Fujitsu AB G18LVTB Series Service manual

DESIGN & TECHNICAL MANUAL
SINGLE
INDOOR
OUTDOOR
ABG18LVTB
AOG18LALL
AIR CONDITIONER
Floor / Ceiling type

DTR_AB033E_01
2011.12.05
1. INDOOR UNIT
FLOOR / CEILING TYPE :
ABG18LVTB

- (3) -
CEILING TYPE ABG18LV CEILING TYPE ABG18LV
CONTENTS
1. INDOOR UNIT
1. FEATURE.................................................................................................................. 01 - 01
2. WIRELESS REMOTE CONTROLLER............................................... 01 - 03
3. SPECIFICATIONS.............................................................................................. 01 - 05
4. DIMENSIONS ........................................................................................................ 01 - 06
5. WIRING DIAGRAMS........................................................................................ 01 - 08
6. CAPACITY TABLE ............................................................................................ 01 - 09
6-1. COOLING CAPACITY ....................................................................................... 01 - 09
6-2. HEATING CAPACITY ........................................................................................ 01 - 10
7. FAN PERFORMANCE.....................................................................................01 - 11
7-1. AIR VELOCITY DISTRIBUTION .......................................................................01 - 11
7-2. AIR FLOW ........................................................................................................... 01 - 13
8. OPERATION NOISE......................................................................................... 01 - 14
8-1. NOISE LEVEL CURVE...................................................................................... 01 - 14
8-2. SOUND LEVEL CHECK POINT ...................................................................... 01 - 15
9. ELECTRIC CHARACTERISTICS........................................................... 01 - 16
10. SAFETY DEVICES ............................................................................................ 01 - 17
11. EXTERNAL INPUT & OUTPUT............................................................... 01 - 18
11-1. EXTERNAL INPUT............................................................................................. 01 - 18
11-2. EXTERNAL OUTPUT ........................................................................................ 01 - 19
12. FUNCTION SETTING...................................................................................... 01 - 20
12-1. INDOOR UNIT..................................................................................................... 01 - 20
12-2. INDOOR UNIT (Setting by remote controller) ............................................ 01 - 21
13. OPTIONAL PARTS ........................................................................................... 01 - 25

- (01 - 01) -
CEILING TYPE ABG18LV CEILING TYPE ABG18LV
FEATURE1.
M O D E L

ABG18LVTB / AOG18LALL
FEATURES

Energy saving
z
High energy saving was realized by making the indoor unit and outdoor unit fan motor and
compressor all DC and optimal design of the refrigerant cycle. Class A was achieved in European
energy classications.
Flexible installation
z
Example for oor installation Example for ceiling installation
Easy installation
z
Main work settings can be done easily from the remote controller at installation
Main work settings
High ceiling setting●
Auto restart●
Temperature adjustment when cooling / heating●
Setting by wireless or
wired remote controller
(Optional parts)
Double auto swing
z
A combination of right/left and up/down directional swing allows 3-dimensional air direction control
Right and Left Swing
1
2
5
4
3
5 steps selectable
Steps
Swing: Cooling , Dry and Fan mode
Swing: Heating and Fan mode
Up and Down Swing
1
2
5
4
3
7 steps selectable
6
7

- (01 - 02) -
CEILING TYPE ABG18LV CEILING TYPE ABG18LV
10°C HEAT Operation
z *Only available with Wireless RC.
The room temperature can be set to go no lower than 10°C,
thus ensuring that the room does not get too cold when not occupied
Caution)
• When the room temperature is higher than 10°C, “10°C HEAT” operation does not start. Operation starts and maintains the room
temperature at 10°C when the temperature drops below 10°C.
• When “10°C HEAT” operation stops, the room set temperature quickly returns to the preset temperature.
10°C
20°C
“10°C HEAT”
Button ON
Indoor unit
operation START
Economy operation
z
The power consumption can be reduced.
Powerful mode ...Standard
Soft mode ...Performs operation which reduces the power consumption

