SFS SERIES PUMPS
SFS & SFS-H MODELS
OPERATION & PARTS MANUAL
P/N 111522

EU Declaration of Conformity
Finish Thompson Inc. hereby declares that the following machine(s) fully comply with the
applicable health and safety requirements as specified by the EU Directives listed. The product may
not be taken into service until it has been established that the drive motor for the Drum and
Container Pump complies with the provisions of all relevant EU Directives. The complete product
complies with the provisions of the EU Directive on machinery safety provided motors
manufactured by Finish Thompson Inc. are used.
This declaration is valid provided that the devices are fully assembled and no modifications are
made to these devices.
Type of Device
Drum and Container Pump
Tubes
Models:
EU Directives:
Machinery Safety (2006/42/EC)
Applied Harmonized Standards
ISEN O 12100:2010
EN
809 1998+A1:2009
Manufacturer:
Finish
Thompson
Inc.
921 Greengarden
Road
Erie, Pennsylvania 16501-1591
U.S.A
Signed,
_
President
Person(s) Authorized to Compile Technical File: Finish Thompson GmbH
Otto-Hahn-Strasse 16
Maintal, D-63477 DEU
Telephone: [phone]
EFP/EFV/EFS-16/27/40/48/54
PFM-27/40/48/ 60
PFV-27/40/48/ 60/72
TTC/TTS-27/40/48
BTS – 40
HVDP LR-27/40/48
PFP-27/40/48/ 60/72
TBP-27/40/48
STTS-40
HVDP HR-27/40/ 8
PFS-27/40/48/ 60/72
TBS-40
TMS-40
SFM/SFM-DEF/SFP/SFV/SFVV/SFS
27/40/48/54/60/72
24 June 2022

3
Introduction
This manual pertains to the SFS Series drum pumps and accessories. Finish Thompson Inc. thanks you for choosing our products. We believe the
use of our products will be fully satisfactory. When properly installed and operated, your Finish Thompson motor and pump will provide long,
trouble-free service; therefore, please read this manual carefully before carrying out any operations on the pump/motor unit. Any use other than
that described herein is considered incorrect; and, consequently, Finish Thompson Inc. shall not be held responsible for any damages to people or
property. In case of doubt or enquiries, please reply to our Technical Service department directly at the following address:
Finish Thompson, Inc.
921 Greengarden Rd.
Erie, PA 16501 U.S.A.
Tel. [phone]; Fax [phone]
www.finishthompson.com; fti@finishthompson.com
Index
Introduction................................................................................................................................. 3
Warranty, General Terms & Conditions ............................................................................................... 4
Safety......................................................................................................................................... 5
Important Safety Information for Pumping Flammable or Hazardous Substances ....................................... 6
Specifications & Dimensions ............................................................................................................ 7
Operation .................................................................................................................................... 8
Disassembly................................................................................................................................. 9-10
Reassembly.................................................................................................................................. 11-12
Exploded View – SFS Pump Tube...................................................................................................... 13
Pump Tube Spare Parts List ............................................................................................................. 14-16
Note: Repair instructions can be downloaded from our web site at www.finishthompson.com or contact
Technical Service at 1-800-888-3743.

4
Warranty, General Terms & Conditions
Finish Thompson, Inc (manufacturer) warrants this pump product to be free of defects in materials and workmanship for a period of one year from date
of purchase by original purchaser. If a warranted defect, which is determined by manufacturer’s inspection, occurs within this period, it will be repaired or
replaced at the manufacturer’s option, provided (1) the product is submitted with proof of purchase date and (2) transportation charges are prepaid to the
manufacturer. Liability under this warranty is expressly limited to repairing or replacing the product or parts thereof and is in lieu of any other warranties,
either expressed or implied. This warranty does not apply to normal wear of the product or components. This warranty does not apply to products or parts
broken due to, in whole or in part, accident, overload, abuse, chemical attack, tampering, or alteration. The warranty does not apply to any other equip-
ment used or purchased in combination with this product. The manufacturer accepts no responsibility for product damage or personal injuries sustained
when the product is modified in any way. If this warranty does not apply, the purchaser shall bear all cost for labor, material and transportation.
Manufacturer shall not be liable for incidental or consequential damages including, but not limited to, process down time, transportation costs, costs asso-
ciated with replacement or substitution products, labor costs, product installation or removal costs, or loss of profit. In any and all events, manufacturer’s
liability shall not exceed the purchase price of the product and/or accessories.
Warranty Registration
Thank you for your purchase of this quality Finish Thompson product. Be sure to take a minute to register your pump at Finishthompson.com/warranty. Simply
provide the model number, serial number and a few other pieces of information.

