Fujitsu ARTG24LMLC User manual

AIR CONDITIONER
Duct Type
Indoor Unit
ARTG24LMLC
PART No. 9381857159-01
KEEP THIS MANUAL FOR FUTURE REFERENCE
OPERATION MANUAL
9381857159-01OMEnARTG24LMLC.indd19381857159-01OMEnARTG24LMLC.indd1 2022/03/0415:50:242022/03/0415:50:24

2
CONTENTS
SAFETY PRECAUTIONS........................................ 2
FEATURES AND FUNCTIONS ............................... 3
NAME OF PARTS ................................................... 4
PREPARATORY OPERATION ................................ 5
OPERATION ........................................................... 6
TIMER FUNCTIONS ............................................... 8
ON/OFF TIMER....................................................... 8
WEEKLY TIMER...................................................... 9
SAFETY PRECAUTIONS
●Do not attempt to install this air conditioner by yourself.
●This unit contains no user-serviceable parts. Always consult authorized service personnel
for repairs.
●When moving, consult authorized service personnel for disconnection and installation of
the air conditioner.
●Do not become excessively chilled by staying for many hours in the direct cooling airflow.
●Do not insert fingers or objects into the outlet port or intake grilles.
●Do not start and stop air conditioner operation by turning offthe electrical breaker and so on .
●In the event of a malfunction (burning smell, etc.), immediately stop operation, turn offthe
electrical breaker, and consult authorized service personnel.
●In the event of refrigerant leakage , be sure to keep away from fire or any flammables.
(consult authorized service personnel)
●THIS PRODUCT CONTAINS A RECHARGEABLE LITHIUM BUTTON BATTERY THAT IS SOL-
DERED IN PLACE.
●If swallowed, the battery can cause severe or fatal injuries within 2 hours. Keep batteries
out of reach of children (whether the battery is new or used). If you think batteries may have
been swallowed or placed inside any part of the body, seek immediate medical attention.
●Provide occasional ventilation during use.
●Do not direct air flow at fireplaces or heating apparatus.
●Do not climb on, or place objects on, the air conditioner.
●Do not hang objects from the indoor unit.
●Do not set flower vases or water containers on top of air conditioners.
●Do not expose the air conditioner directly to water.
●Do not operate the air conditioner with a wet hand. An electric shock may result.
●Do not touch the switches with sharp objects.
●Turn offpower source when not using the unit for extended periods.
●Always turn offthe electrical breaker whenever cleaning the air conditioner or changing the
air filter.
●Connection valves become hot during Heating; handle with care.
●Check the condition of the installation stand for damage.
●Do not place animals or plants in the direct path of the air flow.
●When restarting after a long period of disuse in the winter, turn the power switch on at least
12 hours before starting the unit.
●Do not drink the water drained from the air conditioner.
●Do not use the air conditioner for other purposes. In order to avoid any quality deterioration,
do not use the unit for cooling precision instruments, food, planets, animals or works of art.
●Do not apply any heavy pressure to radiator fins.
●Before using the appliance, read these “SAFETY PRECAUTIONS” thoroughly and operate in the correct way.
●The instructions in this section all relate to safety; be sure to maintain safe operating conditions.
●“DANGER”, “WARNING” and “CAUTION” have the following meanings in these instructions:
TEMPERATURE SET BACK TIMER......................11
ECONOMY OPERATION ...................................... 12
CLEANING AND CARE......................................... 12
TROUBLESHOOTING .......................................... 13
OPERATING TIPS................................................. 14
SELF-DIAGNOSIS ................................................ 16
TEMPERATURE AND HUMIDITY RANGE ........... 16
DANGER
CAUTION
WARNING
DANGER This mark indicates procedures which, if improperly performed, are most likely to result
in the death or serious injury to the user or service personnel.
WARNING This mark indicates which, this product contains button or coin cell battery. Hazardous
if swallowed.
WARNING This mark indicates procedures which, if improperly performed, might lead to the
death or serious injury of the user or service personnel.
CAUTION This mark indicates procedures which, if improperly performed, might possibly result in
personal harm to the user, or damage to property.
9381857159-01OMEnARTG24LMLC.indd29381857159-01OMEnARTG24LMLC.indd2 2022/03/0415:50:252022/03/0415:50:25

