Frymaster SinBaD Series User manual

OPERATOR’S MANUAL
McDonald’s SinBaD Series
SINGLE BASKET DISPENSER
Frymaster L.L.C., 8700 Line Avenue 71106, 5489 Campus Drive 71129
P.O. Box 51000, Shreveport, Louisiana 71135-1000
TEL [phone] FAX (Parts) 318-219-7140 (Tech Support) 318-219-7135
Printed in the United States Service Hotline [phone]
1-800-24-FRYER U.S. $4.00
This document is to be inserted
into the Non-Fryer Section of
the Equipment Manual.
MANUFACTURED FOR
McDONALD’S®
BY FRYMASTER, L.L.C.
P.O. BOX 51000
SHREVEPORT, LOUISIANA 71135-1000
PHONE [phone]
1 (800) 24 FRYER
TABLE OF CONTENTS
WARRANTY STATEMENT.....................................................................................................................Page i
INTRODUCTION..................................................................................................................................... Page 1-1
INSTALLATION AND OPERATION....................................................................................................... Page 2-1
MAINTENANCE AND OPERATOR TROUBLESHOOTING.................................................................. Page 3-1
FOR YOUR SAFETY
Do not store or use gasoline or other
flammable liquids and vapors in the
vicinity of this or any other appliance.

DANGER
IMPROPER INSTALLATION, ADJUSTMENT, ALTERATION, SERVICE OR MAINTENANCE CAN CAUSE PROPERTY
DAMAGE, INJURY, OR DEATH. READ THE INSTALLATION, OPERATING, AND MAINTENANCE INSTRUCTIONS
THOROUGHLY BEFORE INSTALLING, OPERATING, OR SERVICING THIS EQUIPMENT.
DANGER
DO NOT ATTEMPT TO REPAIR OR REPLACE ANY COMPONENT OF THIS EQUIPMENT UNLESS ALL POWER TO THE
EQUIPMENT HAS BEEN DISCONNECTED.
DANGER
FOR YOUR SAFETY, DO NOT STORE OR USE GASOLINE OR OTHER FLAMMABLE VAPORS AND LIQUIDS IN THE
VICINITY OF THIS OR ANY OTHER APPLIANCE.
DANGER
FRYMASTER EQUIPMENT IS MANUFACTURED FOR USE WITH THE TYPE VOLTAGE SPECIFIED ON THE EQUIPMENT
RATING PLATE. FOR PROPER ELECTRICAL INSTALLATION PROCEDURES IN THE UNITED STATES, REFER TO THE
LATEST EDITION OF THE NATIONAL ELECTRIC CODE (ANSI/N.F.P.A. NO 70). IN CANADA, REFER TO THE CANADIAN
ELECTRICAL CODE PART 1 (CSA-22.1.) FOR INSTALLATION IN COUNTRIES OTHER THAN THE UNITED STATES AND
CANADA, REFER TO THE NATIONAL CODE APPROPRIATE FOR THE COUNTRY IN WHICH THE EQUIPMENT IS BEING
INSTALLED.
WARNING
DO NOT OPERATE THIS EQUIPMENT UNLESS ALL SERVICE AND ACCESS PANELS ARE IN PLACE AND PROPERLY
SECURED.
WARNING
COMPUTERS
FCC
This device complies with Part 15 of the FCC rules. Operation is subject to the following two conditions: 1) This device may
not cause harmful interference, and 2) This device must accept any interference received, including interference that may
cause undesired operation. While this device is a verified Class A device, it has been shown to meet the Class B limits.
CANADA
This digital apparatus does not exceed the Class A or B limits for radio noise emissions as set out by the
ICES-003 standard of the Canadian Department of Communications.
Cet appareil numerique n’emet pas de bruits radioelectriques depassany les limites de classe a et b prescrites
dans la norme NMB-003 edictee par le ministre des communications du Canada.
HAZARD COMMUNICATION STANDARD (HCS) – WHEN THE PROCEDURES IN THIS MANUAL INCLUDE
THE USE OF CHEMICAL PRODUCTS, THE PRODUCTS WILL BE PRINTED IN BOLD FACE, FOLLOWED BY
THE ABBREVIATION HCS IN THE TEXT PORTION OF THE PROCEDURE. SEE THE HAZARD
COMMUNICATION STANDARD (HCS) MANUAL FOR THE APPROPRIATE MATERIAL SAFETY DATA SHEET
(MSDS).

