Front Runner MKII User manual

TBRA027_REV_A00 © COPYRIGHT 2016 FRONT RUNNER VEHICLE OUTFITTERS
drop down table MKII
TBRA027
ENG
1
35 min
IMPORTANT WARNING!
IT IS CRITICAL THAT ALL FRONT RUNNER PRODUCTS BE PROPERLY AND SECURELY ASSEMBLED AND ATTACHED TO YOUR VEHICLE.
IMPROPER ATTACHMENT COULD RESULT IN AN AUTOMOBILE ACCIDENT, AND COULD CAUSE SERIOUS BODILY INJURY OR DEATH.
YOU ARE RESPONSIBLE FOR ASSEMBLING AND SECURING ALL FRONT RUNNER PRODUCTS TO YOUR VEHICLE. CHECKING THE ATTACHMENTS PRIOR TO USE, AND PERIODICALLY INSPECTING THE PRODUCTS FOR ADJUSTMENT, WEAR AND DAMAGE.
THEREFORE YOU MUST READ AND UNDERSTAND ALL OF THE INSTRUCTIONS AND PRECAUTIONS SUPPLIED WITH YOUR FRONT RUNNER PRODUCT PRIOR TO INSTALLATION OR USE.
IF YOU DO NOT UNDERSTAND ALL OF THE INSTRUCTIONS AND CAUTIONS, OR IF YOU HAVE NO MECHANICAL EXPERIENCE AND ARE NOT THOROUGHLY FAMILIAR WITH THE INSTALLATION PROCEDURES,
YOU SHOULD HAVE THE PRODUCT INSTALLED BY A PROFESSIONAL INSTALLER OR OTHER QUALIFIED PERSONNEL.
Thank you for purchasing a Front Runner Drop Down Table MKII.
Before you start, take a moment to familiarize yourself with this Fitting Instruction and the components received.
Refer to Page 2 for a list of all the components, quantities and tools required.
READ ME !

TBRA027_REV_A00 © COPYRIGHT 2016 FRONT RUNNER VEHICLE OUTFITTERS 2
TOOLS NEEDED
5
11
2
3
4
1 1 X Drop Down Table
2 4 X Button Head M6 x 25
3 4 X Spring Washer M6
4 4 X Flat Washer M6
5 4 X Turn Nut
6 1 X Left Hand Slide Bracket
IN THE BOX
FIGURE 1.1
4mm
5mm
3mm
16
GET ORGANIZED
1
10.5MM
8MM
3MM
Here is what you are looking at for TBRA027

TBRA027_REV_A00 © COPYRIGHT 2016 FRONT RUNNER VEHICLE OUTFITTERS 3
16
FIT AND SECURE
2
2.1
2.2
2.3
3MM
5MM
8MM
3MM
5MM
8MM
Find a suitable position for the table.
Remove the trim panel if fitted. Mark
out the 4 fixing points, take care
that these points are not on or close to
bends in the bodywork or on
spot-welds.
If your vehicle has a rear door that
opens to the left side you need to
replace the right hand slide bracket
with the left hand slide bracket.
Do this by removing the nut caps and
loosening the fasteners shown.
If your vehicle has a rear door that
opens to the right side, move on to
Step 2.3.
Fit and secure the left hand slide
bracket (Item6) with the fasteners you
removed in Step 2.1.
Relocate the stopper screw to the right
side of the sliding table.
Refit the nut caps you removed in
Step 2.1.
Right Hand
Slide Bracket
Sliding Table
Left Hand
Slide Bracket
Stopper
Screw
Stopper
Screw

TBRA027_REV_A00 © COPYRIGHT 2016 FRONT RUNNER VEHICLE OUTFITTERS 4
5
2
3
4
FIT AND SECURE
2
2.4
2.5
2.6
3MM
10.5MM
4MM
Drill a 3mm pilot hole, using light
pressure and taking care only to
drill through the interior panel.
Use a 10.5mm drill to open up the 3mm
pilot hole.
Insert the turn nut (Item 5)
Secure the drop down table using
the fasteners shown in 2.6

TBRA027_REV_A00 © COPYRIGHT 2016 FRONT RUNNER VEHICLE OUTFITTERS 5
COMPLETION
3
3.1
INSTALL OTHER VEHICLE AND RACK ACCESSORIES
4
Now's the time to visit your favorite Front Runner Dealer in person or online.
Congratulations. You did it. Take a step back and admire your work!
3.1
