Fujitsu ASU9RLS3 User manual

SPLIT TYPE
ROOM AIR CONDITIONER
WALL MOUNTED TYPE
CONTENTS
SPECIFICATIONS. . . . . . . . . . . . . . . . . . .
1
DIMENSIONS . . . . . . . . . . . . . . . . . . . . . . 2
REFRIGERANT SYSTEM DIAGRAM. . . .3
CIRCUIT DIAGRAM . . . . . . . . . . . . . . . . . 4
ERROR DETECTION . . . . . . . . . . . . . . . .
5
INDOOR PCB CIRCUIT DIAGRAM . . . . .
6
OUTDOOR PCB CIRCUIT DIAGRAM . . .
7
PARTS (INDOOR UNIT). . . . . . . . . . . . . .9
PARTS (OUTDOOR UNIT) . . . . . . . . . . .15
18
ACCESSORIES . . . . . . . . . . . . . . . . . . .
Indoor unit Outdoor unit
ASU9RLS3
ASU12RLS3
AOU9RLS3H
AOU12RLS3H

SPECIFICATIONS
TYPE Extra low temp. heating
INDOOR UNIT ASU9RLS3
OUTDOOR UNIT AOU9RLS3H
COOLING CAPACITY
9,000 Btu/h 2.64 kW
HEATING CAPACITY 12,000 Btu/h 3.52 kW
POWER SOURCE 208/230 V
FREQUENCY 60 Hz
RUNNING
CURRENT
MAXIMUM
CURRENT
2.5 A
3.3 A
INPUT WATTS 0.50 kW
0.66 kW
EER Cooling 18.0 Btu/Wh
COP Heating
Cooling
Heating
Cooling
Heating
Cooling
Heating
18.2 Btu/Wh
MOISTURE REMOVAL
AIR CIRCULATION HIGH
9.4 A
11.9 A
2.6 Pts/h 1.2 L/h
ASU12RLS3
AOU12RLS3H
12,000 Btu/h 3.52 kW
16,000 Btu/h 4.69 kW
3.8 A
4.7 A
0.79 kW
1.01 kW
15.2 Btu/Wh
15.8 Btu/Wh
2.7 Pts/h 1.3 L/h
489 CFM, 830 m3/h
FAN MOTOR
POWER SOURCE 208/230 V
High
INDOOR UNIT
Cooling
Medium
Low
Quiet
High
INDOOR UNIT
Heating
Medium
Low
Quiet
High
Medium
Low
Quiet
1,100 r.p.m.
940 r.p.m.
820 r.p.m.
600 r.p.m.
1,100 r.p.m.
940 r.p.m.
820 r.p.m.
600 r.p.m.
OUTDOOR UNIT Heating
OUTDOOR UNIT Cooling
780 r.p.m.
720 r.p.m.
ELECTRICAL DATA
INDOOR UNIT
Cooling
High
Medium
Low
Quiet
INDOOR UNIT
Heating
OUTDOOR UNIT Heating
NOISE LEVEL
42 dB
37 dB
32 dB
23 dB
41 dB
35 dB
31 dB
23 dB
47 dB
OUTDOOR UNIT Cooling 42 dB
47 dB
43 dB
2015.01.06 1
COMPRESSOR TYPE Hermetic type, 4 pole, 3 phase,
DC inverter motor, Rotary
DISCRIMINATION
PRECHARGED REFRIGERANT
REFRIGERANT TYPE R410A
WEIGHT (with oil)
COMPRESSOR AND REFRIGERANT
Pipe length 49 ft. 15m
FULL CHARGE 66 ft. 20m
MAXIMUM PIPING HEIGHT 49 ft. 15m
ADDITIONAL CHARGE 0.22 oz/ft 20 g/m
WEIGHT
INDOOR UNIT Net / Shipping
Net / ShippingOUTDOOR UNIT 86 lb. / 93 lb. 39 kg / 43 kg
INDOOR UNIT H x W x D
H x W x DOUTDOOR UNIT 24-1/2 x 31-3/32 x 11-13/32 inch
620 x 790 x 290 mm
DIMENSIONS
808-884-80
20 lb. 8 oz. 9.3 kg
2 lb. 14 oz., 1,300 g
2 lb. 14 oz. 1,300 g
3 lb. 1 oz. 1,400 g
11-5/8 x 37 x 10-5/8 inch
295 x 940 x 270 mm
31 lb. / 37 lb. 14 kg / 17 kg

