Fujitsu IP-920 E/DC Installation manual

IP-920E/DC
Hardware User’s Guide

(This page is intentionally left blank)

IP-920E/DC
i
USING IP-920E/DC SAFELY
Handling of This Manual
The manual contains important information regarding the safe use of IP-920E/DC. Read it thoroughly
before operating this device. Make sure that users of this equipment read and understand thoroughly all
safety precautions contained in the manual. Keep this manual in a safe and convenient location for
quick reference.
Fujitsu makes every effort to prevent users and bystanders from injury and to prevent property damage.
To ensure no harm to you and bystanders, and to prevent damage to this equipment itself, be sure to use
this equipment in accordance with instructions in the manual.
The following notice is for USA users only.
IP-920E/DC
has been tested and found to comply with the limits for a Class A digital device, pursuant
to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against
harmful interference when the equipment is operated in a commercial environment. This equipment
generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with
the instruction manual, may cause harmful interference to radio communications. Op
eration of this
equipment in a residential area is likely to cause harmful interference in which case the user will be
required to correct the interference at his own expense.
The following notice is for Canada users only.
This Class A digital apparatus meets all requirements of the Canadian Interference-Causing Equipment
Regulations.
The following notice is for EU (European Union) users only.
This is Class A product of Electromagnetic Interference (EMI) standard. In a domestic environment
this produ
ct may cause radio interference in which case the user may be required to make adequate
measures.
This manual includes technology controlled under the Foreign Exchange and Foreign Trade Control
Law of Japan. The manual or a portion thereof must not be exported (or re-
exported) without
authorization from the appropriate governmental authorities in accordance with the above law.
IP-920E/DC
is designed and manufactured for use in standard applications such as office work,
personal devices, and household
appliances. The product is not intended for special uses (such as
nuclear-
reactor control in atomic energy facilities, aeronautic and space systems, air traffic control,
operation control in mass transit systems, medical devices for life support, and mis
sile firing controls in
weapons facilities) where particularly high reliability requirements exist, where the pertinent levels of
safety are not guaranteed, or where a failure or operational error could threaten a life or cause physical
injury (hereafter referred to as "mission-critical" use). Customers considering use of this product for
mission-critical applications must have safety-
assurance measures in place beforehand. Moreover,
they are requested to consult our sales representative before embarking on such specialized use.

IP-920E/DC
ii
Copying of and disassembly, decompilation and other forms of reverse engineering of any program
included with this device is prohibited.
Windows, Internet Explorer are registered trademarks or trademarks of Microsoft Corpor
ation in the
United States and/or other countries.
HDMI, HDMI Logo and High-
Definition Multimedia Interface are trademarks or registered trademarks
of HDMI Licensing LLC.
IMPORTANT NOTE TO USERS
READ THE ENTIRE MANUAL CAREFULLY BEFORE USING THIS PRODUCT.
INCORRECT USE OF THE PRODUCT MAY RESULT IN INJURY OR DAMAGE TO
USERS, BYSTANDERS OR PROPERTY.
While FUJITSU has sought to ensure the accuracy of all information in this manual, FUJITSU
assumes no liability to any party for any damage caused by any error or omission
contained in this
manual, its updates or supplements, whether such errors or omissions result from negligence, accident,
or any other cause. In addition, FUJITSU assumes no liability with respect to the application or use of
any product or system in accordance with descriptions or instructions
contained herein; including any
liability for incidental or consequential damages arising therefrom.
FUJITSU DISCLAIMS ALL WARRANTIES REGARDING THE INFORMATION
CONTAINED HEREIN, WHETHER EXPRESSED, IMPLIED, OR STATUTORY.
FUJITSU reserves the right to make changes to any products described herein without further notice
and without obligation.
No part of this manual shall be reproduced in any way or form without the permission of Fujitsu Limited.
All Rights Reserved. Copyright
©FUJITSU LIMITED 2011-2016

