FilterQuick™FQG60T easyTouch®
Gas Fryer
Service Manual
This manual is updated as new information and models are released. Visit our website for the latest manual.
Part Number: FRY_SM_8197919 09/2020
*8197919*
Your Growth Is Our Goal
FOR YOUR SAFETY
Do Not Store or use gasoline or other
flammable vapors and liquids in the vicinity
of this or any other appliance.

NOTICE
IF, DURING THE WARRANTY PERIOD, THE CUSTOMER USES A PART FOR THIS FRYMASTER EQUIPMENT
OTHER THAN AN UNMODIFIED NEW OR RECYCLED PART PURCHASED DIRECTLY FROM FRYMASTER, OR
ANY OF ITS FACTORY AUTHORIZED SERVICERS, AND/OR THE PART BEING USED IS MODIFIED FROM ITS
ORIGINAL CONFIGURATION, THIS WARRANTY WILL BE VOID. FURTHER, FRYMASTER AND ITS
AFFILIATES WILL NOT BE LIABLE FOR ANY CLAIMS, DAMAGES OR EXPENSES INCURRED BY THE
CUSTOMER WHICH ARISE DIRECTLY OR INDIRECTLY, IN WHOLE OR IN PART, DUE TO THE
INSTALLATION OF ANY MODIFIED PART AND/OR PART RECEIVED FROM AN UNAUTHORIZED SERVICER.
NOTICE
This appliance is intended for professional use only and is to be operated by qualified personnel
only. A Frymaster Authorized Servicer (FAS) or other qualified professional should perform
installation, maintenance, and repairs. Installation, maintenance, or repairs by unqualified
personnel may void the manufacturer’s warranty. See Chapter 1 of the Installation and Operation
manual for definitions of qualified personnel.
WARNING
After installation of a gas fryer and after any maintenance to the gas system of a gas fryer-manifold,
valve, burners, etc. – check for gas leaks at all connections. Apply a thick soapy solution to all
connections and ensure there are no bubbles. There should be no smell of gas.
DANGER
Improper installation, adjustment, maintenance or service, and unauthorized alterations or
modifications can cause property damage, injury, or death. Read the installation, operating, and
service instructions thoroughly before installing or servicing this equipment.
DANGER
Adequate means must be provided to limit the movement of this appliance without depending upon
the gas line connection. All fryers equipped with casters must be stabilized by installing restraining
chains. If a flexible gas line is used, an additional restraining cable must be connected at all times
when the fryer is in use.
DANGER
The front ledge of this appliance is not a step! Do not stand on the appliance. Serious injury can
result from slips or contact with the hot oil.
DANGER
Do not store or use gasoline or other flammable liquids or vapors in the vicinity of this or any other
appliance.
WARNING
Use caution and wear appropriate safety equipment to avoid contact with hot oil or surfaces that
may cause severe burns or injury.
DANGER
Keep all items out of drains. Closing actuators may cause damage or injury.

iii
FQG60T easyTouch® FILTERQUICK™SERIES GAS FRYERS
SERVICE MANUAL
TABLE OF CONTENTS
Chapter 1: Service Procedures
1.1 FQ4000 Menu Summary Trees ......................................................................................................... 1-1
1.1.1 FQ4000 Menu Tree General Market....................................................................................... 1-1
1.1.2 FQ4000 Information Statistics Menu Tree General Market ................................................ 1-2
1.2 FQ4000 Password Codes................................................................................................................... 1-3
1.3 Service Required Errors ..................................................................................................................... 1-3
1.4 Error Log Codes .................................................................................................................................. 1-3
1.5 Component Check.............................................................................................................................. 1-5
1.6 Reading the Model Numbers............................................................................................................ 1-6
1.7 Functional Description....................................................................................................................... 1-6
1.8 Ignition System ................................................................................................................................... 1-6
1.9 Thermostats ........................................................................................................................................ 1-7
1.10 Smart Interface Board (SIB)............................................................................................................... 1-8
1.10.1 Current Flow Through the SIB Board.............................................................................. 1-9
1.10.2 Frequently Used Test Points for SIB.............................................................................. 1-10
1.10.3 SIB (Smart Interface Board) Troubleshooting.............................................................. 1-10
1.10.4 SIB (Smart Interface Board) Pin Positions and Harnesses......................................... 1-11
1.11 Accessing Fryers for Servicing......................................................................................................... 1-12
1.12 Cleaning the Gas Valve Vent Tube.................................................................................................. 1-12
1.13 Checking the Burner Manifold Gas Pressure................................................................................ 1-12
1.14 Adjusting the Pilot Flame................................................................................................................. 1-13
1.15 Replacing Fryer Components.......................................................................................................... 1-13
1.15.1 Replacing the Controller................................................................................................. 1-13
1.15.2 Replacing the SIB, FIB, Time Delay Relay Board, KCCM Board or Ignition Module 1-14
1.15.3 Overview of Vat Components ....................................................................................... 1-15
1.15.4 Replacing the Temperature Probe................................................................................ 1-15
1.15.5 Replacing the High-Limit Probe ..................................................................................... 1-16
1.15.6 Replacing the Float Switch.............................................................................................. 1-16
1.15.7 Replacing the ATO Probe................................................................................................ 1-17
1.15.8 Replacing the VIB Probe ................................................................................................. 1-17
1.15.9 Replacing a Gas Valve ..................................................................................................... 1-18
1.15.10 Replacing a Pilot Assembly or Trailing Pilot Assembly ............................................... 1-18
1.15.11 Adjusting the Ignitor Assembly...................................................................................... 1-19
1.15.12 Replacing the Filter Motor or Filter Pump.................................................................... 1-19
1.15.13 Replacing the Frypot ....................................................................................................... 1-19
1.15.14 Replacing Transformers/Pump Relay/Reset Switch Relay/Power Supply/Frypot... 1-21
1.16Troubleshooting and Problem Isolation ......................................................................................... 1-21
1.16.1 Heating (Ignition) Failure ................................................................................................ 1-22
1.16.2 Improper Burner Function ............................................................................................. 1-23
1.16.3 Improper Temperature Control .................................................................................... 1-24
1.16.4 Controller Malfunctions.................................................................................................. 1-24
1.16.5 Filtration Malfunctions.................................................................................................... 1-24
1.16.6 Leakage............................................................................................................................. 1-25
1.17 Troubleshooting Guides .................................................................................................................. 1-26
1.17.1 Troubleshooting the 24 VAC Circuit.............................................................................. 1-26
1.17.2 Troubleshooting the Gas Valve...................................................................................... 1-27

