FTI TB Series Application guide

TB SERIES PUMPS
TBS
OPERATION & PARTS MANUAL
P/N 108099 R5

2
EU Declaration of Conformity
Finish Thompson Inc. hereby declares that the following machine(s) fully comply with the
applicable health and safety requirements as specified by the EU Directives listed. The product may
not be taken into service until it has been established that the drive motor for the Drum and
Container Pump complies with the provisions of all relevant EU Directives. The complete product
complies with the provisions of the EU Directive on machinery safety provided motors
manufactured by Finish Thompson Inc. are used.
This declaration is valid provided that the devices are fully assembled and no modifications are
made to these devices.
Type of Device:
Drum and Container Pump
Tubes and Accessories
Models:
EU
Directives:
Machinery Safety (2006/42/EC)
Applied Harmonized Standards:
EN ISO 12100
EN
809
Manufacturer:
Finish
Thompson
Inc.
921 Greengarden
Road
Erie, Pennsylvania 16501-1591
U.S.A
Signed,
_
President
25 March 2020
Person(s) Authorized to Compile Technical File: Finish Thompson GmbH
Otto-Hahn-Strasse 16
Maintal, D-63477 DEU
Telephone: [phone]
EFP/EFV/EFS-16/27/40/48/54
PFM-27/40/48/54/60
PFV-27/40/48/60/72
TTC/TTS-27/40/48
Nozzles (111030)
BTS –40/48
HVDP LR-27/40/48
PFP-27/40/48/54/60/72
TBP-27/40/48
STTS-40
HVDP HR-27/40/28
PFS-27/40/48/60/72
TBS-40
TMS-40

3
Introduction
This manual pertains to the TB Series stainless steel drum pump and accessories. Finish Thompson Inc. thanks you
for choosing our products. We believe the use of our products will be fully satisfactory. When properly installed
and operated, your Finish Thompson motor and pump will provide long, trouble-free service; therefore, please
read this manual carefully before carrying out any operations on the pump/motor unit. Any use other than that
described herein is considered incorrect; and, consequently, Finish Thompson Inc. shall not be held responsible for
any damages to people or property. In case of doubt or enquiries, please reply to our Technical Service department
directly at the following address:
Finish Thompson, Inc.
921 Greengarden Rd.
Erie, PA 16501 U.S.A.
Tel. [phone]; Fax [phone]
www.finishthompson.com; fti@finishthompson.com
Index
Introduction....................................................................................................................................3
Warranty, General Terms & Conditions...........................................................................................4
Safety .............................................................................................................................................5
Important Safety Information for Pumping Flammable or Hazardous Substances .......................6
Pump Specifications.......................................................................................................................7
Installation......................................................................................................................................8
Operation .......................................................................................................................................8
Maintenance
Disassembly...............................................................................................................................8
Inspection..................................................................................................................................8
Reassembly ...............................................................................................................................9
Exploded View................................................................................................................................10
Pump Tube Spare Parts List ...........................................................................................................11
Technical Service Hotlne: 1-800-888-3743 or email techservice@finishthompson.com