DIMENSIONS
11-5/8 inch
295 mm
10-5/8 inch
270 mm
37 inch
940 mm
2014.12.16 2
INDOOR UNIT
15.8 to 16.7 mm
Drain hose
Diameter
Outside
Inside :
13.8 mm
600 mm
OUTDOOR UNIT
11-13/32 inch
290 mm
31-3/32 inch
790 mm
21-1/4 inch
540 mm
24-13/32 inch
620 mm

REFRIGERANT
SYSTEM DIAGRAM
Refrigerant direction
Cooling
Heating
Refrigerant pipe diameter
Liquid : 1/4" (6.35 mm)
Gas : 3/8" (9.52 mm)
2-Way valve
Strainer
Strainer
3-Way valve
Muffler
Accumulator
Muffler
4-Way valve
Expansion valve
Heat exchanger
(indoor unit)
Heat exchanger
(outdoor unit)
Compressor
2015.01.06 3

INDOOR UNIT OUTDOOR UNIT
2015.01.06 4
CND01
CNA01
CNB02
CNB01
CNC01
1 2 3 4 5
9
8
7
6
5
4
3
2
1
9
8
7
6
5
4
3
2
1
9
8
7
6
5
4
3
2
1
2
1
2
1
3
2
1
Communication PCB
( Option )
To Main PCB
Remote control
( Option )
Ex. in ( Option )
Ex. out ( Option )
Operation status
Ex. out ( Opyion )
Error status
CN9
Red
White
White
White
White
White
White
White
Blue
Yellow
White
Black
Red
Red
Orange
Yellow
Pink
Blue
Green
Orange
Yellow
Pink
Blue
Red
Orange
Yellow
Pink
Blue
Black
Black
Black
Black
Black
White
Red
White White White
1
2
3
4
5
6
7
8
9
1
2
3
4
5
6
7
1
2
3
4
5
6
7
123 4 5
CN1
1
2
3
4
5
6
7
1
2
3
4
5
6
7
1
2
3
4
5
6
1
2
3
4
5
6
1
2
3
4
5
6
7
1
2
3
4
5
6
7
1
2
3
4
5
6
1
2
3
4
5
6
1
2
3
4
5
1
2
3
4
5
1
2
3
4
5
1
2
3
4
1
2
3
4
3
2
1
3
2
1
123 4 5
3 2 1
3 2 1
CN14
CN10
CN6
CN4
CN2
CN3
CN7
CN5
W4
CN201
Fan motor FM
Diffuser M
Earth terminal
Terminal
Pyroelectric
sensor board
To Communication kit
( Option )
Test
Thermistor ( Room temp. )
Thermistor ( Pipe temp. )
Louver ( Up / Down )
Louver ( Left / Right )
M
M
1 2 3
Indicator PCB
Main PCB
CIRCUIT DIAGRAM
Brown
1
Yellow
White
Black
Red
Red
Blue
Orange
Yellow
White
Black
Black
Black Black
Black
White White White Black
Red
White
Black
Black
Black
Red
White
Black
Brown
Brown
Black
Black
Red
White
White
Green
Green
Black
Black
Black
2
3
4
5
6
7
1
2
3
4
5
6
7
1
2
3
4
5
1
2
3
4
5
1
2
3
1
2
3
1
2
3
4
1
2
3
4
1
2
3
1
2
3
W10
W11
CN71
CN70
W4
W2
W1
W3
3
2
1
U W7
3
2
1
1 2 3 4 5
1 2 3 4 5
CN10
CN30
CN40
CN800
V W8
W W9 S
R
C
Compressor
CM
Fan motor
Expansion valve coil
4-way valve coil
Heater
Thermostat
( 55 {131 F } )
Fuse 250V 5A
x 2
Fuse 250V 20A
Fuse
250V
5A
G
G
Terminal
Power source
Reactor
Thermistor ( pipe temp. )
Thermistor ( discharge temp. )
Thermistor ( outdoor temp. )
Main PCB
1 2 3 L1 L2
4WV
PMV
FM
G

