Fujitsu Siemens Computers has enhanced the LIFEBOOK E Series with a new version
satisfying the needs of the professional user. The modular design makes expansion a 5
second exercise - add a battery, hard drive, CD-ROM, DVD or the combo drive to fit the
LIFEBOOK to your current needs. An integrated BIOS-based password system- and HDD-
protection, a sophisticated Security Panel and native support for SmartCards make the
LIFEBOOKs the most secure mobile family in the world. Through its new stylish design and a
traveling weight of 2.95 kg including CD-ROM, the LIFEBOOKs of the new E Series are ready
for the road.
Mobility
! Mobile IntelPentium4 processor-M
1.90GHz, 2.20GHz or alternatively up to
2.40GHz (in future) with SpeedStep
technology for improved battery operating
time
! Modular bay fitting an extra drive or battery
for more flexibility
! Optional WLAN integrated in the lid
! Optimal connectivity through built-in
56Kbps V.90 modem and 10/100 Mbps
Ethernet LAN adapter
! Fast Infrared (Fast IrDa 1.1), 2 x USB ports
Reliability
! Highest quality design and function stability
! Delivery reliability
! Country-specific warranty
Manageability
! Manageability features included
! Mobile Management – PXE, DMI 2.0 and
wired for Management 2.0
Security
! Mobile Security - via built - in Security
Panel and integrated SmartCard controller
! SecureIT suite including SmardCard
adapter has to be ordered separately
Ergonomics
! Enjoy the viewing quality of brilliant TFT
displays up to 15.1” SXGA+
! Graphics are integrated ATI U2 supported
by shared system memory (with 128 MB
RAM up to 64 MB)
! Port Replicator capable of keeping you
connected to all your peripherals and LAN
LIFEBOOK E2010
The entry level high-end
notebook for professionals
Data Sheet #LIFEBOOK E Series #Issue March 2003

Data Sheet #LIFEBOOK E2010 #March 2003
System, processors, architecture
Mobile IntelPentium4 processor: 1.90 GHz,
2.20 GHz or up to 2.40 GHz, 512 KB second-level
cache, 400 MHz FSB with SpeedSteptechnology
Memory
2 memory slots for 128, 256 or 512 MB, 266 MHz DDR-
SDRAM modules; min. 128 MB - max. 1024 MB
BIOS and chipset
Phoenix NoteBIOS 4.06
Full DMI 2.0 and WfM 2.0 support, PXE support
Ali 1535+ chipset
I/O interfaces
1 x infrared link (Fast IrDa 1.1, 4 Mbps)
2 x type II or 1 x type III for PC Card slots
(32-bit Card Bus)
1 x serial port, 1x parallel port
1 x VGA, 1 x S-Video out (TV-out)
2 x USB 2.0 port
1 x headphone out, microphone in
1 x docking connector for Port Replicator
Communications
Built-in 10/100 Mbps LAN (Realtek) and V.90 mini-PCI
modem combination as standard;
Optional: WLAN antenna integrated in the lid (built to
order)
Audio
AC97 Sigmatel 9767 Codec
SoundBlasterTM Pro compatible stereo speakers
Keyboard and pointing device
Full-sized keyboard with Windows keys;
GS (German ergonomic approval)
TouchPad, status LCD above keyboard
Graphics
ATI MOBILITY RADEON U2
Simultaneous use of LCD/CRT; Dual View (WIN XP)
Shared system memory (with 128 MB RAM up to 64 MB)
Max. ext. CRT: 1600 x 1200 / 64 K colours / 85 Hz
Display
14.1” TFT-XGA-display, 1024 x 768 pixel
15.1” TFT-SXGA+-display, 1400 x 1050 pixel
Storage devices / drives
40 GB or 60 GB IDE hard disk UDMA100
Modular bay
Optional devices for modular bay include: CD-ROM,
DVD-ROM, DVD/CD-RW combo, 40.0 GB hard disk,
second battery, weight saver, floppy disk drive (external,
only via USB, has to be ordered separately)
Security
SmartCard controller integrated in PC Card controller,
SecureIT suite including Smart Card adapter has to be
ordered separately;
O2Micro OZ711E1 (SmartCard adapter is needed to fit
a SmartCard) incl. Standard SecureIT Suite (SmartCard
adapter, SIMCard adapter and CD)
Built-in Security Panel with PIN code
User and supervisor password
Password from resume (only with Security Panel)
S.M.A.R.T hard disk with password
Kensington Lock support
Mobile management
PXE (only combined with built-in LAN), DMI 2.0 and
WfM 2.0; ACPI compliant
Power supply
Li-Ion battery, 8 cells, 14.4V, 3800mAh, dual battery
support. Up to 3 hours with 1st battery (ZD
BatteryMark)
External mini AC adapter input 100-240 V / 50-60 Hz,
output 19V, 4.22 A
Operating conditions and temperatures
5°C to 35°C degrees (ambient temperature)
20% to 85% relative humidity, non-condensing
AC input 100-240 V / 50-60 Hz
Dimensions and weight
325.5 x 271 x 34.7 mm (max. 38.8 mm incl. WLAN)
2.95 kg (incl. CD-ROM)
Certifications
CE and CB
CTR21 approval for V.90 modem
Energy Star
GS (German ergonomic approval)
Operating system / software
Windows 2000 or Windows XP Professional
Adobe Acrobat Reader v4.0
Nero (CD creator)
WinDVD for MPEG II decode (Windows 2000)
Easy Guide on-line user documentation
Fujitsu Siemens Computers recommends
MicrosoftWindowsXP Professional for Mobile
Computing
Options
WLAN (built to order option only)
128, 256 or 512 MB DDR RAM modules
CD-ROM, DVD-ROM, DVD/CD-R/RW combo bay
modules, floppy disk drive (external only via USB)
Additional Li-Ion battery
Slim line Port Replicator
PC Cards (ISDN)
12 V adapter for cars and planes (only for recharging,
not during operation), carrying case
SecureIT suite with Smart Card adapter
Wireless technologies (WLAN)
Import and usage according to country-specific
regulations