4
Warranty, General Terms & Conditions
1. The following terms and conditions apply to the sale of machinery, components and related services and products, of Finish
Thompson Inc. (hereinafter “the products”)
2. Finish Thompson Inc. (the manufacturer) warrants only that:
a) its products are free of defects in material, design and workmanship at the time of original purchase;
b) its products will function in accordance with Finish Thompson Inc. operation manuals; Finish Thompson Inc. does not
guarantee that the product will meet the precise needs of the Customer, except for those purposes set out in any invitation
to render documents or other documents specifically made available to Finish Thompson Inc. before entering into this
agreement;
c) high quality materials are used in the construction of the pumps and that machining and assembly are carried out to the
highest standards. Except as expressly stated above, Finish Thompson Inc. makes no warranties, express or implied,
concerning the products, including all warranties of fitness for a particular purpose.
This warranty shall not be applicable in circumstances other than defects in material, design, and workmanship. In particular
warranty shall not cover the following:
d) Periodic checks, maintenance, repair and replacement of parts due to normal wear and tear;
e) Damage to the product resulting from:
i. Tampering with, abuse or misuse, including but not limited to failure to use the product for its normal purposes as
stated at the time of purchase or in accordance with Finish Thompson, Inc. instructions for use and maintenance of the
product, or the installation or improper ventilation or use of the product in a manner inconsistent with the technical or
safety standard in force;
ii. Repairs performed by non-authorized service workshop, or opening of the unit by non-authorized personnel, or use of
non genuine Finish Thompson Inc. parts;
iii. Accidents, force majeure or any cause beyond the control of Finish Thompson Inc., including but not limited to light-
ning, water, fire, earthquake, and public disturbances, etc.
3. The warranty shall cover the replacement or repair of any part, which is documented to be faulty due to construction or as-
sembling, with new or repaired parts free of charge delivered by Finish Thompson, Inc. Parts subjected to normal wear and
tear shall not be covered by the warranty. Finish Thompson, Inc. shall decide as to whether the defective or faulty part shall be
replaced or repaired. Transportation charges are prepaid to Finish Thompson.
4. The warranty of the products shall be valid for a period of 12 months from the date of delivery, under the condition that notice
of the alleged defect to the products or parts thereof be given to Finish Thompson, Inc. within the term of 8 days from the
discovery.
5. Repair or replacement under the terms of this warranty shall not give a right to an extension to, or a new commencement of,
the period of warranty. Repair or replacement under the terms of this warranty may be fulfilled with functionally equivalent re-
conditioned units. Finish Thompson Inc. qualified personnel shall be solely entitled to carry out repair or replacement of faulty
parts after careful examination of the motor. Faulty parts or components when replaced by Finish Thompson Inc. will become
the property of Finish Thompson Inc. If this warranty does not apply, the purchaser shall bear all cost for labor, material and
transportation.
6. Finish Thompson Inc. will not be liable on any claim, whether in contact, tort, or otherwise, for any indirect, special, incidental,
or consequential damages, caused to the customer or to third parties, including loss of profits, process down time, transpor-
tation costs, costs associated with replacement or substitution products, labor costs, installation or removal costs. In any and
all events, manufacturer’s liability shall not exceed the purchase price of the product and/or accessories.
7. Return Policy. Should you have any problems with this product, please contact the distributor in your area. The distributor
will determine if a return to the factory is necessary and will contact the factory for a Return Authorization Number. Otherwise,
contact our Technical Service Hotline [phone]) or e-mail techservice@finishthompson.com if you have any questions
regarding product operation or repair.
Warranty Registration
Thank you for your purchase of this quality Finish Thompson product. Be sure to take a minute to register your pump at
Finishthompson.com/warranty.Simply provide the model number, serial number and a few other pieces of information.

5
Safety
1. Introduction
This manual contains all the information needed for the correct installation, use and maintenance of your new Finish Thompson
pump and accessories. It should be read and understood by all the personnel involved in installation, operating and servicing of
the pump before it is started.
2. Operator Qualification and Training
The personnel in charge of the installation, the operation, and the maintenance of the pump must be qualified and able to per-
form the operations described in this manual. Finish Thompson, Inc. shall not be held responsible for the training level of
personnel and for the fact that they are not fully aware of the contents of this manual.
3. Safety Instructions
FOR YOUR OWN SAFETY
BEFORE using or servicing your pump or accessories, please make sure to wear the proper clothing, eye protection and follow
standard safety procedures when handling corrosive or personally harmful materials.
GENERAL DANGER
ALWAYS use a stainless steel pump tube with an explosion proof electric motor or air motor and static protection kit with
grounded discharge hose when pumping or mixing flammable or combustible material.
ALWAYS ensure the pump, hose, and motor are bonded to ground, and the tanks/containers are separately bonded to
ground.
ALWAYS inspect the integrity of the ground wire connections prior to each use.
NEVER leave the pump unattended while in use.
NEVER run the pump dry without fluid.
NEVER run the pump with a closed valve (deadhead) for longer than 1 minute.
ALWAYS use and store the pump and motor in an upright position.
NEVER use in pressurized containers.
ALWAYS use a chemically compatible hose rated for the temperature of the product being pumped.
ALWAYS tighten and torque a stainless steel hose clamp to 25 in-lbs (2.8 N·m)
ALWAYS check the pump for leaks on a regular basis. If leaks are noticed, the pump must be repaired or replaced immediately.
DANGER: POWER SUPPLY
Refer to instructions for the appropriate motor in the Operation & Installation Manual - Drum Pump Motors.
4. Noise Level
Refer to specifications in the Operation & Installation Manual - Drum Pump Motors.
5. Modifications and Spare Parts
Any changes concerning the service of the pump or accessories as originally purchased can be executed only after written
approval from Finish Thompson Inc. It is recommended to use only genuine Finish Thompson Inc. spare parts and approved
accessories. The use of non-original spare parts or non-approved accessories will void warranty and removes any responsibility
on the manufacturer’s behalf for any damage caused to people or things.
6. Cleaning
It is highly recommended to flush pumps and accessories with clean water or some other neutralizing fluid compatible with
pump materials when done pumping or when switching chemicals.