1-1
McDonald’s SinBaD SINGLE BASKET DISPENSER
CHAPTER 1: INTRODUCTION
1.1 Parts Ordering and Service Information
In order to assist you as quickly as possible, the Frymaster Factory Authorized Service Center (FASC) or Ser-
vice Department representative requires certain specific information about your equipment. Most of this in-
formation is printed on a data plate affixed to the upper right corner of the right side of your unit.
Parts orders may be placed directly with your local FASC or distributor. Included with your unit when
shipped from the factory is a list of Frymaster FASCs. If you do not have access to this list, contact the
Frymaster Service Department at 1-800-24-FRYER.
When ordering parts, the following information is required:
Model Number:
Serial Number:
Voltage:
Item Part Number:
Quantity Needed:
Service information may be obtained by contacting your local FASC or Distributor. Service may also be ob-
tained by calling the Frymaster Service Department at 1-800-24-FRYER.
When requesting service, please have the following information ready:
Model Number:
Serial Number:
Voltage:
In addition to the model number, serial number, and voltage, please be prepared to describe the nature of the
problem and have ready any other information that you think may be helpful in solving your problem.
1.2 Safety Information
Before attempting to operate your unit, read the instructions in this manual thoroughly. Throughout this
manual, you will find notations enclosed in double-bordered boxes similar to the one below.
DANGER
Example of a DANGER box.
CAUTION boxes contain information about actions or conditions that may cause or result in a malfunction
of your unit.
WARNING boxes contain information about actions or conditions that may cause or result in damage to
your unit, and which may cause your unit to malfunction.
DANGER boxes contain information about actions or conditions that may cause or result in injury to
personnel, and which may cause damage to your unit and/or cause your unit to malfunction.
1.3 Equipment Description

1-2
The McDonald’s Single Basket Dispenser (SinBaD)is designed to dispense french fries in batches of
consistent weight into standard fryer baskets.
A SinBaD unit consists of
• a hopper which holds up to 39 lbs./17.5 kg of fries
• a dispensing chute into which the specified weight of fries for one basket is loaded
• a computer and an operator control panel for controlling operation
• a proximity switch which releases the fries into the basket when the basket is inserted beneath the
dispensing chute
• a sight-glass for monitoring the level of french fries in the hopper.
Additionally, the unit is equipped with casters. The front casters are equipped with locking mechanisms to
secure the units in place.
The SinBaD Batch Weight Selectors have been factory-programmed to dispense batches of three standard
sizes: 0.5 lb./.23 kg, 1.0 lb./.45 kg, or 1.5 lb./.68 kg.
1.4 Installation, Operating, and Service Personnel
Operating information for Frymaster equipment has been prepared for use by qualified and/or authorized
personnel only, as defined in Section 1.5.
All installation and service on Frymaster equipment must be performed by qualified, certified, licensed,
and/or authorized installation or service personnel, as defined in Section 1.5.
1.5 Definitions
QUALIFIED AND/OR AUTHORIZED OPERATING PERSONNEL
Qualified/authorized operating personnel are those who have carefully read the information in this manual
and have familiarized themselves with the equipment functions, or who have had previous experience with
the operation of the equipment covered in this manual.
QUALIFIED INSTALLATION PERSONNEL
Qualified installation personnel are individuals, firms, corporations, or companies which, either in person or
through a representative, are engaged in and are responsible for the installation of commercial electric
appliances. Qualified personnel must be experienced in such work, be familiar with all electrical precautions
involved, and have complied with all requirements of applicable national and local codes.
QUALIFIED SERVICE PERSONNEL
Qualified service personnel are those that are familiar with Frymaster equipment and who have been
authorized by Frymaster to perform service on its equipment. All authorized service personnel are required to
be equipped with a complete set of service and parts manuals, and to stock a minimum amount of parts for
Frymaster equipment.
A list of Factory Authorized Service Centers (FASCs) is included with your unit when shipped from the
factory. Failure to use qualified service personnel will void the warranty on your equipment.

