FS IPC201-2M-D User manual
V1.0
Quick Start Guide
Quick-Start Anleitung
Guide de Démarrage Rapide
Dome Network Cameras
Dome-Netzwerk-Kamera
Caméras Réseau à Dôme
Introduction
Accessories
1EN
Thank you for choosing dome network cameras. This guide is designed
to familiarize you with the structure of the camera and describes how
to deploy the camera in your network.
Dome Network Cameras
NOTE: The installation position map varies according to the dierent
models of cameras.
Waterproof Components ×1 Screw Components ×1
Installation Position Map x1 Wrench x1
T10
Drill Template
HoleB: for Mounting Screw
EN2
Hardware Overview
EN2
Ports
IPC201-2M-D / IPC204-2M-D
IPC301-5M-D
1
2
5
5
3EN
IPC305-5M-D / IPC304-8M-D
NO Ports Description
1
2
Power Interface
Ethernet Interface
Connect DC 12V power
Connect to Ethernet cable
3
4
5
Audio Interface
Alarm Interface
Micro SD Card Slot
Input/output audio signal
Input/output alarm signal
Insert the Micro SD card(purchased
separately)to get a local storage
Network access
device
connected
through copper
interface
Power
adapter
Alarm
output
(Alarm
indicator)
Alarm input
(Voice
activated
switch)
Audio output
(Outdoor sound
box)
Audio input
(Sound pickup
2314
IP Network
1
2
3
4
5
EN4
Buttons
IPC204-2M-D
IPC305-5M-D / IPC304-8M-D
Buttons
Reset Button
Description
Press and hold the reset button for more than 15
seconds to restore factory default settings. Perform t
his operation within 10 minutes after the device is
powered on or the reset will fail otherwise.
Reset Button
Reset Button
5EN
Installation Requirements
* Installation and removal of the device and its accessories must be
carried out by qualied personnel.
* Store or use the device in a proper environment that meets
environmental requirements,including and not limited to,
temperature, humidity, dust, corrosive gases, electromagnetic
radiation, etc.
* Make sure the device is securely installed or placed on a at surface
to prevent falling.
* Unless otherwise specied, do not stack devices.
* Ensure good ventilation in the operating environment. Do not
cover the vents on the device. Allow adequate space for ventilation.
* Protect the device from liquid of any kind.
* Make sure the power supply provides a stable voltage that meets
the power requirements of the device. Make sure the power supply's
output power exceeds the total maximum power of all the connected
devices.
* Take proper waterproof measures in accordance with requirements
before using the device outdoors.
* Using the device may involve the collection of personal information
such as face, ngerprint, license plate number, email, phone number,
GPS. Please abide by your local laws and regulations while using the
device.
EN6
Mounting the Camera
Installing Micro SD Card (Optional)
1. Take o the transparent dome cover by loosening screws.
2. Insert the Micro SD card (purchased separately) into the camera.
3. Do not hot plug the Micro SD card after it is inserted. Otherwise the
camera or the Micro SD card might be damaged.
7EN
Installing Waterproof Connector (Optional)
Install the supplied waterproof components to the Ethernet cable in
sequence.
NOTE: Please use self-adhesive waterproof tape (purchased separately) to
protect the cables.
Ceiling Mount
1. Locate the positions of the holes by pasting installation position
map on the ceiling, and lead the cables through the hole on the
ceiling.
2. Drill holes with a diameter of 6 - 6.5 mm and the depth of 30 mm in
the marked locations.
EN8
3. Knock the plastic rivets of self-tapping screws into the guide holes
and ensure that they are tightened up.
5.0
9EN
4. Take o the transparent dome cover by loosening screws.
5. Connect all cables of the ceiling and the camera.
6. Secure the camera to the ceilingl by leading the self-tapping screws
through the guide holes in the base and x them by using a
screwdriver.
7. Adjust the monitoring direction of the lens horizontally or vertically
by rotating the lens base or loosening the fastening screws. Tighten
the screws after vertically adjusting the lens.
NOTE: Please stop rotating the camera when the lens is blocked, otherwise
the camera lens might be damaged.
NOTE: The installation process above is concealed installation, during
which holes are drilled in the ceiling and tail cable is led out from the top
of the camera. Cables are connected and frapped at the ceiling side to
prevent messy cables from aecting camera mounting. If open installation
is adopted, tail cable is led out from one side of the camera and can be
routed from the side groove of the camera.
EN10
8. Align the screw holes in the base and tighten screws on the edge of
the transparent dome cover to x it.
11EN
Connecting the Power
PoE Device
Use an Ethernet cable to connect the network interface of the camera
to the PoE port on a PoE device, such as a PoE switch.
Power Adapter
Use the power adapter (purchased separately) to connect the power
interface of the camera to the local power source.
PoE
StatusM1 M2PWR1PWR2 PoE
1 2 3 4 5 6 7 8 91011 1213141516 17 18 19
Green=1000M Yellow=10/100MOn=Link Flashing=ACT PoELED:Green=GoodSupply Yellow=OverLoad
CONSOLE
13 14
5678910 11 12
On=Link Flashing=ACT PoELED Mode:Green=Go
Yellow=100M
1234
Green=10G/5G/2.5G/1G
MGMT
SYS PWR FANPoE
PoEFUNC
CONSOLE
EN12
Configuring the Camera
Step 1: Connect the computer to the camera on the same LAN.
Step 2: Set the IP address of the computer to 192.168.1.x.
(“x” is any number from 2 to 254.)
?
x
Intern e t Protocol Version 4（TCP/IPv4）Properties
General
Yo u can g e t IP settings assigned automatically i f y o u r n e t w o r k
supports this capability. Otherwise , y o u need t o a sk y o u r n e t w o r k
administrator f o r the appropriate IP s ettings .