- (01 - 03) -
CEILING TYPE ABG18LV CEILING TYPE ABG18LV
WIRELESS REMOTE CONTROLLER2.
FEATURES

Four kinds of timer setup (ON / OFF / PROGRAM / SLEEP) are
¾
possible.
Four kinds of timers. Easy operation.
¾
Easy to change transmission code (4 patterns) by button operation.
¾
Built-in timers
z
Select from four different timer programs (ON / OFF / PROGRAM / SLEEP).
Program timer
z
The program timer operates the ON and OFF timer once within a 24 hour period.
Sleep timer
z
The sleep timer function automatically corrects the temperature thermostat setting according to
the time setting to prevent excessive cooling and heating while sleeping.
Simple function setting
z
Setting of the air conditioner selection function is performed by remote controller.
Switching remote controller signal code
z
A B C D
A B CD
Mixed-up
I.U. I.U. I.U. I.U. I.U. I.U. I.U. I.U.
After code change
Code selector switch eliminates unit

•
being wrongly switched.
(Up to 4 codes can be set.)
*I.U.=Indoor unit
60min.
1 °C 2 °C
Timer setting
Cooling operation/dry operation
When the sleep timer is set, the set temperature
automatically rises 1°C every hour. The set
temperature can rise up to a maximum of 2°C.
1 °C
30min.
60min.
90min.
2 °C 3 °C 4 °C
Timer setting
Heating operation
When the sleep timer is set, the set temperature
automatically drops 1°C every 30 minutes. The set
temperature can drop to a maximum of 4°C.

- (01 - 04) -
CEILING TYPE ABG18LV CEILING TYPE ABG18LV
FUNCTIONS

Note: Functions will be different due to type of indoor unit.
For details, please see operation manual.
SPECIFICATION

SIZE (H × W × D mm) 170 × 56 × 19
WEIGHT (g) 85 (w/o batteries)
ACCESSORY Holder
Display panel
2
49
3
1
16
15
510
13
11
12
14
8
7
6
17
18
19
21
24
23
22
20
MODE button1
Selects the operating mode (AUTO, COOL, DRY, FAN, HEAT).
/Start / end R.C. signal code change. (Max 4 types)
10°C2 HEAT button
SET TEMP. button ( ▲ / ▼ )3
Sets the indoor temp./ Sets R.C. signal code.
ECONOMY button4
SLEEP button5
Pressed to select sleep timer.
FAN button6
Selects the fan speed (AUTO, HIGH, MED, LOW, QUIET).
START/STOP button7
Pressed to start and stop operation.
SET button (Vertical)8
Air ow direction vertical set button.
SET button (Horizontal)9
Air ow direction horizontal set button.
SWING button10
Air ow direction swing button.
TIMER MODE button11
Pressed to select the timer mode. (OFF TIMER, ON TIMER,
PROGRAM TIMER, TIMER RESET)
TIMER SET (12 / ) button
Sets the current time and on-off time.
CLOCK ADJUST button13
Sets the current time.
RESET button14
Used when replacing batteries.
TEST RUN button15
Used when testing the air conditioner after installation.
Signal transmitter16
Temperature set display17
Operating mode display18
Sleep display19
Transmit indicator20
Fan speed display21
Swing display22
Timer mode display23
Clock display24

- (01 - 05) -
CEILING TYPE ABG18LV CEILING TYPE ABG18LV
SPECIFICATIONS3.
Note :
Specications are based on the following conditions.
Cooling : Indoor temperature of 27˚CDB / 19˚CWB.and outdoor temperature of 35˚CDB / 24˚CWB.
Heating : Indoor temperature of 20˚CDB / 15˚CWB.and outdoor temperature of 7˚CDB / 6˚CWB.
Pipe length : 7.5 m, Height difference : 0 m. (Outdoor unit - Indoor unit)
The maximum current is the maximum value when operated within the operation range (temperature)
The protective function might work when using outside the operation range.
Type FLOOR / CEILING MODEL
INVERTER HEATPUMP
Model name Indoor unit AB¾G18LVTB
Outdoor unit AO¾G18LALL
Power source 230V
~ 50Hz
Available voltage range 198 - 264V
~ 50Hz
European energy label Cooling A
Heating A
Capacity
Cooling
Rated kW 5.20
Btu/h 17700
Min - Max kW 0.90 - 5.90
Btu/h 3100 - 20100
Heating
Rated kW 6.00
Btu/h 20500
Min - Max kW 0.90 - 7.50
Btu/h 3100 - 25600
Input power
Cooling Rated
kW
1.62
Max 2.04
Heating Rated 1.66
Max 2.83
Current
Cooling Rated
A
7.2
Max 9.0
Heating Rated 7.4
Max 12.5
EER Cooling kW/kW 3.21
COP Heating 3.61
Moisture removal l/h (pints/h) 2.0 (3.5)
Fan
Airow
rate
Cooling
High
m3/h
780
Med 700
Low 560
Quiet 500
Heating
High 780
Med 700
Low 560
Quiet 500
Type × Q'ty Sirocco × 2
Motor output W80
Sound pressure level
Cooling
High
dB (A)
44 (Floor console), 43 (Under ceiling)
Med 41 (Floor console), 40 (Under ceiling)
Low 35 (Floor console), 34 (Under ceiling)
Quiet 32 (Floor console), 31 (Under ceiling)
Heating
High 44 (Floor console), 43 (Under ceiling)
Med 41 (Floor console), 40 (Under ceiling)
Low 35 (Floor console), 34 (Under ceiling)
Quiet 32 (Floor console), 31 (Under ceiling)
Heat exchanger type
Dimensions (H × W × D) mm 252 × 800 × 39.9
Fin pitch 1.30
Rows × Stages 3 × 12
Pipe type Copper tube
Fin type Aluminium
Enclosure
Material ABS
Colour WHITE
(Approximate colour of MUNSELL N9.25 /)
Dimensions
(H × W × D)
Net mm 199 × 990 × 655
Gross 320 × 1150 × 790
Weight Net kg 27
Gross 36
Connection pipe Size Liquid mm Ø6.35 (Ø1/4 in.)
Gas Ø12.70 (Ø1/2 in.)
Method Flare
Operation range Cooling ˚C 18 to 32
%RH 80 or less
Heating ˚C 16 to 30
Remote controller type Wireless [Wired (option)]
Drain pipe Material Hard PVC
Size mm Outer diameter : 32 / Inner diameter : 25