BLACK
BLACK
BLACK
BLACK
RED
ORANGE
YELLOW
PINK
BLUE
RED
ORANGE
YELLOW
PINK
BLUE
RED
ORANGE
YELLOW
PINK
BLUE
WHITE
WHITE
WHITE
WHITE
WHITE
WHITE
WHITE
BLACK RED WHITE
WHITE
WHITE
WHITE
WHITE
WHITE
WHITE
WHITE
WHITE
WHITE
WHITE
BLUE
WHITE
YELLOW
BLACK
RED
9
8
7
6
5
4
3
2
1
9
8
7
6
5
4
3
2
1
1
2
3
1
2
3
6
5
4
3
2
1
1
2
3
4
5
6
7
1
2
3
4
5
6
7
1
2
3
4
5
1
2
3
4
5
6
7
1
2
3
4
5
6
1
2
3
4
5
1
2
3
4
12345
W4
CN1
2013485-1
WHITE
CN4
B04B-PL I RK-1
RED
CN10
B05B-PL I SK-1
WHITE
CN9
B06B-PL I RK-1
RED
CN5
B07B-PL I SK-1
WHITE
CN3
SZT15-07WS
WHITE
CN6
B5B-PH-K-S
CN7
B5 ( 6-5 ) B-XN I SK-A-1
WHITE
CN14
B03B-PL I SK-1
WHITE
CN2
B7 ( 9-7.8 ) B-PL I SK
WHITE
CND01
B7 ( 9-7.8 ) B-PL I SK
B03B-PL I SK-1
FAN MOTOR F M
TEST
CN201
S7B-PH-K-S
DIFFUSER
M
M
MLOUVER ( RIGHT / LEFT )
LOUVER ( UP / DOWN )
THERMISTOR ( ROOM TEMP. )
THERMISTOR ( PIPE TEMP. )
GREEN
EARTH TERMINAL
TERMINAL
1
3
2
OUTDOOR UNIT
I NDICATOR PCB
K12JZ-1200HSE-D0
MAIN PCB
ASU9RLS3 : K13RA-1400HSE-C1
PYROELECTRIC SENSOR BOARD
UTY-TWBXF ( OPTION )
COMMUNICATION PCB
K10DC-1000HSE-CA0
CONTROL UNIT
ASU9RLS3 : EZ-014YHSE
INDOORP CB C I RCUIT D I A G RAM
2015.01.06 5
ASU12RLS3 : K13RA-1401HSE-C1
ASU12RLS3 : EZ-01400HSE
CN7 DC Fan motor
6
5
4
3
2
1
Pin No. Terminal
code
Vm
GND
Vcc
Vsp
PG
Function of terminal
Revolution pulse output
Speed control voltage input
Control power voltage input
GND
Motor power voltage input
Lead wire
color
Red
Black
White
Yellow
Blue
CN4 Thermistor Characteristics.
0 20 30
Thermistor
Thermistor ( Pipe temp. ) 176.0 k 62.9 k 39.6 k
1.1 V 2.2 V 2.8 V
Thermistor ( room temp. ) 33.6 k 12.5 k 8.0 k
3.0 V 4.0 V 4.3 V
Temperature
DC5V
DC5V
DC340V
DC340V
DC15V
DC13V
DC13V
DC13V
DC5V
G

