Fujitsu B24-8 TE Pro User manual

Display
Operating Manual
FUJITSU display
B24-8 TE Pro / B24-8 TS Pro

Congratulations on your purchase of an innovative
product from Fujitsu.
Latest information about our products, tips, updates etc. can be found on
the Internet at: "http://www.fujitsu.com/fts/"
You can find driver updates at: "http://support.ts.fujitsu.com/download"
Should you have any technical questions, please contact:
• our Hotline/Service Desk (see the Service Desk list or visit:
"http://support.ts.fujitsu.com/contact/servicedesk")
• Your sales partner
• Your sales office
We hope you enjoy working with your new Fujitsu system!

Published by / Contact address in the EU
Fujitsu Technology Solutions GmbH
Mies-van-der-Rohe-Straße 8
80807 Munich, Germany
"http://www.fujitsu.com/fts/"
Copyright
©Fujits
u Technology Solutions GmbH 2015. All rights reserved.
Publication Date
12/2015
Order No.: A26361-K1577-Z320-1-7619, edition 1

FUJITSU display
B24-8 TE Pro / B24-8 TS Pro
Operating Manual
Your LCD screen... 5
Important notes 7
Getting started 11
Operation 18
Notes on ergonomic colour adjustment 29
Low blue light function 30
Explanatory information about
standard ISO 9241-307 31
Troubleshooting 32
Technical specification 34

Remarks
Notes on the product description meet the design requirements of Fujitsu and are
provided for the purposes of comparison. The actual results may differ due to several
factors. Subject to technical changes without prior notification. Fujitsu accepts no
responsibility for technical or editorial mistakes or omissions.
Trademarks
Fujitsu and the Fujitsu logo are registered trademarks of Fujitsu Limited or its
subsidiaries in the United States and other countries.
Microsoft and Windows are trademarks or registered trademarks of the Microsoft
Corporation in the United States and/or other countries.
VESA, DDC and DPMS are registered trademarks of Video Electronics Standards Association.
All other trademarks specified here are the property of their respective owners.
Copyright
No part of this publication may be copied, reproduced or translated without
the prior written consent of Fujitsu.
No part of this publication may be saved or transmitted by any electronic means
without the written consent of Fujitsu.

Contents
Contents
YourLCD screen... ..................................................................... 5
Targetgroup ............................................................................ 5
Furtherinformation ...................................................................... 6
Notational conventions .................................................................. 6
Important notes ........................................................................ 7
Safetyinstructions ...................................................................... 7
Powercable ............................................................................ 8
Transporting the device .................................................................. 8
Cleaning thedevice ..................................................................... 9
CEmarking ............................................................................ 9
Disposal and recycling .................................................................. 10
Getting started ......................................................................... 11
Unpacking and checking the delivery . . ................................................... 11
Setting up thedevice .................................................................... 12
Setting up an ergonomic video workstation ............................................ 12
Mounting the monitor base . . . ....................................................... 14
Adjustingheight ..................................................................... 14
Adjustingthe inclination .............................................................. 15
Adjustingthe rotation ................................................................ 15
Removing monitorbase .............................................................. 15
Connecting the device . .............................................................. 16
Connecting cables to the computer ................................................... 17
Operation .............................................................................. 18
Switching thedeviceon andoff .......................................................... 18
Notes on power management ............................................................ 19
Changing the monitor settings ............................................................ 19
Changing the monitor settings with the buttons of the control panel . ..................... 20
Changing themonitorsettings usingthe OSDmenu ....................................... 23
OSD menu functions ................................................................ 24
Adjusting thebrightness andcontrast ................................................. 25
Selectingtheapplicationmode ....................................................... 25
Setting screen display ............................................................... 26
Adjustingthevolume ................................................................ 26
Setting colour temperatureandcolours ................................................ 27
Setting theOSDmenu ............................................................... 27
Advanced settingfunctions ........................................................... 28
Displayinginformation ............................................................... 28
Noteson ergonomiccolour adjustment ................................................ 29
Low bluelightfunction ................................................................ 30
Explanatory information about standard ISO 9241-307 . . . . . ............................. 31
Troubleshooting ....................................................................... 32
Technical specification ................................................................. 34
VESA-DDC-compatible VGA interface . ................................................... 35
Preset operating modes . . . . . . ........................................................... 35
Most frequent operating modes ....................................................... 35
Fujitsu 3

