Mini-Split Air Conditioners and Heat Pumps
for Residential and Light Commercial Applications

TABLE OF CONTENTS
FEATURES
Mini-Splits Defined.......................................... 4
Individual Zoning ............................................ 6
Comfort Solution ............................................ 8
Energy Efficient ............................................. 9
Comfort & Convenience ............................... 10
Applications .................................................. 11
Feature Descriptions .................................... 12
MODEL LINEUP
Indoor and Outdoor Model Table .................. 14
SINGLE ZONE MINI-SPLITS
Wall Mount ................................................... 17
Floor/Ceiling ................................................. 23
Ceiling Suspended ....................................... 23
Duct .............................................................. 24
Compact Cassette ........................................ 26
Large Cassette ............................................. 28
MULTI-ZONE MINI-SPLITS
Overview ...................................................... 31
Indoor Units
Wall Mount ............................................... 33
Duct .......................................................... 34
Compact Cassette ................................... 35
Multi-Zone (2-4 Zones) Outdoor .................. 36
Flex-Zone (2-8 Zones) Outdoor ................... 37
Branch Boxes ........................................... 38
Wiring ........................................................ 40
Piping ........................................................ 41
Allowable Combinations ............................... 42
ACCESSORIES
Descriptions .................................................. 44
Compatibility Chart ....................................... 45
MISCELLANEOUS
Line Set Length Chart ................................... 46
Model Nomenclature .................................... 46

4
Fujitsu Mini-Splits:
Year-Round, Whole-Home or Business
Energy Efficient Heating and Cooling
compressor/
condenser
(outdoor)
FEATURES
What is a Mini-Split?
Halcyon systems eliminate the need for a
basement or attic-located evaporator unit and
bulky ductwork by using thin copper tubing
that pumps refrigerant directly to discreet wall
mounted or concealed units inside. Even more
remarkable, this same unit works in reverse in
winter, absorbing heat from the outside air and
moving it indoors to heat your home. The
result? Efficient cooling and heating for year-
round, whole-house comfort in most climates.
Available in numerous mix-and-match
capacities and configurations, there's a
Halcyon mini-split system for even the
most difficult to heat and cool areas.
How Does a Mini-Split Work?
Like your refrigerator, heat pumps use electricity to pump refrigerant and transfer heat from one space
to another. When we transfer heat from within our home to the outdoors, we call it "air conditioning".
Conversely, when we transfer heat from the outdoors to within the home, we call it a "heat-pump".
evaporator/
fancoil (indoor)
refrigerant lines,
electric, drain
Unit Can Be
Showcased...
Wall mounted units
eliminate the need
for ductwork, mount
high on a wall and
deliver all of the
cooling you pay for.
...or Hidden
Compact Duct units are
mounted above a
ceiling or in a framed
enclosure below a
ceiling, so only the
grilles show for a clean
look. They require
minimal ductwork.
air
return
grille
air
supply
grille
Compact Duct Unit
Wall Mount Unit

5
An electric heater converts electricity directly to
heat, and if we assume that the heat loss is zero,
the output from one kilowatt input is one kilowatt
or 3,400 BTU and the EER is 3.4.
Heat pumps are more efficient than some other forms
of heating because heat pumps do not actually create
heat - they just move it from one place to another.
For example, the output of an efficient 10 EER heat
pump is triple that of an electric heater.
Electric Heaters versus Heat Pumps
*EER (Energy Efficiency Rating) = Rated BTU capacity divided by total kW input.
Heat Pumps Provide Heat When it is Chilly
Because refrigerant is naturally much colder than outdoor
temperatures even on a very cold day, it actually absorbs heat
from outdoors, and transfers the heat it absorbs outside to
within your home. The refrigerant's physical properties do this
naturally. What you pay for is the electricity to pump refrigerant
via copper tubing from outdoors to indoors. Because we move
the heat rather than create it (as electric baseboard or resistant
heat does), we can deliver up to 4 times the heat for the energy
we consume!
Basic Heat Pump Configuration
compressor
evaporator
compressor
expansion
valve
Heat In
Heat
Out
Basic Air Conditioner Configuration
compressor
evaporator
compressor
expansion
valve
Heat Out
Heat
In
Air Conditioners Provide Cooling When It’s Warm
Come spring and summer, simply reverse the process and
put the same system into "cooling mode" and transfer heat
from indoors to the outside. For many climates, the advanced
technology that goes into these units creates a far more cost
effective alternative to either gas or oil-fired units for heat, or
a central ducted system for air conditioning. Fujitsu’s mini-splits
come in both cooling-only models or heat pumps, which
provide both heating and cooling.

6
FEATURES
Individual Zoning: Personalized Whole Home Comfort
Halcyon HFI Systems are some of today’s most advanced forms of heating and air
conditioning. One outdoor unit can operate up to 8 indoor units simultaneously. Fujitsu’s
HFI Systems are super quiet as well as highly energy efficient.
Each indoor unit can be operated independently via remote control
Choose from a variety of indoor unit styles
Provide both heating and cooling (not simultaneously)
High energy efficiencies
Quiet operation
Wall Mounted
Stylish, slim and elegant, wall
mounted units are designed to
complement any interior décor.
Compact size
Wireless remote control
Automatic swinging louvers
Shown here is a 3-zone system using outdoor unit AOU36RLXFZ.
flex
48,000 BTUs
multi
18, 24, 36,000 BTUs