- (01 - 06) -
CEILING TYPE ABG18LV CEILING TYPE ABG18LV
DIMENSIONS4.
MODEL
 : ABG18LV
(Unit : mm)
1
2
3
45
6
3
1 2
Side view
Rear view
Bottom view
(Drain hose)
100 hole
50 hole
125
100 hole
655
530
45
65
500 245
990
65
Wall bracket
Side of set
AB¾G18LV
Refrigerant pipe are
connection
Liquid ø 6.35 mm (ø 1/4 in.)
Gas ø 12.70 mm (ø 1/2 in.)
Drain hose connection Drain hose O.D. 32 mm (VP25)
Knock out hole Drain outlet ø 45 mm
- -
Hole for lifting bolt - Use M10 screw bolt

- (01 - 07) -
CEILING TYPE ABG18LV CEILING TYPE ABG18LV
INSTALLATION PLACE

(Unit : mm)
Left Right
300 or more 300 or more
Ceiling
Left Indoor unit Right
150 or more 300 or more
Ceiling
20 or more
1000 or more
2300 or more
Obstruction
Floor

- (01 - 08) -
CEILING TYPE ABG18LV CEILING TYPE ABG18LV
WIRING DIAGRAMS5.
MODEL
 : ABG18LV

- (01 - 09) -
CEILING TYPE ABG18LV CEILING TYPE ABG18LV
CAPACITY TABLE6.
COOLING CAPACITY6-1.
This table is created using the maximum capacity.
MODEL
 : ABG18LV
AFR : Air Flow Rate (m3/min)
TC : Total Capacity (kW)
SHC : Sensible Heat Capacity (kW)
IP : Input Power(kW)
AFR 13.0
Indoor temperature
°CDB 18 21 23 25 27 29 32
°CWB 12 15 16 18 19 21 23
Outdoor temperature
°CDB TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP
-10 4.35 3.28 0.39 4.84 3.30 0.40 5.01 3.59 0.40 5.34 3.60 0.40 5.50 3.89 0.40 5.83 3.88 0.41 6.17 4.13 0.41
0 4.26 3.24 0.46 4.74 3.26 0.46 4.90 3.54 0.47 5.23 3.56 0.47 5.39 3.84 0.47 5.71 3.83 0.48 6.04 4.07 0.48
5 4.14 3.18 0.57 4.61 3.20 0.58 4.77 3.48 0.58 5.08 3.49 0.59 5.24 3.77 0.59 5.55 3.76 0.60 5.86 4.00 0.60
10 4.00 3.12 0.68 4.45 3.14 0.69 4.61 3.41 0.70 4.91 3.42 0.70 5.06 3.70 0.71 5.37 3.68 0.71 5.67 3.92 0.72
15 4.04 3.14 0.59 4.50 3.16 0.60 4.65 3.43 0.61 4.95 3.44 0.61 5.11 3.72 0.62 5.41 3.70 0.62 5.72 3.94 0.63
20 5.16 3.63 1.28 5.75 3.65 1.30 5.95 3.97 1.31 6.34 3.98 1.32 6.54 4.30 1.33 6.93 4.28 1.34 7.32 4.56 1.35
25 4.94 3.54 1.43 5.51 3.57 1.46 5.70 3.88 1.46 6.07 3.89 1.48 6.26 4.20 1.49 6.63 4.18 1.50 7.01 4.46 1.52
30 4.71 3.45 1.59 5.25 3.47 1.61 5.43 3.78 1.62 5.78 3.79 1.64 5.96 4.09 1.65 6.32 4.07 1.66 6.68 4.34 1.68
35 4.66 3.43 1.88 5.19 3.45 1.91 5.37 3.75 1.92 5.72 3.76 1.94 5.90 4.06 1.95 6.25 4.04 1.97 6.61 4.31 1.99
40 3.53 2.90 1.34 3.93 2.92 1.36 4.06 3.18 1.36 4.33 3.19 1.38 4.46 3.44 1.38 4.73 3.43 1.40 5.00 3.65 1.41
46 2.50 2.46 1.01 2.79 2.47 1.02 2.88 2.69 1.03 3.07 2.69 1.04 3.17 2.91 1.05 3.36 2.90 1.06 3.55 3.09 1.07