Obtainan IP address aut o m a tically
Use the following IPa ddress :
I P add r ess:
Subnet mas k :
D e fault g a t e w a y :
192 . 168 . 1 . 2
255 . 255 . 255 . 0
. . .
. . .
. . .
Obtasi n D NS ser v er a ddress aut o m a tically
Use the following DNSser v er addresses:
P r e f e r r e d DNSser v e r :
A l t e r n a t e DNSser v e r :
Vali d a t e settings upon e xltA d v anc e d . . .
O K Canc e l
13EN
Step 3: Open a browser, type http://192.168.1.13, and enter the default
username and password, admin/admin
.
Step 4: Click Login to display the web-based configuration page
NOTE: You may need to install a plug-in at your first login. Please follow
the on-screen instructions to complete the installation and then open the
browser again to log in.
Login
IPC301-5M-D
Username
Password
Reset
Live View
admin
*****
EN14
Support and Other Resources
Download https://www.fs.com/download.html
Help Center https://www.fs.com/service/help_center.html
Contact Us https://www.fs.com/contact_us.html
Product Warranty
FS ensures our customers that any damage or faulty items due to our
workmanship, we will oer a free return within 30 Days from the day
you receive your goods. This excludes any custom made items or
tailored solutions.
Warranty: Dome network cameras enjoy 2 years limited
warranty against defect in materials or workmanship. For more
details about warranty, please check at
https://www.fs.com/policies/warranty.html
2
Return: If you want to return item(s), information on how to
return can be found at
https://www.fs.com/policies/day_return_policy.html
Einführung
Zubehör
15DE
Vielen Dank, dass Sie sich für den Kauf einer Dome-Netzwerk-Kamera
entschieden haben. Diese Anleitung soll Sie mit dem Aufbau der
Kamera vertraut machen und beschreibt, wie Sie die Kamera in Ihrem
Netzwerk einsetzen.
Dome-Netzwerk-Kameras
HINWEIS: Der Installationsplan variiert je nach den verschiedenen
Kameramodellen.
Wasserdichte Komponenten ×1 Schrauben-Komponenten ×1
Installationsplan x1 Schraubenschlüssel ×1
T10
Drill Template
HoleB: for Mounting Screw
DE16
Hardware-Übersicht
Ports
IPC201-2M-D / IPC204-2M-D
IPC301-5M-D
1
2
5
5
17DE
IPC305-5M-D / IPC304-8M-D
Nr. Ports Beschreibung
1
2
Power Interface
Ethernet Interface
Anschluss an DC-12V-Stromversorgung
3
4
5
Audio Interface
Alarm Interface
Micro SD Card Slot
Anschluss an Ethernet-Kabel
Eingang/Ausgang für Audiosignal
Eingang/Ausgang für Audiosignal
Micro-SD-Karte einsetzen (separat
erhältlich) um einen lokalen Speicher zu
erhalten
IP Network
Netzwerk-Zugangsgerät
über Kupferschnittstelle
angeschlossen
Netzadapter
Alarmausgang
(Alarmanzeige)
Alarmeingang
(Sprachaktivierter
Schalter)
Audio-Ausgang
(Außenschalldose)
Audio-Eingang
(Tonabnehmer)
2314
5
IP Network
1
2
3
4
DE18
Tasten
IPC204-2M-D
IPC305-5M-D / IPC304-8M-D
Reset-Taste
Reset-Taste
Reset-Taste
Taste Beschreibung
Halten Sie die Reset-Taste länger als 15 Sekunden
gedrückt, um die Werkseinstellungen
wiederherzustellen. Führen Sie diesen Vorgang
innerhalb von 10 Minuten nach dem Einschalten des
Geräts durch, da das Zurücksetzen sonst fehlschlägt.
19DE
Installationsanforderungen
* Der Ein- und Ausbau des Geräts und seines Zubehörs muss von
qualiziertem Personal durchgeführt werden.
* Lagern oder verwenden Sie das Gerät in einer geeigneten
Umgebung, die die Umgebungsanforderungen erfüllt, einschließlich,
aber nicht beschränkt auf, Temperatur, Feuchtigkeit, Staub, korrosive
Gase, elektromagnetische Strahlung usw.
* Stellen Sie sicher, dass das Gerät sicher installiert ist oder auf einer
ebenen Fläche steht, um ein Herunterfallen zu verhindern.
* Sofern nicht anders angegeben, dürfen die Geräte nicht gestapelt
werden.
* Sorgen Sie für eine gute Belüftung der Betriebsumgebung. Decken
Sie die Lüftungsönungen des Geräts nicht ab. Lassen Sie ausreichend
Platz für die Belüftung.
* Schützen Sie das Gerät vor Flüssigkeiten jeglicher Art.
* Stellen Sie sicher, dass die Stromversorgung eine stabile Spannung
liefert, die dem Leistungsbedarf des Geräts entspricht. Stellen Sie
sicher, dass die Ausgangsleistung des Netzteils die maximale
Gesamtleistung aller angeschlossenen Geräte übersteigt.
* Treen Sie geeignete wasserdichte Maßnahmen gemäß den
Anforderungen, bevor Sie das Gerät im Freien verwenden.
* Die Verwendung des Geräts kann die Erfassung von persönlichen
Daten wie Gesicht, Fingerabdruck, Nummernschild, E-Mail,
Telefonnummer, GPS beinhalten. Bitte halten Sie sich bei der
Verwendung des Geräts an Ihre örtlichen Gesetze und Vorschriften.