ii
1.17.3 Troubleshooting the Temperature Probe.................................................................... 1-27
1.17.4 Replacing the Reset Switch Relay.................................................................................. 1-27
1.18 Probe Resistance Chart ................................................................................................................... 1-28
1.19 ATO (Automatic Top-Off)/Manual Top-Off and Filtration Service Procedures......................... 1-28
1.19.1 ATO (Automatic Top-Off Troubleshooting) .................................................................. 1-28
1.19.2 Filtration Troubleshooting ............................................................................................. 1-31
1.19.3 Control and Transformer Box Connections................................................................. 1-32
1.19.3.1 Control Box Connections............................................................................ 1-32
1.19.3.2 15-pin Control Box Connection Test Points (C6) ..................................... 1-33
1.19.3.3Transformer Box Connections................................................................... 1-33
1.19.4 FIB (Filter Interface Board) Filtration Top-off Pin Positions and Harnesses ............ 1-35
1.19.5 Replacing FIB Board, Power Supply, Filter Relay or Transformer............................. 1-36
1.19.5.1 FIB (Filter Interface Board) LED’s and Test Points ................................... 1-36
1.19.6 Replacing the ATO Pump or Solenoid .......................................................................... 1-36
1.20 FIB (Filter Interface Board) Service Procedures............................................................................ 1-37
1.20.1 Manually Draining, Refilling, Filtering or Topping off - Manual Filtration Mode .... 1-37
1.20.2 Control Power Reset Switch........................................................................................... 1-37
1.21 Bulk Oil Service Issues ..................................................................................................................... 1-38
1.21.1 Bulk FIB Tests................................................................................................................... 1-38
1.21.2 Bulk Oil Wiring Connection Behind Fryer..................................................................... 1-39
1.21.3 Frymaster FQ-T Fryer and Bulk Oil System Plumbing Schematic ............................. 1-39
1.21.4 Bulk Test Quick Reference ............................................................................................. 1-40
1.21.4.1 Dispose to Waste, Refill Vat from Bulk ..................................................... 1-40
1.21.4.2 Dispose to Waste......................................................................................... 1-40
1.21.4.3 Fill Vat from Bulk.......................................................................................... 1-41
1.21.4.4 Fill Oil Reservoir from Bulk......................................................................... 1-41
1.21.5 Troubleshooting Oil Reservoir Filling ............................................................................ 1-41
1.22 VIB (Valve Interface Board) Service Procedures........................................................................... 1-42
1.22.1 VIB (Valve Interface Board) Troubleshooting .............................................................. 1-43
1.22.2 VIB (Valve Interface Board) Pin Positions and Harnesses.......................................... 1-44
1.22.3 Replacing a VIB (Valve Interface Board) Board............................................................ 1-45
1.22.4 Replacing a Rotary Actuator........................................................................................... 1-45
1.22.5 Float Switch ...................................................................................................................... 1-45
1.22.5.1 Float Switch Troubleshooting .................................................................... 1-46
1.22.5.2 Float Switch Time Delay Relay Wiring Diagram ....................................... 1-46
1.23 FQ4000 Controller Service Procedures ......................................................................................... 1-47
1.23.1 FQ4000 Controller Troubleshooting .............................................................................. 1-47
1.23.1.1 FQ4000 Controller Functional Troubleshooting...................................... 1-49
1.24 Loading and Updating Software Procedures ............................................................................... 1-50
1.25 Updating Menu Files ........................................................................................................................ 1-51
1.25.1 Software/Menu Update Troubleshooting ..................................................................... 1-52
1.26 Wiring Diagram................................................................................................................................. 1-53

1-1
FQG60T easyTouch®SERIES FILTERQUICK GAS FRYERS
CHAPTER 1: SERVICE PROCEDURES
1.1 FQ4000 easyTouch®Menu Summary Trees
1.1.1 FQ4000 easyTouch®Menu Tree General Market
Reflected below are the major programming sections in the FQ4000 easyTouch®and the order in which the headings will be
found in the controller.
Filtration Menu
Quick Filter
Clean and Filter (with OQS)
Dispose
Advanced Filter Options
Service
OQS-Filter
Fill Vat from Pan
Fill Vat from Bulk (Bulk Only)
Pan to Waste (Bulk Only)
Drainto Pan
Clean
Polish
Manager (1656)
E-Log
Passcode Setup
USB Menu Operation
Copy Menu from USB to Fryer
Service (3000)
Manual Filtration
Resets
Password Reset
Tech Modes
Crew Hi-Limit Test
Toggle toSelect
F° to C°/ C° to F° (Toggles Temperature Scale)
Filter Pad Time Setup
Clear Statistics
Filter Stats Data
E-Log (Clears E-Log Errors)
Software Upgrade
Vat Tuning (Engineering only)
Component Check (9000)
FIB Reset 1
FIB Reset 2
Blower
Factory Menu (Resets Product Recipes)
Bad CRC (Resets Alert)
Recovery Fault Call Service (Resets Alert)
Reset Factory Defaults (Resets to Factory Default)
Reset Report Card (Resets Report Card)
Reset TPM Value
Reset OQS Sensor
DemoMode
Home Button
Crew Mode(Cooking Mode)
Menus (1650)
Create New
Settings
Manager (1656)
Language
Primary
Secondary
Date& Time
F° to C°/ C° to F° (Toggles Temperature Scale)
Sound
Volume
Tone
Filter Attributes
Energy Savings (Enabled, Temperature, Time)
Lane Assignments (# of Product Buttons)
Brightness
Service (3000)
Locale (CE / Non-CE)
Energy Type (Gas /Electric)
Vat Type
Oil System Type (JIB / Bulk)
Auto Top OffVat (On / Off)
ATO Delay Time
ATO Type (Auto, Push Button, Both)
OQS Setup
OQS Type
Basic Auto Filter (Enable/Disable)
Screen Saver
Alarm Attributes
Shake Alarm Mode (Auto / Manual)
Hold Alarm Mode (Auto / Manual)
Alarm Timer (Shake Timer / Hold Timer)
Temperature (Enable/Disable)
Basket Lift (On/Off)
Oil Dragout
AIF/ATO Temp Display(Enable/Disable)
Menu Book (Enable/Disable)
Low Temp Alarm (Enable/Disable)
Sediment Tray (Enable/Disable)
Initial Delay Time
Skipped Filter Type
Filter Prompt
Filter After Time (Hours)
Filter After Cook
Filter Lockout (Enable/Disable)
Skipped Filter Count
Quick Filter Settings
Filter Off Time (On/Off)
Filter Off Settings
Clean (Cold/Hot)
Auto Menu Change
Fryer Type
Filtration Time Settings
Skipped Cook Count
Skipped Percentage
Skipped Delay Time
Waste Oil (Disposal Unit/Bulk/Wand Frt/Wand Ext.)
Recipes (1650)
Product Name
Temp
Cook Time
Sensitivity
Shake 1
Shake 2
Filter On/Off
Hold Timer
Instant On
Filter Count
Clean Screen
Oil Type (Oil Curve)
Display Type (Number/Text)
Discard Now(TPMValue)
Discard Soon (TPM OffsetValue)
Dispose Delay Timer
AdvanceNotice Change Oil
No OQS (Disabled)
Fryer OQS (Enabled)
Predictive OQS (Fryer and Virtual)
Virtual OQS