- (01 - 10) -
CEILING TYPE ABG18LV CEILING TYPE ABG18LV
HEATING CAPACITY6-2.
This table is created using the maximum capacity.
MODEL
 : ABG18LV
AFR : Air Flow Rate (m3/min)
TC : Total Capacity (kW)
IP : Input Power(kW)
AFR 13.0
Indoor temperature
°CDB 16 18 20 22 24
Outdoor temperature
°CDB °CWB TC IP TC IP TC IP TC IP TC IP
-15 -16 5.25 2.15 5.13 2.20 5.00 2.24 4.88 2.29 4.75 2.33
-10 -11 5.90 2.27 5.76 2.32 5.62 2.37 5.48 2.42 5.34 2.46
-5 -7 6.57 2.40 6.41 2.45 6.26 2.50 6.10 2.55 5.94 2.60
0 -2 7.46 2.57 7.28 2.62 7.10 2.68 6.93 2.73 6.75 2.78
5 3 8.18 2.65 7.98 2.70 7.79 2.76 7.59 2.81 7.40 2.83
7 6 7.88 2.26 7.69 2.30 7.50 2.35 7.31 2.40 7.13 2.44
10 8 8.15 2.31 7.96 2.35 7.77 2.40 7.57 2.45 7.38 2.50
15 10 7.70 1.97 7.52 2.01 7.33 2.05 7.15 2.09 6.97 2.13
20 15 7.23 1.58 7.06 1.62 6.88 1.65 6.71 1.68 6.54 1.72
24 18 7.43 1.59 7.25 1.62 7.07 1.65 6.90 1.68 6.72 1.72

- (01 - 11) -
CEILING TYPE ABG18LV CEILING TYPE ABG18LV
FAN PERFORMANCE7.
AIR VELOCITY DISTRIBUTION7-1.
MODEL
 : ABG18LV (UNDER CEILING) Conditions
Fan speed : High
Operation mode : Fan
10
10
10
(m)
(m)
0
0
1
1
2
2
3
3
4
4
5
5
6
6
7
7
8
8
9
9
Unit : (m/s)
10 (m)
(m)
0
0
1
1
2
2
3
3
4
4
5
5
6
6
7
7
8 9
(m)
(m)
3
3
1
1
2
2
Top view
Vertical ap : Up
Horizontal ap : Right & Left
Unit : (m/s)
(m)
0
1
1
2
2
(m)
0 1 2 3 4 5 6 7 8 9
(m)
0
1
1
2
2
3
4
5
3
4
5
(m)
3
1
2
Unit : (m/s)
Unit : (m/s)
Unit : (m/s)
Top view
Vertical ap : Up
Horizontal ap : Center
Side view
Vertical ap : Down
Horizontal ap : Center
Side view
Vertical ap : Center
Horizontal ap : Center
Side view
Vertical ap : Up
Horizontal ap : Center
0.250.51.02.0
0.25
0.25
0.5
0.5
1.0
1.0
2.0
2.0
0.250.5
1.0
2.0
0.25
0.5
1.0
2.0
0.25
0.5
1.0
2.0

