Fujitsu Siemens Computers AMILO Pi 153 SERIES User manual

Notebook
Getting Started
English, Norsk, Português,
Česky, Türkçe, Slovensko
Slovenský
AMILO Pi 153*/Pi 155*
Downloaded from LpManual.com Manuals

Are there…
... any technical problems or other questions which you would like to be clarified?
Please contact:
●our Hotline/Help Desk
(see the included Help Desk list or go to: www.fujitsu-siemens.com/support/helpdesk.html)
●your sales partner
●your sales outlet
Additional information is contained in the Help Desk list and the "Warranty" manual. The "Warranty"
manual can be found on the "Drivers & Utilities" CD provided with your computer.
The latest information on our products, tips, updates, etc., can be found on the internet at:
www.fujitsu-siemens.com
Downloaded from LpManual.com Manuals

Downloaded from LpManual.com Manuals

This manual was produced by
Xerox Global Services
Published by
Fujitsu Siemens Computers GmbH
AG 01/07
Edition 1
Order No.: 10600790867
Order No.: 440 N00380
Downloaded from LpManual.com Manuals

AMILO Pi 153*/Pi 155*
Getting Started
English
Norsk
Česky
Português
Türkçe
Slovenský
Slovensko
January 2007 edition
Downloaded from LpManual.com Manuals

Microsoft, MS, MS-DOS, Windows, and Windows NT are registered trademarks of Microsoft
Corporation.
Acrobat Reader is a trademark of Adobe Systems Incorporated.
Macrovision is a trademark of Macrovision Corporation, USA.
MultiMediaCard is a registered trademark of Infineon Technologies AG
Sony and Memory Stick are registered trademarks of Sony Electronics, Inc.
All other trademarks referenced are trademarks or registered trademarks of their respective
owners, whose protected rights are acknowledged.
Copyright © Fujitsu Siemens Computers GmbH 2007
All rights, including rights of translation, reproduction by printing, copying or similar methods,
in part or in whole, are reserved.
Offenders will be liable for damages.
All rights, including rights created by patent grant or registration of a utility model or design,
are reserved.
Delivery subject to availability. Right of technical modification reserved.
Downloaded from LpManual.com Manuals

Contents
Innovative technology… .................................................................................................................... 1
Notational conventions ......................................................................................................................... 1
Important notes .................................................................................................................................. 2
Declarations of Conformity ................................................................................................................... 2
Information sources.............................................................................................................................. 2
Safety notes.......................................................................................................................................... 3
Drivers and utilities ............................................................................................................................... 3
Preparation for use and operation.................................................................................................... 4
Unpacking and checking your notebook............................................................................................... 4
Notebook views .................................................................................................................................... 5
Selecting a location .............................................................................................................................. 6
Connecting the mains adapter.............................................................................................................. 6
Switching on the notebook for the first time.......................................................................................... 7
Switching on the notebook ................................................................................................................... 8
Switching off the notebook ................................................................................................................... 8
Touchpad, touchpad buttons and ON/OFF switch for touchpad .......................................................... 9
Battery ................................................................................................................................................ 10
Easy Launch keys .............................................................................................................................. 11
Radio components (Wireless LAN) .................................................................................................... 12
Switching wireless LAN module on and off ................................................................................ 12
BIOS Setup Utility............................................................................................................................... 12
Troubleshooting and tips................................................................................................................. 13
Restoring installed software ............................................................................................................... 13
Restoring the operating system, drivers, manuals and special software ................................... 13
The notebook's date or time is incorrect............................................................................................. 14
The LCD screen of the notebook remains blank ................................................................................ 14
The LCD screen is difficult to read ..................................................................................................... 14
The external monitor stays blank........................................................................................................ 14
The external monitor is blank or the image is unstable ...................................................................... 15
The notebook cannot be started......................................................................................................... 15
The notebook stops working............................................................................................................... 15
The printer does not print ................................................................................................................... 16
Acoustic warnings............................................................................................................................... 16
The wireless connection to a network does not work......................................................................... 16
Are you missing information?
You can find the detailed operating manual for this device as a PDF file on your notebook or on our
website (see “Fehler! Verweisquelle konnte nicht gefunden werden.").
10600790867 edition 1 English
Downloaded from LpManual.com Manuals