IP-920E/DC
iii
PREFACE
Thank you for purchasing the IP-920E/DC.
IP-920E/DC is the video transmission unit with the H.264 encoding technology which performs the high
compression ratio, and transmits the SD (Standard Definition) /HD (High Definition) video and audio signals
in real time through even the optical IP network like FTTH. (*1) IP-920E has functions that encodes SD/HD
video signals from a SD/HD camera or similar device and distributes it across the network in real-time.
This manual is intended for system designers and system managers who use IP-920E/DC. Readers are
assumed to have a basic knowledge of networks and video distribution.
*1: IP-920E/DC supports only SD video. By adding optional software, IP-920E/DC will be upgraded to
support HD video.
Product operating environment
•Designed for use in real-time audio/video transmission systems and in the transmission system of
monitoring systems, IP-920E/DC is intended for indoor use.
Note:
The contents of this manual are subject to change without notice.
Edition 8
June 2016

IP-920E/DC
iv
ORGANIZATION AND CONTENTS OF THIS MANUAL
The manual consists of five chapters, an appendix, a glossary and an index.
Read Chapters 1 and 2 first for information on installing and connecting this equipment. Read Chapter
3 for operating instructions, and Chapter 4 and subsequent chapters can be read as required.
Chapter 1 Preparations
This chapter describes the checks that are required before the start of IP-920E/DC operation.
Chapter 2 Installation and Connection
This chapter describes conditions for IP-920E/DC installation and explains how to connect it to
peripheral this equipments.
Chapter 3 Operating Instructions
This chapter explains how to power on/off, set up and operate this equipment.
Chapter 4 Connection Cable Specifications
This chapter contains a classification of how work is implemented, cable connection system diagrams
and cable connector details.
Chapter 5 Troubleshooting
This chapter describes actions to be taken if this equipment does not operate normally or if an alarm LED
turns on.
Appendix
The appendix contains views of this equipment and its basic specifications. Installation work and
on-site adjustment preparations are also covered in this section.
Glossary
The glossary defines the technical terms used in this manual.
Index
The index lists keywords and corresponding pages on which the words appear, so necessary items can be
looked up immediately.

IP-920E/DC
v
WARNING INDICATIONS
This manual uses warning indications to warn of conditions in order to prevent serious injury and
property damage. Warning indications consist of warning markings of specific levels and warning
messages. The warning markings are shown below along with their definitions.
WARNING indicates a situation that could lead to serious injury
or loss of life if procedures are not followed correctly.
CAUTION indicates a situation that could lead to minor or
moderate injury and/or damage to this equipment itself if
procedures are not followed correctly.
Warning indications within text
Warning markings are followed by warning messages. Every warning marking is centered on a line.
Left and right indents are set for warning messages to differentiate them from ordinary text.
Furthermore, the lines immediately before and after warning indications are left blank.
(Example)
Possibility of electric shock, fire and damage to this equipment
Always observe the precautions given below.
This indicates a hazardous situation that could lead to electric shock, fire or
damage to this equipment.
•When using IP-920E/DC, ensure to set a breaker at an internal wiring
between this equipment and an external power-supply unit or at an
output part of an external power-supply unit. Also, ensure to use a
breaker that cuts off both terminals at the same time. Observe the
conditions below and select a proper breaker.
- Service voltage: DC12 to 24V±10%
- Steady current: 3.3A (maximum in case of 12V)
- Inrush current: up to 10A
Important warning indications are summarized below in “Safety Precautions.”
!
!
CAUTION

IP-920E/DC
vi
SAFETY PRECAUTIONS
List of important warnings
The table below contains a list of important warning indications.
Work type Warning
Normal use
Possibility of electric shock and fire
If an excessive heat, smoke, an abnormal odor or an unusual noise is coming from
this
equipment
, immediately set its power switch to OFF and remove the power cord plug
from the power receptacle. Then, contact a Fujitsu Service Center.
This indicates a hazardous situation that could lead to fire and electric shock.
Possibility of electric shock and fire
If foreign matter (e.g., water, bits of metal, fluid) gets inside this equipment
, immediately
set its power switch to OFF and remove the power cord plug from the power recep
tacle.
Then, contact a Fujitsu Service Center.
This indicates a hazardous situation that could lead to fire and electric shock.
Possibility of electric shock and fire
If this equipment
has been dropped or otherwise damaged, immediately set its power
swit
ch to OFF and remove the power cord plug from the power receptacle. Then,
contact a Fujitsu Service Center.
This indicates a hazardous situation that could lead to electric shock.
Possibility of electric shock and fire
To keep foreign matter out, ensure
that drink containers and metal objects are not placed
on or near this equipment.
The presence of foreign matter such as water inside this equipment
creates a hazardous
situation that could lead to electric shock.
Possibility of electric shock and fire
Ensure that no liquid is splashed on this equipment, making it wet.
The presence of foreign matter such as water inside this equipment
creates a hazardous
situation that could lead to fire and electric shock.
Possibility of electric shock and fire
Ensure that the power cord does not become damaged, and avoid tampering with it.
If the power cord has a heavy object is placed on it, pulled at, bent, or becomes entangled, it
could be damaged as a result. Also, the power cord could be damaged if subjected t
o heat,
creating a hazardous situation that could lead to fire and electric shock.
Indicates a situation that could lead to serious injury or loss of life if procedures
are not followed correctly.