W11
B
W10
B
W1
B
W2
B
W4
B
W3
B
W7
B
W8
B
W9
B
U
V
W
1
2
3
4
5
6
7
1
2
3
4
5
1
2
3
1
2
3
4
1
2
3
3
2
1
CN70
B03B-PASK-1
WHITE
CN10
B3P5-VH-B
WHITE
CN71
B04B-PASK-1
WHITE or BLUE
CN30
B2P3-VH-B-C
BLACK
CN40
B05B-PL I SK-1
WHITE
UL3271 AWG16 x 3
BLACK
WHITE
RED
BLACK
BLACK
RED
BLACK
WHITE
YELLOW
BROWN
RED
BLUE
ORANGE
YELLOW
WHITE
UL1015 AWG14
BLACK
UL1015 AWG14
WHITE
UL1015 AWG20
RED
UL1015 AWG16
GREEN
BLACK
BLACK
BROWN
BROWN or BLACK
BLACK
BLACK
BLACK
WHITE
BLACK
WHITE
W103
UL1015 AWG20
BLACK
W100
UL1015 AWG20
WHITE
W102
UL1015 AWG20 BLACK
W101
UL1015 AWG14
BLACK
WIRE w / TERMINAL ( CORE )
1015#22
GREEN
F202
5A - 250V
F201
20A - 250V
FRAME
TERMINAL
5A - 250V
5A - 250V
HEATER
230V 50W
THERMISTOR ( OUTDOOR TEMP. )
THERMISTOR ( DISCHARGE TEMP. )
THERMISTOR ( PIPE TEMP. )
EXPANSION VALVE COIL
DC FAN MOTOR
COMPRESSOR
C M
F M
PMV
W5 W6
EMI FILTER
ZCAT2132-1130
1 T
UL3271
AWG14
WHITE
UL3271
AWG14
RED
UL3271
AWG14
ORANGE
EMI FILTER
ZCAT2132-1130
1 T
1
2
3
L
N
L
N
SERIAL
EARTH
POWER SOURCE
AC208/230V
60Hz
TO OUTDOOR UNIT
MAIN PCB
AOU9RLS3H : K10CT-1403HUE-C1
AOU12RLS3H : K10CT-1405HUE-C1
INVERTER ASSEMBLY
AOU9RLS3H : EZ-014RHUE
AOU12RLS3H : EZ-014THUE
2015.01.06 6
O U T D OORP CB C I RCUIT D I A G RAM
CN70 Thermistor Characteristics.
Thermistor ( Discharge temp. ) 168.6 k 62.6 k 40.0 k
0.4 V 0.9 V 1.2 V
0 20 30
Thermistor
Thermistor ( Outdoor temp. ) 35.2 k 12.6 k 8.0 k
2.6 V 3.8 V 4.1 V
Temperature
CN71 Thermistor Characteristics.
0 20 30
Thermistor
Thermistor ( Pipe temp. ) 16.1 k 6.0 k 3.8 k
1.1 V 2.2 V 2.8 V
Temperature
U-V
V-W
U-W
Compressor
Winding Resistance
1.408 (25 )
CN800 DC Fan Motor
1
3
4
5
6
Pin No. Terminal
code
Vm
GND
Vcc
Vsp
FG
Function of terminal
Revolution pulse output
Speed control voltage input
Control power voltage input
GND
Motor power voltage input
Lead wire
color
Red
Black
White
Yellow
Brown
2
7
1(Red) - 2(Blue)
1(Red) - 3(Orange)
1(Red) - 4(Yellow)
1(Red) - 5(White)
CN40 Expansion Valve Coil
46.0
(20 )
Recommended Drive Condition
Unipolar Drive, 1-2 Phase Excitation.
Coil resistance
4-WAY VALVE COIL
DC Resistance 2085 (25 )
10%
REACTOR
15mH, 10A
DC Resistance 292.71m (25 )
AC208-230V
CN800
B5 ( 7-2.3 ) B-XASK-1-A
WHITE
DC15V
DC340V
DC12V
DC12V
G

