FTE Maximal MIND Series User manual

v.1.0
MIND
User’s manual

User´s manual ꞏ MIND
Reserved for technical modifications and/or errors - 3 - MIND Version en_1.0 Fte maximal
INDEX
1Starting Installation ............................................................................................................................................ 4
1.1Safety Rules ............................................................................................................................................... 4
1.2Content of the box ..................................................................................................................................... 5
1.3Accessories and complete example ....................................................................................................... 6
2Description ......................................................................................................................................................... 7
2.1Connections ............................................................................................................................................... 7
MIND 32 .............................................................................................................................................. 7
MIND 32S ........................................................................................................................................... 8
2.2Control elements ....................................................................................................................................... 9
3Menu and programming the amplifier .............................................................................................................. 9
3.1Main menu .................................................................................................................................................. 9
3.2Menú BIII-UHF4 MODE ............................................................................................................................ 10
3.3Menu DC PASS ........................................................................................................................................ 10
3.4Menu AUTO SCANNING .......................................................................................................................... 11
3.5Menú UHF1 ............................................................................................................................................... 11
3.6Menu UHF2 ............................................................................................................................................... 12
3.7Menu UHF3 ............................................................................................................................................... 13
3.8Menú BIII-UHF4 ........................................................................................................................................ 13
3.9Menu OUT ................................................................................................................................................ 13
Level ................................................................................................................................................. 13
Slope ................................................................................................................................................ 13
3.10Menu FM .................................................................................................................................................. 13
Preaamplifier FM ............................................................................................................................. 13
Gain FM ............................................................................................................................................ 14
3.11Menú AUX ................................................................................................................................................ 14
Preaamplifier AUX .......................................................................................................................... 14
Gain AUX ......................................................................................................................................... 14
3.12Menú SAT ................................................................................................................................................ 14
Supply .............................................................................................................................................. 14
Gain .................................................................................................................................................. 15
Equalizer .......................................................................................................................................... 15
Polarization ..................................................................................................................................... 15
Band ................................................................................................................................................. 15
3.13Menu ADDITIONAL .................................................................................................................................. 15
Supply .............................................................................................................................................. 15
Config Inport ................................................................................................................................... 16
Config Export .................................................................................................................................. 16
Default Settings .............................................................................................................................. 16
Pin .................................................................................................................................................... 17
Language ......................................................................................................................................... 17
Version ............................................................................................................................................. 17
4Technical specification ................................................................................................................................... 18
4.1Technical specification MIND 32 ........................................................................................................... 18
4.2Technical specification MIND 32S ......................................................................................................... 19