Contents
English 10600790867, edition 1
Downloaded from LpManual.com Manuals

Innovative technology…
… and ergonomic design make your AMILO a reliable, convenient notebook. Your Windows
operating system is already pre-installed and optimally configured. That means you're ready to start
when you switch on your AMILO for the first time.
This "Getting Started" manual tells you how to put your AMILO into operation. If a technical problem
should arise, helpful information can be found in the "Troubleshooting and tips" chapter.
Notational conventions
The following symbols are used in this manual:
Indicates information which is important for your health or for preventing
physical damage. Failure to follow the instructions may lead to loss of data,
invalidate your warranty, destroy the notebook, or endanger your life.
!
Indicates important information which is required to use the system properly.
i
►Text which follows this symbol describes activities that must be performed in
the order shown.
indicates screen outputs.This font
This font indicates programme names, commands, or menu items.
"Quotation marks" indicate names of chapters, hard disks, CDs, DVDs, and terms that are
being emphasised.
10600790867, edition 1 English - 1
Downloaded from LpManual.com Manuals

Important notes
Important notes
This chapter contains references to other sources of information. It is essential that you observe the
safety information for your notebook.
Declarations of Conformity
You will find the Declaration of Conformity for this notebook on the Internet at: http://www.fujitsu-
siemens.com.
Hereby, Fujitsu Siemens Computers, declares that this notebook is in compliance with the essential
requirements and other relevant provisions of Directive 1999/5/EC.
Information sources
I In this "Getting Started" manual you will find information you require to prepare your notebook for
use. Detailed instructions and technical information for your notebook are contained in the
"EasyGuide" manual. If you connect a printer to your notebook, you can print out the manuals that
are otherwise only available in PDF format.
Information source Type of information Where?
Quick Start Guide
(printed)
Poster with information about
getting started
Accessories kit
"Safety" manual (printed
and/or
PDF file)
Safety information
Accessories kit and/or on your
notebook
"Recovery Process"
manual (printed and/or
PDF file)
Information on restoring the
operating system, drivers, manuals
and special software
Accessories kit, on your notebook
or on our web site
www.fujitsu-siemens.com/support/
"EasyGuide" manual
(PDF file)
Detailed instructions for startup,
operation and technical
information
Detailed instructions for using
wireless LAN and technical
information
"Wireless LAN" manual
(PDF file)
"Warranty" manual (PDF
file)
General warranty conditions
Information files
(e.g. *.TXT,
Information on utilities and
programs
T*.DOC,
*.CHM, *.HLP)
The manuals are located on your
notebook under
Start – Manuals
or, in some cases, updated
versions can be found on our web
site
www.fujitsu-siemens.com/support/
information files (e.g.
*.TXT, *.DOC, *.CHM,
*.HLP)
Information on the operating
system
In the software for these
applications
2 - English 10600790867, edition 1
Downloaded from LpManual.com Manuals

Important notes
Safety notes
It is essential that you observe the following safety information, as well as safety
information provided in the "Safety" manual.
!
●When cleaning the notebook, observe the relevant notes in the "EasyGuide" manual.
●Your notebook is equipped with numerous security functions that offer you a high level of
security according to a multi-level concept. Details are contained in the "Safety functions"
chapter in the "EasyGuide" manual.
●Pay attention to the additional safety precautions for devices with wireless LAN provided in the
"Safety" manual.
●Keep this operating manual together with the device.
If you pass this device on to others, you should also give them the operating manual.
This notebook complies with the relevant safety regulations for data processing equipment. If you
have questions about using your notebook in a particular area, please contact your sales outlet or
our Hotline/Help Desk.
Drivers and utilities
If a Windows operating system is installed on your notebook, you will find additional information on
the system and drivers, help programs and updates on your notebook or on our website
www.fujitsu-siemens.com/support/.
If you need to reinstall your operating system, you can reload the original software and the original
drivers of your notebook onto the hard disk using the "Drivers & Utilities" CD/DVD or the drivers from
our website.
10600790867, edition 1 English - 3
Downloaded from LpManual.com Manuals

