Fujitsu RSG09KMCDN User manual

AIR CONDITIONER
Wall mounted type
SERVICE MANUAL
For Extra Cold Climate Area
INDOOR
RSG09KMCDN
RSG12KMCDN
RSG14KMCDN
OUTDOOR
ROG09KMCDN ROG12KMCDN ROG14KMCDN
SR_AS038EJ_02
2020.12.15

Notices:
• Product specifications and design are subject to change without notice for future improvement.
• For further details, please check with our authorized dealer.

CONTENTS
1. GENERAL INFORMATION
2. TECHNICAL DATA AND PARTS LIST
3. TROUBLESHOOTING
4. CONTROL AND FUNCTIONS
5. FILED WORKING

1. GENERAL INFORMATION
2020.11.19
SR_CH01_AS038EJ_01

CONTENTS
1. GENERAL INFORMATION
1. Specifications..............................................................................................01-1
1-1. Indoor unit ......................................................................................................................01-1
1-2. Outdoor unit....................................................................................................................01-3
2. Dimensions..................................................................................................01-4
2-1. Indoor unit ......................................................................................................................01-4
2-2. Outdoor unit....................................................................................................................01-6

1. Specifications
1-1. Indoor unit
Type Wall mounted
Inverter heat pump
Model name RSG09KMCDN RSG12KMCDN RSG14KMCDN
Power supply 230 V ~ 50 Hz
Available voltage range 198—264 V
Capacity
Cooling
Rated kW 2.50 3.40 4.20
Btu/h 8,500 11,600 14,300
Min.—Max. kW 1.0—3.8 1.0—4.2 1.2—4.65
Btu/h 3,400—13,000 3,400—14,300 4,100—15,900
Heating
Rated kW 3.20 4.00 5.40
Btu/h 10,900 13,600 18,400
Min.—Max. kW 0.9—5.7 0.9—5.9 0.9—6.4
Btu/h 3,100—19,400 3,100—20,100 3,100—20,400
Input power
Cooling Rated
kW
0.540 0.800 1.100
Min.—Max. 0.21—1.08 0.21—1.25 0.26—1.25
Heating Rated 0.720 0.960 1.400
Min.—Max. 0.18—2.35 0.18—1.8 0.185—1.9
Current Cooling Rated A 2.5 3.6 4.9
Heating 3.3 4.3 6.2
EER Cooling kW/kW 4.63 4.25 3.82
COP Heating 4.44 4.17 3.86
Sensible capacity Cooling kW 2.37 2.74 3.26
Power factor Cooling %94 96 97
Heating 95 97 98
Moisture removal L/h (pints/h) 0.3 (0.5) 1.1 (1.9) 1.5 (2.6)
Maximum operating current *1 Cooling A6.0 7.0 8.5
Heating 9.5 11.5 16.0
Fan
Airflow rate
Cooling
HIGH
m3/h
670 690 770
MED 530 560 600
LOW 410 450 450
QUIET 280 280 280
Heating
HIGH 750 780 820
MED 620 630 650
LOW 510 520 520
QUIET 290 290 340
Type × Q'ty Crossflow fan × 1
Motor output W 27
Sound pressure level *2
Cooling
HIGH
dB (A)
40 42 43
MED 36 37 40
LOW 30 32 33
QUIET 20 20 20
Heating
HIGH 42 43 44
MED 38 39 40
LOW 33 35 35
QUIET 22 22 24
Heat exchanger type
Dimensions (H × W × D) mm
Main1: 210 × 670 × 26.6
Main2: 112 × 670 × 20
Sub1: 84 × 670 × 13.3
Fin pitch Man1: 1.2, Main2: 1.1, Sub1:1.4
Rows × Stages Main1: 2 × 10, Main2: 2 × 7, Sub:1 × 4
Pipe type Copper tube
Fin type Aluminum
Enclosure
Material Polystyrene
Color White + Pearl white (painted)
Approximate color of Munsell N 9.25/
Dimensions
(H × W × D)
Net mm 270 × 834 × 215
Gross 277 × 914 × 332
Weight Net kg 10.0
Gross 13.0
Connection pipe Size Liquid mm (in) Ø 6.35 (Ø 1/4)
Gas Ø 9.52 (Ø 3/8)
Method Flare
Drain hose Material PP+HDPE
Tip diameter mm Ø 13.8 (I.D.), Ø 15.8 to Ø 16.7 (O.D.)
Operation range Cooling °C 18 to 32
%RH 80 or less
Heating °C 16 to 30
Remote controller type Wireless (Wired, Mobile app*3 [FGLair™] [option])
NOTES:
• Specifications are based on the following conditions:
– Cooling: Indoor temperature of 27 °CDB/19 °CWB, and outdoor temperature of 35 °CDB/24 °CWB.
– Heating: Indoor temperature of 20 °CDB/15 °CWB, and outdoor temperature of 7 °CDB/6 °CWB.
– Pipe length: 5 m, Height difference: 0 m. (Between outdoor unit and indoor unit.)
• Protective function might work when using it outside the operation range.
• *1: Maximum current is maximum value when operated within the operation range.
• *2: Sound pressure level:
– Measured values in manufacturer’s anechoic chamber.
– Because of the surrounding sound environment, the sound levels measured in actual installation conditions might be higher than the specified values here.
• *3: Available on Google Play™ store or on App Store®. WLAN adapter is also required. For details, refer to the setting manual.
1-1. Indoor unit - (01-1) - 1. Specifications
GENERAL INFORMATION GENERAL INFORMATION