1-3
1.6 Shipping Damage Claim Procedure
Your equipment was carefully inspected and packed before leaving the factory. The transportation company
assumes full responsibility for safe delivery upon its acceptance of the equipment for transport.
What to do if your equipment arrives damaged:
1. File a claim for damages immediately, regardless of the extent of damages.
2. Inspect for and record all visible loss or damage, and ensure that this information is noted on the
freight bill or express receipt and is signed by the person making the delivery.
3. Concealed loss or damage that was unnoticed until the equipment was unpacked should be recorded and
reported to the freight company or carrier immediately upon discovery. A concealed damage claim must
be submitted within 15 days of the date of delivery. Ensure that the shipping container is retained for in-
spection.
FRYMASTER DOES NOT ASSUME RESPONSIBILITY FOR DAMAGE OR
LOSS INCURRED IN TRANSIT.

2-1
McDonald’s SinBaD SINGLE BASKET DISPENSER
CHAPTER 2: INSTALLATION AND OPERATION
FINDING YOUR WAY AROUND YOUR
NEW SinBaD UNIT
RUN Switch
Lid
Basket Rack
Basket Rack
Receiver Bracket
Basket Rack
Crumb Pan
ON/OFF
Rocker Switch
Hopper Locking Rim
Sight Glass
Hopper
Rating Plate
Control Panel
Dispensing Chute
(rests on Load
Cell Arms)
Basket Locator Rack
w/Crumb Pan Below
SinBaD
SinBaD
0.5
LB
1.0
LB
1.5
LB
PROGRAM Switch
CHECK HOPPER Indicator
CLEAN Switch
BATCH WEIGHT Selectors

2-2
2.1 Installation
DANGER
All electrically operated appliances must be electrically grounded in accordance with local codes, or
in the absence of local codes, with the applicable national electrical code. If this appliance is
equipped with a three-prong grounding plug for your protection against electrical shock hazard, it
must be plugged directly into a properly grounded three-prong receptacle. DO NOT CUT OFF OR
REMOVE THE GROUNDING PRONG FROM THIS PLUG.
DANGER
This appliance is intended for indoor use only. IT IS NOT SUITABLE FOR OUTDOOR USE.
DANGER
This appliance is not suitable for installation in an area where a water jet could be used.
DANGER
This appliance must be installed on a horizontal surface, i.e., a surface having a slope of less than 2°.
CAUTION
For proper operation, this appliance should be installed in an area having an ambient temperature
within the range 40°– 110°F (4°– 43°C).
Locate the unit in an area where it will not be bumped or jarred during normal activities. Movement of the
unit during operation may cause inaccurate filling of the dispensing chute.
1. Position the cabinet assembly on a horizontal surface adjacent to an AC outlet of appropriate voltage
(refer to the data plate affixed to the upper right corner of the right side of the unit).
2. Attach the receiver bracket to the desired side of the unit. Attach the basket rack arm to the rack on the
side corresponding to the receiver bracket. Attach the basket rack assembly to the unit by inserting the
arm into the receiver bracket. Place the basket rack crumb pan onto the base of the rack.
CAUTION
Do not use the basket rack unless it has been properly attached to the cabinet.
3. Assemble the hopper by inserting the drum into the hole at the
rear of the hopper with the hole in the drum facing out. Position
the lip of the deflector over the left edge of the hopper, and insert
the sight glass into the V-shaped opening at the front of the hop-
per.
4. Place the hopper on top of the cabinet with the sight glass to the
front. Position the hopper so that the drum rotator is inserted
into the hole in the drum, the hopper is sitting flat on the cabinet
top, and its lower front edge is seated behind the locking rim of
the cradle assembly (see illustration on Page 2-1). Place the lid
onto the hopper, making sure the arrow on the lid points to the
front of the unit.
5. Place the crumb pan onto the lower deck behind the two studs.
Position the basket locator rack into the pan with the legs at the
rear (see illustration on Page 2-1). Assembling the Hopper
Lid
Sight Glass
Deflector
Hopper
Drum