3
●Operate only with air filters installed.
●Do not block or cover the intake grille and outlet port.
●Ensure that any electronic equipment is at least 1m away from either the indoor or outdoor
units.
●Avoid installing the air conditioner near a fireplace or other heating apparatus.
●When installing the indoor and outdoor units, take precautions to prevent access by infants.
●Do not use flammable gases near the air conditioner.
●This appliance is not intended for use by persons (including children) with reduced physical,
sensory or mental capabilities, or lack of experience and knowledge, unless they have been
given supervision or instruction concerning use of the appliance by a person responsible
for their safety.
Children should be supervised to ensure that they do not play with the appliance.
●If you see lightning or hear thunder, there might be a lightning strike. To prevent electric
shock hazard, turn off the air conditioner by using the remote controller, and do not touch
the unit or the power plug during thunderstorm.
●Do not place any other electrical products or household belongings under indoor unit or
outdoor unit. Dripping condensation from the unit might get them wet, and may cause dam-
age or malfunction of your property.
●Keep clean and tidy around the outdoor unit, and do not place the things around it. If it is
covered with fallen leaves, there could be an infiltration of small animals or insects whose
contact with the internal electrical components leads to the product malfunction.
●Do not stand on unstable steps when operating or cleaning the air conditioner. It may overturn
and can cause the injury.
CAUTION
SAFETY PRECAUTIONS
FEATURES AND FUNCTIONS
■Energy saving and Comfortable function ■Remote controller
WIRED REMOTE CONTROLLER
The wired remote controller allows convenient control of indoor
unit operation.
WIRELESS REMOTE CONTROLLER (OPTION)
The optional wireless remote controller can be used. When
you use remote controller, there are following different points
as compared with using wired remote controller.
[The additional function for wireless ones]
• SLEEP timer
• TIMER
• 10 °C HEAT operation
And you can use both wireless and wired remote controller
simultaneously. (But function is limited.)
[The restricted functions for wired ones]
• Weekly timer
• Temperature set back timer
WEEKLY TIMER
Use this timer function to set operating times for each day of
the week. Use the DAY OFF setting to switch offtimed opera-
tion for a selected day in the coming week. Because all days
can be set together, the weekly timer can be used to repeat
the timer settings for all of the days.
TEMPERATURE SET BACK TIMER
Use this timer function to change the set temperature in the
operation times set for each day of the week. This can be used
together with other timer settings.
■Convenient function
INVERTER
At the start of operation, large amount of power is used to
bring the room quickly to the desired temperature. Afterwards,
the unit automatically switches to a low power setting for eco-
nomic and comfortable operation.
ECONOMY OPERATION
When ECONOMY operation mode is operated, the room tem-
perature will be little higher than the set-temp under cooling
mode and lower than set-temp under heating mode. Therefore,
the ECONOMY mode is able to save more energy than other
normal mode.
AUTO CHANGEOVER
The operation mode (cooling, dry, heating) is switched auto-
matically to maintain the set temperature, and the temperature
is kept constant at all times.
9381857159-01OMEnARTG24LMLC.indd39381857159-01OMEnARTG24LMLC.indd3 2022/03/0415:50:252022/03/0415:50:25

4
NAME OF PARTS
Remote controller
1
START/STOP button
2
SET TEMP. (temperature) button
3
MODE button
4
FAN button
5
ECONOMY button
6
TIMER MODE (CLOCK AD-
JUST) button
7
DAY (DAY OFF) button
8
SET BACK button
9
SET TIME ( < > ) button
10
TIMER DELETE button
11
TIMER SET button
12
Up/Down airflow direction and
Swing button*1
13
Left/right airflow direction and
Swing button*2
14
MAINTENANCE(FILTER RE-
SET) button#1
15
Operation lamp
16
Timer and Clock indicator
17
Operation mode indicator
18
Fan speed indicator
19
Operation lock indicator
20
Temperature indicator
21
Function indicator
Defrost indicator
Thermo sensor indicator
ECONOMY indicator
Vertical swing indicator*3
Filter indicator#1
*1~3 These functions cannot be used.
(Please also see the operating manual
of the option when using it with options,
etc.)
#1 Can be used if set correctly during
installation. Please consult authorized
service personnel when using this
function.
9381857159-01OMEnARTG24LMLC.indd49381857159-01OMEnARTG24LMLC.indd4 2022/03/0415:50:252022/03/0415:50:25

