Frontgrade Gr740-mini User manual

Quick start guide for GR740-MINI Evaluation board

GR740-MINI

GR740-MINI Quick Start Guide

USER MANUAL

RELEASED JANUARY 2024

Jan 2024, Version 1.1

Jan 2024, Version 1.1 2

Table of Contents

1. Introduction .......................................................................................................................... 4

1.1. Overview ................................................................................................................... 4

1.2. IP addresses ............................................................................................................... 4

1.3. Handling .................................................................................................................... 4

1.4. References .................................................................................................................. 4

2. Overview .............................................................................................................................. 6

3. Board Configuration ............................................................................................................... 7

3.1. Overview ................................................................................................................... 7

3.2. Prerequisites ............................................................................................................... 7

3.3. Pre programmed .......................................................................................................... 7

3.4. Power Up the board ..................................................................................................... 7

3.5. LEDs indication .......................................................................................................... 8

3.5.1. Power ............................................................................................................. 8

3.5.2. GR740 ............................................................................................................ 8

3.5.3. FPGA ............................................................................................................. 8

3.6. Switch buttons ............................................................................................................ 8

3.6.1. Master reset (SW1) ........................................................................................... 8

3.6.2. Program switch (SW2) ....................................................................................... 8

3.7. FTDI chip .................................................................................................................. 9

4. GRMON3 hardware debugger ................................................................................................ 10

4.1. Overview .................................................................................................................. 10

4.2. GR740 License options ............................................................................................... 10

4.3. Debug-link alternatives for GR740 ................................................................................ 10

4.3.1. Connecting via the FTDI USB/JTAG interface ..................................................... 10

4.3.2. Connecting via the Ethernet debug interfaces ........................................................ 10

4.4. Debug-link alternatives for CertusPro ............................................................................ 11

4.4.1. Connecting via the FTDI USB/UART interface .................................................... 11

4.4.2. Connecting via the Ethernet debug interfaces ........................................................ 11

4.5. First steps ................................................................................................................. 11

4.6. Connecting to the board .............................................................................................. 12

4.6.1. GR740 ........................................................................................................... 12

4.6.2. CertusPro ....................................................................................................... 13

5. Software Development Environment ........................................................................................ 14

5.1. Overview .................................................................................................................. 14

5.2. Bare C Cross-Compiler System .................................................................................... 14

5.2.1. Overview ....................................................................................................... 14

5.2.2. Compiling with BCC ....................................................................................... 14

5.2.3. Running application with GRMON3 ................................................................... 15

5.3. Boot Loaders ............................................................................................................ 15

6. FPGA development Environment ............................................................................................ 17

6.1. Lattice Radiant Software ............................................................................................. 17

6.2. Program the FPGA .................................................................................................... 17

6.2.1. Lattice programmer ......................................................................................... 17

6.2.2. GRMON3 ...................................................................................................... 17

7. Example Bitstreams .............................................................................................................. 19

7.1. Overview .................................................................................................................. 19

7.2. EX-1 ....................................................................................................................... 19

7.2.1. UART ........................................................................................................... 20

7.2.2. SPIMCTRL .................................................................................................... 20

7.2.3. PCI ............................................................................................................... 20

7.2.4. Ethernet ......................................................................................................... 20

7.2.5. SpaceWire ...................................................................................................... 21

7.3. EX-2 ....................................................................................................................... 21

7.3.1. LEON 3 ........................................................................................................ 22

7.3.2. GPIO ............................................................................................................ 22

7.3.3. UART ........................................................................................................... 23

7.3.4. SPIMCTRL .................................................................................................... 23

Jan 2024, Version 1.1 3

7.3.5. PCI ............................................................................................................... 23

7.3.6. Ethernet ......................................................................................................... 23

7.4. EX-3 ....................................................................................................................... 24

7.4.1. UART ........................................................................................................... 25

7.4.2. SPIMCTRL .................................................................................................... 25

7.4.3. PCI ............................................................................................................... 25

7.4.4. Ethernet ......................................................................................................... 25

7.4.5. GPIO ............................................................................................................ 25

7.4.6. General Purpose Register Bank .......................................................................... 26

7.4.7. SpaceFibre ..................................................................................................... 27

7.4.8. SpaceWire Router ........................................................................................... 27

7.4.9. SpaceFibre-to-SpaceWire bridge application ......................................................... 27

8. Frequently Asked Questions / Common Mistakes / Know Issues ................................................... 29

8.1. Why is there no /dev/ttyUSB on Linux? ......................................................................... 29

8.2. Why am I getting "invalid cable"? ................................................................................ 29

8.3. Can I use GRMON2? ................................................................................................. 29

9. Support ............................................................................................................................... 30

Jan 2024, Version 1.1 4

1. Introduction

1.1. Overview

This document is a quick start guide for the GR740-MINI Development Board.