1-2
1.1.2 FQ4000 Information Statistics Menu Tree General Market
Reflected below are the information statistics in the FQ4000 and the order in which the headings will be found in the controller.
Information Statistics
Report Card
1. Today’s Report
2. Yesterday’s Report
3. Weekly Report
Life 1. Commission Date
2. Unit Serial Number
3. Controller Serial Number
4. Total On Time (Hours)
5. Total Heat Cycle Count
6. Total Energy Saving Time
7. Total Cook Time
Usage
1. Usage Start Date
2. Total Number of Cook Cycles
3. Total Number of Quit Cook Cycles
4. Total Vat On Time (Hours)
Recovery
1. Last Recovery Time
Last Load
1. Last Cooked Product
2. Last Load Start Time
3. Last Load Cook Time
4. Last Load Program Time
5. Last Load Max Vat Temp
6. Last Load Min Vat Temp
7. Last Load Avg Vat Temp
8. % of Cook Time, Heat Is On
9. Vat Temp Before Cook Starts
10. Vat Temp at Cook End
Software Version
1. UIB Software Version
2. SIB Software Version (1, 2 – Splits)
3. VIB Software Version
4. FIB Software Version
5. OQS Software Version
6. Actual Vat Temp (L, R – Splits)
7. AIF RTD Temp (L, R – Splits)
8. ATO RTD Temp (L, R – Splits)
9. Board ID
10. Gateway Software Version
11. Gateway IP Address
12. Gateway Link Quality
13. Gateway Signal Strength and Noise
Usage Reset (Resets Usage Data 1656)
Fresh Oil
1. Number of Cooks Since Last Dispose
2. Dispose Count Since Last Reset
3. Fresh Oil Counter Reset Date
4. Fresh Oil Counter
Fresh Oil Reset (Resets Fresh Oil Data 1656)
Filter 1. Current Day and Date
2. Cooks Remaining Until Next Filter
3. Daily Number of Cooks
4. Daily Number of Filters
5. Daily Number of Skipped Filters
6. Average Cooks Per Filter
7. Weekly Number of Filters
8. Weekly Number of Skipped Filters
9. Filtration
TPM Statistics
Oil 1. Last Dispose Date
2. Cooks Since Last Dispose
3. Filters Since Last Dispose
4. Skipped Filters Since Last Dispose
5. Current Oil Life
6. Average Cooks Over Oil Life
7. Daily Dispose Bypass Count
8. Oil Dragout per Dispose
9. Oil Dragout per Day
10. Oil Dragout per Hour
Filter Reset (Resets Filter Stats Data 1656)