7
Compact Duct
Mounted in a ceiling or in a framed
enclosure below a ceiling. They use
minimal ductwork and remain very
energy efficient.
Concealed and out of sight
Look of central air with the
efficiency of a mini-split
Less ducts = higher efficiency
Compact Cassette
Cassettes are extremely discreet, with
only the grille showing in the ceiling.
They use the latest fan technology to
distribute the conditioned air evenly.
Wired remote controller
(wireless is optional)
Powerful turbo fan operation
Fits into a standard 2’ x 2’
ceiling grid
Wall Mounted
They mount high on a wall, out of sight
and do not require ductwork, increasing
energy efficiency.
Quiet operation
Easy maintenance
High delivered efficiency means
lower utility bills

8
FEATURES
Whole Home or Business Comfort
Fujitsu's Halcyon HFI systems provide home
and business owners just the right amount of
heating and cooling needed by installing 2 to 8
indoor units connected to one outdoor unit.
Indoor units vary by size and style and each
creates its own "zone" of comfort, allowing you
to heat or cool individual rooms, hallways and
open spaces.
Thick black lines
represent ducts
of a Central Air
System.
Red lines
represent mini-
ducts of a Fujitsu
Quad Zone
Compact Duct
System.
Ductless Technology
Don’t waste money cooling and heating the ducts
in your walls and attic. Fujitsu systems are duct-
less, meaning they install easily and won’t take
up valuable closet space. Since mini-splits have
little to no ducting, they forego those energy
losses typically associated with central forced-air
systems. Duct losses in a central air system can
easily account for more than 30% of energy
consumption, especially if the ducts are not
sealed tight or in an unconditioned space such
as an attic or crawlspace.
Central Air System versus Fujitsu HFI Quad Zone
A Solution for All of Your Comfort Needs
S
St ta ay y C Co oo ol l. .S St ta ay y W Wa ar rm m. .
S
St ta ay y C Co om mf fo or rt ta ab bl le e. .
B
Be ed dr ro oo om m 1 1
7
72 2° °F FB
Be ed dr ro oo om m 1 1
6
68 8° °F F
K
Ki it tc ch he en n
7
74 4° °F F
D
Di in ni in ng g
R
Ro oo om m
7
70 0° °F F
A Year Round Solution
Revolutionary Halcyon heat pumps provide
both heating and cooling for year round comfort
in most climates. A simple push of a button on
the remote control allows you to switch from
heating to cooling (or vice versa) automatically.

9
Energy Efficient: The Smart Choice in Comfort
*Savings may vary based on model selected, hours of operation
and geographical location. Example given based on 26-SEER
system versus 13-SEER system.
Where Does My Money Go? Other
8%
Electronics
7%
Lighting
10%
Clothes
Washer &
Dryer 6%
Dishwasher
2%
Refrigerator
5% Water
Heater
13%
Heating
& Cooling
49%
Fujitsu
saves 25%
on your
utility bill
Rebates
To encourage customers to buy energy efficient products, many
local utility companies offer significant rebates for the purchase
of a ductless mini-split system. Go to Fujitsu’s web site to search
for local rebates, consumer loans and utility bill discounts. We
provide a listing of rebates and offerings on qualifying Fujitsu
mini-splits by state. www.fujitsugeneral.com/utility_rebates.htm
As much as half of the energy used in your home goes to heating and cooling.
So, making smart decisions about your home’s heating and air conditioning
system can have a big effect on your utility bills — and your comfort.
The high energy efficiencies of
Halcyon systems slash utility
bills by up to 25%. If your
average annual utilities are
$4,200, Fujitsu can save you up to
$1,050 annually or $10,500 in 10 yrs!*
Federal Tax Credit Up To $300 through 2013
A tax credit can provide significant savings. It reduces the
amount of income tax you have to pay. Unlike a deduction,
which reduces the amount of income subject to tax, a tax
credit directly reduces the tax itself.
Federal tax credits are effective for systems purchased
through December 31, 2013 for “Qualified Energy Property”
The federal tax credit for qualified equipment is 10% of the
amount paid but shall not exceed $300 for the qualified
energy property.
Fujitsu has 16 qualifying systems in 2013
Check with your tax professional for details and visit
www.energystar.gov and click on “Tax Credits” for additional
information.

10
FEATURES
Comfort and Convenience
Flexible and Quiet
Mini splits offer flexibility because they can
be suspended from a ceiling, mounted flush
behind a drop ceiling, hung on a wall or floor-
standing. Ductless heat pumps allow for a
peaceful inside environment by enabling the
contractor to install components like
compressors and motors outdoors.
Weakest
Sound
Heard
Jet Engine
at 100’
Whisper
Quiet
Library
Normal
Conversation
from 3 - 5’
Power
Tools
140
105
70
35
0
dB(A) Level
Fujitsu
Indoor
Units
22~49
dB(A)
User Friendly Control
Fujitsu is using ergonomics to expand the use of
user friendly designs such as easy-to-read large
LCD displays, easy-to-operate buttons, and
displays with easily recognizable colors and icons.
We are producing control systems that provide
greater convenience for both individual and
centralized control with operability suitable
for the application.
Standard
Wireless
Remote for
RLS2 and
RLS2H
Systems
Optional Wired
Remote UTY-RVNUM
Constant Comfort through
Inverter Technology
Inverter technology is like cruise control for your
heating or cooling system. Compressors only run as
fast as they need to handle the cooling or heating
demand. They can handle greater extremes in
temperature, are smoother and more stable in
operation, and reach the desired temperature more
quickly than conventional air conditioners. Set
Temp.
Set
Temp.
Temp.
Temp.
Inverter System
Conventional
System
Inverter Benefits
More heat at lower outdoor temperatures
Lower RPMs = quieter operation
Desired temperature in half the time
Up to 30% more efficient
Stable temperature