User´s manual ꞏ MIND
Reserved for technical modifications and/or errors - 4 - MIND Version en_1.0 Fte maximal
1 Starting Installation
1.1 Safety Rules
Please read the manual carefully before using the amplifier.
You will receive a lot of information to use this product correctly and you will prevent incidents.
Please keep the manual on a safe place.
This sign warns you about
high voltages, with risk
of electric shock
Caution: Do not open the housing of this
amplifier. Repairs can only be made by
professionals authorized by Fte maximal.
If not, warranty will not be valid anymore.
This sign informs about
special information which is
important to know.
Caution: Keep this amplifier far away from liquids. Do not place it on placements close to water like
flowers vases, wash basin, aquariums or pools. A high risk of electric exists shock when water or high
humidity filters inside the amplifiers. Never place other devices on it; they can overheat the amplifiers as
well as daring fire risk. The amplifiers must be used only with original power cord to 230V main plug.
Please read carefully this manual and do not hesitate to contact to professional help if you have any
doubt.
Opening the amplifier housing will mean a warranty void.
Installation:
1. Respect the ventilation holes of the equipment without covering them with any object.
2. Keep clear the environment of the equipment, with a minimum ratio of 40 cm.
3. Do not place the equipment close to any heating source.
4. Do not make the equipment work at any temperature that exceeds the range of working temperatures.
5. Avoid placements with risk of dumping liquids inside and with big changes in temperature.
6. Never open the equipment by yourself, due to risk of electrocution. In case of problems, please get always
qualified technicians.
7. Never open the equipment while it is plugged to the Power Network.
8. It is preferable that the equipment is disconnected during the connection of it.
9. Respect the safety electrical rules during the installation. Use the materials that perform the current
regulations.
10. The connection plug must be accessible in an easy and simple mode, and always to get a fast disconnection.
11. Never touch the power network plug with wet hands. Disconnect always the equipment before handling its
connections.
12. Do not place any heavy object over the equipment, due to it could get damaged.
Cleaning: Before cleaning the amplifier with a slightly damped cloth, please disconnect the main 230 Vac connection
from the amplifier. Please use only mild cleaners.
Accessories: Please, do not use accessories which are not agreed by the manufacturer of the amplifier.
Unsuitable accessories could increase the risk of getting on fire, an electrical impact or other damages.
Placement: Select a placement where the Amplifiers has air circulation enough, otherwise it may have overheating
accumulation.
Power connection: Select a main plug with easy access, in case of unplugging necessity; it will be easier and faster.
Please, make sure that the cord as well as the plug is in perfect conditions. Do not pull the cable, use always the plug.
Housing: Please, make sure that no liquid will filter into the housing of the amplifier. If so, disconnect immediately the
amplifier from the main 230 V plug and bring the amplifier to a professional.
Air humidity: When you take the Amplifier from a cold to a warm place, please wait until the amplifier gets the same
temperature as the new environment, in order to avoid problems of humidity condensation.
Maintenance / Repairing: Within the warranty time all the repairing processes should be done by Fte Maximal
technical staff. Otherwise, the warranty will be lost.
RISK OF ELEKTRIC SHOCK
DO NOT OPEN
CAUTIONR

User´s manual ꞏ MIND
Reserved for technical modifications and/or errors - 5 - MIND Version en_1.0 Fte maximal
1.2 Content of the box
When you open the box or the first time, you will find the following content:
User´s manual AC Power cord
Depending of the model selected, you will find the following content in the box:
MIND 32:
Programmable amplifier MIND 32 3xF loads 75Ω
MIND 32S:
Programmable amplifier MIND 32S 4x F loads 75Ω

User´s manual ꞏ MIND
Reserved for technical modifications and/or errors - 6 - MIND Version en_1.0 Fte maximal
1.3 Accessories and complete example
1. OS 100 STB 100cm Ø Satellite dish Code: 0701105
2. EXCELLENTO RED HD SINGLE Universal single LNB Code: 0400311
3. F DAB F DAB outdoor antenna Code: 0203924
4. Phoenix UHF outdoor antenna Code: 9003953
5. Diamond UHF outdoor antenna Code: 9003955
6. EYE UHF Lte outdoor antenna Code: 9003960
7. F 0-F FM outdoor antenna Code: 9002005-F
In this example, 6 types of antennas can be connected to the programmable amplifier. Also pre-amplifiers can
be connected at UHF inputs.
All the different elements for the reception of different bands will be connected through the Wide Band
programmable amplifier MIND 32S (FM, BIII-DAB, UHF and Satellite), which will be treated by the equipment.
Once the Wide Band Central is programmed, it will be connected through the outputs OUT TER and OUT
TER+SAT, the last one is already mixed with the Satellite and Terrestrial signal, designed for ICT
Installations.
1
7
2
34
5
6
DISTRIBUTIÓN

User´s manual ꞏ MIND
Reserved for technical modifications and/or errors - 7 - MIND Version en_1.0 Fte maximal
2 Description
2.1 Connections
MIND 32
1 FM: Input for FM aerial.
2 UHF 1/ UHF2/ UHF 3: Input for UHF antenna
3 BIII-UHF4: Input for BIII/DAB and UHF antenna
4 USB PORT: USB port to save and restore configuration backups.
5 OUT: Terrestrial TV Output
6 TEST: Test output (-30 dB)
7 AC POWER: Connector to plug the AC power cord.
5 6
47
1 3 2