Specifications for Lot10
Model name RSG09KMCDN RSG12KMCDN RSG14KMCDN
Energy efficiency class Cooling A++
Heating (Average) A++
Pdesign Cooling kW 2.5 (35 °C) 3.4 (35 °C) 4.2 (35 °C)
Heating (Average) 2.5 (-10 °C) 3.6 (-10 °C) 4.2 (-10 °C)
SEER Cooling kWh/kWh 6.5 7.5 7.3
SCOP Heating (Average) 4.6 4.6 4.6
Annual energy consumption QCE kWh/a 135 159 201
QHE (Average) 761 1,096 1,278
Sound power level Cooling HIGH dB (A) 55 56 58
Heating 57 58 60
1-1. Indoor unit - (01-2) - 1. Specifications
GENERAL INFORMATION GENERAL INFORMATION

1-2. Outdoor unit
Type Inverter heat pump
Model name ROG09KMCDN ROG12KMCDN ROG14KMCDN
Power supply 230 V ~ 50 Hz
Available voltage range 198—264 V
Starting current A 3.3 4.3 6.2
Fan
Airflow rate Cooling m3/h 1,770 2,210 2,450
Heating 1,313 1,335 2,330
Type × Q'ty Propeller fan × 1
Motor output W 23 49 49
Sound pressure level *1 Cooling dB (A) 48 49 49
Heating 43 43 49
Sound power level Cooling dB (A) 59 61
Heating 56 59
Heat exchanger type
Dimensions
(H × W × D) mm
Main1: 504 × 881 × 18.19
Main2: 504 × 851 × 18.19
Main1: 588 × 881 × 18.19
Main2: 588 × 851 × 18.19
Main1: 672 × 881 × 18.19
Main2: 672 × 851 × 18.19
Fin pitch 1.3
Rows × Stages Main1: 1 × 24
Main2: 1 × 24
Main1: 1 × 28
Main2: 1 × 28
Main1: 1 × 32
Main2: 1 × 32
Pipe type Copper
Fin type Type (Material) Corrugate (Aluminum)
Surface treatment PC Fin
Compressor Type × Q'ty DC TWIN ROTARY × 1
Motor output W 810 900 1,060
Refrigerant Type (Global warming potential) R32 (675)
Charge g 850 940 1,120
Refrigerant oil Type FW68S RmM68AF
Amount cm3350 400
Enclosure
Material Steel sheet
Color Beige
Approximate color of Munsell 10YR 7.5/1.0
Dimensions
(H × W × D)
Net mm 542 × 799 × 290 632 × 799 × 290 716 × 820 × 315
Gross 602 × 940 × 375 692 × 940 × 375 776 × 961 × 450
Weight Net kg 35
Gross 40
Connection pipe
Size Liquid mm (in) Ø 6.35 (Ø 1/4)
Gas Ø 9.52 (Ø 3/8)
Method Flare
Pre-charge length
m
15
Max. length 20
Max. height difference 15
Operation range Cooling °C -10 to 43
Heating -25 to 24
NOTES:
• Specifications are based on the following conditions:
– Cooling: Indoor temperature of 27 °CDB/19 °CWB, and outdoor temperature of 35 °CDB/24 °CWB.
– Heating: Indoor temperature of 20 °CDB/15 °CWB, and outdoor temperature of 7 °CDB/6 °CWB.
– Pipe length: 5 m, Height difference: 0 m.
• Protective function might work when using it outside the operation range.
• *1: Sound pressure level
– Measured values in manufacturer’s anechoic chamber.
– Because of the surrounding sound environment, the sound levels measured in actual installation conditions might be higher than the specified values here.
1-2. Outdoor unit - (01-3) - 1. Specifications
GENERAL INFORMATION GENERAL INFORMATION

