En-8
To Use the ON timer or OFF timer
1Press the START/STOP button (Fig. 5 K)
(if the indoor unit is already operating, proceed to step 2).
The indoor unit’s OPERATION Indicator Lamp (green) (Fig. 3
5
) will light.
2Press the TIMER MODE button (Fig. 5 I) to select the
OFF timer or ON timer operation.
Each time the button is pressed the timer function changes in the fol-
lowing order:
CANCEL OFF ON
PROGRAM(OFF
→ON, OFF ←ON)
The indoor unit’sTIMER Indicator Lamp (orange) (Fig. 3
6
) will light.
3Use the TIMER SET buttons (Fig. 5 O) to set the de-
sired OFF time or ON time.
Set the time while the time display is flashing (the flashing will continue
for about five seconds).
button: Press to advance the time.
button: Press to reverse the time.
About five seconds later, the entire display will reappear.
To Use the Program timer
1Press the START/STOP button (Fig. 5 K)
(if the indoor unit is already operating, proceed to step 2).
The indoor unit’s OPERATION Indicator Lamp (green) (Fig. 3
5
) will light.
2Set the desired times for OFF timer and ON timer.
See the section “To Use the ON timer or OFF timer” to set the desired
mode and times.
About 3 seconds later, the entire display will reappear.
The indoor unit’sTIMER Indicator Lamp (orange) (Fig. 3 6) will light.
3Press the TIMER MODE button (Fig. 5 I) to select the
PROGRAM timer operation (OFF ON or OFF ON
will display).
The display will alternately show “OFF timer” and “ON timer”, then
change to show the time setting for the operation to occur first.
●
The program timer will begin operation. (If the ON timer has been se-
lected to operate first, the indoor unit will stop operating at this point.)
About five seconds later, the entire display will reappear.
About the Program timer
●The program timer allows you to integrate OFF timer and ON timer operations
in a single sequence. The sequence can involve 1 transition from OFF timer to
ON timer, or from ON timer to OFF timer, within a 24 hour period.
●The first timer function to operate will be the 1 set nearest to the current time.
The order of operation is indicated by the arrow in the Remote Controller's Dis-
play (OFF →ON, or OFF ←ON).
●1 example of Program timer use might be to have the air conditioner automati-
cally stop (OFF timer) the operation after you go to sleep, then start (ON timer)
the operation automatically in the morning before you arise.
TIMER OPERATION
▲
Before using the timer function, be sure that the Remote Controller is set to the correct current time (☞P. 5).
To Cancel the Timer
Use theTIMER button to select “CANCEL”.
The indoor unit will return to normal opera-
tion.
To Change theTimer Settings
Perform steps 2and 3.
To Stop Air Conditioner Operation while
theTimer is Operating
Press the START/STOP button.
To Change Operating Conditions
If you wish to change operating conditions
(Mode, Fan Speed,Thermostat Setting, SU-
PER QUIET mode), after making the timer
setting and waiting until the entire display
reappears, then press the appropriate
buttons to change the operating condition
desired.
▲
▲
▼
To Cancel the Timer
Use theTIMER MODE button to select
“CANCEL”.
The air conditioner will return to normal
operation.
To Change theTimer Settings
1.
Follow the instructions given in the sec-
tion “To Use the ON Timer or OFF Timer”
to select the timer setting you wish to
change.
2. Press the TIMER MODE button to select
either OFF ON or OFF ON.
To Stop Air Conditioner Operation while
theTimer is Operating
Press the START/STOP button.
To Change Operating Conditions
If you wish to change operating conditions
(Mode, Fan Speed, Thermostat Setting, SU-
PER QUIET mode), after making the timer
setting and waiting until the entire display
reappears, then press the appropriate
buttons to change the operating condition
desired.