2-3
6. Make any final positioning adjustments necessary, then lock the casters and connect the unit to an appro-
priate electrical source. If this equipment is wired directly into the electrical power supply, a means
for disconnection from the supply having a contact separation of at least 3 mm in all poles must be
incorporated in the fixed wiring.
7. Once the unit has been positioned, and connected, remove the load cell shipping protector. The load cell
shipping protector consists of a bolt, red wingnut, shim, and large red tag. The bolt and shim
MUST be removed for proper operation.
This bolt (with attached red wignut) and shim are used
to protect the load cell during shipment. They must be
removed before the unit will work properly.
Bolt
Red Wingnut
Shim
"Remove
before Use"
Tag
2.2 Self-Zeroing
The SinBaD unit is self-zeroing. Each time the unit is placed in the RUN mode, it performs a self-zeroing
routine. The routine is characterized by the Dispensing Chute door opening for about 20 seconds and the se-
quential flashing of the batch weight selector lights. The door will close and the lights will stop flashing
when the self-zeroing routine is complete.
2.3 Operation
CAUTION
Ensure the ON/OFF Rocker Switch is in the OFF position before installing the hopper.
1. Verify that the ON/OFF Rocker Switch is in the “OFF” position.
2. Verify that the crumb pan is properly inserted in the deck cutout.
3. Verify that the basket locator rack is properly positioned with the wide end facing you.
4. Verify that the dispensing chute is properly positioned on the load cell arms, with the door hinge screws
to the right as you face the unit. Failure to properly position the chute will result in erratic batch weights.

2-4
5. Verify that the drum and deflector are properly positioned inside the hopper. Failure to do so will result
in a malfunction of your unit. If the deflector is deformed (i.e., bent or distorted), a malfunction of your
unit is likely.
DANGER
A pinch-point exists between the drum and hopper when the drum is turning. When removing or
installing the deflector or dispensing chute, place the ON/OFF Rocker Switch in the “OFF” position.
6. Verify that the hopper is properly positioned in its cradle. Make sure that the hopper is seated behind the
locking rim on the cradle. Failure to do so will result in malfunctioning of your unit.
7. Verify that the sight glass is installed. If it is not installed, fries will fall out of the hopper during opera-
tion.
8. Place the ON/OFF Rocker Switch in the ON position. The switch will illuminate, indicating that electri-
cal power is being supplied to the unit.
9. Press the RUN Switch once to place the unit in the RUN mode. The indicator light in the switch will
illuminate. The dispensing chute door will open as the unit begins self-calibration and the lights in the
batch weight selectors will sequentially flash. The door will close about 20 seconds later and the lights
will stop flashing when calibration is completed. Only the RUN mode indicator will be illuminated.
10. Open the hopper lid and load up to 42 lbs/19 kg of French fries into the hopper. Close the hopper lid.
11. Press the BATCH WEIGHT Selector that corresponds to the desired weight of potatoes. The factory-
programmed weights are 0.5 lb/.23 kg, 1.0 lb/.45 kg, and 1.5 lb/.68 kg (see illustration on Page 2-1).
The indicator light in the selector will illuminate and the drum will begin to rotate, transferring fries from
the hopper to the dispensing chute. When the prescribed weight has been transferred, drum rotation will
cease.
12. Insert an empty basket all the way to the rear of the dispensing chamber. The dispensing chute door will
open, dropping the fries into the basket. When the chute is empty, the door will close and the unit will
begin to transfer another batch of fries into the chute.
CAUTION
The dispensing of fries into a basket is initiated by an inductive proximity switch located in the
dispensing well. The proximity switch activates only when it senses a metallic mass greater than a
certain size (e.g., an inserted basket). Thus, it will not be activated by the operator’s hand, a cleaning
cloth, or any other non-metallic object. However, a ring, watch or some other type of metal could
initiate a dispense cycle if inserted into the switch detection area.
NOTE: Built-in logic recognizes the removal and replacement of the basket. Once a dispense cycle has been
completed, another basket may be inserted into the dispense well. As soon as the fries in the chute reach the
specified weight, the unit will immediately dispense them into the waiting basket. The unit will NOT initiate
another dispense cycle if the full basket is not removed and replaced, nor will it initiate another dispense cy-
cle if there is no basket in the dispense well.
To change the batch weight, press another of the numbered selectors before the chute is emptied. If the
weight is increased, fries will be dispensed until the new weight is attained. If the batch weight is reduced,
the change will take effect with the next cycle after the dispensing chute is emptied.