Preparation for use and operation
Preparation for use and operation
!Please take note of the safety information in the "Important notes" chapter.
You must charge the battery and install the application programmes before you can work with the
notebook. The operating system and drivers required are preinstalled.
This chapter also describes the basics for operating your notebook.
Unpacking and checking your notebook
►Unpack all the individual parts.
►Check your notebook for damage incurred during transportation.
Should you discover damages incurred during transportation, notify your local sales outlet
immediately!
!
Do not discard the original packing material of the devices. You may need the packaging
in the future if you need to transport your device.
i
4 - English 10600790867, edition 1
Downloaded from LpManual.com Manuals

Preparation for use and operation
Notebook views
This chapter presents the individual hardware components of your notebook. You can obtain an
overview of the displays and connections of the notebook. Please familiarise yourself with these
components before you start to work with your notebook.
1
2
3
4
5
6
7
9
10
11
12
13
20
21
22
24
25
19
15
16
17
23
8
18
14
26
1 = Modem port
2 = DVI-I connector
3 = S Video out socket
4 = Kensington Lock
5 = LAN port
6 = Memory card slot
7 = FireWire port
8 = USB ports
9 = ExpressCard slot
10 = Battery
11 = Battery release latch
12 = Hard disk
13 = On/Off switch for Wireless LAN
14 = Touchpad buttons
15 = Touchpad
16 = ON/OFF switch for touchpad
17 = Built-in loudspeakers
18 = ON/OFF switch of the Notebook
19 = Easy Launch keys
20 = Built-in microphone
21 = Volume control
22 = Headphone port/SPDIF
23 = Microphone port/Line In
24 = CD/DVD drive
25 = USB port
26 = DC jack (DC IN)
10600790867, edition 1 English - 5
Downloaded from LpManual.com Manuals

Preparation for use and operation
Selecting a location
!
Select a suitable location for the notebook before setting it up. Consider the following
points when looking for a location:
●Never place the notebook on a soft surface (e.g. carpeting, upholstered furniture,
bed). This can block the air vents and cause overheating and damage.
●Do not place the notebook on your legs for a longer period of time. The underside of
the notebook heats up during normal operation. Longer contac with the skin can
become unpleasant or even result in burns.
●Place the notebook on a stable, flat, nonslippery surface. Please note that the rubber
feet may mark certain types of surfaces.
●Keep other objects 100 mm away from the notebook and its mains adapter to ensure
adequate ventilation.
●Never cover the fan intake or exhaust openings of the notebook or the mains
adapter.
●Do not expose the notebook to extreme environmental conditions.
Protect the notebook from dust, humidity, and heat.
Connecting the mains adapter
!
Please take note of the information in the section "Safety notes".
The power cable supplied conforms to the requirements of the country in which you
purchased your notebook. Make sure that the power cable is approved for use in the
country in which you intend to use it.
The mains adapter's AC cable should only be connected to a mains socket if the
notebook is connected to the mains adapter.
Do not use the mains adapter for other notebooks or devices.
Do not use a mains adapter that is not specially intended for this notebook.
6 - English 10600790867, edition 1
Downloaded from LpManual.com Manuals

Preparation for use and operation
►Connect the mains adapter cable (1) to the DC jack (DC IN) of the notebook.
►Connect the power cable (2) into the mains adapter.
►Plug the power cable (3) into a mains outlet.
The battery will charge.
Switching on the notebook for the first time
!
When you switch on your notebook for the first time, the supplied software is installed and
configured. Due to the fact that this installation procedure must not be interrupted, you
should set aside enough time for it to be fully completed and connect the notebook to the
mains outlet using the mains adapter.
During installation, the notebook may only be rebooted when you are requested to do so!
To make it easier to set your notebook up, the operating system is preinstalled on the hard disk and
the manuals are saved there.
►Switch the notebook on (see "Fehler! Verweisquelle konnte nicht gefunden werden.").
►During installation, follow the instructions on screen.
Consult the operating system manual if anything is unclear about the requested input data.
If a Windows operating system is installed on your notebook, you will find additional
information on the system as well as the drivers, help programs, updates, manuals, etc. on
your notebook or on the "Drivers & Utilities" CD/DVD or on our website (see "Fehler!
Verweisquelle konnte nicht gefunden werden.").
i
10600790867, edition 1 English - 7
Downloaded from LpManual.com Manuals