6
IMPORTANT SAFETY INFORMATION FOR PUMPING FLAMMABLE OR HAZARDOUS SUBSTANCES
Read these instructions before operating the pump and motor equipment. The manufacturer will not be responsible for any damage to property or to persons
caused by improper use of the equipment.
WARNING: It is the responsibility of the user to operate the pump in conformance with OSHA rules for dispensing liquids. Pump containers should be
grounded when using with flammable or combustible liquids to avoid static electricity.
1. Use only an explosion-proof rated electric or non-electric (air) motors on stainless steel pump tubes with a Static Protection Kit when transferring flammable
or combustible liquids.
WARNING: Never use an open, splash-proof, TEFC, battery-operated or non-explosion-proof rated motor or a plastic pump tube when transferring flammable
or combustible liquids.
2. When operating a drum pump (especially when pumping flammable, combustible or hazardous liquids) follow all electrical and safety codes.
a) In the United States: the United States Occupational Safety and Health Act (OSHA), most recent National Electrical Code (NEC), National Fire
Protection, Inc. (NFPA) Code 30 (Flammable and Combustible Code), NFPA 77 (Static Electricity), NFPA 251 (Standard Method of fire Test of Building
Construction), NFPA 704 (Identification of the Fire Hazards of Materials), and other NFPA codes, local codes and ordinances.
b) Outside the United States: the ATEX equipment directive 2014/34/EU where applicable, the ATEX workplace 99/92/EC directive where applicable, in
addition the precautions of the U.S. codes listed herein and all other local codes and ordinances.
3. Pumping hazardous, flammable, or combustible liquids should only be done in buildings, rooms, or areas suited for this purpose. (See NFPA 30, NFPA 78,
NFPA 80, NFPA 251, NFPA 704, other suitable NFPA codes, OSHA, ATEX workplace 99/92/EC directive insurance companies, and other local codes and ordi-
nances.)
4. When filling cans, drums, etc. with combustible or flammable liquids, both container pumping from and container pumping to, should be bonded and
grounded to dissipate possible accumulations of static electricity, and minimize sparks caused by static electricity (refer to NFPA 77 and CLC/TR 60079-32-1
for specific details).
WARNING: Avoid splashing. Splash filling can create static electricity and is extremely hazardous. Reduce motor speed to prevent splashing.
WARNING: Fluid velocity must be 3 feet/.9 meter/second maximum (7 gpm/26.5 lpm in 1” hose and 4 gpm/15 lpm in ¾” hose) to reduce risk of static electric-
ity. Reduce motor speed to reduce the fluid velocity.
5. Before using, confirm that the pump and any accessories (hose, nozzle, flow meter, etc.) materials of construction are suitable for the material to be pumped
and that the maximum temperature is not exceeded.
INFORMATIONS IMPORTANTES SUR LA SÉCURITÉ DURANT LE POMPAGE DE SUBSTANCES INFLAMMABLES OU DANGEREUSES
Veuillez lire attentivement ces instructions avant d’utiliser la pompe et l’équipement du moteur. Le fabricant ne sera pas tenu responsable des dommages matéri-
els ou corporels causés par une utilisation inappropriée de l’équipement.