2-5
If the dispensing chute does not fill within 30 seconds, the CHECK HOPPER indicator in the
middle of the control panel will begin to blink and drum rotation will stop. Check the hopper to see if
it is empty. If it is empty, reload the hopper then press the PROGRAM Switch once to place the unit
back into operation. If the hopper appears to contain plenty of fries, the fries have probably “bridged”
(i.e., stuck together to form an arch over the drum). Redistribute the fries then press the PROGRAM
Switch once to place the unit back into operation.
2.4 Manual Operation
If the unit fails to zero, the unit can be manually operated until a servicer arrives to make repairs. Follow the
procedure below.
1. Turn the computer off (press the RUN Switch ).
2. Place a basket under the hopper dispense door.
3. Press the CLEAN Switch once to dispense fries into the basket. NOTE: If the dispense door fails to
open, pull down on the door arm to manually open the door.
4. When the basket is filled to the desired level, press the CLEAN Switch once to stop dispensing fries.

3-1
McDonald’s SinBaD SINGLE BASKET DISPENSER
CHAPTER 3: MAINTENANCE & OPERATOR TROUBLESHOOTING
3.1 Cleaning and Maintenance
Routine cleaning in accordance with the following steps is the only operator maintenance required for your
SinBaD unit.
1. Put the unit in STANDBY mode. Place a container beneath
the dispensing chute and press the CLEAN Switch. The
indicator in the switch will light. The dispensing chute door
will open and the drum will rotate, transferring fries from the
hopper to the container. Press the CLEAN Switch again to
stop transferring. To transfer more fries, press the CLEAN
Switch again. When the hopper is empty, press the RUN
Switch once to return to the STANDBY mode. The dis-
pensing chute door will remain open.
2. Place the ON/OFF Rocker Switch in the OFF position.
3. Remove the hopper lid and the metal deflector. Lift up on
the hopper while carefully pulling it toward you. This will
disengage the hopper from its retainer, allowing it to slide
forward for removal.
4. Remove the dispensing chute by lifting it up from the load
cell arms and carefully sliding it out toward you.
These components
shown separated from
cabinet to reveal load
cell arms.
Dispense
Chute
Load Cell Arms
WARNING
NEVER REMOVE THE ALUMINUM LOAD CELL ARMS FROM YOUR UNIT! DOING SO CAN CAUSE
SERIOUS DAMAGE TO YOUR UNIT.
5. Clean the cabinet by brushing away crumbs with a basting brush, then wiping down all exposed surfaces
with a soft cloth dampened with a solution of McDonald’s All Purpose Cleaner (HCS).
6. Clean the hopper and associated components by removing the hopper from the unit, disassembling the
components, and washing all components with a solution of McDonald’s All Purpose Cleaner (HCS).
Rinse with clean water and dry thoroughly.
7. Clean the dispense chute, basket locator rack, crumb pan, and basket rack by washing them with a solu-
tion of McDonald’s All Purpose Cleaner (HCS). Rinse with clean water and dry thoroughly.
DANGER!
Do not use a water jet to clean this appliance. The hopper, deflector, crumb pan, basket locator rack,
dispense chute, and basket rack may be cleaned with a water jet ONLY if removed from the unit.