The purpose of this document is to get users quickly started using the board.

For a complete description of the board please refer to the GR740-MINI Board User's Manual [RD-1].

The GR740 system-on-chip is described in the GR740 Data Sheet and User’s Manual, [RD-2].

The CertusPro FPGA is described in the CertusPro-NX Family Data Sheet [RD-3].

This quick start guide does not contain as many technical details and is instead how-to oriented. However, to make

the most of the guide the user should have glanced through the aforementioned documents and should ideally also

be familiar with the GRMON3 debug monitor, [RD-4] .

1.2. IP addresses

The GR740-MINI board is equipped with two Ethernet ports that have default IP addresses 192.168.0.24 and

192.168.0.51. The GR740-MINI should not be connected to an existing network where these addresses may be

already occupied. Please see Chapter 4 before conneceting to the network or for more information.

1.3. Handling

This unit contains sensitive electronic components which can be damaged by Electrostatic Discharges (ESD).

When handling or installing the unit observe appropriate precautions and ESD safe practices.

When not in use, store the unit in an electrostatic protective container or bag.

When connecting/disconnecting cables, ensure that the unit is in an un-powered state.

This equipment has SpW ports that use Low Voltage Differential Signalling (LVDS) which has limited common

mode voltage protection. Please refer to the user’s manual for instructions on how to ensure that the grounds of

equipment are connected together when using SpaceWire.

1.4. References

Table 1.1. References

RD-1 GR740-MINI User’s Manual [https://gaisler.com/index.php/products/boards/gr740-mini]

RD-2 GR740 Data Sheet and User’s Manual [https://gaisler.com/gr740]

RD-3 CertusPro-NX Family Data Sheet [https://www.latticesemi.com/Products/FPGAandC-

PLD/CertusPro-NX]

RD-4 GRMON3 User's Manual [https://www.gaisler.com/doc/grmon3.pdf]

RD-5 GRLIB IP Core User’s Manual [https://www.gaisler.com/products/grlib/grip.pdf]

RD-6 RTEMS homepage [https://www.rtems.org]

Jan 2024, Version 1.1 5

RD-7 LEON/ERC32 RTEMS Cross Compilation System (RCC) [https://www.gaisler.com/

index.php/products/operating-systems/rtems]

RD-8 RCC User's manual [https://gaisler.com/anonftp/rcc/doc]

RD-9 Frontgrade Gaisler RTEMS driver documentation [https://gaisler.com/anonftp/rcc/doc]

RD-10 Bare C Cross-Compilation System [https://www.gaisler.com/index.php/products/operat-

ing-systems/bcc]

RD-11 BCC User's Manual [https://www.gaisler.com/doc/bcc2.pdf]

RD-12 VxWorks 7 SPARC architectural port and BSP [https://www.gaisler.com/index.php/prod-

ucts/operating-systems/vxworks-7]

Jan 2024, Version 1.1 6

2. Overview

The GR740-MINI board is software development and evaluation platform for the GR740 (a quad-core radiation

tolerant microprocessor) and the CertusPro-NX FPGA. A variant of the CertusPro-NX qualified for use in space

is available from Frontgrade in the form of the CertusPro-NX-RT family. shown in Figure 2.1.

Figure 2.1. Top view of GR740-MINI board

The GR740-MINI architecture includes the following parts:

• 2 x USB-C connectors for debug and power

• GR470 Processor

• 1 x USB interface via FTDI FT4232HP providing JTAG and UART

• 1 x Ethernet for communication and debug

• 4 x SpaceWire channels to FMC+ connector

• 256MiB SDRAM

• 128MiB FLASH

• CertusPro-NX FPGA

• 1 x USB interface via FTDI FT4232HP providing JTAG and UART

• 1 x Ethernet for communication and debug

• 4 x SerDes to FMC+ connector

• LVDS to FMC+ connector

• 3V3 IO to FMC+ connector

• I2C link to FMC+ connector

• 1GiB DDR3 memory

• 512Mib SPI FLASH

• Intercommunication between GR740 and CertusPro-NX

• PCI link 32bit 33MHz

• GMII/MII

• 4 x SpaceWire channels

Jan 2024, Version 1.1 7

3. Board Configuration

3.1. Overview

The primary sources of information for the development board is the GR740-MINI User’s Manual, [RD-1]. The

primary information for the Processor is GR740 Data Sheet and User’s Manual [RD-2] and for the FPGA Certus-

Pro-NX Family Data Sheet [RD-3].