Contents
Video/TV operating modes using DisplayPort or HDMI . . . .............................. 36
SUBD port ............................................................................. 36
DVI-Dport .............................................................................. 37
DisplayPort socket ...................................................................... 38
HDMIport .............................................................................. 39
4Fujitsu

Your LCD screen...
Your LCD screen...
has a whole range of useful features and functions, e.g.:
• TFT display (Thin Film Transistor; active matrix)
• minimal space requirements thanks to slim casing
• optimum ergonomic characteristics (totally distortion-free, excellent picture
definition and colour purity right into the corners)
• high degree of brightness and good contrast
• high resolution (1920 x 1080)
• presentation of up to 16.7 million colours (in conjunction with an appropriate display adapter)
• automatic scanning of horizontal frequencies from 30 to 82 kHz and refresh rates
(vertical frequencies) from 56 to 76 Hz (absolutely flicker-free)
• digital screen controller with microprocessor for storing 46 different display modes
• freely adjustable colour alignment for matching the screen colours to the
colours of various input and output devices
• convenient operation via integrated OSD (On-Screen-display) menu
• VESA-DDC compatibility
• VESA-FPMPMI compatibility (Flat Panel Monitor Physical Mounting Interface) –
Mounting device for swivel arm or a similar accessory
• Plug&Play capability
• Digital video inputs (DVI, DP or HDMI) with HDCP
• power management for reducing power consumption when the computer is not in use
• Compliance with the recommendations according to TCO 7.0
• the monitor fulfills all GS ("Geprüfte Sicherheit", Certified Security) requirements.
This operating manual contains important information you require to start up and run your LCD monitor.
A graphics card (display adapter) with VGA interface or a digital graphics card with DVI interface
and/or a video signal source with DP interface for a B24-8 TE Pro monitor or with an HDMI
interface for a B24-8 TS Pro monitor is required to control the LCD monitor. The monitor
processes the data supplied to it by the graphics card. The graphics card or the associated
driver software is responsible for setting the modes (resolution and refresh rate).
When putting the monitor into operation for the first time, the screen display should be
optimally adapted to the display adapter used and adjusted in accordance with your
needs (see chapter "Changing the monitor settings", Page 19).
Target group
You don’t need to be an "expert" to perform the operations described here.
Nonetheless, it is important to always observe the safety notes given in the operating
instructions for the computer and in this manual.
In the event of any problems, please contact your sales office or our Service Desk.
Fujitsu 5

Your LCD screen...
Further information
Details of how you set the resolution and refresh rate are provided in the documentation
for your display adapter and the associated driver software.
For ergonomic reasons, we recommend a screen resolution of 1920 x 1080 pixels.
Because of the technology used (active matrix) an LCD monitor provides a totally
flicker-free picture even with a refresh rate of 60 Hz.
Notational conventions
Pay particular attention to text marked with this symbol. Failure to observe
these warnings could pose a risk to health, damage the device or lead
to loss of data. The warranty will be invalidated if the device becomes
defective through failure to observe these warnings.
Indicates important information for the proper use of the device.
►Indicates an activity that must be performed
Indicates a result
This font indicates data entered using the keyboard in a program dialogue or at
the command line, e.g. your password (Name123) or a command used to
start a program (start.exe)
This font indicates information that is displayed on the screen by a program, e.g.:
Installation is complete.
This font indicates
• terms and texts used in a software interface, e.g.: Click on Save
• names of programs or files, e.g. Windows or setup.exe.
"This font" indicates
• cross-references to another section, e.g. "Safety information"
• cross-references to an external source, e.g. a web address: For more
information, go to "http://www.fujitsu.com/fts/"
• Names of CDs, DVDs and titles or designations of other materials, e.g.:
"CD/DVD Drivers & Utilities" or "Safety" Manual
Key indicates a button on the monitor, e.g: MENU
This font indicates terms and texts that are emphasised or highlighted, e.g.: Do
not switch off the device