AVERTISSEMENT: Il est de la responsabilité de l’utilisateur de faire fonctionner la pompe conformément aux règles OSHA (Santé et Sécurité au Travail)
relatives à la distribution de liquides. Les conteneurs de pompes doivent être électriquement mis à la terre lors de l’utilisation de liquides inflammables ou
combustibles afin d’éviter toute électricité statique.
1. Lors du transfert de liquides inflammables ou combustibles, utilisez uniquement des moteurs électriques ou non électriques (pneumatiques) antidéflagrants
sur des tubes de pompe en acier inoxydable dotés d’un dispositif de protection antistatique.
AVERTISSEMENT: N’utilisez jamais de moteur ouvert, à l’épreuve des éclaboussures, TEFC, alimenté par piles ou non antidéflagrant, ni un tube de pompe en
plastique lors du transfert de liquides inflammables ou combustibles.
2. Lors de l’utilisation d’une pompe à tambour (en particulier lors du pompage de liquides inflammables, combustibles ou dangereux), respectez tous les codes
électriques et les codes de sécurité.
a) Aux États-Unis : Loi américaine sur la sécurité et la santé au travail (OSHA); le code national de l’électricité (NEC) le plus récent; le code 30 de la
NFPA (code d’inflammabilité et de produits combustibles); le code NFPA 77 (électricité statique); le code NFPA 251 (Méthode standard de test
d’incendie de la construction de bâtiments); le code NFPA 704 (Identification des risques d’incendie des matériaux) et autres codes et règlements de
la NFPA.
b) En dehors des États-Unis : La directive sur les équipements ATEX 2014/34 / EU, le cas échéant, la directive ATEX sur le lieu de travail 99/92 /EC, le
cas échéant, ainsi que les précautions des codes des États-Unis énumérés dans la présente et de tous les autres codes, lois et règlements locaux.
3. Le pompage de liquides dangereux, inflammables ou combustibles ne doit être eectué que dans des bâtiments, des pièces ou des zones adaptées à cet
usage. (Voir NFPA 30, NFPA 78, NFPA 80, NFPA 251, NFPA 704, autres codes NFPA appropriés, OSHA, les directives des compagnies d’assurance ATEX 99/92
/CE, et autres codes, lois et règlements locaux.)
4. Lors du remplissage de bidons, fûts, etc. avec des liquides combustibles ou inflammables, les conteneurs d’où le liquide est pompé et le conteneur
recevant le liquide doivent être reliés et mis à la terre pour éviter toute accumulation éventuelle d’électricité statique et minimiser ainsi les étincelles
causées par l’électricité statique (voir NFPA 77). et CLC / TR 60079-32-1 pour des détails spécifiques).
AVERTISSEMENT: Évitez les éclaboussures. Les éclaboussures peuvent créer de l’électricité statique et sont extrêmement dangereuses. Réduisez la vitesse
du moteur pour éviter les éclaboussures.
AVERTISSEMENT: La vitesse du fluide doit être au maximum de 3 pieds / 0,9 mètre / seconde (7 gpm / 26,5 lpm dans un tuyau de 1”; et 4 gpm / 15 lpm
dans un tuyau de ¾”) afin de réduire le risque d’électricité statique. Réduisez la vitesse du moteur afin de réduire ainsi la vitesse du fluide.
5. Avant utilisation, assurez-vous que les matériaux de la pompe et des accessoires (tuyau, ajutage, débitmètre, etc.) sont compatibles avec le
fluide et que la température maximale n’est pas dépassée.