5
PREPARATORY OPERATION
Press the TIMER MODE (CLOCK
ADJUST) button for 2 seconds or
more. The time indicator on the
remote controller will blink.
2
SU MO TU WE TH FR SA
Press the DAY button and select the current day.
A appears around the selected day.
Press the SET TIME (< >) buttons to set the current time.
Press repeatedly to adjust the current time in 1-minute incre-
ments. Press and hold to adjust the current time in 10-minute
increments.
ex. Monday 23:00
Press again to end.
SU MO TU WE TH FR SA
1
3
5
Press the SET BACK button to switch between the
12- and 24-hour time displays.
3
4
SU MO TU WE TH FR SA SU MO TU WE TH FR SA
SET BACK
Set the current day and time
9381857159-01OMEnARTG24LMLC.indd59381857159-01OMEnARTG24LMLC.indd5 2022/03/0415:50:262022/03/0415:50:26

6
OPERATION
AUTO COOL DRY HEAT*FAN
Temperature setting range
AUTO............................................... 18 to 30°C
COOL/DRY ...................................... 18 to 30°C
HEAT*.............................................. 16 to 30°C
Lower Rise
Operation lamp
Air conditioner ON: Lit brightly
Air conditioner OFF: Not lit
Press the START/STOP button.
Press the MODE button to set the operation mode.
If DRY is selected, the fan speed will be set to AUTO.
Press the SET TEMP. buttons to set the room temperature.
Press the FAN button to set the fan speed.
Press the ECONOMY button to start or stop ECONOMY opera-
tion.
For details on the function, refer to page 12.
To start/stop operation
To set the operation mode
●Operation mode setting
●Room temperature setting
●Fan speed setting
ECONOMY operation
AUTO HIGH MED LOW QUIET
9381857159-01OMEnARTG24LMLC.indd69381857159-01OMEnARTG24LMLC.indd6 2022/03/0415:50:262022/03/0415:50:26

7
Press the ECONOMY button for more than 2 seconds to select
whether the room temperature is detected at the indoor unit or
the remote controller.
When the thermo sensor indicator appears, the room
temperature is detected at the remote controller.
NOTES
●If this function is locked, the location where the room temperature is detected cannot be changed and the mark blinks
when the ECONOMY button is pushed for 2 seconds or more.
Indoor unit
Room temperature sensor selection
OPERATION
Child lock function
Press the DAY (DAY OFF) button and TIMER SET button
simultaneously for 2 seconds or more to activate the child lock
function and lock all of the buttons on the remote controller
except the START/STOP button, SET TEMP. buttons, MODE
button, and FAN button. Press the buttons again for 2 seconds
or more to deactivate the child lock function.
When the child lock function is activated, the mark
appears. If any button is pressed during the child lock, the CL
indicator blinks.
●This function is locked at the factory. In order to detect the room temperature correctly, consult authorized ser-
vice personnel when using this function.
9381857159-01OMEnARTG24LMLC.indd79381857159-01OMEnARTG24LMLC.indd7 2022/03/0415:50:262022/03/0415:50:26