IP-920E/DC
vii
Work type Warning
Installation
Possibility of electric shock and fire
Always observe the precautions given below.
This indicates a hazardous situation that could lead to electric shock, fire and damage
to
this equipment.
•Ensure to use a DC power supply with SELV safety status.
Using a power supply
with another safety status could lead to electric shock, fire or damage to
this
equipment.
Possibility of electric shock and fire
Do not install this equipment in the following places because using it there
may cause a
fire:
•Extremely dusty or dirty place
•Wet or humid location
•Hot location, such as a place where this equipment
is exposed to direct sunlight or
is near heating equipment
•Near products (e.g., speakers) that generate a strong magnetic field
•Location where the temperature is too hot or cold
•In an environment with sharp temperature fluctuations
•Area with poor ventilation
•Near a fire
Possibility of electric shock, fire, and damage to this equipment
Always observe the precautions given below.
This indicates a hazardous situation that could lead to fire and damage to this equipment.
•Choose a power supply that meets the nominal voltage of IP-920E/DC.
•Use the power cable (DC) attached to IP-920E/DC
. If the attached cable is not
usable, use a cable adapted to current capacity of more than 5A.
•When using IP-920E/DC, ensure to set an internal wiring between IP-920E/DC
and
an external power-supply unit or a breaker at an outp
ut part of an external
power-supply unit. Also, ensure to use a breaker that cuts off both terminals
at the
same time. Observe the conditions below and select a proper breaker.
- Service voltage: DC12 to 24V±10%
- Steady current: 3.2A (maximum in case of 12V)
- Inrush current: up to 10A

IP-920E/DC
viii
Work type Warning
Installation
and
relocation
Possibility of serious injury and damage to this equipment
Do not install this equipment
in places where it is exposed to shock and strong vibrations,
on an incline or in unstable locations.
This indicates a hazardous situation that could lead to serious injury or damage to this
equipment.
Possibility of serious injury and damage to this equipment
When relocating this equipment, observe the following precautions to prote
ct against
serious injury and damage to this equipment:
•
Set the power switch to OFF, and disconnect all connected cables. Take care to
avoid getting your feet entangled in the cables.
•To prevent serious personal injury when moving this equipment, take spe
cial care
to pay attention to your surroundings.
Clean
Possibility of fire, serious injury and damage to this equipment
When cleaning this equipment, observe the following precautions to protect against
fire,
serious injury and damage to this equipment:
•When cleaning this equipment, please do not use cleaning spray that is including
combustible material. Also, please do not use it around this equipment.
•When cleaning this equipment
, please wipe off with the cloth squeezing water (or
neutral detergent thinned by water).
•When wiping off, please be careful not to put water into this equipment from
switches or the spaces.