User´s manual ꞏ MIND
Reserved for technical modifications and/or errors - 8 - MIND Version en_1.0 Fte maximal
MIND 32S
1 AUX: Auxiliary input with the full band.
2 FM: Input for FM antenna.
3 UHF 1 / UHF2 / UHF 3: Input for Terrestrial UHF antenna
4 BIII-UHF4: Input for DAB/BIII and UHF antenna
5 USB PORT: USB port to save and restore configuration backups.
6 SAT: Input for IF signal
7 Power: Input for AC power cord.
8 TEST: Test output (-30 dB)
9 OUT TER: TV terrestrial Output
10 OUT TER+SAT: Terrestrial and Satellite Output
1 2 5
3 7
8 9 10
6
4

User´s manual ꞏ MIND
Reserved for technical modifications and/or errors - 9 - MIND Version en_1.0 Fte maximal
2.2 Control elements
The control of the programmable amplifiers MIND will be done through two elements:
1. LCD display with 2 lines and 8 characters for showing the information..
2. Control buttons:
- MENU: Cancels the edition and return to the initial screen.
- OK: Enter in the next level of the menu, enable the edition mode or confirm the new
values of the parameters.
- ESC: Goes back one level in menus or cancels the current parameter edition.
- ◄ ►: Move through menus options or change the parameter values while is in edition
mode.
3 Menu and programming the amplifier
The programming of the amplifier is through the integrate programmer. Below
the steps and the menu options are explained:
When you connect the headend to the mains or exit of sleep mode, the LCD
display shows an initial screen showing the model and software version of the
amplifier.
If no key is pressed for 60 seconds, the amplifier enter in sleep mode. To exit
the sleep mode and access the programming press any key on the keypad.
3.1 Main menu
Press the OK key to open the main menu. If the headens has a PIN code
previously set, a screen will appear asking to enter it.
Select the digits values with ◄ ► keys. Press OK button to confirm the values
The main menu contains the following options:
- BIII-UHF4 MODE: Allow configure the bands for the input BIII-UHF4.
- DC PASS: In this menú can set the power for pre amplifiers in the UHF inputs.
- AUTO SCANNING: Search the UHF signals in the inputs selected.
- UHF1: Permits add or change the configuration of filters assigned to the input UHF1.
- UHF 2: Allow add or change the configuration of filters assigned to the input UHF2.
- UHF 3. Permits add or change the configuration of filters assigned to the input UHF3.
- BIII-UHF4: Allow add or change Allow add or change in the input BIII-UHF4. This option only will be
displaying is not configure as DAB mode.
- OUT: Allow set the output level value and the equalization of the terrestrial band.
- FM: Allow change the settings of the amplifier for the FM band.
- AUX: Allow change the settings of the amplifier for the Auxiliary input. (Only available in the model
MIND 32S).
- SAT: Allows change the parameters of amplifier for IF satellite band (Only available in the model
MIND 32S).
- ADDITIONAL: Selecting this menu is possible see information of the amplifiers and save and restore
configuration backups.
Move through options and menus with buttons ◄ ► of the keyboard.
OK to confirm and ESC to go back.
Press MENU at an
y
time to
g
o back to the initial screen.
MIND 32S
v.19e48
=
PIN
***_

User´s manual ꞏ MIND
Reserved for technical modifications and/or errors - 10 - MIND Version en_1.0 Fte maximal
3.2 Menu BIII-UHF4 MODE
Press Ok button to edit the configuration of the menu BIII-UHF4 MODE. It has two options available:
1. BIII-UHF4: This mode allows BIII and UHF channels in the input. The
filters can be configured in this mode.
2. DAB: This mode assigned 8 of the 32 filters available to amplify all
BIII. This mode disables the options to supply a pre amplifier in the
input, the auto scanning channels for the input and disable the menu
BIII-UHF4. Remember to enable this mode is necessary at least 8
unused filters.
Press the button OK to edit. The current option blink in the display to
confirm is in edit mode. Use the buttons ◄ ► to select the mode and
press OK to confirm your selection.
Press ESC to return to the main menu.
3.3 Menu DC PASS
This menu enables or disables power for preamplifier in the UHF inputs.
Press OK to edit the voltage value for the preamplifier. The voltage value is equal for all inputs.
Use the buttons ◄ ► of the keyboard to select between the options <DC
PASS: 12V> and <DC PASS: 24V>. Press the button Ok to confirm.
After that, Select with input allow or not. The numbers showing in the display
LCD correspond to the UHF inputs. For example the 1 is the input UHF1 and
the 4 is the input BIII-UHF4.
The option in the right side of the “1:” (UHF1) will be starting to blink to
indicate is in edit mode. Use the buttons ◄ ► of the keyboard to select one
of the next options:
1. “+”: Allow power for pre amplifiers in the input.
2. “-”: Does not allow power for pre amplifiers in the input.
Press OK to confirm your selection for the input. Repeat for the other UHF inputs and confirm with the button OK.
Note: If the input 4 (BIII-UHF4) is configured as DAB mode, it will be not appear as option in the menu.
Press ESC to go back to the main menu.
< DC PASS:
1
2
V
>
1:- 2:- 3:- 4:-
< DC PASS: 24V
>
1:+ 2:- 3:- 4:-