3.2. Prerequisites

• GR740-MINI board

• USB-C Cable

• Host computer (Windows/Linux)

• GRMON3 hardware debugger (See for Section 4.2 for license options )

• Optional; 5V Power adapter (min 15W)

3.3. Pre programmed

The GR740-MINI Board is preproggramed when delivired. The GR740 is booted from the prom memory with

helloblink.prom, built with MKPROM2 se Section 5.3. The boot file is necessary to initialize the SDRAM,

L2-cache, clock-gating unit and UART pin-multiplexing, example is available for download on the webpage

www.gaisler.com/gr740-mini. The FPGA is configurated from the SPI memory which is flashed with a bitstream,

EX-1.bit, please se Chapter 7 for more information about the bitstream.

3.4. Power Up the board

The GR740-MINI board is powered using either of the USB-C connectors (J1 or J2). Therefor there are two ways

to power up the board and it is accomplished by attaching a 2-pin jumper to the 3-pin head (JP5), see Figure 3.1.

The overall power requirement for the board is 15W. Note that both the UCB-C cable and source must deliver

at least 3A, 5V (15W). Observe that not all sources with USB-C sockets support that. Check the source's manual

before connecting to the GR740-MINI board.

J2 is considered as the main power supply, and the configuration jumper is set to this as default JP5: 1-2 mode

(blue). This mode can be used when communicating with USB-C (data and power through the same cable), Eth-

ernet or FMC+ connector.

If J2 is connected to a source that cannot provide the minimum power requirement (for example a computer port

or a docking station), then J1 can be connected to a external power source. Set jumper JP5 to 2-3 (red) mode to

use J1 as the power source.

Figure 3.1. Jumper configuration for power supply

Jan 2024, Version 1.1 8

3.5. LEDs indication

With the preprogramed devices some LEDs on board are suppost to be on/blinkning during the start-up, see the

corresponding parts below.

3.5.1. Power

When powering the board there are 3 LEDs for indicating the availability and communication status.

LED1 : ON, Indicates that 3V3 is available

LED2 : OFF, Light when USB is in suspended mode

LED3 : ON, Indicate normal USB operational mode

3.5.2. GR740

The are LEDs correspondning the GR740, see Figure 3.2 and the list below for behavior.

Figure 3.2. LEDs corresponding GR740

LED4 : ON, Indicates debug support unit is active

LED6 : Blinkning

LED7 : Blinkning

LED8 : Blinkning

LED9 : Blinkning

LED10 : Blinkning

3.5.3. FPGA

When the FPGA is configurated there are two LEDs for indicating the configuration status, se below.

D8 : OFF, Indicates that a error occur during configuration

LED11 : ON, Indicates when configuration completed successfully

3.6. Switch buttons

3.6.1. Master reset (SW1)

There is a switch button (SW1) to reset the board. The reset signal will reset the GR740, the Ethernet PHYs, flash

memory(GR740)andtheFPGA(fortheprovidedexamplebitstreams).ItwillnottriggeranFPGAreconfiguration

or interrupt USB communication

3.6.2. Program switch (SW2)

This switch is connected to the FPGA and will initiate configuration sequence when asserted.

Jan 2024, Version 1.1 9

3.7. FTDI chip

A FTDI FT4323HP chip is connected to USB-C connector J2 and provides Serial to USB conversion up to 4 ports.

In Table 3.1 the port are listed. The corresponing "vendor id" is 0403 and "product id" is 6043 for the FTDI chip.

Table 3.1. FTDI port assignment

Port Function Target

A JTAG GR740

B JTAG CertusPro-NX

C UART GR740

D UART CertusPro-NX

Verify that the board is recognized by the host computer. In windows go to Device Manager, in linux use the lsusb

command in the terminal. If you cannot see the device please refer to Chapter 8

Jan 2024, Version 1.1 10

4. GRMON3 hardware debugger

4.1. Overview

GRMON3 is a debug monitor used to develop and debug GRLIB/LEON systems. The target system, including

the processor and peripherals, is accessed on the AHB bus through a debug-link connected to the host computer.

GRMON3 has GDB support which makes C/C++ level debugging possible by connecting GDB to the GRMON3's

GDB socket. With GRMON3 one can for example:

• Inspect LEON and peripheral registers

• Upload applications to RAM with the load command.