1-3
1.2 FQ4000 Password Codes
Press the HOME button to enter MENUS, RECIPES, SETTINGS or SERVICE menus.
•1650 – MENUS, RECIPES,
•1656 – SETTINGS (MANAGER), SERVICE (MANAGER)
•3000 – SETTINGS (SERVICE), SERVICE (SERVICE) Enter Tech Mode
•9000 – Component Check [SETTINGS (SERVICE), SERVICE (SERVICE) Enter Tech Mode]
The following code is entered when prompted to do so.
•1111 – Reset SERVICE REQUIRED Message – Enter when the issue is fixed and prompted to enter code.
1.3 Service Required Errors
A SERVICE REQUIRED error with a description of the error displays on the controller. After YES is pressed the alarm
is silenced. The controller displays an error message from the list below three times with the location of the error.
Then the controller displays SYSTEM ERROR FIXED? YES/NO. If yes is chosen, enter code 1111. If NO is chosen, the
system returns to cook mode if possible, for 15 minutes, then redisplays error until issue is fixed.
1.4 Error Log Codes
To access the error log, press the home button. Press the service button. Press the manager button. Enter 1656
and press the check button. Press the E-log button. The ten most recent errors are listed from top to bottom, with
the top error being the most recent error. A “G” indicates a global error such as a filtration error. Side specific
errors in split vats are indicated by L for left or R for right. Pressing the left down arrow allows scrolling through the
errors. If no errors are present the screen will be blank.
Code
ERROR MESSAGE
EXPLANATION
E13
TEMPERATURE PROBE FAILURE
TEMP Probe reading out of range
E16
HIGH LIMIT 1 EXCEEDED High limit temperature is past more than 410°F (210°C), or in
CE countries, 395°F (202°C)
E17
HIGH LIMIT 2 EXCEEDED
High limit switch has opened.
E18
HIGH LIMIT PROBLEM
DISCONNECT POWER
Vat temperature exceeds 460°F (238°C) and the high limit has
failed to open. Immediately disconnect power to the fryer
and call service.
E19
HEATING FAILURE – XXX F or XXX C
Heating Control latch circuit failed.
Heat Contactor failed to latch.
E25
HEATING FAILURE - BLOWER
The air pressure switch(s) failed to close.
E27
HEATING FAILURE - PRESSURE SWITCH - CALL SERVICE
The air pressure switch has failed closed.
E28
HEATING FAILURE – XXX F or XXX C
The fryer has failed to ignite and has locked out the ignition
module.
E29
TOP OFF PROBE FAILURE - CALL SERVICE
ATO RTD reading out of range
E32
DRAIN VALVE NOT OPEN - FILTRATION AND TOP OFF
DISABLED - CALL SERVICE
Drain valve was trying to open and confirmation is missing
E33
DRAIN VALVE NOT CLOSED - FILTRATION AND TOP OFF
DISABLED - CALL SERVICE
Drain valve was trying to close and confirmation is missing
E34
RETURN VALVE NOT OPEN - FILTRATION AND TOP OFF
DISABLED - CALL SERVICE
Return valve was trying to open and confirmation is missing
E35
RETURN VALVE NOT CLOSED - FILTRATION AND TOP OFF
DISABLED - CALL SERVICE
Return valve was trying to close and confirmation is missing
E36
VALVE INTERFACE BOARD FAILURE - FILTRATION AND
TOP OFF DISABLED - CALL SERVICE
Valve Interface Board connections lost or board failure.
E37
AUTOMATIC INTERMITTENT FILTRATION PROBE FAILURE
- FILTRATION DISABLED - CALL SERVICE
AIF (VIB Probe) RTD reading out of range.
E39
CHANGE FILTER PAD
25-hour timer has expired, or dirty filter logic has activated.
E41
OIL IN PAN ERROR
The system detects that oil may be present in the filter pan.
E42
CLOGGED DRAIN (Gas)
Vat did not empty during filtration
E43
OIL SENSOR FAILURE - CALL SERVICE
Oil level sensor may have failed.
E44
RECOVERY FAULT
Recovery time exceeded maximum time limit.
E45
RECOVERY FAULT – CALL SERVICE
Recovery time exceeded maximum time limit for two or more
cycles. Reset the error code by going to: HOME -> SERVICE
-> SERVICE ->3000-> TECH MODE -> RESETS -> RECOVERY
FAULT CALL SERVICE -> YES.

1-4
Code
ERROR MESSAGE
EXPLANATION
E46
SYSTEM INTERFACE BOARD 1 MISSING - CALL SERVICE
SIB board 1 connection lost or board failure.
E51
DUPLICATE BOARD ID - CALL SERVICE
Two or more controllers have the same location ID.
E52
USER INTERFACE CONTROLLER ERROR - CALL SERVICE
The controller has an unknown error.
E53
CAN BUS ERROR - CALL SERVICE
Communications are lost between boards.
E55
SYSTEM INTERFACE BOARD 2 MISSING - CALL SERVICE
SIB board 2 connection lost or board failure.
E62
SLOW HEATING FAILURE XXXF OR XXXC - CHECK ENERGY
SOURCE - CALL SERVICE
The vat is not heating properly.
E63
RATE OF RISE
Rate of rise error occurred during a recovery test.
E64
FILTRATION INTERFACE BOARD FAILURE - FILTRATION
AND TOP OFF DISABLED - CALL SERVICE
Filtration Interface Board connections lost or board failure.
E65
E65
The float switch does not detect oil.
1. Ensure the frypot is full of oil.
2. Float switch may be stuck up or down.
3. Clean the float switch.
Ensure when removing the float switch that its position is
clearly marked and replaced properly. Installing the float
upside down will change the switch from N/O to N/C. This
could allow the empty frypot to ignite. Ensure the float switch
moves freely up and down.
E66
DRAIN VALVE OPEN – XXXF OR XXXC
Drain valve is opened during cooking.
E67
SYSTEM INTERFACE BOARD NOT CONFIGURED - CALL
SERVICE
Controller is turned on when the SIB board is not configured.
E68
FUSE TRIPPED – CALL SERVICE
The VIB board fuse has tripped and didn’t reset.
E69
RECIPES NOT AVAILABLE
The controller has not been programmed with product
recipes. Replace controller with factory programmed
controller.
E70
OQS TEMP HIGH
Oil temperature is too high for a valid OQS reading. Filter at a
temperature between 300ºF (149ºC) and 375ºF (191ºC).
E71
OQS TEMP LOW
Oil temperature is too low for a valid OQS reading. Filter at a
temperature between 300ºF (149ºC) and 375ºF (191ºC).
E72
TPM RANGE LOW
The TPM is too low for a valid OQS reading. This may also be
seen with fr
esh new oil. The incorrect oil type may be
selected in the setup menu. The sensor may not be calibrated
for the oil type. See oil type chart in instruction document
8197316. If issue continues contact an FAS.
E73
TPM RANGE HIGH
The TPM reading is too high for a valid OQS reading. Dispose
the oil.
E74
OQS ERROR
The OQS has an internal error. If issue continues contact an
FAS.
E75
OQS AIR ERROR
The OQS is detecting air in the oil. Check the O-rings and
check/tighten prescreen filter to ensure no air is entering the
OQS sensor. If issue continues contact an FAS.
E76
OQS ERROR
The OQS sensor has a communication error. Check
connections to the OQS sensor. Power cycle the entire fryer
battery. If issue continues contact an FAS.

1-5
1.5Component Check
The FQ4000 controller has a function to check the major components and their status.
With the controller soft powered OFF, press the HOME button. Select Service, Service, Enter 9000, Select Tech
Modes, scroll down and select Component Check.
The component name is above each button. The status of the component is below the function. Pressing the
button will change the status of the function to what is stated on the button. If the button is shaded that function is
not available unless that function is enabled (such as bulk). The JIB reset button and Waste Tank full only displays
the status of the switch.
Pressing the home button to exit
the function will display driving
valves to ensure all valves return
to home state. Once completed
the controller will display FILL VAT
FROM DRAIN PAN? YES NO.
Press YES to ensure that any oil in
the filter pan is returned to the
vat.