3-2
CAUTION
When replacing the dispensing chute, ensure that the door hinge screws are to the right as you face
the unit.
3.2 Operator Troubleshooting
The operator troubleshooting guides that follow are intended to help operators resolve routine problems that
may be encountered during operation of the unit.
PROBLEM Probable Causes Corrective Action
A. ON/OFF rocker switch is in OFF
position.
A. Place rocker switch in the ON
position.
B. Unit is not plugged in. B. Plug unit in.
C. Main circuit breaker is tripped. C. Reset circuit breaker.
UNIT WILL NOT
POWER UP or
NOTHING HAPPENS
WHEN “RUN” MODE
IS SELECTED. If the problem is not corrected by one of the above actions, call FASC.
A. Dispensing chute is not properly
positioned on the load cell arms.
A. Reposition dispensing chute so that
is firmly seated on the load cell
arms. Turn the unit OFF then back
ON using the ON/OFF rocker
switch. Press the RUN switch
RUN SWITCH
INDICATOR AND
PROGRAM SWITCH
INDICATOR ARE
FLASHING. Simultaneous flashing of the run switch indicator and program switch indicator
signals that the unit is not properly zeroed. If the problem is not corrected by the
above action, call FASC.
A. Dispensing chute is full. A. If the dispense chute has been
loaded but not dispensed, nothing
will happen until the batch has been
dispensed, except when the batch
weight is increased. Insert a basket
into the dispensing well to dispense
batch.
B. Unit is not in RUN mode. B. Press RUN switch once.
NOTHING HAPPENS
WHEN A BATCH
SIZE SELECTOR IS
PRESSED.
If one of the above actions did not correct the problem, call FASC.
A. The load cell may not have been
satisfied within 30 seconds, normally
because the hopper is empty or the
fries have “bridged”.
A. Check the hopper to verify that the
deflector is properly positioned. If
there are fries in the hopper, verify
that there is no bridging. If the
hopper is empty, reload the hopper.
Press the PROGRAM switch once
to place the unit back into opera-
tion.
DISPENSE DOOR
DOES NOT OPEN
WHEN BASKET IS
INSERTED.
If the above action did not correct the problem, call FASC.
ERRATIC BATCH
WEIGHTS ARE
BEING DISPENSED.
A. If the erratic batch weights are
occurring only occasionally, the
probable cause is bumping, jarring,
and/or unusual vibration (such as
caused by inserting a basket with
undue force, the slamming of a freezer
door, or the passing of a nearby train).
A. Exercise care when working around
the unit to avoid bumping or jarring
it while it is in operation. Ensuring
that the unit is not touching
adjacent walls, and placing the unit
on a rubber mat will reduce the
effect of environmental vibrations.

3-3
PROBLEM Probable Causes Corrective Action
B. If the erratic batch weights are
occurring consistently, the probable
cause is a misaligned component.
B. Verify that the dispensing chute is
properly positioned on the load cell
arms, that the deflector is properly
positioned in the hopper, and that
the hopper is fully seated behind
the locking rim on the cradle
assembly.
Continued from
previous page.
If one of the above actions does not correct the problem, there may be a problem
with the programmed weight settings or the load cell. Call FASC.
A. Unit was not in STANDBY mode
when attempt was made to enter
CLEAN mode.
A. The CLEAN mode can only be
selected when the unit is in the
STANDBY mode.
Press the RUN Switch once to
place the unit in the STANDBY
mode, and then press the CLEAN
Switch.
UNIT WILL NOT GO
INTO CLEAN MODE.
If the above action did not correct the problem, call FASC.