• Program the FLASH with the flash command.

• Control execution flow by starting applications (run), continue execution (cont), single-stepping (step), in-

serting breakpoints/watchpoints (bp) etc.

• Inspect the current CPU state listing the back-trace, instruction trace and disassemble machine code.

The first step is to set up a debug link in order to connect to the board. The following section outlines which

debug interfaces are available and how to use them on the GR740-MINI Evaluation Board. After that, a basic first

inspection of the board is exemplified.

4.2. GR740 License options

The GRMON3 evaluation version which is freely available can be used to operate the GR740-MINI board. The

evaluation version does not support any other GR740 boards. The evaluation version is limited in certain regards

compared with the GRMON3 professional product. GRMON3 can be downloaded from the GRMON3 homepage

[RD-4].

The following table summarizes the GRMON3 license options for GR740.

Table 4.1. GRMON3 license options for GR740. All references to GRMON3 is for version 3.3.6 or later.

Program version License Supported hardware Supported FPGA designs

GRMON3 professional Professional All GR740 systems All GRLIB designs

GRMON3 evaluation Evaluation

• No cost

• No registration

GR740-MINI • The provided example bit-

streams

• GRLIB designs with open-

source IP cores (GPLv2 li-

cense), see GRLIB IP Core

User’s Manual [RD-5]

4.3. Debug-link alternatives for GR740

4.3.1. Connecting via the FTDI USB/JTAG interface

Please see GRMON3 User's Manual for how to set up the required FTDI driver software. Verify the serialnumber

and that GRMON3 is able to detect the board with grmon -ftdi -jtaglist , if it's not showing any devices please

refer to Chapter 8

Due to the SDRAM configuration on the board the -sddcs flag must be set. -jtagserial is used to connect to the

board, where xxx is the serialnumber of the board. Connect the PC to the board by using a USB cable to the J2

connector and issue the following command:

grmon -ftdi -jtagserial GR740M0xxxA -sddcs

4.3.2. Connecting via the Ethernet debug interfaces

Note: Debugging using Ethernet is not supported by grmon-eval

The GR740 supports one Ethernet debug communication link (EDCL) in the default configuration of the GR740-

MINI. The debug link have default address 192.168.0.24. The GR740-MINI should not be connected to an existing

network where this address may be already occupied.

Jan 2024, Version 1.1 11

If another address is wanted for the Ethernet debug link then the UART debug link must be used to connect

GRMON3 to the board. The EDCL IP address can then be changed using GRMON3's edcl command. This new

address will persist until next system reset.

Ethernet debug link traffic is routed to the Debug AHB bus as default. Ethernet debug link traffic can be routed

either to the Master I/O AHB bus or to the Debug AHB bus by changing a bootstrap signal. In order to control

the LEON processors the debug link must be routed to the Debug AHB bus, otherwise GRMON3 will not be able

to use the debug link to access the Debug Support Unit.

After reset the Ethernet debug communication link will attempt to configure the Ethernet PHY. In order for this

to succeed, the Ethernet port must be connected to a switch or other networking equipment.

Connect the Ethernet to connector J3B. Due to the SDRAM configuration on the board the -sddcs flag must be

set. Issue the following command:

grmon -eth 192.168.0.24 -sddcs

4.4. Debug-link alternatives for CertusPro

The interfaces to debug the CertusPro can vary depening on how the FPGA is programmed. In this chapter the

interfaces that will be provided from our pre-built bitsreams will be described.

4.4.1. Connecting via the FTDI USB/UART interface

Please see GRMON3 User's Manual for instructions how to connect GRMON3 to a board using a serial UART

connection. The PC is connected using a USB cable to the USB connector J2 and then start GRMON3 with the

-uart PORTNAME debug-link option and device name.

Example in Linux:

grmon -uart /dev/ttyUSB3

Example in Windows:

grmon -uart \\.\COM6

4.4.2. Connecting via the Ethernet debug interfaces

Note: Debugging using Ethernet is not supported by grmon-eval

Ethernet debug communication link (EDCL) have default address 192.168.0.51 The GR740-MINI should not be

connected to an existing network where these addresses may be already occupied.

If another address is wanted for the Ethernet debug link then the UART debug link must be used to connect

GRMON3 to the board. The EDCL IP address can then be changed using GRMON3's edcl command. This new

address will persist until next system reset.

The Ethernet debug link traffic is routed to the Debug AHB bus.