5
Safety
1. Introduction
This manual contains all the information needed for the correct installation, use and maintenance of your new Finish Thompson pump and accessories. It
should be read and understood by all the personnel involved in installation, operating and servicing of the pump before it is started.
2. Operator Qualification and Training
The personnel in charge of the installation, the operation, and the maintenance of the pump must be qualified and able to perform the operations
described in this manual. Finish Thompson, Inc. shall not be held responsible for the training level of personnel and for the fact that they are not fully
aware of the contents of this manual.
3. Safety Instructions
FOR YOUR OWN SAFETY
BEFORE using or servicing your pump or accessories, please make sure to wear the proper clothing, eye protection and follow standard safety
procedures when handling corrosive or personally harmful materials.
GENERAL DANGER
While operating in a hazardous environment or pumping flammable or combustible materials:
ALWAYS use a conductive grounded discharge hose and grounding wire according to these instructions under the section below titled "Static
Protection Kit Assembly." The grounded discharge hose must comply with ISO 80079-36 and CLC/TR 60079-32-1, and must not exceed 10^6 ohms
between each end. Certain fluid applications with the pump may lead to electrostatic discharges. Ensure proper grounding and transferring methods are
followed for the particular fluid.
ALWAYS use a Finish Thompson Haz Loc or ATEX motor rated for the hazardous environment.
NEVER use a plastic pump, plastic accessory, or an open, splash-proof, TEFC, non-Haz Loc, or non-ATEX motor when pumping or mixing flammable or
combustible material.
ALWAYS ensure the pump, hose, and motor are bonded to ground, and the tanks/containers are separately bonded to ground.
ALWAYS inspect the integrity of the ground wire connections prior to each use.
ALWAYS ensure all components above the hose discharge of the pump (motor, bearing, coupling, etc) reside outside of the tank/container.
NEVER leave the pump unattended while in use.
NEVER run the pump dry without fluid.
NEVER run the pump with a closed valve (deadhead) for longer than 1 minute.
ALWAYS use and store the pump and motor in an upright position.
NEVER use in pressurized containers.
ALWAYS use a chemically compatible hose rated for the temperature of the product being pumped.
ALWAYS tighten and torque a stainless steel hose clamp to 25 in-lbs (2.8 N·m)
ALWAYS select the proper o-ring material. Improper material selection could lead to swelling and be a possible source of leaks. This is the
responsibility of the end user.
ALWAYS check the pump for leaks on a regular basis. If leaks are noticed, the pump must be repaired or replaced immediately.
ALWAYS check compatibility and temperature range of pump with liquids used. A Chemical Resistance and Material Selection Guide can be down
loaded from our website at www.finishthompson.com
NEVER use with liquids containing solids that can damage the internals (i.e. metal chips) without optional strainer.
ALWAYS store unit upright, i.e. motor above pump, and away from corrosive liquids and vapors.
ALWAYS check bearings and coupling insert for signs of overheating, abnormal noise or other signs of premature failure on a daily basis. Bearings
and coupling insert should be replaced at the first sign of failure.
DANGER: POWER SUPPLY
Refer to instructions in the appropriate motor Operation & Installation Manual.
4. Noise Level
Refer to specifications in the appropriate motor Operation & Installation Manual.
5. Modifications and Spare Parts
Any changes concerning the service of the pump or accessory as originally purchased can be executed only after written approval from Finish Thompson
Inc. It is recommended to use only genuine Finish Thompson Inc. spare parts and approved accessories. The use of non-original spare parts or non-
approved accessories will void warranty and removes any responsibility on the manufacturer’s behalf for any damage caused to people or things.
6. Cleaning
It is highly recommended to flush pumps and accessories with clean water or some other neutralizing fluid compatible with pump materials when done
pumping or when switching chemicals.