If you use a wireless remote control, the lamp
on the photo detector unit will output error codes
by way of blinking patterns.
If you use a wired remote control, error codes
will appear on the remote control display.
See the lamp blinking patterns and error codes
in the table.
An error display is displayed only during operation.
Indoor unit lamps Wired
remote
control
Description
OPERATION
(green)
TIMER
(orange)
ECONOMY
(green)
Indoor unit lamps Wired
remote
control
Description
OPERATION
(green)
TIMER
(orange)
ECONOMY
(green)
(1) (1) Serial communication error
(1) (2) Wired remote control
communication error
(1) (5) Check run unfinished
(2) (2) Indoor unit capacity error
(2) (3) Combination error
(3) (2) Indoor unit PCB model
information error
(3) (5) Manual auto switch error
(4) (1) Room temp. sensor error
(4) (2) Indoor unit Heat Ex. Middle temp.
sensor error
(5) (1) Indoor unit fan motor error
(5) (15) Indoor unit error
Intake grill error
(6) (2)
Outdoor unit main PCB model
information error or
communication error
(6) (3) Inverter error
(6) (4) Active filter error,
PFC circuit error
(6) (5) Trip terminal L error
(6) (10) Display PCB microcomputers
communication error
(7) (1) Discharge temp. sensor error
Compressor temp. sensor error
(7) (3) Outdoor unit Heat Ex. liquid
temp. sensor error
(7) (4) Outdoor temp. sensor error
(7) (5) Suction Gas temp. sensor error
(7) (6) 2-way valve temp. sensor error•
3-way valve temp. sensor error•
(7) (7) Heat sink temp. sensor error
(8) (2)
Sub-cool Heat Ex. gas inlet•
temp. sensor error
Sub-cool Heat Ex. gas outlet•
temp. sensor error
(8) (3) Liquid pipe temp. sensor error
(8) (4) Current sensor error
(8) (6)
Discharge pressure sensor error•
Suction pressure sensor error•
High pressure switch error•
(9) (4) Trip detection
(9) (5) Compressor rotor position
detection error (permanent stop)
(9) (7) Outdoor unit fan motor error
(9) (9) 4-way valve error
(10) (1) Discharge temp. error
(10) (3) Compressor temp. error
(10) (4) High pressure error
(10) (5) Low pressure error
Branch boxes error
Wired remote control display (Option)
If an error occurs, the following display will be shown.
(“Er” will appear in the set room temperature display.)
Error code
E R R O R D ETE C TIO N
2015.01.06 7
: 0.5s ON / 0.5s OFF
: 0.1s ON / 0.1s OFF
( ) : Number of flashing
INDOOR UNIT
REMOTE CONTROL
(13) (2)
(2) (1)
Unit number or Refrigerant circuit
address setting error
[Simultaneous Multi]
(2) (7) Primary unit, secondary unit set-up
error [Simultaneous Multi]
(2) (4)
•Connection unit number error
(indoor unit)
[Simultaneous Multi]
•Connection unit number error
(indoor unit orbranch unit)
[Flexible Multi]
(5) (3) Drain pump error
(5) (7) Damper error
(5) (8)
(7) (2)
OPERATION indicator lamp (green)
TIMER indicator lamp (orange)
ECONOMY indicator lamp (green)

LED
OUTDOOR UNIT
0.5 second on / 0.5 second off
on
0.1 second on / 0.1 second off
2.0 second on / 2.0 second off
IPM overcurrent protection
Discharge temperature abnormal
Thermistor abnormal
CT abnormal
0.1 second on / 2.0 second off
5.0 second on / 5.0 second off
ERROR
Compressor location abnormal
Fan abnormal
2011.08.04 8

PART S
INDOOR UNIT
2015.01.06 9
6
9
10
8
Intake Grille with logotype 9333052083
7 Front Panel Sub Assy 9320459017
Bracket Panel
4
Wire Cover 9318786026
Wire shield
Electric Filter Holder 9332911008
5 Air Clean Filter Assy 9317250009
1
Remote Control 9320360047
2
3
Remote Control Holder 9318912005
9318861013
Ref. Description Part number
Air Filter 9380997009
Louver 9318849028
11 Diffuser Assy 9319232096
9
5
4
3
6
8
1
2
710 11

INDOOR UNIT
Control box
10
2014.12.16
Terminal 990072002524
Control Box22
Cover shield
21 9318757033Control Cover
9380996026
Main PCB (ASU9RLS3) 970962211723
Main PCB (ASU12RLS3) 970962212423
26 Room Thermistor Holder 9379930000
Ref. Description Part number
25
27 Thermistor Assy 9900627003
Display Assy 9709642023
23
22
21
26
25
24
27