After reset the first Ethernet debug communication link will attempt to configure the Ethernet PHY. In order for

this to succeed, the Ethernet port must be connected to a switch or other networking equipment. Connect the

Ethernet to connector J3A and issue the following command:

grmon -eth 192.168.0.51

4.5. First steps

The previous sections have described which debug-links are available and how to start using them with GRMON3.

The subsections below assume that GRMON3, the host computer and the GR740-MINI board have been set up

so that GRMON3 can connect to the board.

When connecting to the board for the first time it is recommended to get to know the system by inspecting the

current configuration and hardware present using GRMON3. With the info sys command more details about the

system is printed and with info reg the register contents of the I/O registers can be inspected. Below is a list of

items of particular interest:

Jan 2024, Version 1.1 12

• AMBA system frequency is printed out at connect, if the frequency is wrong then it might be due to noise in

auto detection (small error). See -freq flag in the GRMON User's Manual [RD-4].

• Memory location and size configuration is found from the info sys output.

4.6. Connecting to the board

4.6.1. GR740

The transcript below shows an example session with GRMON3. GRMON3 is started with the -u flag in order to

redirect UART output to the GRMON3 terminal.

user@user:~/ $ grmon -ftdi -jtagserial GR740M0001A -sddcs -u

GRMON debug monitor v3.3.6 64-bit eval version

For latest updates, go to https://www.gaisler.com/

Comments or bug-reports to [email protected]

This eval version will expire on 28/04/2024

Parsing -ftdi

Parsing -sddcs

Parsing -u

Commands missing help:

echotrace

package

JTAG chain (1): GR740

Device ID: 0x740

GRLIB build version: 4153

Detected system: GR740 rev1

Detected frequency: 250.0 MHz

Component Vendor

JTAG Debug Link Frontgrade Gaisler

GRSPW2 SpaceWire Serial Link Frontgrade Gaisler

EDCL master interface Frontgrade Gaisler

LEON4 SPARC V8 Processor Frontgrade Gaisler

IO Memory Management Unit Frontgrade Gaisler

AHB-to-AHB Bridge Frontgrade Gaisler

L2-Cache Controller Frontgrade Gaisler

AHB Memory Scrubber Frontgrade Gaisler

IOMMU secondary master i/f Frontgrade Gaisler

AHB-to-AHB Bridge Frontgrade Gaisler

LEON4 Debug Support Unit Frontgrade Gaisler

AHB/APB Bridge Frontgrade Gaisler

AMBA Trace Buffer Frontgrade Gaisler

AHB/APB Bridge Frontgrade Gaisler

Muxed FT DDR/SDRAM controller Frontgrade Gaisler

Memory controller with EDAC Frontgrade Gaisler

GRPCI2 PCI/AHB bridge Frontgrade Gaisler

GRSPW Router Frontgrade Gaisler

LEON4 Statistics Unit Frontgrade Gaisler

GRPCI2 Trace buffer Frontgrade Gaisler

Generic UART Frontgrade Gaisler

General Purpose I/O port Frontgrade Gaisler

Multi-processor Interrupt Ctrl. Frontgrade Gaisler

Modular Timer Unit Frontgrade Gaisler

GRSPW Router DMA interface Frontgrade Gaisler

GR Ethernet MAC Frontgrade Gaisler

Jan 2024, Version 1.1 13

GR Ethernet MAC Frontgrade Gaisler

CAN Controller with DMA Frontgrade Gaisler

SPI Controller Frontgrade Gaisler

Clock gating unit Frontgrade Gaisler

MIL-STD-1553B Interface Frontgrade Gaisler

AHB Status Register Frontgrade Gaisler

General Purpose I/O port Frontgrade Gaisler

General Purpose Register Frontgrade Gaisler

Temperature sensor Frontgrade Gaisler

General Purpose Register Bank Frontgrade Gaisler

CCSDS TDP / SpaceWire I/F Frontgrade Gaisler

LEON4 Statistics Unit Frontgrade Gaisler

64-bit PC133 SDRAM Controller Frontgrade Gaisler

Use command 'info sys' to print a detailed report of attached cores

4.6.2. CertusPro

Please see Chapter 7 for the output corresponding the FPGA design.