User´s manual ꞏ MIND
Reserved for technical modifications and/or errors - 11 - MIND Version en_1.0 Fte maximal
3.4 Menu AUTO SCANNING
This menu can be use to scan all UHF signal received in the selected inputs
and automatically assigned filters of the channels founds. If the same UHF
channel is detected in several inputs only will be assigned the filter to input
with the best level detected. All filters assigned to one input will be removed
in the scanning process and only add the filters of the channels found.
The auto scanning could be not found the signals depending of the level. Consider the following case:
1. If the signal is between 54 dBµV and 110 dBµV, the signal must be found by the auto scan.
2. If the signal is between 51 dBµV to 53 dBµV could be detect or not depending the levels of adjacent
channels.
3. If the signal is lower or equal than 50 dBµV is very low and never found.
If the digital signals are low but have enough quality use a preamplifier to get
a correct level in the input of the amplifier.
Press OK, to enter in the menu “AUTO SCANNING”. Use the buttons ◄ ► of
the keyboard and select “+” to add the input in the auto scanning. If select
“-” the input will be not included in the scan. Press Ok to confirm the selection.
Repeat the process with the other inputs. If the input 4 (BIII-UHF4) is configured in DAB mode will be not showing
in the menu.
After confirm the las input with OK, the next step is select the limit of the UHF band to scan in the option LTE/5G
filter. The options available are:
1. 694 MHz: Search the channels between C21 and C48.
2. 790 MHz: Search the channels between C21 and C60.
3. Off: Search the channels between C21 and C69.
Use the buttons ◄ ► of the keyboard to select and press Ok to confirm and
start the auto scanning. The time depend of the number of input and
channels to scan.
When the auto scanning finish appear the number of UHF channels detected.
Press ESC to return to the main menu.
3.5 Menu UHF1
Allow add, delete or edit configuration of the assigned filter of the UHF1 input.
To enter in the menu press OK.
a) Add a new channel.
To add a new channel select with the buttons ◄ ► until show the
message in the screen “Adding channel”. Press "OK and will be add and
edit the filter.
<AUTO SCANNING >
LTE/5G Filter
694 MHz
SCANNING
[****** ]
RESULTS:
CH UHF:16
< UHF1
>
UHF:
1:+ 2:- 3:+ 4:-
U
HF1 Adding
Channel