1-6
1.6 Reading Model Numbers
1FQG60U0ZQTZZNG
Number
of vats
Model
Family Energy
Type1
Touch
Screen
Controller
Spreader5
1 = E-Electric, G-Gas
2 = 30, 40, 50, 60lb frypot capacity
3 = U-Open Fryer, T-Tube Fryer
4 = L-Left Side, R-Right Side, M-Middle, X-Mixed Positions, Z-All or
None if # of Split Vats = 0
5 = S-Spreader; Z-none
6 = B-Basket Lift; Z-none
7 = kW 14,17,22 or NG-Natural Gas, PG-Propane Gas, BG-Butane
Gas, LG-LP Mix Gas
Basketlift6
Quick
Filtration
Fryer
Vat
Capacity2
Fryer
Type3
kW or Gas
Type7
# of
Splits
Position
of
Splits4
1.7 Functional Description
FQG60T Series gas fryers contain a welded stainless steel frypot heated by gas flames diffused evenly through tubes
built into the frypot.
Flames originate from orifices in a burner manifold positioned beneath cast-steel burners. The burners are
positioned in the tube openings at the front of the frypot. The diameter of the orifices differs for natural and LP gas
as indicated in the accompanying table.
GAS INFORMATION (Altitudes of 2000 feet or less)
MODEL INPUT
(BTU)
GAS
TYPE
ORIFICE
MM
(INCH)
ORIFICE
PART NO. QTY
EQUIPMENT
PRESSURE
MBAR
INCH
W.C.
FQG60T 119,000 NAT
LP
2.26(#43)
1.40(#54)
8102938
8102939
5
5
10
27.5
4
11
An electromechanical gas valve regulates gas flow to the manifold. FQG60T series gas fryers are equipped with a
24V ignition system.
1.8 Ignition System
The ignition module located inside the control box performs three important functions: It provides an ignition spark,
supplies voltage to the gas valve, and proofs the pilot flame.
The module contains a 90-second time delay circuit and a coil that activates the gas valve. The ignitor assembly
consists of a spark plug, a pilot, and a flame sensor element.
At start-up, the power switch on the touchscreen controller is placed in the ON position, supplying approximately 24
VAC to the heat-control circuitry in the Smart Interface Board and to one side of the heat relay coils on the Smart
Interface Board. If the resistance in the temperature probe indicates the temperature in the frypot is below 180ºF

1-7
(82ºC), the melt cycle function is activated where a timer activates for six seconds and deactivates for 24 seconds. If
the temperature is 180ºF (82ºC) or above, the melt cycle is bypassed. In either case, ground is supplied to the other
leg of the heat relay coils, which closes electronic switches in the 24 VAC circuit to provide current to the ignition
module. Circuitry in the ignition module sends 24 VAC current to the gas valve via a normally closed high-limit
switch and a float safety switch. Simultaneously, the module causes the ignitor to spark for up to 90 seconds to
light the pilot flame. A flame sensor verifies that the pilot is lit by measuring the flow of microamps through the
flame. If the pilot does not light (or is extinguished), current to the ignition module is interrupted, preventing the
main valve from opening, and the ignition module "locks out" until the power switch is turned OFF, then back ON. A
probe monitors the temperature in the frypot. When the programmed setpoint temperature is reached, resistance
in the probe causes the heat cycle circuitry in the SIB board to cut off current flow through the heat relay. This in
turn cuts off the 24 VAC to the ignition module, causing the gas valve to close.
NOTE: Microamp readings on these black modules will move up and down as the module pulses on and off and
this is an indication that the module is functioning.
1.9 Thermostats
A temperature probe monitors the temperature in the frypot. The probe resistance varies directly with the
temperature. As the temperature rises, resistance increases at a rate of approximately 2 ohms for every 1°F
(approximately 3.7 ohms for every 1°C). When the programmed setpoint temperature is reached, resistance in the
probe causes the heat cycle circuitry in the controller to interrupt current flow through the heat relay. This in turn
interrupts the 24 VAC current to the ignition module, resulting in closure of the gas valve.
Circuitry in the controller monitors the probe resistance and controls burner firing when the resistance exceeds or
falls below the programmed temperature or setpoint.
The fryers are also equipped with a high-limit thermostat. If the fryer fails to properly control the oil temperature,
the high-limit thermostat prevents the fryer from overheating to the flash point. The high-limit thermostat acts as a
normally closed power switch that opens when exposed to temperatures above 425ºF to 450ºF (218ºC to 232ºC).

1-8
1.10 Smart Interface Board (SIB)
All fryers in this series have a smart interface board (SIB)
located in the component box behind the controller panel.
The SIB board provides a link between the controller and
the fryer’s individual components without requiring
excessive wiring and executes commands from one
central point.
K2 is a single-pole-double throw (SPDT) relay that supplies
24VAC to the ignition and gas valve circuits.The relays on
this board are soldered to the board. If a relay fails, the board must be replaced. K1 is a single-pole-double throw
(SPDT) relay that supplies voltage through the high limit and the optional air pressure switch.
The SIB LEDs (labeled LED1 through LED7) are arrayed around the board to assist in troubleshooting.
The chart on pages 1-9 illustrates current flow through the board, and the table at the top of page 1-10 identifies
frequently used test points.
NOTE: Refer to Section 1.17.1 for troubleshooting flowchart.
SMART INTERFACE BOARD LED
DIAGNOSTIC LIGHTS
LED 1
24VAC Heat Relay
LED 2
12VDC to Controller
LED 3
24VAC Latch Relay
LED 4
5VDC to probes and switches
LED 6
3.3VDC to Micro Processor
LED 7
Communication to/from Micro Processor
Smart Interface (SIB)
Board
12VDC
Green
LED
LED 2 12VDC
Test
Point
5VDC
Test
Point
J1 K2
K1
J2
J10 J9 J6 J8 J7
UI Interface C-Bus C-Bus P-Bus
Ignition
Module
Control
Heat Relay
Latch Relay
P-Bus
1
20
1
1
1
24
8075729
Cook
Probe
ATO
Probe
Red
Comm.
LED
LED 7
5VDC
Green
LED
LED 4
2
2
1 6 1 6 1 8 1 4 1 4
3.3VDC
Green
LED
LED 6 3.3VDC
Test
Point
1
2
3
1
2
Latch Relay
Blue
LED
LED 3
Heat Relay
Blue
LED
LED 1
1 2 3
Ground
Test
Point
J3
J11
12VDC should be lit and bright at all times.
If LED is dim then something is pulling
voltage down. Short to ground on 12VDC
circuit will cause dim LED.
5VDC should be lit and bright at all
times. If LED is dim then something is
pulling voltage down. Short to ground
on 5VDC circuit will cause dim LED.
When UI is soft
powered on this
Latch Relay LED
will come on first
confirming high
limit is closed.
The blower will
then come on
and prove the air
switch. The relay
is a true latch
circuit and when
broken or turned
off the heat relay
will also turn off.
When UI calls for HEAT this LED will
come on with the heat relay only after
latch relay has been latched in and
AIR switch has been proven. This LED
will cycle with the call for heat.
Blinking red LED, (Heartbeat). This
LED should be blinking and bright
at all times when board is
powered. The other green LED’s
being dim or off will cause this
LED to be off.
3.3VDC LED should be lit and
bright at all times. If dim, then
something is pulling voltage
down. Short to
ground on
3.3VDC circuit will cause dim
LED.

