FujiFilm SPRAY Auto V8 Series User manual

1
CONTENTS
Speciications
Safety Precautions
Assembly
Operation
Technique
Pars Diagram
Air Cap Sets
Finish Problems
Troubleshooting
Cleaning
Reassembly
Disassembly for Service or Repairs
Warranty Information
2
3 - 4
5
6 - 7
7
8 - 9
10
10
11 - 12
13 - 14
14 - 15
16
17

V8 Series
SPECIFICATIONS
Max. cfm at psi
MP Max. 12.2 cfm at 35 psi
HVLP Max. 14.7 cfm at 28 psi
Air Consumption
MP 12.2 cfm
HVLP 14.7 cfm
Operating Pressure Range
MP 9 to 35 psi
HVLP 9 to 28 psi
Standard Air Cap Set
MP 1.3mm
HVLP 1.4mm
Air Inlet Size 1/4” BSP and NPS
Air Supply Hose Width 5/16” ID
Fluid Coupler Size (Gravity) 3/8” PF
Gun Weight (Without Cup) 521g
Nozzle Sizes Available (in mm) 1.2; 1.3; 1.4; 1.7; 2.0; 2.2
Spray Gun Materials
Body Forged Aluminum
Air Cap Nickel Plated Brass
Nozzle Stainless Steel
Needle Spring Stainless Steel
Fluid Passages Anodized Aluminum
Seal Gaskets PTFE (Telon)

3
Please read these instructions before using the equipment
Equipment must not be used in an area contaminated by volatile
or lammable materials. This could ignite the contaminants
causing a dangerous explosion.
• Do not spray lammable or combustible materials near an open
lame or sources of ignition such as cigarettes, motors, and
electrical equipment.
• Never use 1,1,1-Trichloroethane, Methylene Chloride, other
Halogenated Hydrocarbon solvents or luids containing such
solvents in equipment with aluminum wetted pars. Such use
could result in a serious chemical reaction, with the possibility of
explosion. Consult your luid suppliers to ensure that the luids
being used are compatible with aluminum pars.
• Always keep spray area well-ventilated. Always keep a good
supply of fresh air moving through the area.
• Do not smoke in the spray area.
• Do not operate light switches, engines, or similar spark
producing products in the spray area.
• Always keep area clean and free of paint or solvent containers,
rags, and other lammable materials.
• Fire extinguisher equipment shall be present and working.
Toxic luids or fumes can cause serious injury or death if splashed
in the eyes or on skin, inhaled, or swallowed.
• Read MSDS (Material Safety Data Sheet) to know the speciic
hazards of the luids you are using.
• Always wear appropriate gloves and eye protection.
• Always wear a respirator. Read all instructions of the respirator
to ensure that it will provide the necessary protection against
the inhalation of harmful vapors. Also check with the local
jurisdiction.
• Paint, solvents, insecticides and other materials may be harmful
if inhaled.
• Store hazardous luid in approved containers and dispose of it
according to applicable guideline.
• Do not stop or delect luid leaks with your hand or body.
FIRE AND EXPLOSION HAZARD
TOXIC FLUID OR FUMES HAZARD

V8 Series
Misuse of equipment can cause serious injury or death.
• Health and safety, accident prevention, work and environment
protection regulations and policies are mandatory.
• Never aim the Spray Gun at another person or animal. In the
event of injury, seek exper medical attention immediately.
• Do not operate or spray near children. Always keep children
away from equipment at all times.
• Do not overreach or stand on an unstable suppor. Always keep
efective footing and balance.
• Stay aler and watch what you are doing.
• Do not operate the unit when fatigued or under the inluence of
drugs or alcohol.
• Check the hose, hose connectors and Spray Gun before
every use. Any worn or damaged pars should be replaced
immediately.
• Before perorming any maintenance to the equipment, de-
energize, depressurize, disconnect and lock out all power
sources.
• Use only genuine Fuji Spray replacement pars. Never modify the
equipment.
EQUIPMENT MISUSE HAZARD
STATIC CHARGE HAZZARD
Static electricity may be produced by luid. Make sure any electrically
conductive object being sprayed, spray area, and spray equipment is
properly grounded to prevent static sparking. Improper grounding or
sparks can cause a hazardous condition and result in electric shock,
ire, or even explosion and other serious harm.
THE EMPLOYER IS RESPONSIBLE TO PROVIDE THIS INFORMATION
TO THE OPERATOR OF THE EQUIPMENT
Prop 65 for California Residents
WARNING: This product may contain chemicals known
to the State of California to cause cancer, birh defects,
or other reproductive harm
Warning: Sound levels produced by spray guns during use may be
harmful to the ear depending on the set-up. It is recommended that
ear protection is always worn at all times when spraying.