User´s manual ꞏ MIND
Reserved for technical modifications and/or errors - 12 - MIND Version en_1.0 Fte maximal
Screen to add or edit a filter
The next screen permits add and edit the parameter of the filter and show information of the level. If not
appear the screen to edit means all the filters are used.
1) Input: Show the input where the filter is associated.
2) Input level: The value of the level of the channel detected in the input. Remember the value of level
detected could be a little different than your field strength meter. If the level is lower than 50 dBµV, the
value showing in the display will be “Low Lev”. In the next line you can see and edit the next
parameters:
3) Input channel: Use the buttons ◄ ► to select the input channel.
If in the position of the name of the current input, in the example
“UHF1”, appear the message “Error”, means the input channel is
assigned by other filter. In this case need select another input
channel. Press Ok to confirm the input channel.
4) Output channel: The programmable amplifier has an option to change the output channel of each
filter. Use this option if sort channels or to left free part of the band for other channels. Remark only
can change the output frequency but keep the rest of parameter of the signal. For example the
bandwidth will be the same after change the output channel. If use one input can amplifier BIII and
UHF channel avoid it is possible move channel with bandwidth 8 MHz to one channel with 7 MHz of
bandwidth. For example, the channel UHF has a bandwidth of 8 MHz and the BIII have a bandwidth
of 7 MHz. If move the channel from UHF to VHF band remember the output channel use part of the
bandwidth of the adjacent channels in VHF band. For that, is recommended move channels in the
same band.
Note: The input BIII-UHF4 can amplifier channels in BIII and UHF.
When the output channel is blinking, use the ◄ ► to select the new output channel and press OK to
confirm.
5) Output level. The output level of the channel can be adjusting from 100 dBµV to 120 dBµV. The
maximum value (120 dBµV) can be limited by the value Level in the Out menu.
When the output level parameter is blinking use the buttons ◄ ► to change the value level of the
channel of this filter. Press the button OK to confirm.
b) Editing a filter.
Select the filter to edit using the buttons ◄ ► and press the button OK. To select the parameter to modify
press OK until the parameter is blinking. Use the buttons ◄ ► to select the new value and confirm with
the button OK. Repeat these operations with the other parameter to update. The edit mode finish when all
parameter will be confirmed with OK.
c) Deleting a filter from an input
Select the filter to delete usign the button ◄ ►. Press and hold 5
second the button OK. When the operation finish appears the
message “Channel deleted”. Press OK to continue.
Press ESC to return to the main menu.
3.6 Menu UHF2
Allow add, delete and edit the filter assigned to the input UHF2. Follow the
steps in the point Menu UHF1 to do the adjustment.
U
HF1 L= 67dBµ
V
25=>22 L=119dBµV
< UHF2
>
Channel
deleted!
1 UHF1 N
=
6
4dBµ
V
21=>21 N=120dBµV 2
3 5
4

User´s manual ꞏ MIND
Reserved for technical modifications and/or errors - 13 - MIND Version en_1.0 Fte maximal
3.7 Menu UHF3
Allow add, delete and edit the filter assigned to the input UHF3. Follow the
steps in the point Menu UHF1 to do the adjustment.
3.8 Menu BIII-UHF4
Allow add, delete and edit the filter assigned to the input BIII-UHF4. This input
allows BIII and UHF channels. This menu appears only when the BIII-UHF4
mode is BIII-UHF. Follow the steps in the point Menu UHF1 to do the
adjustment.
3.9 Menu OUT
In this menu will be doing the output settings. It has 2 options:
Level
- Set the maximum output level. This parameter set the maximum
output level of the channels. The values are between 100 dBµV to
120 dBµV. The maximum level is reduced automatic depending of
the number of channel in the output.
If the filters were added manually in the UHF and BIII-UHF menu, remember adjusment the value of
Level.
Press OK to edit the value and use the buttons ◄ ► to select the new value. Press OK to confirm.
Press the button ► to select the screen Slope.
Slope
- Change the Tilt regulation. The values of regulation are between 0
and -9 dB.
Press OK to edit and use the buttons ◄ ► to select the new value.
Press the button OK to confirm.
Press ESC to return to the main menu.
3.10 Menu FM
From this menu you can adjust the settings of the FM signal. There are 2
options:
- Preamplifier: To activate or deactivate the first amplifier stage.
- Gain: Gain regulation adjustment.
Preaamplifier FM
This screen allows activating (on) or deactivating (off) the first amplifier stage
for the FM band. This option is set (off) by default.
In order to activate (on) or deactivate (off) press OK to edit and ◄ ► keys to
change. Then press OK to confirm.
Pulse ► para acceder a la pantalla GAIN FM.
< FM
>
PREAMPLIFIER OFF
< FM
>
OUT ^
Level 120dBµV
< OUT
>
OUT ^
Slope 0
< UHF3
>