6
IMPORTANT SAFETY INFORMATION FOR PUMPING FLAMMABLE OR HAZARDOUS SUBSTANCES
Read these instructions before operating the pump and motor equipment. The manufacturer will not be responsible for any damage to property or to persons
caused by improper use of the equipment.
WARNING: It is the responsibility of the user to operate the pump in conformance with OSHA rules for dispensing liquids. Pump containers should be
grounded when using with flammable or combustible liquids to avoid static electricity.
1. Use only an explosion-proof rated electric or non-electric (air) motors on stainless steel pump tubes with a Static Protection Kit when transferring flammable
or combustible liquids.
WARNING: Never use an open, splash-proof, TEFC, battery-operated or non-explosion-proof rated motor or a plastic pump tube when transferring flam-
mable or combustible liquids.
2. When operating a drum pump (especially when pumping flammable, combustible or hazardous liquids) follow all electrical and safety codes.
a) In the United States: the United States Occupational Safety and Health Act (OSHA), most recent National Electrical Code (NEC), National Fire Protec-
tion, Inc. (NFPA) Code 30 (Flammable and Combustible Code), NFPA 77 (Static Electricity), NFPA 251 (Standard Method of fire Test of Building Construc-
tion), NFPA 704 (Identification of the Fire Hazards of Materials), and other NFPA codes, local codes and ordinances.
b) Outside the United States: the ATEX equipment directive 2014/34/EU where applicable, the ATEX workplace 99/92/EC directive where applicable, in
addition the precautions of the U.S. codes listed herein and all other local codes and ordinances.
3. Pumping hazardous, flammable, or combustible liquids should only be done in buildings, rooms, or areas suited for this purpose. (See NFPA 30, NFPA 78, NFPA
80, NFPA 251, NFPA 704, other suitable NFPA codes, OSHA, ATEX workplace 99/92/EC directive insurance companies, and other local codes and ordinances.)
4. When filling cans, drums, etc. with combustible or flammable liquids, both container pumping from and container pumping to, should be bonded and grounded to
dissipate possible accumulations of static electricity, and minimize sparks caused by static electricity (refer to NFPA 77 and CLC/TR 60079-32-1 for specific details).
WARNING: Avoid splashing. Splash filling can create static electricity and is extremely hazardous. Reduce motor speed to prevent splashing.
WARNING: Fluid velocity must be 3 feet/.9 meter/second maximum (7 gpm/26.5 lpm in 1” hose and 4 gpm/15 lpm in ¾” hose) to reduce risk of static
electricity. Reduce motor speed to reduce the fluid velocity.
5. Before using, confirm that the pump and any accessories (hose, nozzle, flow meter, etc.) materials of construction are suitable for the material to be
pumped and that the maximum temperature is not exceeded.
INFORMATIONS IMPORTANTES SUR LA SÉCURITÉ DURANT LE POMPAGE DE SUBSTANCES INFLAMMABLES OU DANGEREUSES
Veuillez lire attentivement ces instructions avant d’utiliser la pompe et l’équipement du moteur. Le fabricant ne sera pas tenu responsable des dommages maté-
riels ou corporels causés par une utilisation inappropriée de l’équipement.
AVERTISSEMENT: Il est de la responsabilité de l’utilisateur de faire fonctionner la pompe conformément aux règles OSHA (Santé et Sécurité au Travail)
relatives à la distribution de liquides. Les conteneurs de pompes doivent être électriquement mis à la terre lors de l’utilisation de liquides inflammables ou
combustibles afin d’éviter toute électricité statique.
1. Lors du transfert de liquides inflammables ou combustibles, utilisez uniquement des moteurs électriques ou non électriques (pneumatiques) antidéflagrants
sur des tubes de pompe en acier inoxydable dotés d’un dispositif de protection antistatique.
AVERTISSEMENT: N’utilisez jamais de moteur ouvert, à l’épreuve des éclaboussures, TEFC, alimenté par piles ou non antidéflagrant, ni un tube de pompe
en plastique lors du transfert de liquides inflammables ou combustibles.
2. Lors de l’utilisation d’une pompe à tambour (en particulier lors du pompage de liquides inflammables, combustibles ou dangereux), respectez tous les
codes électriques et les codes de sécurité.
a) Aux États-Unis : Loi américaine sur la sécurité et la santé au travail (OSHA); le code national de l’électricité (NEC) le plus récent; le code 30 de la
NFPA (code d’inflammabilité et de produits combustibles); le code NFPA 77 (électricité statique); le code NFPA 251 (Méthode standard de test d’incendie de la
construction de bâtiments); le code NFPA 704 (Identification des risques d’incendie des matériaux) et autres codes et règlements de la NFPA.
b) En dehors des États-Unis : La directive sur les équipements ATEX 2014/34 / EU, le cas échéant, la directive ATEX sur le lieu de travail 99/92 /EC, le cas
éché ant, ainsi que les précautions des codes des États-Unis énumérés dans la présente et de tous les autres codes, lois et règlements locaux.
3. Le pompage de liquides dangereux, inflammables ou combustibles ne doit être eectué que dans des bâtiments, des pièces ou des zones adaptées à cet
usage. (Voir NFPA 30, NFPA 78, NFPA 80, NFPA 251, NFPA 704, autres codes NFPA appropriés, OSHA, les directives des compagnies d’assurance ATEX 99/92/
CE, et autres codes, lois et règlements locaux.)
4. Lors du remplissage de bidons, fûts, etc. avec des liquides combustibles ou inflammables, les conteneurs d’où le liquide est pompé et le conteneur
recevant le liquide doivent être reliés et mis à la terre pour éviter toute accumulation éventuelle d’électricité statique et minimiser ainsi les étincelles
causées par l’électricité statique (voir NFPA 77). et CLC / TR 60079-32-1 pour des détails spécifiques).
AVERTISSEMENT: Évitez les éclaboussures. Les éclaboussures peuvent créer de l’électricité statique et sont extrêmement dangereuses. Réduisez la vitesse
du moteur pour éviter les éclaboussures.
AVERTISSEMENT: La vitesse du fluide doit être au maximum de 3 pieds / 0,9 mètre / seconde (7 gpm / 26,5 lpm dans un tuyau de 1”; et 4 gpm / 15 lpm dans
un tuyau de ¾”) afin de réduire le risque d’électricité statique. Réduisez la vitesse du moteur afin de réduire ainsi la vitesse du fluide.
5. Avant utilisation, assurez-vous que les matériaux de la pompe et des accessoires (tuyau, ajutage, débitmètre, etc.) sont compatibles avec le fluide et que la
température maximale n’est pas dépassée.