5
Cup Assembly Installation:
Inser Paint Strainer into the base of the Cup from the outside. Attach the
cup assembly by screwing into the Fluid Coupler of the Spray Gun. Hand-
tightened is enough.
Connecting to Air Supply:
1. Attach pressure regulator with gauge (not included) to the Spray
Gun’s air inlet
2. Attach hose connector itting (not included) to pressure regulator
with gauge
3. Connect air supply hose
(OPTIONAL) Attach hose connector itting directly to the Spray Gun’s air
inlet and connect air supply hose
NOTE: For best spray results, it is recommended using a 5/16” ID air
pressure hose. If hose is over 20 then a 3/8” diameter would be ideal.
Using a smaller diameter hose will result in a signiicant drop in pressure.
NOTE: Air supply must be clean, moisture free, oil free air and proper-
ly regulated.
Most HVLP and MP (Mid-Pressure or reduced pressure) compressor
Spray Guns will operate between 10 and 20cfm. A 20cfm Spray Gun will
drain the air from a moderate sized 5hp compressor. If an additional air
tool is connected to the circuit and used during this time, the Spray Gun’s
atomizing pressure will vary. This will result in a lower quality perormance
and inconsistent outcome. For best results, a larger compressor is
recommended.
ASSEMBLY

V8 Series
To clean out any impurities that may have accumulated during assembly
or shipping of the Spray Gun, we recommend spraying a small quantity of
clean paint thinner through the gun. If you intend to spray water-based
paints and materials, make sure luid passages and components that may
have come in contact with paint thinner are completely dry.
• Mix material to manufacturer’s requirements, and properly strain.
• Fill the material cup no more than maximum 3/4 full - Do not overill.
• As a safety guard and reference point, turn Fluid Control Knob (#15)
clockwise, do not force. This will prevent any accidental trigger pull as
you complete setting up.
• Turn the Fan Pattern Control Knob (#16-6) counter-clockwise, this will
set the Spray Gun to the widest fan pattern.
• Connect air supply to the Spray Gun and rotate the Fluid Control
Knob (#15) counter-clockwise two full turns. This will allow for some
material to low out of the Nozzle to atomize.
• Point Spray Gun away from you, pull the trigger and gauge the Spray
Gun’s settings. You may need to adjust material low, air pressure, or
fan pattern settings at this time to achieve desired settings.
Fluid Control - If the material low is too heavy, turn the Fluid Control
Knob clockwise, this will reduce material volume low. To increase material
volume low for a wet inish, turn the Fluid Control Knob counter-clockwise.
Pressure Regulator - Air pressure adjustment will signiicantly afect how
the material is atomized. If looking too coarse when wet, increase air supply
pressure at the pressure regulator located at base of the Spray Gun’s
handle. If looking too ine, decrease pressure. For pressure speciications of
the Spray Gun, see page 2.
OPERATION

7
Pattern Control - To produce a smaller fan pattern, turn the Fan Pattern
Control Knob (#16-6) clockwise. For widest pattern, turn Fan Pattern
Control Knob counter-clockwise.
NOTE: In most cases, a combination of all three adjustments will provide
the desired results.
The Spray Gun should be held perpendicular to the surace at all times.
Hold the gun no more than 8” (20cm) away from the surace to be sprayed.
CORRECT METHOD
Begin spraying by pulling the Trigger and move the Spray Gun in the
direction you want to spray. Star your pass from of the edge of the piece;
then continue of the edge of the piece on the other end before releasing
the Trigger. Between each successive pass, overlap by 50%.
INCORRECT METHOD
CAUTION: Never for any reason point the Spray Gun directly at the
face or head of a person.
TECHNIQUE

V8 Series
FUJI SPRAY AUTO™ V8 SERIES SPRAY GUN
PART DESCRIPTION
• • 6882 Spray Gun
Rebuild Kit con-
sists of one each
of these pars
•Pars not
removable
ITEM PART NAME
1 Air Cap with Collar
1-1 Air Cap Retaining Ring
1-2 Collar
1-3 Air Cap O-Ring
1-4 Air Cap
1-5 Collar Seal
2 Fluid Nozzle
• • 3 6803 Air Distributor
4 Gun Body
5 6805 Rear Barrel Plug with Seal