User´s manual ꞏ MIND
Reserved for technical modifications and/or errors - 14 - MIND Version en_1.0 Fte maximal
Gain FM
Here you can adjust the gain regulation of FM band, from 0 to 20 dB.
Press OK to edit the value and ◄ ► keys to change. Then press OK to
confirm.
Press ► to return to the FM AMP screen or ESC to go back to the main
menu.
3.11 Menú AUX
AUX configuration is only available for the model MIND 32S
From this menu you can adjust the settings of the FM signal. There are 2
options:
- Preamplifier: To activate or deactivate the first amplifier stage.
- Gain: Gain regulation adjustment.
Preaamplifier AUX
This screen allows activating (on) or deactivating (off) the first amplifier stage
for the AUX band. This option is set (off) by default.
In order to activate (on) or deactivate (off) press OK to edit and ◄ ► keys to
change. Then press OK to confirm.
Pulse ► para acceder a la pantalla GAIN AUX.
Gain AUX
Here you can adjust the gain regulation of FM band, from 0 to 20 dB.
Press OK to edit the value and ◄ ► keys to change. Then press OK to
confirm.
Press ► to return to the AUX PREAMPLIFIER screen or ESC to go back to
the main menu.
3.12 Menú SAT
Satellite configuration is only available for the model MIND 32S
Allows change all setting of the amplifier for satellite signal. The MIND 32S
can amplify the signal of one polarity and band of a satellite. These
parameters are programmable from the control panel so a "single" type LNB
can be used.
Supply
When you enter the SAT submenu, the "Supp" screen appears which is used
to enable or disable the power of the satellite module. By default it is disabled
(off) and the rest of the SAT module settings do not appear.
To configure the satellite module, first of all activate the option Supp (on)
You can then access the following options:
- Equalizer: Satellite signal equalization
- Gain: adjustment of gain
- Pol: polarity assignment
- Band: band assignment
Press OK to edit the Supp option and change the value to (on) with the ◄ ► keys. Confirm pressing OK
again.
Press ► to access the next screen.
FM ^
GAIN 20
AUX ^
PREAMPLIFIER ON
< AUX
>
AUX ^
GAIN 20
< SAT
>
SAT ^
Supply off
SAT ^
Supply on

User´s manual ꞏ MIND
Reserved for technical modifications and/or errors - 15 - MIND Version en_1.0 Fte maximal
Gain
Here you can adjust the gain regulation of the satellite signal, from 0 to 20 dB.
Press OK to edit the value and ◄ ► keys to change. Then press OK to
confirm.
Press ► to access the next screen.
Equalizer
The "Equalizer" screen activates or deactivates the frequency equalization of
the satellite band, thus compensating for the attenuation of the signal level at
the higher frequencies.
If you select (on) the equalization of 9dB is activated and selecting off is
disabled.
Press OK to edit the value and ◄ ► keys to change. Then press OK to confirm.
Press ► to access the next screen.
Polarization
In this option you can select the polarity of the satellite, selecting the voltage
that is sent to the LNB. Available Options 0V: No envía tensión hacia la
LNB.
- Ver: Vertical polarity or 13V.
- Hor: Horizontal polarity or 18V.
Press OK to edit the value and ◄ ► keys to change. Then press OK to confirm.
Press ► to access the next screen.
Band
In this option you can select the satellite band, activating or deactivating the
22KHz tone.
Options: High (High band) o Low (Low band).
Press OK to edit the value and ◄ ► keys to change. Then press OK to
confirm.
Press ► to access the next screen.
Press ► to return to the first screen of SAT submenu or ESC to go back to the main menu.
3.13 Menu ADDITIONAL
This menu can do backup or restore the configuration, set the PIN or get some information. Witin this menu
are these options:
- Temperat.: It show the temperature inside of the amplifier.
Supply: It show the status of the power supply.
Config Import: Import a configuration from the USB disk. *
- Config Export: Export a configuration to a USB disk. *
- Default Settings: Load the factory settings.
- PIN: Enable or disable the Pin to enter in the menu of the amplifier.
- Version: Show the software version.
* The option appears in the menu when a USB disk is connected in the USB port.
Supply
This screen shows information about the level of the supply voltage from the
external power supply. The messages that may appear on the screen are:
- Supply: OK: The supply voltage is normal.
- Supply: Hi: The supply voltage is high. It could be a power supply
failure.
ADDITIONAL ^
Supply: Ok
SAT ^
Gain 20
SAT ^
Equalizer on
SAT ^
Polarization Ver
SAT ^
Band Low