7
PUMP SPECIFICATIONS
Impeller Type High Flow (standard oering) or High Head "-H"
Discharge Spout 1" (DN 25 (25MM)) Barb
(standard) 1" BSPP Thread (Model -BSP) 1" NPT Thread (Model -MT) 1" Tri-Clamp Fitting (Model -TC)
Discharge Attachment
Thread 1-1/4" BSPP
Outer Tube Diameter 1-5/8" (41mm)
Max. Specific Gravity 2.0
Max. Viscosity 1200 cP
Min./ Max. Fluid Tempera-
ture
5°F (-15°C) Min.
212°F (100°C) Max.
Wetted Pump Components 316SS, PTFE, ETFE
Wetted O-rings Option of: FKM, FFKM, FDA FFKM or FDA Buna
* SFV-54, SFV-60, SFV-72: 140°F (60°C) Max. SFVV-54, SFVV-60, SFVV-72: 115°F (46°C) Max.
1 5/8"
41mm
DIM B
DIM A
6 1/16"
154mm
5 5/8"
142mm
13 3/16"
335mm
5 7/16"
139mm
4 11/16"
119mm
9 7/8"
251mm
MOUNTING FACE
M6 & M6A AIR MOTORS
MV MOTOR SHOWN ON PUMP
TEFC & EXP MOTORS
MOUNTING FACE
MOUNTING FACE
MV MOTORS
MOUNTING FACE
CAD GENERATED DRAWING,
DO NOT MANUALLY UPDATE
TITLE
PRODUCT:
CHECKED
SIZE:
DIMENSIONS ARE IN INCHES
TOLERANCES ARE:
.XXX .005
.XX
.010
FRAC.
1/32
DEGREE
1°
FINISH 125
SIGNATURES
DO NOT SCALE DRAWING
SCALE: SHEET
REV.
PART NUMBER
UNLESS OTHERWISE SPECIFIED
DISTRIBUTION BLOCK
DATE
DRAWN:
ENGR:
DEPT
REC'D
DEPT
REC'D
PUMP ASSM
STILL ASSM
WELD SHOP
MACH SHOP
INJ MOLD
PURCH
SALES
ADV
A
921 GREENGARDEN ROAD
ERIE, PENNSYLVANIA 16501
PHONE: [phone]
FAX: [phone]
XX-XX-XX
3/26/21
R102360
OUTLINE DIMENSIONAL
SFS
0
X
1 OF 1
THIRD ANGLE
PROJECTION
DAC
X
MODEL DIM A DIM B
SFS27 26 7/8" (683mm) 28 7/16" (722mm)
SFS40 39 7/8" (1013mm) 41 7/16" (1053mm)
SFS48 47 7/8" (1216mm) 49 7/16" (1256mm)
SFS54 53 7/8" (1368mm) 55 7/16" (1408mm)
SFS60 59 7/16" (1510mm) 61 1/16" (1551mm)
SFS72 72 9/16" (1843mm) 74 1/8" (1883mm)
1 5/8"
41mm
DIM B
DIM A
6 1/16"
154mm
5 5/8"
142mm
13 3/16"
335mm
5 7/16"
139mm
4 11/16"
119mm
9 7/8"
251mm
MOUNTING FACE
M6 & M6A AIR MOTORS
MV MOTOR SHOWN ON PUMP
TEFC & EXP MOTORS
MOUNTING FACE
MOUNTING FACE
MV MOTORS
MOUNTING FACE
CAD GENERATED DRAWING,
DO NOT MANUALLY UPDATE
TITLE
PRODUCT:
CHECKED
SIZE:
DIMENSIONS ARE IN INCHES
TOLERANCES ARE:
.XXX .005
.XX
.010
FRAC.
1/32
DEGREE
1°
FINISH 125
SIGNATURES
DO NOT SCALE DRAWING
SCALE: SHEET
REV.
PART NUMBER
UNLESS OTHERWISE SPECIFIED
DISTRIBUTION BLOCK
DATE
DRAWN:
ENGR:
DEPT
REC'D
DEPT
REC'D
PUMP ASSM
STILL ASSM
WELD SHOP
MACH SHOP
INJ MOLD
PURCH
SALES
ADV
A
921 GREENGARDEN ROAD
ERIE, PENNSYLVANIA 16501
PHONE: [phone]
FAX: [phone]
XX-XX-XX
3/26/21
R102360
OUTLINE DIMENSIONAL
SFS
0
X
1 OF 1
THIRD ANGLE
PROJECTION
DAC
X
1 5/8"
41mm
DIM B
DIM A
6 1/16"
154mm
5 5/8"
142mm
13 3/16"
335mm
5 7/16"
139mm
4 11/16"
119mm
9 7/8"
251mm
MOUNTING FACE
M6 & M6A AIR MOTORS
MV MOTOR SHOWN ON PUMP
TEFC & EXP MOTORS
MOUNTING FACE
MOUNTING FACE
MV MOTORS
MOUNTING FACE
CAD GENERATED DRAWING,
DO NOT MANUALLY UPDATE
TITLE
PRODUCT:
CHECKED
SIZE:
DIMENSIONS ARE IN INCHES
TOLERANCES ARE:
.XXX .005
.XX
.010
FRAC.
1/32
DEGREE
1°
FINISH 125
SIGNATURES
DO NOT SCALE DRAWING
SCALE: SHEET
REV.
PART NUMBER
UNLESS OTHERWISE SPECIFIED
DISTRIBUTION BLOCK
DATE
DRAWN:
ENGR:
DEPT
REC'D
DEPT
REC'D
PUMP ASSM
STILL ASSM
WELD SHOP
MACH SHOP
INJ MOLD
PURCH
SALES
ADV
A
921 GREENGARDEN ROAD
ERIE, PENNSYLVANIA 16501
PHONE: [phone]
FAX: [phone]
XX-XX-XX
3/26/21
R102360
OUTLINE DIMENSIONAL
SFS
0
X
1 OF 1
THIRD ANGLE
PROJECTION
DAC
X
1 5/8"
41mm
DIM B
DIM A
6 1/16"
154mm
5 5/8"
142mm
13 3/16"
335mm
5 7/16"
139mm
4 11/16"
119mm
9 7/8"
251mm
MOUNTING FACE
M6 & M6A AIR MOTORS
MV MOTOR SHOWN ON PUMP
TEFC & EXP MOTORS
MOUNTING FACE
MOUNTING FACE
MV MOTORS
MOUNTING FACE
CAD GENERATED DRAWING,
DO NOT MANUALLY UPDATE
TITLE
PRODUCT:
CHECKED
SIZE:
DIMENSIONS ARE IN INCHES
TOLERANCES ARE:
.XXX .005
.XX
.010
FRAC.
1/32
DEGREE
1°
FINISH 125
SIGNATURES
DO NOT SCALE DRAWING
SCALE: SHEET
REV.
PART NUMBER
UNLESS OTHERWISE SPECIFIED
DISTRIBUTION BLOCK
DATE
DRAWN:
ENGR:
DEPT
REC'D
DEPT
REC'D
PUMP ASSM
STILL ASSM
WELD SHOP
MACH SHOP
INJ MOLD
PURCH
SALES
ADV
A
921 GREENGARDEN ROAD
ERIE, PENNSYLVANIA 16501
PHONE: [phone]
FAX: [phone]
XX-XX-XX
3/26/21
R102360
OUTLINE DIMENSIONAL
SFS
0
X
1 OF 1
THIRD ANGLE
PROJECTION
DAC
X

