is lower than conventional
solid fuel appliances. Although they are not classed as condensing appliances, the low flue gas temperature
results in condensation occurring within the flue. Any chimney flue system must therefore be able to withstand
the effects of condensate and operate under wet conditions (designation letter W). In addition it should be
soot fire resistant and able to withstand the corrosive effects of flue products generated by solid fuels
(designation G and 3 respectively). If installation is into an existing masonry chimney then it will require re-
lining with a liner meeting the specification described above. Existing concrete or clay lined chimneys are not
suitable for these boilers and must be lined as described above. All installations must be in accordance with
Building Regulations Approved Document J.
Any existing chimney must be clear of obstruction and have been swept clean immediately before installation
of the lining system.
If there is no existing chimney then any new system must be to the designation described above and in
accordance with Building Regulations Approved Document J.
A single wall metal fluepipe is suitable for connecting the boiler to the chimney but is not suitable for use as
the complete chimney. The chimney and connecting fluepipe must not be less than the size of the outlet
socket of the boiler. The length of this connecting pipe should be kept to a minimum. Refer also to the main
instruction manual for further guidance.
Any bend in the chimney or connecting fluepipe should not exceed 45 . 90 bends should not be used,
except for connecting to a rear outlet appliance, and the connection should be no more than 150 mm in length
and have a debris trap.
Combustible material should not be located where the heat dissipating through the walls of fireplaces or flues
could ignite it. Therefore when installing the boiler in the presence of combustible materials due account must
be taken of the guidance on the separation of combustible material given in Building Regulations Approved
Document J and also in these boiler instructions.
If it is found that there is excessive draught in the chimney then a draught stabiliser should be fitted in the
chimney above the chimney above the flue pipe connection. Fitting of a draught stabiliser will affect the
requirement for the permanent air supply into the room in which the boiler is fitted in accordance with

Version of 27 Oct 2011
Page 3 of 7
Approved Document J (see also combustion air supply).
Adequate provision e.g. easily accessible soot door or doors must be provided for sweeping the chimney and
connecting fluepipe.
Connection to the chimney
All the boilers have a flue gas connector that allows connection to the main chimney using a suitable
connecting pipe. All joints must be sealed in accordance with the recommendations in Approved Document J.
See also “Chimney” above.
Hearth
The hearth should be able to accommodate the weight of the boiler and its chimney if the chimney is not
independently supported. The weight of the boiler is indicated in the instruction manual.
The boiler should always be installed on a non-combustible hearth of a size and construction that is in
accordance with the provisions of the current Building Regulations Approved Document J.
The clearance distances to combustible material beneath, surrounding or upon the hearth and walls adjacent
to the hearth should comply with the guidance on the separation of combustible material given in Building
Regulations Approved Document J and also in these boiler instructions.
Combustion air supply
In order for the boiler to perform efficiently and safely there should be an adequate air supply into the room in
which the boiler is installed to provide combustion air. This is particularly necessary if the room is double-
glazed or a flue draught stabiliser is operating in the same room as the appliance. The provision of air supply
to the boiler must be in accordance with current Building Regulations Approved Document J. An opening
window is not appropriate for this purpose.
Connection to the central heating system
Ensure the heating system is the correct design for the boiler. It is an essential requirement that the system
incorporates a heat storage buffer tank (often referred to as an accumulator). Full guidance is given in the
main installation manual. Depending on the intended design of the heating installation and also on the output
of the boiler, the central heating system must be in accordance, as appropriate, with either BS 6880:1988
Parts 1 to 3, Code of Practice for low temperature hot water heating systems of output greater than 45kW.
Further guidance is available from the following sources: BS EN 14336:2004: Heating Systems in Buildings.
Installation and commissioning of water based heating systems. BS EN 12828: 2003; Heating Systems in
Buildings. Design of water based heating systems. BS EN 12831: 2003; Heating Systems in Buildings.
Method for calculation of the design heat load.
Particular attention must be paid to the installation and correct functioning of any Thermal Safety Device
where necessary. This is described fully in the installation manual.

Version of 27 Oct 2011
Page 4 of 7
Electrical connections
The installation of any electrical services during the installation of this boiler and the associated heating
system must be carried out by a registered competent electrician and in accordance with the requirements of
the latest issue of BS 7671.
Commissioning and handover
Before commissioning this boiler be sure to read and follow the operation manuals to ensure that everything is
carried out in accordance with the correct procedures.
Ensure any loose parts are fitted in accordance with the instructions.
Once the boiler is under fire check all seals for soundness and that the boiler and water system are operating
correctly. Ensure that the flue is functioning correctly and that all products of combustion are vented safely to
atmosphere via the chimney terminal.
On completion of the installation and commissioning ensure that the instruction manuals for the boiler are left
with the customer. Ensure to advise the customer on the correct use of the appliance with the fuels likely to be
used on the boiler and warn them to use only the recommended fuels for the boiler. The user should be given
a demonstration of the required routine maintenance and safety checks. Remind the user of the importance of
regular chimney sweeping and servicing by qualified persons to ensure continued safe operation of the boiler.
Leave the boiler operational and inform the user that this is the case.
Advise the user what to do should smoke or fumes be emitted from the boiler. The customer should be
warned about the dangers to children, aged and/or infirm persons and that access to the boiler should be
protected by a lockable door.