1-9
1.10.1 Current Flow Through the SIB board
J1
GND
J2
HEAT 24VAC OUT
MODULE ALARM 24VAC
GAS/PILOT 24VAC
S-T-P POWER OUT 24VAC
MAIN VALVE IN 24VAC
HIGH
LIMIT 2
3 4 5 6 7 8 9
10 11 12
1 3 4 5 6 7
10 11 12 14 15
17
20
HEAT
RELAY
LATCH
CIRCUIT
SENSORS
SPARK TO PILOT IGNITION
MODULE SYSTEM
IGNITION
MODULE
GND
PV1
TH/W
MV1
SPARK
2
14 16 17 18
20
HIGH LIMIT 24VAC HIGH LIMIT RETURN 24VAC
GAS VALVE
COM
PV
MV
8 1
2
3
7
6
54
C
NO
NC
TIME DELAY
RELAY BOARD
NC
V2
S1
FLOAT
SWITCH
VIB J1 PIN 9 24VDC +
VIB J1 PIN 10 24VDC -
SMART
INTERFACE
BOARD
(SIB)
24VAC 1
24

1-10
1.10.2 Frequently Used Test Points for SIB (Smart Interface Board)
NOTE: DO NOT CHECK WITH HARNESSES UNPLUGGED AS SHORTING THE PINS MAY OCCUR WHICH WILL DAMAGE THE
BOARD.
FREQUENTLY USED TEST POINTS FOR INTERFACE BOARD 1085980
Test
Meter
Pins
Results
Setting
24VAC Power to SIB
50VAC Scale
1 on J1 and GROUND
22-28
12VDC Power to Controller 50VDC Scale 7 and 8 on J6 12-18
24VAC Power to Module
50VAC Scale
5 on J2 and GROUND
22-28
24VAC Power to High-Limit
50VAC Scale
3 on J1 and GROUND
22-28
Probe Resistance
R x 1000 OHMS
Disconnect and test across probe leads
**
Probe Isolation R x 1000 OHMS 2 on Probe Connector and GROUND ***
High-Limit Continuity
R x 1 OHM
3 on J1 and 4 on J1
0
** See Probe Resistance Chart in section 1.18.
*** 5 mega-Ohms or greater.
1.10.3 SIB (Smart Interface Board) Troubleshooting
Problem
Probable Causes
Corrective Action
No power to SIB board
A. J1 connection unplugged
B. Fuse blown.
C. Transformer malfunction
A. Check to ensure J1 on front of SIB board is
fully locked into connector.
B. Ensure fuse located at the bottom of the
control box is not blown and cap is securely
tightened.
C. Check that proper voltage is present at
transformer. See table in section 1.10.4.
SIB BOARD 1 MISSING
displayed on the
controller.
Loose wire connection. Ensure the connector is securely attached to plug
J6 on the SIB board.
SIB NOT CONFIGURED
displayed on the
controller.
SIB board not configured Replace the SIB board.
Green LED’s on SIB board
are blinking or dim.
Damaged harness between J2 on the VIB board to
J9 on the SIB board.
Inspect for heat damage and routing of harness
close to the frypot. If damaged replace harness
(8075555).

1-11
1.10.4 SIB (Smart Interface Board) Pin Positions and Harnesses
NOTE: DO NOT CHECK WITH HARNESSES UNPLUGGED (except ATO and Temp Probes) AS SHORTING THE PINS MAY OCCUR WHICH WILL DAMAGE THE
BOARD.
Connector
From/To
Harness #
Pin
#
Function
Voltage
Wire Color
J1
From Transformer
8076408
1
24VAC Input
24VAC
Orange
2
Ground -
Blue
To High Limit
3
24VAC Out
24VAC
Orange
From High Limit
4
24VAC Input
24VAC
Blue
J2
To 24VAC Gas Valve
8076408
1
24VAC Out
24VAC
Orange
2
Ground
From Ignition Module NC
3
Alarm In
24VAC
Yellow
From Module / Gas Valve PV1
4
24VAC Input
24VAC
Orange
To 24VAC Time Delay Relay Board
/Ignition Module
5
24VAC Out
24VAC Red
From Ignition Module MV1
6
2VAC Input
24VAC
Orange
J3 ATO Probe 8263286
1
Ground
Yellow
2
RTD
Red
3
J6 From Controller
1
C-BUS +
5VDC
2
C-BUS -
5VDC
3
5VDC
5VDC
4
RS485 -
5VDC
5
RS485 +
5VDC
6
Signal Ground
7
12VDC
12VDC
8
Signal Ground
J7 C-Bus Harness
8076106 or
8075550 or
(8075632 Resistor)
1
5VDC+
+5VDC
2
CAN High
3
CAN Low
4
Ground
J8
C-Bus Harness or
Network Resistor
(pins 2 & 3)
8075549 or
8075550 or
(8075632 Resistor)
1
5VDC+
+5VDC
2
CAN High
3
CAN Low
4
Ground
J9
P-Bus Power Communication from
SIB to VIB
RJ11
8075555
1
Ground
2
P-BUS power
+5VDC
3
Modbus RS485 B
4
Modbus RS485 A
5
Signal ground
6
P-BUS power
+12VDC
J10 P-Bus Power Communication
1
Ground
2
P-BUS power
+5VDC
3
Modbus RS485 B
4
Modbus RS485 A
5
Signal ground
6
P-BUS power
+12VDC
J11 Cooking Probe 8263642
1
Ground
Yellow
2
Probe
Red