INDOOR UNIT
Evaporator
Fan
Fan Motor 9603253028
Crossflow Fan Assy 9315024060
Bearing C Assy 9306628017
37
32
Evaporator Total Assy 931925418031
Casing Total Assy 9319171272
33
34
Motor Cover 9316568006
Motor Cover 9316601000
35
36
Ref. Description Part number
112014.12.16
37
34
33
31
32
35
36

41
42
43
INDOOR UNIT
Casing total assy
12
41 Outlet Cover Assy 9319776002
43
42
Casing Assy 9319172101
- Cable Guide 9321517006
Motor Case Assy 9319173085
Ref. Description Part number
2014.12.12

53
51
54
56
58
57
61
52
52
52
55
60
59
INDOOR UNIT
Motor case assy
13
Louver Gear B 9316616004
52
55
Step Motor (R&L)
60
Link A 9317507004
53
Step Motor (Louver)56
Step Motor (Diffuser)
9900384135
9900384142
9900139230
59
Gear A 9309994003
54
Louver Gear A 9318749007
51
Gear Cover A 9318748000
Gear Cover B 9318750003
Louver Link Holder 9319150000
Motor Case 9318746020
61
57
58
Ref. Description Part number
2014.09.09

80
77
74
75
73
79
71
72
78
76
INDOOR UNIT
Casing assy
14
Fan Guard 9320458003
79
80
76
Drain Hose Assy 9316904019
Pipe Bracket 931874301278
Drain Cap 9316177017
71
Casing Cover B 9318862003
74
Casing Cover F 9318864007
Casing Cover L 9318830002
Casing Cover R 931883100975
R and L Louver Assy 9319229027
Casing 9318840018
77
72
73
Ref. Description Part number
2014.12.12

4
5
6
12
10
11
2
8
7
3
OUTDOOR UNIT
PARTS
2014.12.18 15
3 Top Panel Assy 9318464023
4 Front Panel Assy 9318463026
2 Protective Net
6 Cabinet Left Assy 9318461015
5 Emblem
Valve bracket
Motor bracket
10 Propeller Fan 9313808013
9 Base Assy 9316885059
12 Reactor Assy 9900611019
Separator assy
11 Fan Motor 9602724017
Ref. Description Part number
9
1 Thermistor Holder 9313954031
9332492002
1
7
9317903011
Switch Cover 9317692021
8 Cabinet Right Assy 9316044050

OUTDOOR UNIT
2015.03.04 16
Ref. Description Part number
28 Outdoor Thermistor 9900544010
Terminal
bracket
Conduit bracket
24 Terminal 9900016081
23 Terminal Cover Assy 9317898034
29 Thermistor Assy 9900614027
Sealed panel
Inverter case
Inverter
case cover
Main PCB (AOU9RLS3H)21 9709221433
Main PCB (AOU12RLS3H)21 9709221457
22 PCB Holder 9313074029
27 Heat Sink B 9314090011
26 Heat Sink A 9314410017
25 Semiconductor Accessory 9705840010
24
23
21
27
26
22
28
29
25

OUTDOOR UNIT
2014.12.18 17
33 Compressor Assy 9317117005
35 3-way Valve Sub Assy 9317109000
38 Pulse Motor Valve Assy 9332368048
4-way Valve Assy 9315311092
37 Solenoid 9970110047
32 Condenser Total Assy 9317089098
39 Expansion Valve Coil 9970095030
36
34 2-way Valve Assy 9332371000
Ref. Description Part number
Heater
holder A
Heater holder B
31 Heater Unit Assy 9900616014
33
32
34
38
35
39
36
37
31

Name and Shape Part number
9310519004
0600185541Battery (penlight)
Cloth tape
ACCESSORIES
2014.12.18 18
INDOOR UNIT
Remote Control 9320360047
Remote Control
Holder
9318912005
Bracket Panel
9318861013
Name and Shape Part number
0700076046
9317250009
9332911008Filter holder
Air cleaning
filter assy
Tapping screw
(M4 x 25 mm)
Tapping screw
(M3 x 12 mm)
0700019036

1411G4392