9
ITEM PART NAME
5-1 Rear Barrel Plug Seal
5-2 Rear Barrel Plug
•6 Valve Seal
•7 Spindle Valve Housing
• • 8 6808 Spindle Valve Bushing
• • 9 6809 Spindle Valve
• • 10 6810 Spindle Valve Spring
• • 11 6811 Fluid Screw Nut
12 Needle
• • 13 6813 Needle Spring
• • 14 6814 Needle Spring Cap
• • 15 6815 Fluid Control Knob
16 6816 Fan Pattern Control Assembly
16-1 Fan Assembly Valve Seal
16-2 Fan Assembly Valve Retaining Ring
16-3 Fan Assembly Valve Housing
16-4 Fan Assembly Valve
16-5 Fan Assembly O-Ring
16-6 Fan Pattern Control Knob
16-7 Fan Pattern Control Knob Screw
19 6819 Air Control Assembly
19-1 Air Control Seal Valve Locking Ring
19-2 Air Control Seal Valve
19-3 Air Control Seal Valve Washer
19-4 Air Control Housing Locking Ring
19-5 Air Control Housing
19-6 Air Control Knob O-Ring
19-7 Air Control Knob
•20 Air Inlet
• • 21 6821 Needle Packing Assembly
21-1 Needle Packing
21-2 Needle Packing Spring
21-3 Needle Packing Nut
22 6822 Trigger Pin
23 6823 Trigger
24 6824 Trigger Retaining Ring
•25 Fluid Coupler
26 6840 600cc Gravity Nylon Cup (6841 - Aluminum)

V8 Series
Air Cap Set Sizes (Sold Separately) Par Number MP Par Number HVLP
1.2mm 6800MP-V8-1.2 6890H-V8-1.2
1.3mm (Standard MP-V8) 6800MP-V8-1.3 6890H-V8-1.3
1.4mm (Standard H-V8) 6800MP-V8-1.4 6890H-V8-1.4
1.7mm 6800MP-V8-1.7 6890H-V8-1.7
2.0mm 6800MP-V8-2.0 6890H-V8-2.0
2.2mm 6800MP-V8-2.2 6890H-V8-2.2
PROBLEM CAUSE FIX
ORANGE PEEL - Finish
is rough and resembles
orange peel.
Surace is spotty
Material is too thick Add more thinner (or
appropriate solvent)
Air inlet pressure is too
low Increase air pressure to the gun
Drying too fast Add retarder
Too close to surace Keep distance 8” (20cm)
away from surace
Fluid Volume Control
Knob set to heavy low
Turn Fluid Control Knob
clockwise to decrease
low
Spray an extremely thin
ilm, but still wet coat
Surace is rough or diry Prep or clean thoroughly
GRITTY FINISH - Sprayed
surace is rough and dry
to the touch
The material is too thin,
it is likely to be over-
atomized
Set the luid control knob
to increment material
low
Spray a wetter coat
Too far from surace Keep distance 8” (20cm)
away from surace
Contaminated surace Prep and clean
thoroughly
FISH EYES - A sprayed
surace or spot that the
material does not adhere
to
Contamination such
as silicone or oil on the
surace that intereres
with the inish
Thoroughly clean, wash
or sand the area, then
spray over. Star with
light coats
RUNS AND SAGS - When
paint/material is pooling
in an area causing drips
Fluid Volume Control
Knob set to heavy low
Turn Fluid Control Knob
clockwise to decrease
low
The speed of your pass is
too slow Bring your pass to a moderate speed
Inconsistent distance
from surace per pass
Keep distance 8” (20cm)
away from surace. See
page 7 - Technique
FINISH PROBLEMS
AIR CAP SETS