1-12
1.11 Accessing Fryers for Servicing
Before performing any maintenance on your Frymaster fryer, shut off the gas supply to the unit and disconnect the
fryer from the electrical power supply. Remove any attached restraining devices.
DANGER
Moving a fryer filled with oil may cause spilling or splattering of the hot liquid. Follow the Drain to
Pan instructions in Chapter 2 of the FQ4000 Controller Operation Manual before attempting to
relocate a fryer for servicing.
1. Shut off the gas supply to the unit. Unplug the power cords. Disconnect the unit from the gas supply.
2. Remove any attached restraining devices and relocate the fryer for service accessibility.
3. After servicing is complete, reconnect the unit to the gas supply and turn on gas supply, reattach restraining
devices, and plug in the electrical cords.
1.12 Cleaning the Gas Valve Vent Tube
1. Set the fryer power switch and the gas valve to the OFF position.
2. Carefully unscrew the vent tube from the gas valve. NOTE: The vent tube may be straightened for ease of
removal.
3. Pass a piece of ordinary binding wire (.052-inch diameter) through the tube to remove any obstruction.
4. Remove the wire and blow through the tube to ensure it is clear.
5. Reinstall the tube and bend it so that the opening is pointing downward.
1.13 Checking the Burner Manifold Gas Pressure
1. On non-CE fryers only ensure that the gas valve knob is in the OFF position (see
Figure 1A).
2. Remove the pressure tap plug from the gas valve assembly (see Figure 1B).
3. Insert the fitting for a gas pressure-measuring device into the pressure tap
hole.
4. On non-CE fryers only, place the gas valve in the ON position
5. Place the fryer power switch in the ON position. When the burner has lit and
burned steadily for at least one minute, compare the gas pressure reading to
the pressure for the corresponding gas in the appropriate table on the
following page. The tables on the following page list the burner manifold gas
pressures for each of the gas types that can be used with this equipment.
6. To adjust the burner gas pressure, remove the cap from the gas valve
regulator and adjust to the correct pressure.
Non-CE
Valve CE Valve
GAS VALVE REGULATOR CAP
7. Place the fryer power switch (and the gas valve in non-CE fryers) in the OFF position. Remove the fitting from the
pressure tap hole and reinstall the pressure tap plug.
ON
OFF
Figure 1A
Figure 1B

1-13
Non- CE Standard for Incoming Gas Pressure
FQG60T
Gas Type
Nat
LP
Min Pressure W.C/kpa/mbar
6/1.49/14.93
11/2.74/27.37
Max Pressure W.C/kpa/mbar
14.00/3.48/34.84
14.00/3.48/34.84
CE Standard for Incoming Gas Pressure
FQG60T
Gas Type
G20
G25
G30
G31
Pressure (mbar) (1) mbar=10,2mm H20
20
20 or 25
28/30 or 50
37 or 50
Australia Standard for Incoming Gas Pressure
FQG60T
Gas Type
Nat
LP
Min Pressure W.C/kpa/mbar
4.54/1.13/11.30
11.05/2.75/27.50
Max Pressure W.C/kpa/mbar
14.00/3.48/34.84
14.00/3.48/34.84
Korea Standard for Incoming Gas Pressure
FQG60T
Gas Type
LNG (Natural)
LPG (Propane)
Min Pressure W.C/kpa/mbar
4/1.00/10.00
9.2/2.30/23.00
Max Pressure W.C/kpa/mbar
10/2.50/25.00
13.2/3.30/33.00
DANGER
When pressure-testing incoming gas supply lines, disconnect the fryer from the gas line if the test
pressure is ½" PSI [3.45 kPa (14 inches W.C.)] or greater to avoid damage to the fryer’s gas piping
and gas valve(s).
NOTE: External gas regulators are not normally required on this fryer. A safety control valve protects the fryer against
pressure fluctuations. If the incoming pressure is in excess of ½" PSI (3.45 kPa/35 mbar), a step-down regulator is
required.
1.14 Adjusting the Pilot Flame
1. Remove the cap from the pilot adjustment screw hole on the gas valve.
2. Using a small, flat-tipped screwdriver, turn the pilot adjusting screw counterclockwise to increase length of flame
or clockwise to decrease length of flame. Adjust to obtain a flame from 1 inch to 1½ inches long.
3. Reinstall the pilot adjustment screw cap.
1.15 Replacing Fryer Components
1.15.1 Replacing the Controller
1. Disconnect the fryer from the electrical power supply. The fuse located at the bottom of the control box
can be removed to remove power from individual control boxes.
2. The controller is held in place by two screws in upper corners.
3. Remove the two screws from the upper corners of the controller.
4. Slide the controller up and it and will swing open from the top.
5. Disconnect the RJ45 cable from the SIB board FIRST (see Figure 2).
6. Disconnect the other cables from the connectors on the back of the controller marking their position for
reassembly.
7. Disconnect the lanyard tether.
8. Remove the controller.