User´s manual ꞏ MIND
Reserved for technical modifications and/or errors - 16 - MIND Version en_1.0 Fte maximal
- Supply: Lo: The supply voltage is low. It may be due to excessive consumption of the amplifier and
various elements connected to it, such as LNBs and preamplifiers or possible power supply failure.
-
Press ► to access the next screen.
Config Inport
This screen allows import a complete configuration of the equipment. (*).
If usually set the same channel settings is possible store the configuration in
the USB memory, (The MIND amplifier allow up to 1000 configurations). With
this option, The MIND amplifier read the configuration file from the USB disk
and does a fast programming in Nebula amplifiers.
When entering, a screen appears to select the stored file number. Select the file with ◄ ► keys and press
OK to confirm.
Once selected, the file loads the configuration into the amplifier. Please wait.
When finished, a message appears indicating that the configuration load is complete.
Press ► to access the next screen.
(*) it is necesary to connect a USB memory to the USB port of amplifier to access this menu. The USB
memory must be formatted in a FAT or FAT32 file system.
Config Export
This screen allows you to save the current configuration of the headend to the
USB disk. (*)
When entering, a screen appears to select the file number to store. Select the
file with ◄ ► keys and press OK to confirm.
Once selected, save the configuration of the amplifier to the USB. Please wait.
When finished, a message appears indicating that the configuration load is complete.
Press ► to access the next screen.
(*) It is necessary to have a USB memory connected to the amplifier to access this menu. The USB memory
must be formatted in a FAT or FAT32 file system.
Default Settings
The “Defaults” screen is used to load the factory settings of the amplifier.
Pressing OK displays a confirmation screen. Select Yes to confirm to load the
default value. Once confirmed, it deletes the current configuration to restore
the factory settings..
Press ► to access the next screen.
ADDITIONAL ^
Config Import
Select file:
MIND32S_001.dat ADDITIONAL ^ Wait.. ADDITIONAL ^ Completed
ADDITIONAL ^
Config Export
Select file:
MR32S_001.dat ADDITIONAL ^ Wait.. ADDITIONAL ^ Completed
ADDITIONAL ^
Default Settings
ADDITIONAL ^
Default: No ADDITIONAL ^ Default: Yes

User´s manual ꞏ MIND
Reserved for technical modifications and/or errors - 17 - MIND Version en_1.0 Fte maximal
Pin
Here you can enable or disable a password or PIN in order to access to the
headend programming. By default it is set (off). To activate it follow these
steps:
- Press OK and change the PIN to (on)
- The amplifier will ask you to enter the 4-digit PIN. Use the ◄ ► keys
to change the value of each digit and the OK key to confirm it.
The PIN will be requested from the moment the Nebula comes back from
sleep mode.
Press ► to access the next screen.
Language
This screen can select the language of the display. The options available are:
English (default value) and Spanish.
- Press OK to change the language using the keys ◄ ► and press
OK to confirm it.
Press ► to access the next screen.
Version
This screen shows the software version of the amplifier.
Press ► to return to the first screen of CONFIG submenu or ESC to go back
to the main menu.
.
ADDITIONAL ^
PIN: Off
ADDITIONAL ^
PIN: *___
V
ersion: 19e48
0.1_0.2.0_0_6
ADDITIONAL ^
Language:english