2. Dimensions
2-1. Indoor unit
¢Models: RSG09KMCDN, RSG12KMCDN, and RSG14KMCDN
Unit: mm
834
(834)
Outline of indoor unit 327
273273 54
215
3.0
270(270)
43
43
9.5220
for pipe inlet Ø65 for pipe inlet Ø65
182 182
35634648 84
63 63
2-1. Indoor unit - (01-4) - 2. Dimensions
GENERAL INFORMATION GENERAL INFORMATION

Installation space requirement
Provide sufficient installation space for product safety.
Unit: mm
Wall hook bracket
Outline of the indoor unit
50 or more
67 or more
The flare connection
part should be installed
outdoors.
40 or more
70 or more
107 or more
1,500 or more
1,800 or more
183 or more
2-1. Indoor unit - (01-5) - 2. Dimensions
GENERAL INFORMATION GENERAL INFORMATION

2-2. Outdoor unit
¢Model: ROG09KMCDN
Unit: mm
580 109
330 353
Pitch of bolts for installation
Pitch of bolts for installation
Top view
4- M1 0 hole
Side viewSide view Front view
799 68 29016
33 30
19
542
20
Airflow
Bottom view Side view (Valve part)
37
399
Drain port Ø42
184
120
180
2-2. Outdoor unit - (01-6) - 2. Dimensions
GENERAL INFORMATION GENERAL INFORMATION

¢Model: ROG12KMCDN
Unit: mm
Side view
Side view Front view
Bottom view Side view (Valve part)
Top view
580
19
109
353
799 68 13 290
33 30
632
20
330
Pitch of bolts for installation
Pitch of bolts for installation
4-
M1 0 hole
Airflow
Drain port Ø42
37
120
184
399 180
2-2. Outdoor unit - (01-7) - 2. Dimensions
GENERAL INFORMATION GENERAL INFORMATION

¢Model: ROG14KMCDN
Unit: mm
Side viewSide view Front view
Airflow
600 109
353 330
Pitch of bolts for installation
Pitch of bolts for installation
4-
M1 0 hole
Drain port Ø42
37
410
Bottom view Side view (Valve part)
119
184
194
13 315
20 18
82019 68
716
20
2-2. Outdoor unit - (01-8) - 2. Dimensions
GENERAL INFORMATION GENERAL INFORMATION

2. TECHNICAL DATA AND PARTS LIST
2020.11.19
SR_CH02_AS038EJ_01

CONTENTS
2. TECHNICAL DATA AND PARTS LIST
1. Precautions..................................................................................................02-1
2. Indoor unit parts list....................................................................................02-2
2-1. Models: RSG09KMCDN, RSG12KMCDN, and RSG14KMCDN ....................................02-2
3. Outdoor unit parts list.................................................................................02-4
3-1. Model: ROG09KMCDN ..................................................................................................02-4
3-2. Model: ROG12KMCDN ..................................................................................................02-8
3-3. Model: ROG14KMCDN ................................................................................................02-12
4. Accessories ...............................................................................................02-16
4-1. Indoor unit ....................................................................................................................02-16
4-2. Outdoor unit..................................................................................................................02-16
5. Refrigerant system diagrams...................................................................02-17
5-1. Models: ROG09KMCDN and ROG12KMCDN .............................................................02-17
5-2. Model: ROG14KMCDN ................................................................................................02-18
6. Wiring diagrams ........................................................................................02-19
6-1. Indoor unit ....................................................................................................................02-19
6-2. Outdoor unit..................................................................................................................02-20
7. PC board diagrams ...................................................................................02-22
7-1. Models: RSG09KMCDN, RSG12KMCDN, and RSG14KMCDN ..................................02-22
7-2. Models: ROG09KMCDN and ROG12KMCDN .............................................................02-23
7-3. Model: ROG14KMCDN ................................................................................................02-24