8
OPERATION
1. Make sure the motor (electric or air) is properly installed on the pump tube and is in the o position. See
motor instruction manual for installation instructions.
2. Insert the pump tube into the fluid to be dispensed and the hose into the container to be filled prior to starting the pump. Bung adapters are available to provide
a tighter fit between the pump tube and bung opening of a standard drum. Check drum pump accessories at www.finishthompson.com or contact your local Finish
Thompson distributor for bung adapter info.
3. Make sure the pump’s discharge hose is properly secured before operating the motor, torque Finish Thompson hose clamps to 25 in-lbs(2.8 N·m).
4. Begin pumping by turning the motor on and verifying that there are no leaks. If leaks are noticed immediately turn the motor o and check all discharge hose
connections.
NEVER allow the pump to run dry.
NEVER pump liquids containing solids that can damage internal pump parts (i.e. metal chips). Pumping solids
can lead to increased wear.
Static Protection Kit Assembly
Hose attachment to pump:
1. Place the stainless steel hose clamp onto the short section of the grounded hose.
2. Slide the short section of the grounded hose assembly over the pump tubes discharge spout. Tighten and torque the SS clamp to 25 in-lbs (2.8 N-m).
3. Attach the ground wire assembly to the pump tube using the #8 ring terminal and supplied 8-32 x 1/4" brass screw and brass lock washer.
4. Attach the ground wire assembly to the motor (see instructions below).
5. Check the electrical continuity between the clamp on the end of the ground wire assembly and the end of the grounded hose. The electrical resistance must be one (1)
Ohm or less. If it is greater than one (1) Ohm, re-check all connections.
Hose & Cord Storage
SF model pumps have a built-in hose & cord clip. You can use these clips to store your hose and keep the plug o the floor, free of damage and corrosion. When
selecting a discharge hose, you should use a 1" ID reinforced chemically compatible hose secured with a stainless steel hose clamp. See figures A and B below.
Choice of two types of Impellers
The SFS-Series pump models can be ordered with either a "High Flow" or "High Head" impeller. The high flow impeller utilizes an axial design impeller and built in
strainer/diuser cover for quickly dispensing fluids from drums & totes. The high head impeller utilizes a centrifugal design impeller to produce high head for dispensing
through long hose runs or to overcome high system pressures. Either impeller can be used with the same pump but it is important to use the correct diuser cover to
attain the proper performance. See figures below.
Figure B
Figure A
High Flow Impeller High Head Impeller

9
DISASSEMBLY & REASSEMBLY INSTRUCTIONS
Disassembly
Figure 1 A & B
1. Cover, Impeller, & Diuser Removal - Unthread the diuser
cover (item 22 or 23). Turn it clockwise (left-hand thread). See
Figure 1 A & B. Unthread the impeller (item 20 or 21) turning it
counter clockwise (right hand thread) using your hand while
holding the coupling insert and coupling (items 1 & 2) with the
other hand. See Figure 2 A & B. Note: If the shaft unthreads
from the coupling, use a pliers to hold the bottom of the shaft
just above the impeller. See figures 3 A & B. For longer 40” to
72” pump lengths, two people may be required to hold the shaft
and unthread the impeller.
2. Shaft Removal - To remove the shaft (item 4), tap the bottom
of the shaft on a piece of wood or plastic and push the shaft up
and out of the head (item 6). See Figure 4 A & B. Grab the half
coupling or bearing and pull the shaft assembly straight out of
the head. Note: Take care to not bend the shaft.
Important - The shaft should only be removed if the bearing
is frozen and needs to be replaced. Hold the pump shaft (item
4) with a pliers or vise grip. Turn the half coupling (item 2)
counter clockwise (right hand thread) to remove it from the
shaft. The bearing (item 3) will slide o the shaft. See Figure 5
A, B, and C. If the bearing is frozen or corroded to the shaft use
a penetrating fluid and socket to help tap it o. Install a new
bearing (item 3), reuse and hand tighten the half coupling (item
2). These items will only fit properly on one end of the shaft.
Figure 2 A & B
Figure 4 A & B
Figure 5 A, B, C
Figure 3 A & B