IP-920E/DC
ix
LABEL
The warning label shown below is affixed to this equipment.
・Never remove the label.
・Be sure to check the label at the bottom of this device before coming to the power supply.
・The following label is intended for users of this equipments.
Mark for rubber feet
Label：IP-920E/DC
LISTED
R
CUS
1K91
I T E
E136004
Manufacture
Fujitsu Limited
Address: 1-1, Kamikodanaka 4-Chome, Nakahara-Ku, Kawasaki 211-8588, Japan
Authorised representative
Fujitsu Services Limited
Address: 22 Baker Street, London, W1U 3BW, United Kingdom
CAN ICES-3 (A) / NMB-3 (A)
MODEL
PART NO.
IP-920E/DC
TA23742-B7XX
This device complies with Part 15 of the FCC Rules.
operation is subject to the following two conditions:
(1) This device may not cause harmful interference. and
(2) this device must accept any interference received,
including interference that may cause undesired operation.
MADE IN JAPAN
3.2A-1.6A
+12V-24V
2.3kg
FUJITSU LIMITED
T
認証番号
01A
11-03
00001
D08-0454001
12345
ACCESSORY
MODEL
PART NO.
IP-920E/DC TA23742-B72X
This device complies with Part 15 of the FCC Rules.
operation is subject to the following two conditions:
(1) This device may not cause harmful interference. and
(2) this device must accept any interference received,
including interference that may cause undesired operation.
MADE IN JAPAN
3.2A-1.6A
+12V-24V
2.3kg
FUJITSU LIMITED
T
認証番号
01A
11-03 00001
D08-0454001
00001
I T E
ACCESSORY
LISTED
R
CUS
1K91
E136004
MODEL
PART NO.
IP-920E/DC
TA23742-B72X
This device complies with Part 15 of the FCC Rules.
operation is subject to the following two conditions:
(1) This device may not cause harmful interference. and
(2) this device must accept any interference received,
including interference that may cause undesired operation.
MADE IN JAPAN
3.2A-1.6A
+12V-24V
2.3kg
FUJITSU LIMITED
T
認証番号
01A
11-03
00001
D08-0454001
12345
LISTED
R
CUS
1K91 I T E
E136004
Manufacture Fujitsu Limited Address: 1-1, Kamikodanaka 4-Chome, Nakahara-Ku, Kawasaki 211-8588, Japan
Authorised representative Fujitsu Services Limited Address: 22 Baker Street, London, W1U 3BW, United Kingdom
CAN ICES-3 (A) / NMB-3 (A)
MODEL PART NO.
IP-920E/DC TA23742-B7XX
This device complies with Part 15 of the FCC Rules. operation is subject to the following two conditions: (1) This device may not cause harmful interference. and (2) this device must accept any interference received, including interference that may cause undesired operation.
MADE IN JAPAN
3.2A-1.6A
+12V-24V
2.3kg
FUJITSU LIMITED
T
認証番号
01A
11-03 00001
D08-0454001
12345
ACCESSORY

IP-920E/DC
x
PRODUCT HANDLING PRECAUTIONS
Maintenance
Do not try to repair this equipment yourself. Contact a Fujitsu Service
Center.
Read this manual thoroughly before attempting to operate this equipment.
If you have any questions, contact a Fujitsu Service Center.
If a problem occurs, contact a Fujitsu Service Center.
The Fujitsu Service Center will ask you to describe the problem, the lamp display status of
alarm LEDs and other details. Check the system for this information.
Connectable devices
Only devices that conform to this equipment interface specifications (see Appendix 2.3, "Device
Specifications") can be connected. Otherwise, if incompatible devices are connected, the result
may be personal injury and property damage.
CF card consideration
Please note that you need to remove the CF card or take the backup of its recorded data in case of
requesting the repair of the main unit that the CF card is installed, since Fujitsu does not guarantee
the recorded content during the repair work.
Please also note that the recorded content might be deleted by the process of the diagnostic and
the repair work after Fujitsu starts the work even if you already cancel the repair request
Disposal
To dispose of this equipment, contact a Fujitsu Service Center, or request a specialist to take care
its disposal.
Modification and restoration
Do not use any device that has been modified or rebuilt with refurbished used parts. Doing so
may result in personal injury and property damage.
WARNING
CAUTION