8
To set the On/Offtimer
TIMER FUNCTIONS
ON/OFF TIMER
Press the TIMER MODE button to
select the On timer or Offtimer.
2
• Press the TIMER DELETE button to cancel the timer mode.
•
The timer mode can also be canceled by changing the timer mode using the TIMER MODE button .
1
NON
STOP
OFF
TIMER
ON
TIMER
WEEKLY
TIMER
No indicator
SU MO TU WE TH FR SA
Press the SET TIME (< >) buttons to set the time.
After the time is set, the timer will start automatically.
The amount of time until the Offtimer operates that is displayed
on the timer indicator decreases as time passes.
From 1 to 24 hours ex. Offtimer set for 6 hours
●To cancel
Offtimer (See page 8.)
Use this timer function to stop air conditioner operation. The timer operates and air conditioner operation stops after the
set time has passed. The timer can be set up to 24 hours in advance.
On timer (See page 8.)
Use this timer function to start air conditioner operation. The timer operates and air conditioner operation starts after the
set time has passed. The timer can be set up to 24 hours in advance.
Weekly timer (See page 9.)
Use this timer function to set operating times for each day of the week.
Use the DAY OFF setting to switch offtimed operation for a selected day in the coming week.
Because all days can be set together, the weekly timer can be used to repeat the timer settings for all of the days.
Temperature set back timer (See page 11.)
Use this timer function to change the set temperature in the operation times set for each day of the week.
This can be used together with other timer settings.
9381857159-01OMEnARTG24LMLC.indd89381857159-01OMEnARTG24LMLC.indd8 2022/03/0415:50:262022/03/0415:50:26

9
WEEKLY TIMER
Press the TIMER MODE button to select the weekly timer.
2
Press the TIMER SET button for
2 seconds or more.
1
3●Day of the week setting
Press the DAY button to select the day of the week, and then press the TIMER
SET button to confirm the setting.
For ALL, all of the days can be set together when a appears around
each day.
ALL SU MO TU WE TH FR SA
4●Time setting
Press the SET TIME (< >) buttons to set the time, and then press the TIMER SET
button to confirm the setting and proceed to the next on or offtime setting.
Up to 2 times on and offtimes can be set per day.
Press the DAY button to complete the time setting and return to the day of the week
setting.
5
Repeat steps 3and 4.
To complete the weekly timer settings, press the TIMER
SET button for 2 seconds or more.
●To delete the operating time
If the TIMER DELETE button is pressed dur-
ing steps 3or 4, the operating time for the
selected day will be deleted.
If all the days are selected, the operating
times for all of the days will be deleted.
NOTES
●The operating time can be set in 30 minute increments only.
●The offtime can be carried over to the next day.
●The On timer and the Offtimer functions cannot be set using the weekly timer. Both an On and Offtime must be set.
ON-1 OFF-1 ON-2 OFF-2
ex. The timer is set for 7:00-18:00.
12
123
Weekly timer setting
When the operating time is set,
the mark appears.
9381857159-01OMEnARTG24LMLC.indd99381857159-01OMEnARTG24LMLC.indd9 2022/03/0415:50:262022/03/0415:50:26

10
SU MO TU WE TH FR SA
369 12 15 18 21
SU MO TU WE TH FR SA
369 12 15 18 21
WEEKLY TIMER
●To start
When the weekly timer is selected, the
timer starts automatically.
The operating time for the current
day is displayed.
●To cancel
●Press the TIMER DELETE button to
cancel the timer mode.
●The timer mode can also be
cancelled by changing the timer
mode using the TIMER MODE
button.
1
During the weekly timer, press
the TIMER SET button for
2 seconds or more to set the
day.
Select the day to set the
day off.
Press the DAY (Day off) button
for 2 seconds or more to set
the day off.
Press the TIMER SET but-
ton for 2 seconds or more to
complete the day offsetting.
243
●To cancel
Follow the same procedures as those
for setup.
ex. The day offis set for Monday.
NOTES
●The day offsetting is only available for days for which weekly settings already exist.
●If the operating time carries over to the next day (during a next day setting), the effective day offrange will be set as shown
below.
●Normal ●Next day setting
Setting dayPreceding day Next day Setting dayPreceding day Next day
●The day offsetting can only be set 1 time. The day offsetting is cancelled automatically after the set day has passed.
The mark blinks under a day of the week.
ON OFF ON OFF
DAY OFF
WEEKLY WEEKLY
WEEKLY
WEEKLY
ON OFF ON OFF
DAY OFF
ex. Operating time 7:00-18:00
Weekly timer operation
To set the day off(for a holiday)
9381857159-01OMEnARTG24LMLC.indd109381857159-01OMEnARTG24LMLC.indd10 2022/03/0415:50:282022/03/0415:50:28