10
3. Intake Tube Removal - Unthread the diuser (item 18) turning
it clockwise (left-hand thread). The shaft sleeve (item 15) will
drop out of the inner tube by holding it in a vertical position.
Remove the intake tube (item 16). Hold the head (item 6) in one
hand and with the other hand, turn the intake tube clockwise
(left-hand thread). When completely unthreaded, pull the intake
tube away from the head exposing the inner tube (item 14) See
Figure 6 A, B, C, D, & E.
4. Inner Tube Removal - To remove the inner tube, turn the inner
tube to unseat the o-rings (item 13) and then pull the inner tube
away from the head. See Figure 7 A & B.
5. Outer Tube O-ring Replacement - If the o-ring (item 12) needs
replaced use an o-ring pick to pull it out of the pump head (item
6). See Figure 8 A, B & C.
6. Seal Removal - To remove the seal (item 5) from the head (item
6), use a hook tool, available at most hardware stores, to pull
the seal out from the top of the head. Take care not to damage
the seal seat area. See Figures 9 A & B. Note: The seal should
be replaced if worn or the bearing is failing or frozen.
Disassembly Continued
Figure 6 A, B, C, D, & E
Figure 9 A & B
Figure 7 A & B
Figure 8 A, B, & C

11
Reassembly
1. Seal Installation - Take the head (item 6), and install a new seal (item 5). It is recommended to lubricate the seal with a compatible lubricant or
water prior to pressing it in. Insert the open part of the seal into the lower bore of the head. Use a 7/16” (12 mm) dowel to press and seat the seal
into place. Seal sits slightly below the surface. See figures 10 A, B, C & D. If the outer tube o-ring (item 12) was removed, replace it before installing
the outer tube. A compatible lubricant or Vasoline can be used to help the tube slide up into place to engage the threads. Note:
never reuse an old lip seal.
Figure 10 A, B, C & D
2. Inner Tube Installation -
Reinstall the inner tube (item 14). The double o-ring side seats up
into the head with a slight twisting motion. Make sure the inner
tube is seated properly. It is recommended to use a compatible
lubricant or water on the o-rings. See figures 11 A & B.
3. Intake Tube Installation -
Install the intake tube (item 16). Slide the intake tube with
external threads over the inner tube up into the head (item 6).
While pushing the intake tube's threads beyond the o-ring, turn
the intake tube counter clockwise (left hand thread) to tighten it
into the head. Ensure the threads do not start to cross-thread.
Hand tighten. The bottom of the inner tube will be recessed
slightly with the bottom of the outer tube when properly seated.
See figures 12 A, B & C.
4. Reinstall the half coupling, bearing and shaft (items 2, 3, & 4
indicated on the Exploded View Drawing) as an assembly into the
head. If the bearing needs to be replaced see section 2 of the
disassembly instructions on the prior page. See figures 13 A & B.
Figure 13 A & B
Figure 11 A & B
Figure 12 A, B, & C

12
6. Diuser Installation - Install the diuser (item 8) onto the bottom of the outer tube. This is a tight fit so it is recommended to use a compatible
lubricant or water. Insert the shaft through the small support opening on the diuser. The small support opening will insert up inside the inner tube
(item 12). With a slight push and turn, thread the diuser into the outer tube (item 6) turning counter clockwise (left hand thread). Thread the diuser
(item 6) completely onto the bottom of the outer tube (item 5). Hand tighten. See figures 15 A, B, & C.
7. Thread the impeller (items 20 or 21) onto the shaft by hand. While holding the half coupling with the other hand, turn the impeller clockwise (right
hand thread). Install the diuser cover (item 22 or 23) onto the diuser turning counter clockwise (left hand thread). Hand Tighten. See Figures 16 A,
B, C, D, E, F, & G.
5. Shaft Installation - Slide the shaft down through the seal until the
bearing engages the bearing bore in the head. Set the half coupling
on the floor and push the pump down using the intake tube (item 16)
for leveridge. Make sure the bearing (item 3) is flush with the top of
the head (item 6). While the pump is in thie upright position slide the
shaft sleeve (item 15) between the shaft (item 4) and inner tube (item
14). The shaft sleeve is self positioning so just push it in all the way
completely into the inner tube. Sleeve is flared on the bottom to help
hold it in position. See figures 14 A, B, C, D.
Reassembly Continued
Figure 14 A, B, C, D
Figure 15 A, B, & C
Figure 16 A, B, C, D, E, F, & G

