FrSky Neuron II 80 User manual

Instruction Manual for FrSky Neuron II 80
FrSky Electronic Co., Ltd. www.frsky-rc.com Contact us : [email protected]
Add: F-4,Building C, Zhongxiu Technology Park, No.3 Yuanxi Road, Wuxi, 214125, Jiangsu, China Technical Support: [email protected]
Introduction
Based on the performance and design features of the first-gen NEURON ESC products, the NEURON II line
steps it up by offering a broader selection of ESC models to various demands in different applications.
The NEURON II 80 comes with a fully enclosed all-CNC machined aluminum casing design, ensuring efficient
heat dissipation while handling a continuous current of 80A. The NEURON II series can transmit telemetry data
from built-in sensors to the radio by the receiver, allowing users to get real-time insights right from the radio
system. RPM, power consumption, temperature, input/output voltage, and current readings are all at your
fingertips.
With added support for the FBUS protocol, the NEURON II takes convenience to a whole new level! Users can
now easily configure the BEC output voltage and other ESC parameters directly from the transmitter via the
receiver. Or with even more flexibility, hook up NEURON II ESC to the ETHOS radio’s S.Port for seamless wired
configuration without requiring a receiver (this feature will be available on ETHOS 1.5.0 and later versions). The
traditional configuration method through a PC webpage is also retained. There’s more! The NEURON II 60/80
comes with support for multiple signaling protocols which can be used to drive and configure a wide range of
compatible motors.
Overview
PWM/SBUS
FBUS/S.Port
LED
BATTERY INPUT
3S-6S (11.2V-25.2V)
CONFIGURABLE BEC
[email protected]
80
64.5mm
16.5mm 34mm
Specifications
● Dimension: 64.5×34×16.5mm(L×W×H)
● Weight: 94g (with wires included.)
● Battery Input Voltage Range: 11.2-25.2V (3S-6S Li batteries)
● BEC Output Voltage Range: 10A@5V~8.4V (Adjustable & Voltage Step 0.1V)
● Continuous Current: 80A

Instruction Manual for FrSky Neuron II 80
FrSky Electronic Co., Ltd. www.frsky-rc.com Contact us : [email protected]
Add: F-4,Building C, Zhongxiu Technology Park, No.3 Yuanxi Road, Wuxi, 214125, Jiangsu, China Technical Support: [email protected]
Features
● All-CNC Machined Aluminum Case aiding in Heat Dissipation
● Various Telemetry Data (for ESC & SBEC) via FBUS / S.Port
- Telemetry data for ESC: Batt Voltage & Current (Resolution 125mA, Precision ±2%), RPM, Power
Consumption, Temperature.
- Telemetry data for SBEC: Output Voltage & Current (Resolution 50mA, Precision ±2%).
● Adjustable SBEC Output Voltage & ESC Parameters by LUA scripts (on ETHOS, OPTX radios.) or PC
Configuration Webpage (by STK tool)
● Supports Various Signaling Inputs for Motor Control (PWM, DShot, OneShot)
● High-Performance32-bit Microprocessor
● Over-Temperature and Over-Current Protection
Parameter Configuration ( PC Webpage Programming via STK tool )
The FrSky ESC Neuron II 80 supports editing parameters through the STK tool. The STK tool is not included in
the packaging and needs to be purchased separately by the user.
Connection Diagram
RECEIVER
RECEIVER
10
9
RECEIVER
SBUS + S.Port
PWM + S.Port
FBUS (FBUS Capable Receiver)
Yellow: S.Port / FBUS
Green: PWM / SBUS
PWM/SBUS
FBUS/S.Port
LED
BATTERY INPUT
3S-6S (11.2V-25.2V)
CONFIGURABLE BEC
[email protected]
80
PWM/SBUS
FBUS/S.Port
LED
BATTERY INPUT
3S-6S (11.2V-25.2V)
CONFIGURABLE BEC
[email protected]
80
PWM/SBUS
FBUS/S.Port
LED
BATTERY INPUT
3S-6S (11.2V-25.2V)
CONFIGURABLE BEC
[email protected]
80
PWM/SBUS
FBUS/S.Port
LED
BATTERY INPUT
3S-6S (11.2V-25.2V)
CONFIGURABLE BEC
[email protected]
80

The configuration methods provided below are for reference only. Due to firmware updates or other reasons, the
functionality description may vary. Please refer to the latest official user manual for accurate configuration
instructions.
Here are the descriptions of various features on the web-based ESC configuration page of FrSky Neuron II.
1. Reverse motor direction: This feature allows you to control whether the motor spins in the opposite direction.
Checking this option will reverse the motor direction.
2. Slow start: It controls the gradual acceleration of the motor during startup to avoid sudden and strong reactions.
3. Soft start: This feature enables a smooth acceleration of the motor during startup, reducing the impact force
and load on the motor.
4. ESC beeps: It determines whether the ESC emits audible beeps during startup, serving as an indicator of its
status.
5. PWM Min: This setting determines the minimum PWM signal value that the ESC will recognize as the lowest
throttle position.
6. PWM Max: It sets the maximum PWM signal value that the ESC will recognize as the full throttle position.
7. Soft brake: This feature controls whether the ESC implements a smooth braking action when transitioning to
low throttle.
8. 3D Mode: It activates a special mode in the ESC suitable for performing aerobatic maneuvers and 3D flight
actions.
Note: To configure the Neuron II ESC, please connect the STK tool to your computer and connect the
power supply to the Neuron II ESC.
Instruction Manual for FrSky Neuron II 80
FrSky Electronic Co., Ltd. www.frsky-rc.com Contact us : [email protected]
Add: F-4,Building C, Zhongxiu Technology Park, No.3 Yuanxi Road, Wuxi, 214125, Jiangsu, China Technical Support: [email protected]