User´s manual ꞏ MIND
Reserved for technical modifications and/or errors - 18 - MIND Version en_1.0 Fte maximal
4 Technical specification
4.1 Technical specification MIND 32
Model MIND 32
Code 2003410
Description Programable amplifier 32 filters (BIII / UHF)
Inputs
FM 88 – 108 MHz
BIII/UHF4
DAB Mode: 174 – 230 MHz
BIII-UHF Mode: 174 – 230 MHz/ 470- 862 MHz
DAB Mode: Use 8 programmable filters available
BIII-UHF Mode: 32 programmable filters with BW 1
channel ( 7 MHz* ó 8MHz*)
The filters are share with the other UHF inputs
3 x UHF
470-862 MHz
32 filters programmable with BW of 1 channel per filter (7
MHz* or 8MHz*).
The filters are share with the input BIII/UHF4
Input level range FM: 40-90 dBuV
BIII/ UHF: 50-100 dBuV
Outputs 1 TER + 1 TEST (-30dB)
Gain: FM (35/ 25) dB (1)
BIII-DAB/UHF > 55 dB
Regulation FM: 20 dB / Input BIII-UHF and UHF 0..20 dB + AGC
Output level FM 123 dBuV
BIII/UHF 123 dBuV
Preamplifiers feeding In all UHF inputs 0/12/24 VDC (80mA maximum per Input). Total current for all
inputs is 200 mA.
Equalization 0..9 dB in step of 1 dB
Noise figure FM < 6 dB
BIII-DAB/UHF -
Selecti
v
ity filters BIII/UHF
(± 1 MHz) > 35 dB
LTE/5G filtering Yes, using the selectivity extreme of the programmable filters
Programming Through integrated programmer with 5 buttons and 2-line LCD display of 16
characters
Digital channel
conversion Yes
Auto scan channels in
UHF band Yes
Select standard and
region Yes
LCD language English and Spanish
Supply 100-254Vac 50-60Hz
Power consumption 15W
USB Port USB 2.0 to import / export settings
Temperatu
r
e -5 /+50ºC
Dimensions 265mm x 190 mm x 52 mm
1 The gain value depends on the On / Off state of the input AMP stage
* The bandwidth of the channel depends of the band.

User´s manual ꞏ MIND
Reserved for technical modifications and/or errors - 19 - MIND Version en_1.0 Fte maximal
4.2 Technical specification MIND 32S
Model MIND 32S
Code 2003412
Description Programmable amplifier 32 filters (BIII/UHF) and SAT
Inputs
FM 88-108MHz
AUX 47-862 MHz
BIII/UHF4
DAB Mode: 174 – 230 MHz
BIII-UHF Mode: 174 – 230 MHz/ 470- 862 MHz
DAB Mode: Use 8 programmable filters
available
BIII-UHF Mode: 32 programmable filters with BW
1 channel ( 7 MHz* ó 8MHz*)
The filters are share with the other UHF inputs
3 x UHF
470-862 MHz
32 filters programmable with BW of 1 channel per
filter (7 MHz* or 8MHz*).
The filters are share with the input BIII/UHF4
SAT 950-2150 MHz
Input level range
FM: 40-90 dBuV
AUX: 60-90 dBuV
BIII/UHF: 50-100 dBuV
SAT: 40-90 dBuV
Outputs TER+SAT, TER + 1 de test (-30 dB)
Gain:
FM: 40/30 dB (1)
AUX 10/20 dB (1)
BIII/UHF > 55 dB
SAT: 40 dB
Regulation FM: 20 dB / AUX: 20 dB/ BII and UHF 0..20 dB + AGC / SAT: 20 dB
Equalization SAT: 0/9±2 dB
Output level
FM: 120 dBµV
AUX: 112 dBuV
BIII-DAB/ UHF: 120 dBµV
SAT: 120 dBµV
LNB feeding 0/13/18VDC – 0/22KHz / 300 mA
Preamplifiers feeding In all UHF inputs 0/12/24 VDC (80mA maximum per Input). Total
current for all inputs is 200 mA.
Noise figure
FM : ≤6 dB
AUX: -
BIII/DAB: -
UHF: -
SAT: ≤7 dB
Selectivity filters BIII/UHF (± 1
MHz) > 35 dB
LTE/5G filtering Yes, using the selectivity extreme of the programmable filters
Programming Through integrated programmer with 5 buttons and 2-line LCD display
of 16 characters
Digital channel conversion Yes
Auto scan channels in UHF band Yes
LCD language English and Spanish
Supply 100-240Vac 50-60Hz
Power consumption 25W
USB Port USB 2.0 to import/export settings
Temperature -5 /+50ºC
Dimensions 265mm x 190 mm x 52 mm
1 The gain value depends on the On / Off state of the input AMP stage
* The bandwidth of the channel depends of the band.