13
SFS SERIES PUMP
EXPLODED VIEW
PHONE: [phone]
1 OF 2
921 GREENGARDEN ROAD
FAX: [phone]
3/16/21
X
SFS
ERIE, PENNSYLVANIA 16501
PROJECTION
WELD SHOP
SPARE PARTS
1°
STILL ASSM
D
ADV
PUMP ASSM
SALES
PURCH
TOLERANCES ARE:
INJ MOLD
MACH SHOP
R102354
1
X
DO NOT MANUALLY UPDATE
TITLE
PRODUCT:
CHECKED
SIZE:
DIMENSIONS ARE IN INCHES
FINISH 125
SIGNATURES
DO NOT SCALE DRAWING
SCALE: SHEET
REV.
PART NUMBER
UNLESS OTHERWISE SPECIFIED DISTRIBUTION BLOCK
DATE
DRAWN:
ENGR:
DEPT REC'D DEPT REC'D
CAD GENERATED DRAWING,
.XXX .005
.XX .010
FRAC. 1/32
DEGREE
THIRD ANGLE
DAC
21
23
22
8B
10
12
11
20
18
19
1
2
3
4
5
6
78A
8C
14
15
16
9
17
13
8D
REV DESCRIPTION DATE APPR'D TRACK
0PRODUCT RELEASE 2/16/2021 DAC 5734
1CHG ITEMS TO 8A, 8B, 8C, 8D 6/1/2022 DAC -
RE VIS IONS
MODEL S FS MODEL SFS-H
RUBBER
ALUMINUM
STEEL
27"
40"
48"
54"
60"
72"
FKM (STANDARD)
PTFE (OPTIONAL)
316 STAINLESS STEEL
FKM (STANDARD)
FFKM (-FF MODELS)
FDA FFKM (-P MODELS)
FDA BUNA (-B MODELS)
8A 1" TRI-CLAMP (INCLUDES NUT) (-TC MODELS)
8B 1" BARB (DN 25) (STANDARD)
8C 1" NPT (-MT MODELS)
8D 1" BSPP (-BSP MODELS)
316 STAINLESS STEEL
#8 BRASS
#8-32 x 1/4 BRASS PAN HEAD
FKM (STANDARD)
FFKM (-FF MODELS)
FDA FFKM (-P MODELS)
FDA BUNA (-B MODELS)
FKM (STANDARD)
FFKM (-FF MODELS)
FDA FFKM (-P MODELS)
FDA BUNA (-B MODELS)
27"
40"
48"
54"
60"
72"
27"
40"
48"
54"
60"
72"
27"
40"
48"
54"
60"
72"
27" ELECTROPOLISHED (-P OR -B MODELS)
40" ELECTROPOLISHED (-P OR -B MODELS)
48" ELECTROPOLISHED (-P OR -B MODELS)
54" ELECTROPOLISHED (-P OR -B MODELS)
FKM (STANDARD)
FFKM (-FF MODELS)
FDA FFKM (-P MODELS)
FDA BUNA (-B MODELS)
316 STAINLESS STEEL
PTFE (STANDARD)
FDA PTFE (-P OR -B MODELS)
CFF ETFE (STANDARD) 111210-3 N/A
PURE ETFE (FOR MODELS ENDING IN -P OR -B) 111210-2 N/A
CFF ETFE (STANDARD) N/A 111211-3
PURE ETFE (FOR MODELS ENDING IN -P OR -B) N/A 111211-2
316 STAINLESS STEEL 111519 N/A
316 STAINLESS STEEL N/A 111520
*Recommended spare parts
DIFFUSER COVER - HIGH HEAD
DIFFUSER COVER - HIGH FLOW
IMPELLER - HIGH HEAD (FOR USE W ITH "DIFFFUSER COVER - HI GH HEAD")
122*
23* 1
108198
DIFFUSER
111517
18 1
111518-1
111518-2
IMPELLER - HIGH FLOW (FOR USE WITH "DIFFFUSER COVER - HIGH FLOW")
20* 1
21* 1
117*
119*
BUSHING, DIFFUSER
PART NUMBER
DESCRIPTION
4
SHAFT (316 STAINLESS STEEL)
BEARING
COUPLING HALF
1
111202-1
111202-5
111202-7
111202-9
111202-11
111202-3
QTYITEM
1
12
11*
111500
109526
COUPLING INSERT
SEAL
6 1 HEAD
O-RING, DISCHARGE SPOUT
107622
5* 1
J100014
111530
111057
107592
3*
OUTER TUBE (316 STAINLESS STEEL)
SHAFT SLEEVE (PTFE)
115*
116
111513-4
111513-5
DISCHARGE SPOUT (316 STAINLESS STEEL)
NUT
INNER TUBE (316 STAINLESS STEEL)
14 1
9 1
O-RING, INNER TUBE
111511
1
105080
111509
111510
108069
105620
108197
111502
111503
17*
111505
111508
J100018
111506
111507
111521
LOCK W ASHER
SCREW
J100822
J100823
10
11
1
1
111501
1
213*
O-RING, OUTER TUBE
12*
111512-2
111513-1
111513-2
111513-3
111513-7
107616-1
107616-2
107616-3
107616-7
111512-1
111515-1
111515-2
111515-3
111515-4
111515-5
111515-6
J100132
111516
107621
111532-1
111532-2
111532-3
111532-4
O-RING, DIFFUSER