1-14
Figure 3
Figure 2
5. With the replacement controller face down resting in the control box, reattach the lanyard tether FIRST. Failure
to reinstall lanyard could result in damage to the SIB board.
6. Reinstall the controller by reversing steps 1 thru 6.
7. Setup the controller following the instructions in section 1.7 of the FQ4000 Controller Operation Manual. If the
controller being replaced is in the far-left position the current date and time will need to be setup following the
instruction in section 1.8 of the FQ4000 Controller Operation Manual. Setup MUST be performed prior to reset.
8. Once setup is complete on all replaced controllers, CYCLE POWER TO ENTIRE FRYER SYSTEM. See section 1.20.2 to
reset control power.
9. Check software version and if necessary, update the software. If a software update was necessary, follow the
instructions to update the software in section 1.24.
1.15.2 Replacing Control Box Components
(Smart Interface Board (SIB), the Filtration
Interface Board (FIB), Time Delay Relay
Board, KCCM (SUI) communication board, or
the Ignition Module) (NOTE: On some units
the FIB board and KCCM (SUI) board may be
located elsewhere in the fryer.)
1. Perform steps 1 through 8 from section 1.15.1.
2. Remove the bezel by removing the two (2) screws on the
bottom of the bezel.
3. Disconnect the cables attached to the component,
marking or making a note of the connectors to facilitate
reconnection.
4. Remove the hardware attaching the components.
5. Remove the component from the box. When removing the boards, be careful not to lose the spacers that fit over
the studs behind the boards.
6. Reverse the procedure to install the component. Ensure the spacers behind the board are in place and the
controller locator wire is attached to a stud.
7. Check software version and if necessary, update the software. If a software update was necessary, follow the
instructions to update the software in section 1.24. Press the information (?)button; press the down arrow;
press the SW version button to verify software version of the FIB. If the FIB software version is not visible,
the FIB may not be connected properly.
Speaker
Harness
USB Harness
RJ-45 Power /
Communication
Locator Wire
Lanyard Tether
FIB
SIB
Ignition
Module
Time Delay
Relay Board
KCCM (SUI)
Board

1-15
Figure 4
Figure 7
Figure 5
1.15.3 Overview of Vat Components
1.15.4 Replacing the Temperature Probe
1. Drain the cooking oil from the frypot. Allow the frypot
to cool completely before proceeding.
2. Perform steps 1 through 8 from section 1.15.1.
3. Remove the bezel removing the two (2) screws on the
bottom of the bezel (see Figure 5).
4. Disconnect the temperature probe (J11) from the SIB
board (see Figure 6).
5. Locate the temperature probe to be replaced inside
the frypot (see Figure 4).
6. Using pliers or a screwdriver, carefully bend the two
tabs (one forward and toward the back) so the probe
will clear the tabs (see Figure 7).
7. Removal of other components and/or repositioning the fryer may be
necessary to gain access to the bottom of the probe. Remove the side access
panel if applicable.
8. Carefully loosen the compression fitting around the temperature probe (see Figure 8).
9. Carefully remove the probe by pulling it through the bottom of the frypot. As the probe is removed, tilt the probe
at an angle to facilitate removal. Retain the mounting hardware for reassembly.
10. Carefully pull the probe and insulation out of the control box, noting the path.
11. Remove the insulation from the old temperature probe wires to reuse on the new temperature probe.
12. Feed the new temperature probe from the top side of the frypot.
13. Apply Loctite™ PST 567 or equivalent sealant to the threads of the replacement and loosely attach the
compression fittings.
14. Mount the temperature probe into the mounting bracket by carefully bending the two tabs back into alignment to
retain the probe.
15. Using the hardware removed from step 9, securely tighten the compression fitting.
16. Using the wire insulation from step 11, slip the insulation over the new probe wires.
17. Route the wires to and through the control box.
18. Reverse steps 2-4.
19. Once the fryer is filled with oil check for leaks and proper operation.
ATO Probe
VIB (AIF)
Probe
Temp
Probe
High
Limit
Probe
Float
Switch
Figure 8
Temperature Probe –
Lower View
Figure 6

1-16
Figure 9
Figure 14
Figure 16
1.15.5 Replacing the High Limit Probe
1. Drain the cooking oil from the frypot. Allow the frypot to
cool completely before proceeding.
2. Perform steps 1 through 8 from section 1.15.1.
3. Remove the bezel removing the two (2) screws on the
bottom of the bezel (see Figure 5 from section 1.15.4).
4. Locate the high-limit probe to be replaced inside the frypot
(see Figure 4).
5. Using pliers, carefully bend the outer tab at the rear of the
high limit until the high limit can slide back and out of the
retaining bracket (see Figure 9).
6. Removal of other components and/or repositioning the fryer
may be necessary to gain access to the bottom of the probe.
Remove the side access panel if applicable.
7. Carefully loosen and completely unscrew the compression
nut, then the pass-through nut on the frypot bottom (see
Figure 10).
8. Carefully remove and pull the high-limit capillary tube and
bulb through the bottom of the frypot (see Figure 11).
9. Remove two screws securing the high-limit mounting-
bracket (see Figure 12).
10. Mark and disconnect the wires from the high limit in the
control box (see Figure 13).
11. Remove the high limit from fryer by pulling the capillary tube and bulb through the control box opening.
12. Reverse the steps above for the high limit installation. Ensure that Loctite™ PST 567 or equivalent sealant is
applied to the threads of the replacement and screw it securely into the frypot. IMPORTANT: When installing
new high limit, ensure the capillary tube and bulb are positioned properly with tab back in alignment
prior to tightening the compression nut. Once tightened, the capillary tube cannot be repositioned.
13. Once the fryer is filled with oil check for leaks and proper operation.
1.15.6 Replacing the Float Switch.
1. Drain the cooking oil from the frypot. Allow the frypot to cool
completely before proceeding.
2. Disconnect the fryer from the electrical power supply.
3. Mark the position of the float switch in the frypot (see Figure 4
on the previous page). Ensure when removing the float switch
that its position is clearly marked and replaced properly.
Installing the float upside down will change the switch from N/O
to N/C. This could allow the empty frypot to ignite.
4. Removal of other components and/or repositioning the fryer
may be necessary to gain access to the bottom of the float
switch (see Figure 14). Remove the side access panel if
applicable.
5. Disconnect the two-pin connector from the float switch (see Figure 15).
6. Using a pin-pusher push the pins of the float switch out of the connector.
7. Remove the insulation from the old float switch wires and reuse on the new float switch.
8. Remove the retaining ring at the top of the float (see Figure 16).
9. Remove the float barrel from the shaft (see Figure 16).
10. Carefully loosen the compression fitting around the bottom of the float switch (see Figure 14).
11. Carefully remove the float switch shaft by pulling it through the bottom of the frypot. Retain the mounting
hardware for reassembly.
12. Feed the new float switch wires from the top side of the frypot.
13. Apply Loctite™ PST 567 or equivalent sealant to the threads of the replacement and loosely attach the
compression fittings.
Figure 10
Lower View
Figure 11
Figure 12
Figure 13
Figure 15