Jan 2024, Version 1.1 14

5. Software Development Environment

5.1. Overview

Frontgrade Gaisler provides a comprehensive set of software tools to run several different operating systems. The

GR740 platform supports the following:

BCC the Bare C Cross-Compiler System is a toolchain to compile bare C or C++ applications di-

rectly on top of the processor without the services provided by an operating system

RTEMS a hard Real Time Operating System. Frontgrade Gaisler provides RCC, a toolchain to develop

and compile RTEMS applications specifically for the LEON

Linux the open source operating system. Board Support Packages and tools to ease the compilation

and deployment of the kernel are provided

VxWorks an embedded real-time operating system developed by WindRiver. Frontgrade Gaisler pro-

videsaLEON architectural port (HAL) and a Board Support Package (BSP) in full source code

Frontgrade Gaisler also provides a set of debug tools. The GR740 platform is supported by the following:

GRMON Used to run and debug applications on GR740-MINI hardware. See (Chapter 4).

Developer tools are generally provided for both Linux and Windows host operating systems. Frontgrade Gaisler

also provides an integrated, easy-to-use solution to help programmers with the task of developing for the LEON.

The LEON Integrated Development Environment for Eclipse (LIDE) is an Eclipse plug-in integrating compilers,

software and hardware debuggers in a graphical user interface. The plugin makes it possible to cross-compile C

and C++ application for LEON, and to debug them on either simulator and target hardware (TSIM or GRMON3).

The recommended method to load software onto a LEON board is by connecting to a debug interface of the board

through the GRMON3 hardware debugger (Chapter 4). Execution of programs by a PROM-loaded boot loader

is also possible.

5.2. Bare C Cross-Compiler System

5.2.1. Overview

The Bare C Cross-Compiler (BCC for short) is a GNU-based cross-compilation system for LEON processors. It

allowscross-compilationofCand C++applicationsfor LEON2,LEON3and LEON4.Thissection givesthereader

a brief introduction on how to use BCC together with the GR740-MINI Evaluation Board. It will be demonstrated

how to build an an example program and run it on the GR740-MINI using GRMON3.

The BCC toolchain includes the GNU C/C++ cross-compiler 7.2.0, GNU Binutils, Newlib embedded C library,

the Bare-C run-time system with LEON support and the GNU debugger (GDB). The toolchain can be downloaded

from [RD-10] and is available for both Linux and Windows. Further information about BCC can be found in

[RD-11].

The installation process of BCC is described in [RD-11]. The rest of this chapter assumes that sparc-gaisler-elf-

gcc is available in the PATH variable.

5.2.2. Compiling with BCC

The following command shows an example of how to compile a typical hello, world program with BCC.

$ cat hello.c

#include <stdio.h>

int main(void)

{

printf("hello, world\n");

return 0;

}

$ sparc-gaisler-elf-gcc -mcpu=leon3 -O2 -g hello.c -o hello.elf

All GCC options are described in the gcc manual. Some of the most common options are:

Jan 2024, Version 1.1 15

Table 5.1. BCC's GCC compiler relevant options

-g generate debugging information - recommended for debugging with GDB

-msoft-float emulate floating-point - must be used if no FPU exists in the system

-O2 optimize for speed

-Os optimize for size

-Og optimize for debugging experience

-qsvt use the single-vector trap model

-mflat enable flat register window model. The compiler will not emit SAVE and RESTORE

instructions.

It is recommended to use the options

-mcpu=leon3

with GR740. For more details, see [RD-10].

5.2.3. Running application with GRMON3

Once your application is compiled, connect to your GR740-MINI with GRMON3. The following log shows how

to load and run the the application using breakpoint. Note that the console output is redirected to GRMON3 by the

use of the -u command line switch, so that the application standard output is forwarded to the GRMON3 console.

grmon3> load hello.elf

40000000 .text 23.6kB / 23.6kB [===============>] 100%

40005E70 .data 2.7kB / 2.7kB [===============>] 100%

Total size: 26.29kB (806.59kbit/s)

Entry point 0x40000000

Image hello.elf loaded

grmon3> bp main

Software breakpoint 1 at <main>

grmon3> run

CPU 0: breakpoint 1 hit

0x40001928: b0102000 mov 0, %i0 <main+4>

CPU 1: Power down mode

grmon3> step

0x40001928: b0102000 mov 0, %i0 <main+4>

grmon3> step

0x4000192c: 11100017 sethi %hi(0x40005C00), %o0 <main+8>

grmon3> cont

hello, world

CPU 0: Program exited normally.

Alternatively you can run GRMON3 with the -gdb command line option and then attach a GDB session to it.

For further information see Chapter 3 of [RD-11].

5.3. Boot Loaders

Frontgrade Gaisler provides two boot loaders for the LEON2, LEON3 and LEON4 processors listed below for

more information. The boot loaders covers different use cases and requirements on software quality level. The

boot loaders are all capable of booting all the supported Operating Systems provided by Frontgrade Gaisler.