1. Precautions
When you start servicing, pay attention to the following points. For detailed precautions, refer to the
installation manual of the products.
CAUTION
• Service personnel
– Any person who is involved with working on or breaking into a refrigerant circuit should hold a
current valid certificate from an industry-accredited assessment authority, which authorizes
their competence to handle refrigerants safely in accordance with an industry recognized as-
sessment specification.
– Servicing shall only be performed as recommended by the equipment manufacturer. Mainte-
nance and repair requiring the assistance of other skilled personnel shall be carried out under
the supervision of the person competent in the use of flammable refrigerants.
– Servicing shall be performed only as recommended by the manufacturer.
• Work
– Prior to beginning work on systems containing flammable refrigerants, safety checks are nec-
essary to ensure that the risk of ignition is minimized. When repairing the refrigerant system,
refer to the precautions written in the installation manual of the products before you start ser-
vicing.
– Work shall be undertaken under a controlled procedure so as to minimize the risk of a
flammable gas or vapor being present while the work is being performed.
– All maintenance staff and others working in the local area shall be instructed on the nature of
work being carried out.
– Work in confined spaces shall be avoided.
– The area around the workspace shall be sectioned off.
– Ensure that the conditions within the area have been made safe by control of flammable ma-
terial.
– Electric shock may occur. After turning off the power, always wait 5 minutes before touching
electrical components.
– Do not touch the fins of the heat exchanger. Touching the heat exchanger fins could result in
damage to the fins or personal injury such as skin rupture.
– Do not place any other electrical products or household belongings under the product.
– Condensation dripping from the product might get them wet, and may cause damage or mal-
function to the property.
• Checking for presence of refrigerant
– The area shall be checked with an appropriate refrigerant detector prior to and during work, to
ensure the technician is aware of potentially flammable atmospheres.
– Ensure that the leak detection equipment being used is suitable for use with flammable refrig-
erants, i.e. non-sparking, adequately sealed or intrinsically safe.
• Service parts information and design are subject to change without notice for product improve-
ment.
• For the latest information of the service parts, refer to our Service Portal.
https://fujitsu-general.force.com/portal/
• Precise figure of the service parts listed in this manual may differ from the actual service parts.
- (02-1) - 1. Precautions
TECHNICAL DATA AND PARTS LIST TECHNICAL DATA AND PARTS LIST

2. Indoor unit parts list
2-1. Models: RSG09KMCDN, RSG12KMCDN, and RSG14KMCDN
¢Exterior parts
18 1
4
a
5
6
8
8
9
10
13
16
2
17
15
12
3
14
19
20 21
b
7
11
Item no. Part no. Part name Service part
1 9387480047 Bracket panel ♦
2 9333951003 Louver spring P ♦
3 9333608006 Bush ♦
4 9387714043 Step motor holder assy ♦
5 9901011016 Step motor ♦
6 9332861006 Shaft cover ♦
7 9387590104 Drain pan total assy ♦
8 9387476002 Screw cap ♦
9 9387479041 U/D louver assy ♦
10 9387478006 Under cover R ♦
11 9387596953 Front panel total assy ♦
12 9333704005 Grille clamper R ♦
13 9387756203 Intake grille assy ♦
14 9333719009 Grille clamper L ♦
15 9387473018 Air filter ♦
16 9387477009 Under cover L ♦
17 9387597066 Wire cover assy ♦
18 9316177017 Drain cap ♦
19 9316904002 Drain hose assy ♦
20 9318912005 Remote controller holder ♦
21 9383712036 Remote controller ♦
a— Step motor holder —
b— Front panel —
2-1. Models: RSG09KMCDN, RSG12KMCDN, and RSG14KMCDN - (02-2) - 2. Indoor unit parts list
TECHNICAL DATA AND PARTS LIST TECHNICAL DATA AND PARTS LIST

¢Chassis
65
50
51
a
b
c
52
d
53
54
55
58
59
e
f
60
61
66
63
62
64
67
68
Item no. Part no. Part name Service part
50 9387587074 Base assy ♦
51 9383765032 WLAN adapter holder assy ♦
52
9711141446 Main PCB (For 09 model) ♦
9711141453 Main PCB (For 12 model) ♦
9711141460 Main PCB (For 14 model) ♦
53 9387488029 Cable guide ♦
54 9711146021 Display assy ♦
55 9711147028 Indicator PCB ♦
58 9333879000 Display case assy ♦
59 9901013010 Terminal ♦
60 9603688028 Brushless motor (For 09 model) ♦
9603492021 Brushless motor (For 12-14 model) ♦
61 9387589047 Motor case assy ♦
62 9317250009 Air clean filter assy ♦
63 9332911008 Electric filter holder ♦
64 9387593297 Evaporator total assy ♦
65 9900627065 Thermistor assy ♦
66 9387467017 Room thermistor holder ♦
67 9333628004 Bearing D assy ♦
68 9333606033 Crossflow fan assy ♦
— 9901010019 Wire with connector ♦
a— Box shield —
b— Control box —
c— PCB holder A —
d— Control cover —
e— Motor case —
f— Motor cover —
2-1. Models: RSG09KMCDN, RSG12KMCDN, and RSG14KMCDN - (02-3) - 2. Indoor unit parts list
TECHNICAL DATA AND PARTS LIST TECHNICAL DATA AND PARTS LIST

3. Outdoor unit parts list
3-1. Model: ROG09KMCDN
¢Exterior parts and Chassis
1
5
6
18
17
20
a
13
21
22
3
23
b
19
12
7
8
9
10
16 15
4
2
3-1. Model: ROG09KMCDN - (02-4) - 3. Outdoor unit parts list
TECHNICAL DATA AND PARTS LIST TECHNICAL DATA AND PARTS LIST