9. Current calibration(%): This option allows you to calibrate the ESC to accurately measure current, providing
precise current data.
10. Current limit: It lets you set the maximum current output limit of the ESC to protect both the ESC and the motor
from overloading.
11. BEC output Voltage: You can specify the output voltage of the ESC's built-in BEC (Battery Eliminator Circuit).
12. Activated: Display ESC Activation Status.
13. Trapeziodal commutation
14. Physical ID: This setting specifies the physical ID used for communication.
15. Application ID: This setting specifies the Sensor ID used for communication.
16. Response Time(*100ms): It determines the time gap between communications.
17. High demag. protection
18. Motor pole count: It refers to the number of magnetic poles inside the motor. You need to set the correct pole
count to ensure proper motor rotation and ESC commutation.
19. Throttle channel: Specify the serial port signal channel for the throttle channel input signal used to control the
ESC, such as SBUS/FBUS.
20. OneWire ID: This feature assigns a unique ID to each ESC when using OneWire bus communication.
These features offer a wide range of configuration options to meet the requirements of different types of aircraft
and flight preferences. Specific features and options may vary based on the version of FETtec Configurator and
device support. Please consult the relevant documentation or official guides for more detailed information before
using these options.
Instruction Manual for FrSky Neuron II 80
FrSky Electronic Co., Ltd. www.frsky-rc.com Contact us : [email protected]
Add: F-4,Building C, Zhongxiu Technology Park, No.3 Yuanxi Road, Wuxi, 214125, Jiangsu, China Technical Support: [email protected]

Instruction Manual for FrSky Neuron II 80
FrSky Electronic Co., Ltd. www.frsky-rc.com Contact us : [email protected]
Add: F-4,Building C, Zhongxiu Technology Park, No.3 Yuanxi Road, Wuxi, 214125, Jiangsu, China Technical Support: [email protected]
Parameter Configuration ( ETHOS Lua Programming via FBUS / S.Port )
Here are the descriptions of various features on the ETHOS LUA configuration page of FrSky Neuron II
ESC.
This feature allows you to control whether the motor spins in the opposite direction. Checking this option will
reverse the motor direction.
Use Sine Wave Start
This feature enables a smooth acceleration of the motor during startup, reducing the impact force and load on the
motor.
It determines whether the ESC emits audible beeps during startup, serving as an indicator of its status.
This setting determines the minimum PWM signal value that the ESC will recognize as the lowest throttle position.
It sets the maximum PWM signal value that the ESC will recognize as the full throttle position.
This feature controls whether the ESC implements a smooth braking action when transitioning to low throttle.
It activates a special mode in the ESC suitable for performing aerobatic maneuvers and 3D flight actions.
This option allows you to calibrate the ESC to accurately measure current, providing precise current data.

It lets you set the maximum current output limit of the ESC to protect both the ESC and the motor from
overloading.
You can specify the output voltage of the ESC's built-in BEC (Battery Eliminator Circuit).
Trapeziodal commutation
This setting specifies the physical ID used for communication.
This setting specifies the Sensor ID used for communication.
It determines the time gap between communications.
It refers to the number of magnetic poles inside the motor. You need to set the correct pole count to ensure proper
motor rotation and ESC commutation.
Specify the serial port signal channel for the throttle channel input signal used to control the ESC, such as
SBUS/FBUS.
High demag. protection
Warnings
● Before using the ESC, please read through the manuals of all power devices and models. Ensure rational
power configuration, or it will make the unit overloaded and damaged.
Instruction Manual for FrSky Neuron II 80
FrSky Electronic Co., Ltd. www.frsky-rc.com Contact us : [email protected]
Add: F-4,Building C, Zhongxiu Technology Park, No.3 Yuanxi Road, Wuxi, 214125, Jiangsu, China Technical Support: [email protected]
Parameter configuration Telemetry feedback
Here is the telemetry sensor configuration and feedback for the ETHOS system.

Instruction Manual for FrSky Neuron II 80
FrSky Electronic Co., Ltd. www.frsky-rc.com Contact us : [email protected]
Add: F-4,Building C, Zhongxiu Technology Park, No.3 Yuanxi Road, Wuxi, 214125, Jiangsu, China Technical Support: [email protected]
● Always keep your model away from unsafe elements, such as concrete buildings and high-voltage power lines.
Fly your models according to the manual strictly, or it may cause damage and serious injuries.
● Always disconnect the batteries from the ESC after use, or it may drive the motor to rotate and cause injuries.
If the ESC is connected to the battery for a long time, the battery will be fully discharged, which may lead to the
malfunction of both batteries and the ESC.
Firmware Upgrade for NEURON2 ESC
● Configuration Device: STK Tool (Separate Purchase Required)
● Webpage Configurator: https://gui.fettec.net/FrSky/ESC/
Step 1: Connect the STK tool to the PC, and select
the "USB UART" port on the Configurator webpage.
Step 4：Click the "Local Firmware" button and find
the path of the firmware to update the ESC.
Step 2: A connecting request window prompts up at
this moment and then click the "Connect" button.
Step 3: Connect the NEURON2 ESC to the S.Port 2
and switch the Dip to "Upgrade" mode. Once
powering the ESC then, please click the "Connect"
button in 5 seconds to complete the connection.
Step 5: Click the tab "Flash selected" waiting for the
completion of the flashing bar. A prompt of the
"Warning" window means the flash is done.
PWM/SBUS
FBUS/S.Port
LED
BATTERY INPUT
3S-6S (11.2V-25.2V)
CONFIGURABLE BEC
[email protected]
80