MKPROM2 MKPROM2 is a free open-source boot loader supporting a minimal system initialization,

extractionof asingleROM applicationimageinto mainmemoryand bootingit.No system

self-tests are performed by MKPROM2.

GRBOOT The GRBOOT boot loader software is based on the GR712RC Boot SW using the same

ECSS software engineering standards previously used to guarantee a high reliability for

flight. By isolating mission and device specific parts into BSPs and generalizing the im-

plementation, GRBOOT provides similar a reusable feature set for systems based on

LEON3/4FT processor devices acting as either payload or OBC.

Jan 2024, Version 1.1 16

One or more application images can be located in parallel flash or SPI flash. Multiproces-

sor application booting is supported.

GRBOOT is available for GR712RC and GR740 based systems together with the appro-

priate quality proofs, documentation and test suites. A version without references to the

ESA requirements documents is also available.

Jan 2024, Version 1.1 17

6. FPGA development Environment

6.1. Lattice Radiant Software

Lattics provides a software development tool for the FPGA development. Lattice Radiant software is available

for both linux and windows enviorment.

For download and information about licensing please see webpage: www.latticesemi.com/latticeradiant.

6.2. Program the FPGA

The FPGA can be programmed in the volatile (RAM) memory or non-volatile (SPI flash) memory. The FPGA is

programmed with JTAG through the FTDI chip.

6.2.1. Lattice programmer

TBC

6.2.2. GRMON3

GRMON3 can be used to program the FPGA in both linux and windows enviorment, see sections below for

prerequisites. Note that GRMON version 3.3.6 or higher is needed.

In order to program the FPGA using GRMON3 it is needed to connect the debug link to GR740 via JTAG. Please

se section Section 4.3.1 for how to connect. In GRMON3, the following command is used to program the RAM

grmon3> fpgaload ex-1.bit

write to ram

Jtag frequency : requested 1.00MHzOpen file: DONE

Parse file: DONE

Enable configuration: DONE

SRAM erase: DONE

Loading: [==================================================] 100.00%

Done

Disable configuration: DONE

To program the SPI memoory use the -f flag, see below:

grmon3> fpgaload ex-1.bit -f

write to flash

Jtag frequency : requested 1.00MHzOpen file DONE

Parse file DONE

Enable configuration: DONE

SRAM erase: DONE

Detected: Macronix MX25L51245G 1024 sectors size: 512Mb

00000000 00000000 00000000 00

Erasing: [==================================================] 100.00%

Done

Writing: [==================================================] 100.00%

Done

Refresh: DONE

6.2.2.1. Linux prerequisites

Prerequisites: the following programs needs to be installed:

• libusb-1.0

• libftdi1

• libudev

• libhidapi-hidraw

• libz

• glibc-2.29 or higher

• libstdc++.so.x.x.21 or higher

Jan 2024, Version 1.1 18

6.2.2.2. Windows prerequisites

To be able to program the FPGA you must replace the driver for the FT4232 interface connected to FPGA. The

tool Zadig can be used for this purpose and can be downloaded from https://zadig.akeo.ie/ . Start Zadig and click

on "Options" and enable "List All Devices" from the drop-down menu. Select GR740-MINI (Interface 1) and set

the driver to WinUSB as in Figure 6.1. Click on "Replace Driver"

Figure 6.1. Zadig interface

Jan 2024, Version 1.1 19

7. Example Bitstreams

7.1. Overview

For the GR740-MINI board, example bitstreams for the CertusPro-NX are available for download on the webpage

www.gaisler.com/gr740-mini. The bitstreams are based on an architecture centered around the AMBA Advanced

High-speed Bus (AHB), to which high-bandwidth units are connected. Low-bandwidth units are connected to the

AMBA Advanced Peripheral Bus (APB) which is accessed through an AHB to APB bridge.

In the sections below we shortly present the different bistreams and corresponding IP cores also a simplified

interactions is shown. The AHB/APB memory mapping and interrupts are not included in this document but, can

be displayed for each design using the info sys command in GRMON3.