11
PROBLEM CAUSE FIX
NO PAINT
OR VERY LITTLE PAINT
No pressure from air
supply hose
Check for air leaks
on hose or adjust to
appropriate pressure
The air passage in Lid
of the Cup may be
obstructed
Clean obstruction at
pinhole located on Lid of
the Cup
Cup is empty Reill Cup with material
Strainer may be clogged Replace/remove Strainer
Fluid Coupler is blocked
with material Clean Fluid Coupler
UNEVEN SPRAY
PATTERN
One of the holes in the Air
Cap may be blocked
Remove Air Cap or Nozzle
and clean by soaking in
appropriate solvent and
using a so bristle brush
or a rag. NEVER use metal
objects to clean holes in
the Air Cap.
The material could
be contaminated and
parially blocking Fluid
Nozzle
LEAKAGE
If material comes out of
the Fluid Nozzle without
pulling the Trigger...
The Needle is not seating
in Fluid Nozzle properly
- check if Needle or Fluid
Nozzle is damaged or
worn
Lubricate Needle or
Replace Needle and Fluid
Nozzle
Foreign matter trapped
between Needle and Fluid
Nozzle
Remove Needle and Fluid
Nozzle and thoroughly
clean
Loose Fluid Nozzle Tighten Fluid Nozzle
Wrong Fluid Nozzle or
Needle size installed
Check and install correct
Fluid Nozzle or Needle
size to match
TROUBLESHOOTING
SPRAY GUN PROBLEMS

V8 Series
PROBLEM CAUSE FIX
CUP LEAKS
Cup or Lid may be
cracked Replace Cup Assembly
Cup Lid is too loose
Tighten Cup Lid - hold
Cup (not Gun) with one
hand, and tighten Lid
with the other
THE TRIGGER IS
SLUGGISH
Bent Needle or not
lubricated
Replace
Lubricate sha of needle
POOR SPRAY PATTERN
Damaged Needle or
Nozzle Replace
Air holes in Air Cap or
Nozzle clogged
Clean Air Cap or Fluid
Nozzle
Damaged Air Cap Replace
Gun too far from surace Keep consistent distance
of 8”- 20cm from surace
PAINT AT THE AIR
NOZZLE HOLES
Fluid Nozzle is loose and
material is leaking around
it
Tighten with supplied
Wrench
GUN SPRAYS IN A
PULSATING MANNER
Cup is almost empty Reill Cup with material
Blocked luid passage
Thoroughly clean
luid passages with
appropriate solvent
Air passage in the Lid
of the Cup may be
obstructed
Clean obstruction at
pinhole located on Lid of
the Cup
Fluid Nozzle is loose or
damaged
Tighten with supplied
Wrench or replace
CAUTION
With the standard 600cc Gravity Cup installed on the Gun, do not lay
the Gun down on its side with material in it.
SPRAY GUN PROBLEMS CONTINUED

13
GENERAL CLEANING
It is very imporant to properly clean your Spray Gun aer each use. This
will prevent any build-up and/or contamination when spraying other
materials. Keeping your Spray Gun clean will also prevent spray problems
due to blockage.
PLEASE DO NOT USE A WIRE BRUSH OR ANYTHING METAL TO CLEAN THE
GUN OR CUP AS THIS WILL CAUSE DAMAGE. We recommend using the Fuji
Spray Gun Cleaning Kit (par # 3100).
WARNING
DO NOT remove the Fluid Coupler (#25), the threads in your Spray
Gun have been sealed at the factory to prevent leakage.
CAUTION
Never soak the complete Spray Gun in solvent as this is detrimental to
the seals and removes the lubricants from pars.
CLEANING FLUID PASSAGES (Level 1)
1. Remove lid of the cup and pour le over material into a container
2. Wipe the inside of the cup with a solvent-soaked cloth
3. Add some appropriate solvent into the Cup, reattach Lid to the cup
and spray
4. Pull the trigger repeatedly to properly lush the luid passages,
Needle and Nozzle
5. This process lushes solvent through the Spray Gun while it is still
connected to the air supply hose and the paint is still wet inside the
Gun.
If this type of quick cleaning is perormed frequently, the Spray Gun will
function well for many years. More than 50% of problems with a Spray Gun
stem from clogs in the luid passages and perhaps more imporant, the air
passages.
CLEANING