Preparation for use and operation
Switching on the notebook
1
2
►Slide the release button in the direction of
the arrow (1) and unfold the LCD screen
upward (2).
1
►Press the ON/OFF switch (1) to switch the
notebook on.
The power-on indicator on the notebook is on.
Switching off the notebook
2
1
►Shut down the operating system properly
(e. g. from the Windows Start menu, by
clicking on Start – Shut Down – Shut down –
OK).
►If the notebook is not switched off
automatically, press the ON/OFF switch (1)
for approx. five seconds.
►Close the LCD screen (2) so that it locks
into place.
8 - English 10600790867, edition 1
Downloaded from LpManual.com Manuals

Preparation for use and operation
Touchpad, touchpad buttons and ON/OFF switch for touchpad
2
1
4
3
1 = ON/OFF switch for touchpad
2 = Touchpad
3 = Touchpad scroll bar
4 = Touchpad buttons
The touchpad enables you to move the mouse pointer on the screen.
The touchpad buttons allow the selection and execution of commands. They correspond to the
buttons on a conventional mouse.
You can switch on the touchpad with the ON/OFF switch for the touchpad to avoid accidentally
moving the pointer on the screen.
!
Keep the touchpad clean. Protect it from dirt, liquids, and grease.
Do not use the touchpad if your fingers are dirty.
Do not rest heavy objects (e.g. books) on the touchpad or the touchpad buttons.
Moving the pointer
►Move your finger on the touchpad.
The pointer will move accordingly.
Selecting an item
►Move the pointer to the item you wish to select.
►Tap the touchpad once or press the left button once.
The item will be selected.
10600790867, edition 1 English - 9
Downloaded from LpManual.com Manuals

Preparation for use and operation
Executing a command
►Move the pointer to the field you wish to select.
►Tap the touchpad twice or press the left button twice.
The command will be executed.
Dragging an object
►Select the desired object.
►Press and hold the left button and drag the object to the desired position with the finger on the
touchpad.
The item will be moved.
Scrolling with the touchpad scroll bar
►Move your finger upwards or downwards on the scroll bar at the right edge of the touchpad.
The display area moves up or down.
Battery
The battery in the notebook is not fully charged at the time of delivery. You must first
charge the battery with the mains adapter connected to the power socket (see "Connecting
the mains adapter").
!
The battery supplies your notebook with the necessary power during mobile use. The battery
indicator displays the battery’s current charge status.
Information on how to install and remove the battery, how to maintain and service it, and how to
optimise the battery operating time can be found in the "EasyGuide" manual.
10 - English 10600790867, edition 1
Downloaded from LpManual.com Manuals

Preparation for use and operation
Easy Launch keys
Your notebook is equipped with four Easy Launch keys. You can start the following applications or
functions by pressing a single key.
Multimedia
This button starts the multimedia applications.
Internet
With this button you can start the standard internet browser of your system.
E-mail
Use this button to start the standard e-mail programme for your system.
Silent Mode (whisper mode)
This key reduces the speed of the fan.
When Silent Mode is switched on, the processor and graphics do not operate at the full
performance level.
10600790867, edition 1 English - 11
Downloaded from LpManual.com Manuals

Preparation for use and operation
Radio components (Wireless LAN)
The installation of a wireless LAN module not approved by Fujitsu Siemens
Computers GmbH voids the permits (CE!, FCC) issued for this device.
!
A wireless LAN is integrated in your notebook.
Switching wireless LAN module on and off
ONOFF wireless
►Slide the ON/OFF switch for Wireless LAN
into the "ON" position to activate the
wireless LAN module.
The wireless LAN indicator lights up.
or
►Slide the ON/OFF switch for Wireless LAN
into the "OFF" position to deactivate the
wireless LAN module.
The wireless LAN indicator goes out.
i
Please observe the additional safety notes for devices with wireless components provided
in the "Safety" manual.
Details on using the wireless LAN are contained in the online help for your wireless LAN
software and in the "Wireless LAN" manual (see "Fehler! Verweisquelle konnte nicht
gefunden werden.").
BIOS Setup Utility
With the BIOS Setup Utility you can change a number of parameters and therefore the configuration of
your notebook. For example, you can use the BIOS Setup Utility to set the date and time. The BIOS
Setup Utility can also be used to assign passwords. The "EasyGuide" manual describes how to run
and end the BIOS Setup Utility.
12 - English 10600790867, edition 1
Downloaded from LpManual.com Manuals