For more information considering the operations of each individual core, please refer to the grip documentation

available at GRLIB IP Core User’s Manual

7.2. EX-1

Figure 7.1. Architectural block diagram of bitstream EX-1

Expected output when connecting with GMON3.

user@user:~/ $ grmon -uart /dev/ttyUSB3 -u

GRMON debug monitor v3.3.6 64-bit eval version

For latest updates, go to https://www.gaisler.com/

Comments or bug-reports to [email protected]

This eval version will expire on 28/04/2024

Parsing -uart /dev/ttyUSB3

Parsing -u

using port /dev/ttyUSB3 @ 115200 baud

Device ID: 0x801

Jan 2024, Version 1.1 20

GRLIB build version: 4283

Detected frequency: 50.0 MHz

Component Vendor

AHB Debug UART Frontgrade Gaisler

GR Ethernet MAC Frontgrade Gaisler

GRPCI2 PCI/AHB bridge Frontgrade Gaisler

GRSPW2 SpaceWire Serial Link Frontgrade Gaisler

AHB/APB Bridge Frontgrade Gaisler

SPI Memory Controller Frontgrade Gaisler

Single-port AHB SRAM module Frontgrade Gaisler

Generic UART Frontgrade Gaisler

Modular Timer Unit Frontgrade Gaisler

Use command 'info sys' to print a detailed report of attached cores

7.2.1. UART

This design includes UART IP cores thats connect to J2 through a FTDI chip. Please refere to Section 4.4.1 for

how to interface GRMON3 using UART to the FPGA.

7.2.2. SPIMCTRL

This IP block allows the user to access the SPI Flash memory featured on the board. The user can set the IP and

the memory to work in Extended, Dual or Quad SPI. By issuing spim flash detect, GRMON3 can recognise the

memory and therefore load the needed settings to operate.

grmon3> spim flash detect

Got manufacturer ID 0xc2 and device ID 0x201a

Detected device: Macronix MX25L51245G

7.2.3. PCI

In this bitstream the FPGA is configured as a target and can therefore not been found using the info -reg pci0

command. Since the FPGA is a target, only the GR740 can perform an access. The GR740 is the host and need

to perform configuration when seting up the PCI.

****** GR740 ******

grmon3> pci init

grmon3> pci conf

PCI devices found:

Bus 0 Slot 0 function: 0 [0x0]

Vendor id: 0x1ac8 (Aeroflex Gaisler)

Device id: 0x55 (Unknown device)

BAR 0: 80000008 [64MB]

BAR 1: 84000008 [1MB]

grmon3> # Sets the AMBA adress for the RAM (FPGA)

grmon3> pci wcfg32 0:0:0 0x44 0x40000000

grmon3> # Read the RAM memory corresponing the FPGA

grmon3> mem 0x80000000

0x80000000 46504741 20436572 74757350 726f0000 FPGA CertusPro..

0x80000010 00000000 00000000 00000000 00000000 ................

0x80000020 00000000 00000000 00000000 00000000 ................

0x80000030 00000000 00000000 00000000 00000000 ................

7.2.4. Ethernet

This bitstream provides ethernet in 10/100/1000 Mbit speed. By default the PHY is set to 1000Mbit mode and the

IP address is 192.168.0.51. The ethernet is connected to connector J3A. To evalauate how the PHY is configurated

use the mdio info command. Please refere to Section 4.3.2 for how to interface GRMON3 with ethernet to the

FPGA.

grmon3> mdio info

greth0: PHY address 2

Model: Micrel KSZ9031

Link: 1000Mbps Full Duplex (autoneg on)

Other manuals for GR740-MINI

Table of contents

Other FRONTGRADE Motherboard manuals

FRONTGRADE

FRONTGRADE GR716-BOARD User manual

FRONTGRADE

FRONTGRADE GR740-MINI User manual

FRONTGRADE

FRONTGRADE GR-CPCI-GR716-DEV User manual

Popular Motherboard manuals by other brands

Avalue Technology

Avalue Technology ERX-W480P user manual

Cypress

Cypress MB39C326-EVBSK-01 Operation manual

Nuvoton

Nuvoton NuMicro NuMaker-M467HJ user manual

PRIZM

PRIZM 201750 Series User's manual and troubleshooting guide

sparkfun

sparkfun ProtoShield quick start guide

ASROCK

ASROCK P4 COMBO user manual

Gigabyte

Gigabyte GA-Z68XP-UD3-iSSD user manual

Altera

Altera Nios II user guide

Texas Instruments

Texas Instruments AMC7823 EVM user guide

Asus

Asus PRIME H510M-A R2.0 manual

Asus

Asus P4V8X-MX user guide

Gigabyte

Gigabyte GA-945GCM-S2L user manual

DFI

DFI G586IPC user manual

Active-semi

Active-semi HYDRA-X10 user guide

Gigabyte

Gigabyte GA-B85-HD3 user manual

Asus

Asus P8H77-I manual

Intel

Intel MB970 user manual

Biostar

Biostar NF4UL-A9 user guide