V8 Series
THOROUGH CLEANING (Level 2)
DISSASSEMBLY - See page 16 for images
You may soak only the metal pars in neutral cleaning solution (pH value
6 to 8) and clean with the so bristle cleaning brush.
Aer perorming Level 1 cleaning and removing the gravity cup from the
Spray Gun:
1. Fig. A - Remove Fluid Control Knob #15 and Needle Spring with Cap
#13 and #14
2. Fig. B - Pull the Trigger #23 and the Needle #12 will extend from the
rear of the gun
3. Fig. C - Carefully slide the Needle #12 out - Do not bend
4. Fig. D - Remove the Air Cap with Collar #1
5. Fig. E - Using the supplied Wrench, remove the Fluid Nozzle #2
6. Fig. F - Remove Air Distributor #3 and inspect for material residue
7. Fig. G - Use the supplied cleaning brush and appropriate solvent to
clean behind the Fluid Nozzle #2
8. Fig. H - Soak the Air Cap with Collar #1, Nozzle #2 and Needle #12 in
appropriate solvent, and clean. It is not necessary to soak or clean Air
Distributor #3 unless there are traces of material on it
Aer cleaning the Spray Gun, it is recommended that the luid passages,
threads and cup be blown dry with clean compressed air.
Prior to assembly, always make sure ALL Gun components are present.
Assembly of Spray Gun with missing pars may cause damage or harm.
To reassemble, irst oil or grease all moving and threaded pars.
1. Fig. I - Match the Locating Pin of the Air Distributor #3 to Gun Body
2. Fig. E - Attach Fluid Nozzle #2 and tighten with the supplied Wrench
3. Fig. D - Screw in the Air Cap with Collar #1
4. Fig. J - Add lubricant to the sha of the Needle #12
5. Fig. C - Carefully slide in the Needle - Do not bend
6. Fig. A - Add Needle Spring with Cap #13 and #14 and attach Fluid
Control Knob #15
REASSEMBLY

15
A B
C D
E F
G H
IJ
230-240 lbf-in
200-208 kgf-cm

V8 Series
Disassembly for Service or Repairs
Needle Packing Nut Assembly
Follow instructions on page 15 up to #6, then follow the steps below:
1. Fig. K - Use an Allen Key size 6 to remove Fluid Screw Nut # 11, Then
remove Spindle Valve Spring #10, Spindle Valve #9 and Spindle Valve
Bushing #8
2. Fig. L - Remove Trigger #23 by unclipping Retaining Ring #24 with
a size 0.375” (7/64”) Retaining Ring Tool from Trigger Pin #22 and
slide out. This will release Trigger #23
3. Fig. M - Remove Needle Packing Nut Assembly #21 by insering long
end of supplied Allen Key from rear of Spray Gun. Push Allen Key all
the way through until the end almost comes out at front of Spray
Gun. Turn Allen Key counter-clockwise to unscrew Needle Packing
Nut Assembly #21
Fan Pattern Control Assembly
1. Fig. N - Remove Fan Pattern Control Knob Screw #16-7 using Torx
screwdriver. Remove Pattern Control Knob #16-6
2. Fig. O - With a wrench, unscrew Pattern Control Assembly #16
K L
MN
O
DISASSEMBLY

17
Fuji Spray Auto™ Limited 1 Year Warranty
Fuji Industrial Spray Equipment Ltd. (“Fuji”) provides a 12 month
limited warranty on the product to the original purchaser efective
from the date of purchase against defects in materials and
workmanship.
The warranty does not cover damage or defects arising as a result of
abuse, misuse, accident, negligence, malfunction, corrosion, normal
wear and tear, inadequate or lack of spray gun or other aspects of
maintenanceofthe product, damagearisingfromimproper assembly,
installation or operation, damage arising from the product being
used with pars that are not genuine Fuji Spray® pars, or damage
arising from the product being used for a purpose other than that for
which it was designed or intended. The warranty is void if repairs to
the product are made or attempted by anyone other than Fuji or its
authorized agent, or if any modiications to the product are made or
attempted.
Purchasers located in Norh America must obtain a Return Material
Authorization number by calling Fuji at 1-800-650-0930 before
returning the product to Fuji or its designated representative.
Purchasers located outside Norh America must contact the vendor
from which they purchased the product. In all instances purchasers
must return the product together with proof of purchase and with
shipping prepaid. For valid warranty claims the product will be
returned to the purchaser with shipping prepaid.
This is the only warranty provided by Fuji with respect to the product
and is in lieu of any other warranties, express or implied, including
but not limited to any warranty of merchantability or itness for a
paricular purpose. Fuji’s sole obligation under this warranty shall,
at its option, be to either repair or replace a product determined
by Fuji to be defective. In no event shall Fuji be liable for loss or
proits, incidental or consequential damages, injury to any person or
propery, or any other damages of whatsoever nature.

FUJI SPRAY® AUTO
CONNECT WITH US!
@FUJISPRAYAUTO
@FUJISPRAYAUTO
@FUJISPRAY
[e-mail]
[phone]
FUJISPRAY.COM
FUJISPRAYAUTO.COM
NEED HELP?
Fuji Industrial Spray Equipment Ltd.
40 Magnetic Drive. #48, Toronto, ON, Canada M3J 2C4