14
PUMP SPARE PARTS LIST
ITEM QTY DESCRIPTION
PART NUMBER
MODEL SFS MODEL SFS-H
1* 1 COUPLING INSERT
RUBBER J100014
2 1 COUPLING HALF
ALUMINUM 111530
3* 1 BEARING
STEEL 111057
4 1
SHAFT (316 STAINLESS STEEL)
27” 111202-1
40” 111202-3
48” 111202-5
54” 111202-7
60” 111202-9
72” 111202-11
5* 1
SEAL
FKM (STANDARD) 107592
PTFE (OPTIONAL) 107622
6 1 HEAD
316 STAINLESS STEEL 111500
7* 1
O-RING, DISCHARGE SPOUT
FKM (STANDARD) 109526
FFKM (-FF MODELS) 111501
FDA FFKM (-P MODELS) 111502
FDA BUNA (-B MODELS) 111503
1
DISCHARGE SPOUT (316 STAINLESS STEEL)
8A 1" TRI-CLAMP (INCLUDES NUT) (-TC MODELS) 111505
8B 1" BARB (DN 25) (STANDARD) 111506
8C 1" NPT (-MT MODELS) 111507
8D 1" BSPP (-BSP MODELS) 111521
9 1 NUT
316 STAINLESS STEEL 111508
10 1 LOCK WASHER
#8 BRASS J100018
11 1SCREW
#8-32 x 1/4 BRASS PAN HEAD J100822
12* 2
O-RING, OUTER TUBE
FKM (STANDARD) 105080
FFKM (-FF MODELS) 111509
FDA FFKM (-P MODELS) 111510
FDA BUNA (-B MODELS) 108069

15
ITEM QTY DESCRIPTION
PART NUMBER
MODEL SFS MODEL SFS-H
1* 1 COUPLING INSERT
RUBBER J100014
2 1 COUPLING HALF
ALUMINUM 111530
3* 1 BEARING
STEEL 111057
4 1
SHAFT (316 STAINLESS STEEL)
27” 111202-1
40” 111202-3
48” 111202-5
54” 111202-7
60” 111202-9
72” 111202-11
5* 1
SEAL
FKM (STANDARD) 107592
PTFE (OPTIONAL) 107622
6 1 HEAD
316 STAINLESS STEEL 111500
7* 1
O-RING, DISCHARGE SPOUT
FKM (STANDARD) 109526
FFKM (-FF MODELS) 111501
FDA FFKM (-P MODELS) 111502
FDA BUNA (-B MODELS) 111503
1
DISCHARGE SPOUT (316 STAINLESS STEEL)
8A 1" TRI-CLAMP (INCLUDES NUT) (-TC MODELS) 111505
8B 1" BARB (DN 25) (STANDARD) 111506
8C 1" NPT (-MT MODELS) 111507
8D 1" BSPP (-BSP MODELS) 111521
9 1 NUT
316 STAINLESS STEEL 111508
10 1 LOCK WASHER
#8 BRASS J100018
11 1SCREW
#8-32 x 1/4 BRASS PAN HEAD J100822
12* 2
O-RING, OUTER TUBE
FKM (STANDARD) 105080
FFKM (-FF MODELS) 111509
FDA FFKM (-P MODELS) 111510
FDA BUNA (-B MODELS) 108069
ITEM QTY DESCRIPTION PART NUMBER
MODEL SFS MODEL SFS-H
13* 1
O-RING, INNER TUBE
FKM (STANDARD) J100018
FFKM (-FF MODELS) 111511
FDA FFKM (-P MODELS) 105620
FDA BUNA (-B MODELS) 108197
14 1
INNER TUBE (316 STAINLESS STEEL)
27” 107616-1
40” 107616-2
48” 107616-3
54” 107616-7
60” 111512-1
72” 111512-2
15* 1
SHAFT SLEEVE (PTFE)
27” 111513-1
40” 111513-2
48” 111513-3
54” 111513-7
60” 111513-4
72” 111513-5
16 1
OUTER TUBE (316 STAINLESS STEEL)
27” 111515-1
40” 111515-2
48” 111515-3
54” 111515-4
60” 111515-5
72” 111515-6
27" ELECTROPOLISHED (-P OR -B MODELS) 111532-1
40" ELECTROPOLISHED (-P OR -B MODELS) 111532-2
48" ELECTROPOLISHED (-P OR -B MODELS) 111532-3
54" ELECTROPOLISHED (-P OR -B MODELS) 111532-4
17* 1
O-RING, DIFFUSER
FKM (STANDARD) J100132
FFKM (-FF MODELS) 111516
FDA FFKM (-P MODELS) 107621
FDA BUNA (-B MODELS) 108198
18 1 DIFFUSER
316 STAINLESS STEEL 111517
19* 1
BUSHING, DIFFUSER
PTFE (STANDARD) 111518-1
FDA PTFE (-P OR -B MODELS) 111518-2
20* 1
IMPELLER - HIGH FLOW (FOR USE WITH "DIFFUSER COVER - HIGH FLOW")
CFF ETFE (STANDARD) 111210-3 N/A
PURE ETFE (FOR MODELS ENDING IN -P OR -B) 111210-2 N/A
PUMP SPARE PARTS LIST

ITEM QTY DESCRIPTION
PART NUMBER
MODEL SFM
21* 1
IMPELLER - HIGH HEAD (FOR USE WITH "DIFFFUSER COVER - HIGH HEAD")
CFF ETFE (STANDARD) N/A 111211-3
PURE ETFE (FOR MODELS ENDING IN -P OR -B) N/A 111211-2
22* 1 DIFFUSER COVER - HIGH FLOW
316 STAINLESS STEEL 111519 N/A
23* 1 DIFFUSER COVER - HIGH HEAD
316 STAINLESS STEEL N/A 111520
*Recommended spare parts
PUMP SPARE PARTS LIST
Service 1-800-888-3743
P/N 111522
08/09/2022