7
PUMP SPECIFICATIONS
MODEL TBS
Outer Tube Diameter 1-1/2” (3.8 cm)
Discharge Thread 1” hose barb
Max. Specific Gravity 1.4
Max. Viscosity 200 cP
Min./ Max. Fluid
Temperature
-20°F Min. to 150°F Max.
(-29°C Min. to 66°C Max.)
Wetted Materials 316 Stainless Steel, PTFE

8
Installation & Maintenance Instructions
Installation
1. Remove the drum pump and motor from its packaging and inspect for shipping damage.
2. Turn the pump coupling to verify there is no binding.
3. Adjust the coupling so that the empty slots in the insert are at 3 and 9 o’clock with the pump discharge at 12
o’clock.
5. Install the motor according to instructions in the appropriate motor manual.
6. Attach discharge hose and install pump into the container. Torque Finish Thompson hose clamps to 25 in-lbs
(2.8 N·m)
Operation
1. Make sure the motor (electric or air) is properly installed on the pump tube and is in the o position. See
motor instruction manual for installation instructions.
2. Insert the pump tube into the uid to be dispensed and the hose into the container to be lled prior to
starting the pump. Bung adapters are available to provide a tighter t between the pump tube and bung
opening of a standard drum. Check drum pump accessories at www.nishthompson.com or contact your
local Finish Thompson distributor for bung adapter info.
3. Make sure the pump’s discharge hose is properly secured before operating the motor.
4. Begin pumping by turning the motor on and verifying that there are no leaks. If leaks are noticed immedi-
ately turn the motor o and check all discharge hose connections.
NEVER allow the pump to run dry.
Maintenance
Disassembly
1. Loosen the setscrew and remove the half coupling (item 2) from the end of the pump shaft.
2. Gently holding the intake tube so as not to crush the tube, use a 3/8” punch and hammer to drive the bottom
of the shaft (item 11) toward the top. This will drive the bearing assembly (item 3) out of the top of the
pump. Stop when the bearing assembly is exposed.
3. Use a 1/8” punch and drive out the roll pin that is located in the center of the bearing assembly (item 3), and
slide the bearing assembly o of the shaft.
4. Remove the pump shaft assembly by pushing it down through the intake tube (item 7) and out the bottom.
5. Remove the seal assembly (item 4) and discard. Never re-use a seal assembly.
Inspection
1. Visually inspect the impeller assembly (item 8), the center bearings (item 10), and the compressor (item 12)
for damage and replace as needed.

9
2. Inspect the bearing assembly for rust, corrosion, or tightness and replace as needed.
3. Inspect the pump shaft in the seal area and the center bearing areas for excessive wear. Replace the shaft if
needed.
Reassembly
1. Insert the shaft assembly up through the bottom of the tube until it sticks out the top of the pump head.
2. Warm up the seal assembly (item 4) prior to installation by using a heat lamp or socking them in hot water.
This will aid in the ease of proper seal installation. Make sure there are no metal burrs on the pump shaft in
the bearing hole location or the coupling half setscrew location that could “cut” the seal during installation.
3. Lubricate the end of the shaft with Vaseline to aid in the seal installation. Carefully install the seal down
over the shaft with the two “slots” facing up toward the bearing assembly. The raised lip in the center of the
seal (that faces the bottom of the pump) must go on straight and not buckle on one side.
4. After the seal is on the shaft correctly, install the bearing assembly (item 3) onto the shaft. Use the bearing
assembly to push the seal further down the shaft until the hole in the center of the bearing assembly matches
up to the hole in the shaft. Install the roll pin through the bearing assembly and shaft.
5. Line up the bearing assembly with the top of the pump head and press the bearing in. Use a block of wood
and a mallet if needed.
6. Install the coupling half and tighten the setscrew into the dimple in the shaft. Spin the coupling to insure
there is no binding.
Note: Repair instructions can be downloaded from our web site at www.nishthompson.com or contact Technical Service at
1-800-888-3743.

10
TBS SPARE PARTS EXPLODED VIEW

11
ITEM QTY DESCRIPTION PART NUMBER
1 1 COUPLING INSERT
J100014
2 1 COUPLING HALF
J100013
3* 1 BEARING ASSEMBLY
W/ ROLL PIN A101672
4* 1 SEAL ASSEMBLY
PTFE A100284
5 1 LOCK WASHER
#8 BRASS J100823
6 1 SCREW
#8-32 X 1/4 BRASS PAN HEAD M/S J100822
7 1 INTAKE TUBE ASSEMBLY
40” 316 STAINLESS STEEL A100927-4
8 1 IMPELLER ASSEMBLY
PTFE WITH STAINLESS STEEL PIN A100030
9 1 SPACER SET
FEP A100031-1
10* 3 CENTER BEARING
PTFE M100039
11 1 SHAFT
40” 316 STAINLESS STEEL M100011-3
12* 1 COMPRESSOR
PTFE WITH STAINLESS STEEL PIN A100033
SPARE PARTS LIST
*Recommended Spare Parts

Service 1-800-888-3743
P/N 108099 REV. 5, 3/27/2020