IP-920E/DC
I
CONTENTS
Chapter 1 Preparations ..........................................................................1
1.1 Main Features.........................................................................................3
1.2 Components ...........................................................................................4
1.3 Basic Application Examples ...................................................................5
1.4 Part Names.............................................................................................6
Chapter 2 Installation and Connection .................................................9
2.1 Installation Conditions .......................................................................... 11
2.1.1 Environment conditions ........................................................... 11
2.1.2 Installation environment........................................................... 11
2.1.3 Air supply and exhaust of the equipment ................................30
2.1.4 Open space required around this equipment ..........................31
2.2 Power Supply System Connections ........................................................32
2.2.1 Connection to ground ..............................................................32
2.2.2 Connection to power source....................................................33
2.3 Audio and Video Device Connections ..........................................................35
2.4 Connection to Network .........................................................................36
2.5 Connection to RS-232C Device ...........................................................37
2.6 CF Card Insertion and Removal...........................................................38
Chapter 3 Operation Instructions........................................................41
3.1 Turn ON/OFF IP-920E/DC ...................................................................43
3.1.1 Turn on IP-920E/DC ..................................................................43
3.1.2 Turn off IP-920E/DC ..................................................................43
3.2 Device Settings and Operation ............................................................44
3.2.1 Reboot .......................................................................................45
3.3 Special Use of MNT Button ..................................................................46
Chapter 4 Cable Specifications...........................................................47
4.1 Installation Preparations.......................................................................49
4.2 Cable and Connector Details ...............................................................50
Chapter 5 Troubleshooting..................................................................59
5.1 Help Information ...................................................................................61
5.2 Alarm LED Lamp Is On ........................................................................65
5.3 Maintenance .........................................................................................67
5.3.1 Maintenance space ...................................................................67
5.3.2 Change equipment (Only for CE)..............................................68

IP-920E/DC
II
Appendix ................................................................................................. 69
A.1 Appearance ..........................................................................................71
A.2 Basic Specifications..............................................................................73
A.2.1 External specifications............................................................... 73
A.2.2 Environment specifications........................................................ 73
A.2.3 Function specifications .............................................................. 74
A.3 Preparations for Installation Work ........................................................ 79
A.3.1 Scope of installation work.......................................................... 79
A.3.2 Unpacking and device check..................................................... 79
A.3.3 Installation conditions ................................................................ 79
A.3.4 Connecting external cables....................................................... 79
A.4 Preparations for On-site Turn-up.......................................................... 80
Glossary and Index ................................................................................ 83
Glossary.........................................................................................................85
Index ..............................................................................................................88
CE Conformity Information ............................................................................90

Chapter 1 Preparations
This chapter describes the checks that are required before the start of IP-920E/DC
operation.
1.1 Main Features ..............................................................................................3
1.2 Components .................................................................................................4
1.3 Basic Application Examples .........................................................................5
1.4 Part Names ..................................................................................................6
CHAPTER 1
PREPARATIONS

(This page is intentionally left blank)

Chapter 1 Preparations
IP-920E/DC
3
1.1 Main Features
IP-920E/DC is the video transmission unit with the H.264 encoding technology which performs the
high compression ratio, and transmits the SD (Standard Definition) /HD (High Definition) video and
audio signals in real time through even the optical IP network like FTTH.
IP-920E has functions that encodes SD/HD video signals from a SD/HD camera or similar device and
distributes it across the network in real-time.
Main Features
Item Specifications
Video input
HD-SDI / SD-SDI
1ch
[BNC]
HDMI 1.2a (*2)
1ch
[HDMI]
Analog Composite
1ch
[BNC]NTSC/PAL
Audio input
HD/SD-SDI embedded
2ch
[BNC], 1 stereo pairs
HDMI 1.2a (*2)
2ch
[HDMI]
Analog balanced
2ch
[D-sub9-pin], female connector, 1 stereo pair
Network LAN 1ch
[RJ45],
10BASE-T / 100BASE-TX
Data input/output
RS-232C
1ch
[D-sub9-pin], male connector
CF CARD slot
CF CARD
1
Data storage application
Installation conditions
Indoor: On a desk, mounted in a rack
Dimensions
W: 210 H: 42 D: 300 (mm) Note: Excluding protrusions (i.e., not including feet)
Cooling system
Forced air cooling
Power supply
+12-24VDC
Weight
Maximum 2.3kg
Power consumption
38.4W or less
Temperature
Humidity
-10 to 55°C (No low temperature startup: -10 to -1°C)
20 to 90%RH (No condensing)
Safety Standard
Approved as Class III device of IEC60950-1, UL60950-1, EN60950-1
*1: IP-920E supports only SD video. By adding optional software, IP-920E will be upgraded to support HD video.
*2: DVI isn't supported.
1.1

