AIR CONDITIONER
2-unit multi-split type
SERVICE MANUAL
OUTDOOR
AOYG14KBTA2 AOYG18KBTA2
SR_MU001EF_11
2022.04.13
2-6. Outdoor unit
¢Model: AOYG14KBTA2
Unit: mm
580 109
330
353
Pitch of bolts
for installation
Pitch of bolts for installation
Top view
4-
M1
0 hole
Side viewSide view Front view
799 68 29016
33 30
19
542
20
Airflow
Bottom view Side view (Valve part)
37
399
Drain port Ø42
114
57104.4
150.1
19.7
2-6. Outdoor unit - (01-32) - 2. Dimensions
GENERAL
INFORMATION
GENERAL
INFORMATION
¢Model: AOYG18KBTA2
Unit: mm
Side viewSide view Front view
Bottom view Side view (Valve part)
Top view
580
79919 68 16 290
33 30
109
353
632
20
330
Pitch of bolts
for installation
Pitch of bolts for installation
4-
M1
0 hole
Airflow
Drain port Ø42
37
114
57104.4
399 150.1
19.7
2-6. Outdoor unit - (01-33) - 2. Dimensions
GENERAL
INFORMATION
GENERAL
INFORMATION
4. Outdoor unit parts list
4-1. Model: AOYG14KBTA2
¢Exterior parts and Chassis
2
1
3
4
Item no. Part no. Part name Service part
1 9322144003 Drain pipe ♦
2 9900565060 Outdoor thermistor ♦
3 9322811011 Protective net assy ♦
4 9322556028 Top panel assy ♦
4-1. Model: AOYG14KBTA2 - (02-58) - 4. Outdoor unit parts list
TECHNICAL DATA
AND PARTS LIST
TECHNICAL DATA
AND PARTS LIST
14
13
18 17
15
16
20
19
12
11
Item no. Part no. Part name Service part
11 9319151007 Emblem ♦
12 9322555014 Front panel assy ♦
13 9322570055 Switch cover assy ♦
14 9322552181 Cabinet right assy ♦
15 9900369064 Terminal 3P ♦
16 9900435042 Terminal 6P ♦
17 9900963019 Reactor assy ♦
18 9322553010 Motor bracket assy ♦
19 9603553005 Brushless motor ♦
20 9322136008 Propeller fan ♦
4-1. Model: AOYG14KBTA2 - (02-59) - 4. Outdoor unit parts list
TECHNICAL DATA
AND PARTS LIST
TECHNICAL DATA
AND PARTS LIST
IPM spacer L
IPM
spacer R
PWB Holder
Auxiliary
plate
Terminal
bracket assy
Shield panel
22
21
23
Item no. Part no. Part name Service part
21 9709683781 Main PCB (Service unit) ♦
22 9322418005 Heat sink ♦
23 9900727062 Thermistor assy ♦
— 9900984014 Thermistor (Heat exchanger) ♦
— 9901025013 Thermistor assy (AB) ♦
— 9900985035 Compressor temp. thermistor ♦
4-1. Model: AOYG14KBTA2 - (02-60) - 4. Outdoor unit parts list
TECHNICAL DATA
AND PARTS LIST
TECHNICAL DATA
AND PARTS LIST
Hair pin
cushion
31
Item no. Part no. Part name Service part
31 9323834576 Heat exchanger unit ♦
— 9322535009 S-insulator B ♦
— 9322536013 S-insulator F ♦
— 9322537003 S-insulator H ♦
— 9323045002 S-insulator V ♦
4-1. Model: AOYG14KBTA2 - (02-61) - 4. Outdoor unit parts list
TECHNICAL DATA
AND PARTS LIST
TECHNICAL DATA
AND PARTS LIST
Rubber
cushion
41
43
42
Item no. Part no. Part name Service part
41 9322427021 Compressor assy ♦
42 9322444035 4-way valve assy ♦
43 9970206009 Solenoid ♦
4-1. Model: AOYG14KBTA2 - (02-62) - 4. Outdoor unit parts list
TECHNICAL DATA
AND PARTS LIST
TECHNICAL DATA
AND PARTS LIST
51
55
54
53
52
Item no. Part no. Part name Service part
51 9383070006 Valve assy ♦
52 9382236038 Valve gas pipe assy ♦
53 9383071003 Pulse motor valve assy ♦
54 9970186042 Expansion valve coil (A) ♦
55 9970187032 Expansion valve coil (B) ♦
4-1. Model: AOYG14KBTA2 - (02-63) - 4. Outdoor unit parts list
TECHNICAL DATA
AND PARTS LIST
TECHNICAL DATA
AND PARTS LIST
4-2. Model: AOYG18KBTA2
¢Exterior parts and Chassis
2
1
3
4
Item no. Part no. Part name Service part
1 9322144003 Drain pipe ♦
2 9900565060 Outdoor thermistor ♦
3 9322811028 Protective net assy ♦
4 9322556028 Top panel assy ♦
4-2. Model: AOYG18KBTA2 - (02-64) - 4. Outdoor unit parts list
TECHNICAL DATA
AND PARTS LIST
TECHNICAL DATA
AND PARTS LIST