- (01 - 12) -
CEILING TYPE ABG18LV CEILING TYPE ABG18LV
Conditions
Fan speed : High
Operation mode : Fan
MODEL : AB
 ¾G18LV (FLOOR CONSOLE)
10
10
10
(m)
(m)
0
0
1
1
2
2
3
3
4
4
5
5
6
6
7
7
8
8
9
9
Unit : (m/s)
(m)
0 1 2 34 5 6 7
(m)
3
4
1
2
Top view
Vertical ap : Up
Horizontal ap : Right & Left
Unit : (m/s)
(m)
0
1
1
2
2
(m)
0 1 2 3 4 5 6 7 8 9
(m)
0
1
1
2
2
3
4
5
3
4
5
(m)
3
1
2
Unit : (m/s)
Unit : (m/s)
Unit : (m/s)
(m)
0 1 2 34 5 6 7
(m)
3
4
1
2
Top view
Vertical ap : Up
Horizontal ap : Center
Side view
Vertical ap : Up
Horizontal ap : Center
Side view
Vertical ap : Center
Horizontal ap : Center
Side view
Vertical ap : Down
Horizontal ap : Center
0.250.5
1.0
2.0
0.25
0.25
0.5
0.5
1.0
1.0
2.0
2.0
0.25
0.5
1.0
2.0
0.25
0.5
1.0
2.0
0.25
0.5
1.0
2.0

- (01 - 13) -
CEILING TYPE ABG18LV CEILING TYPE ABG18LV
AIR FLOW7-2.
MODEL
 : ABG18LV
Cooling
z
Heating
z
Fan speed
Number of
rotations
(r.p.m.)
Air ow
HIGH 1040
m3/h 780
l/s 217
CFM 459
MED 950
m3/h 700
l/s 194
CFM 412
LOW 800
m3/h 560
l/s 156
CFM 330
QUIET 740
m3/h 500
l/s 139
CFM 294
Fan speed
Number of
rotations
(r.p.m.)
Air ow
HIGH 1040
m3/h 780
l/s 217
CFM 459
MED 950
m3/h 700
l/s 194
CFM 412
LOW 800
m3/h 560
l/s 156
CFM 330
QUIET 740
m3/h 500
l/s 139
CFM 294

- (01 - 14) -
CEILING TYPE ABG18LV CEILING TYPE ABG18LV
OPERATION NOISE8.
NOISE LEVEL CURVE8-1.
MODEL
 : ABG18LV
QUIET
HIGH
Heating
z
Octave band sound pressure level, dB:(0dB=0.0002µbar)
Octave band center frequency,Hz
80
70
60
50
40
30
20
10
0
63 125 250 500 1,000 2,000 4,000 8,000
NC-65
NC-60
NC-55
NC-50
NC-45
NC-40
NC-35
NC-30
NC-25
NC-20
NC-15
QUIET
HIGH
Cooling
z
Octave band sound pressure level, dB:(0dB=0.0002µbar)
Octave band center frequency,Hz
80
70
60
50
40
30
20
10
0
63 125 250 500 1,000 2,000 4,000 8,000
NC-65
NC-60
NC-55
NC-50
NC-45
NC-40
NC-35
NC-30
NC-25
NC-20
NC-15

- (01 - 15) -
CEILING TYPE ABG18LV CEILING TYPE ABG18LV
SOUND LEVEL CHECK POINT8-2.
Floor console
z
Microphone
1m
Microphone
1 m
1 m
Under ceiling
z
Microphone
CENTER
Microphone
1 m
0.8 m

- (01 - 16) -
CEILING TYPE ABG18LV CEILING TYPE ABG18LV
ELECTRIC CHARACTERISTICS9.
Model name AB¾G18LV
Power supply Voltage V 230 ~
Frequency Hz 50
Max. operating current A 0.45
*1) Wiring Spec. Connection cable mm21.5
Limited wiring length m 26
*1) Wiring Spec.
Selected Sample
(Selected based on Japan Electrotechnical Standard and Codes Committee E0005)

- (01 - 17) -
CEILING TYPE ABG18LV CEILING TYPE ABG18LV
SAFETY DEVICES10.
Protection form Model
AB¾G18LV
Circuit protection Current fuse (PCB) 250V 3.15A
Fan motor protection Thermal protection
program
138 ± 15 °C OFF
115 ± 15 °C ON