Chapter 1 Preparations
IP-920E/IP-920D
4
1.2 Components
The IP-920E/DC product package consists of the following components.
Attachments for all series consist of same contents.
･IP-920E/DC: 1 pc (cables separate order)
･
Safety manual: 1pc
･
User’s Guide: 1pc
･
Feet: 4 pcs
・
DC Power cable: 1 pc
・
Audio adapter cable (type 1) : 1 pc
CF CARD
/ACT
RDY
PWR ALM
IN
DWN
OPT
100M
LINK
E
1.2
A-IN (L)
A-INL
()A-INR
()

Chapter 1 Preparations
IP-920E/DC
5
1.3 Basic Application Examples
Examples (sys tem configuration) of use of IP-920E/DC are shown below.
CFCARD
/ACT
RDY
PWR ALM
IN
DWN
OPT
100M
LINK
E
ＩＰ-920E/DC
CFCARD
/ACT
RDY
PWR ALM
IN
DWN
OPT
100M
LINK
E
ＩＰ-920E/DC
CFCARD
/ACT
RDY
PWR ALM
IN
DWN
OPT
100M
LINK
E
RDY
PWR ALM
DEC
MNT
FG
/ACT
100M
LINK
10/100BASE RS-232C
ANALOG
VIDEOOUT
100-240V
SDI
D
ANALOGAUDIO OUT
IP Network
FTTB / FTTH
Dart Fiber
AP
AP
HD VTR
HD Camera
AP
Encoder Site
Live Coverage
ＩＰ-920E/DC
Monitoring
Control
HD Archive Server
Strage(NR)
AP
Dual Encoding (SD)
File Transfer by Flow Control
HD VTR
Video Editing
Equipment
On demand file transfer
From affiliates
Decoder Site
1U サーバー
Live Coverage
ＩＰ-920D
HD Camera
1.3

Chapter 1 Preparations
IP-920E/IP-920D
6
1.4 Part Names
This section gives the name and describes the function of individual parts of IP-920E/DC.
The diagrams below show the layout of parts on the outside of this equipment, and the table below
lists the name and describes t he function of individual parts.
- IP-920E/DC
Figure Front panel
Figure Rear panel
Part names
No. Name Description
(1)
Power inlet connector
(DC +12-24V)
By using a DC power cable attached to IP-920E/DC, it enables to connect to a
power supply of DC12-24V.
However, a connectable power-source equipment needs to be SELV (*) safety
status.
See Section 2.2.2, “Connection to a Power Source,” for an explanation on using
this connector. See Section 4.2, “Cable and Connector Details,” for cable
connection information.
(2)
Power button
Turns this equipment on and off.
(3)
Power LED (PWR)
Turns on when this equipment is powered on.
(4)
Status LED
(RDY)
Turn on when IP-920E power is on. For more information, see Table 5.3,
“Details of LED Indications,” in Section 5.2.
(5)
Alarm LED
(ALM)
Turns on when IP-920E operation is abnormal. For more information, see
Table 5.3, “Details of LED Indications,” in Section 5.2.
(6)
AV input status LED
(INDWN)
Audio/Video input setting status indicator and LED that indicates the input off
status during input setting. For more information, see Table 5.3, “Details of
LED Indications,” in Section 5.2.
(7)
Option LED
(OPT)
Turn on when option license is installed. For more information, see Software
guide.
* SELV is a secondary circuit protected in the structure that electrical potential difference between any two
touchable points is not dangerous under the normal condition or even under the condition that any one point is
broken. It indicates up to 60V in case of DC voltage.
RDY
PWR ALM
IN
DWN
OPT
MNT
FG
/ACT
100M
LINK
10/100BASE RS-232C
ANALOG
VIDEO IN
SDI
ANALOG AUDIO IN
12 -24V
E
(2) (7)(8) (9) (10) (11)(12)
(13)(14) (15)(16) (17)
(1)(3) (4)(5)(6)
E
/ACT
RDY
PWR ALM
IN
DWN
OPT
100M
LINK
11
CF CARD
AUX
(18)
(19)(20)
(3) (4) (5) (6) (7) (9)
(10)
1.4
