Fujitsu D1919 User manual

Produktfamilie
System board D1919
for TX200 S2
Technical manual
Redakteur
Fujitsu Siemens Computers GmbH München
81730 Munich
e-mail: email: [email protected]
Tel.: [phone]-???
Fax: (++49) 700 / 372 00000
A26361-D1919-Z120-1-7419
Sprachen: En
Edition October 2004

This manual is printed on
paper treated with
chlorine-free bleach.
Comments…Suggestions…Corrections…
The User Documentation Department would like to
know your opinion of this manual. Your feedback helps
us optimize our documentation to suit your individual
needs.
Fax forms for sending us your comments are included in
the back of the manual.
There you will also find the addresses of the relevant
User Documentation Department.
Certified documentation
according to DIN EN ISO 9001:2000
To ensure a consistently high quality standard and
user-friendliness, this documentation was created to
meet the regulations of a quality management system
which complies with the requirements of the standard
DIN EN ISO 9001:2000.
cognitas. Gesellschaft für Technik-Dokumentation mbH
www.cognitas.de
Copyright and Trademar s
Copyright © 2004 Fujitsu Siemens Computers GmbH.
All rights reserved.
Delivery subject to availability; right of technical modifications reserved.
All hardware and software names used are trademarks of their respective manufacturers.

A26361-D1919-Z120-1-7419
Contents
1Introduction. . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
2 Important notes . . . . . . . . . . . . . . . . . . . . . . . . . . 3
2.1 Notes on safety . . . . . . . . . . . . . . . . . . . . . . . . . . 3
2.2 CE Certificate . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
2.3 Environmental Protection . . . . . . . . . . . . . . . . . . . . . 7
3Features. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
3.1 Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
3.2 Main memory . . . . . . . . . . . . . . . . . . . . . . . . . . 12
3.3 PCI bus . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
3.3.1 ISA bus resources . . . . . . . . . . . . . . . . . . . . . . . . 15
3.3.2 PCI resources . . . . . . . . . . . . . . . . . . . . . . . . . . 16
3.4 Screen resolution . . . . . . . . . . . . . . . . . . . . . . . . 17
3.5 Temperature / system monitoring . . . . . . . . . . . . . . . . 18
3.6 LEDs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
3.7 Interfaces and connectors . . . . . . . . . . . . . . . . . . . . 21
3.7.1 External ports . . . . . . . . . . . . . . . . . . . . . . . . . . 22
3.8 Settings with switches . . . . . . . . . . . . . . . . . . . . . . 24
4 SCSI/IME configuration program . . . . . . . . . . . . . . . 27
5 Replacing the lithium battery . . . . . . . . . . . . . . . . . 37
Abbreviations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39

A26361-D1919-Z120-1-7419 1
1 Introduction
This technical manual describes the system board D1919, which can be
equipped with one or two Intel®processors.
Further information about drivers is provided in the readme files on the hard
disk, on the supplied "ServerSupport" or "ServerStart" CDs.
You will find further information in the BIOS description.
Notational conventions
The meanings of the symbols and fonts used in this manual are as follows:
italics indicates commands, menu items, file and path
names or software programs
fixed font indicate system output on the monitor
semi-bold fixed
font
indicates values to be entered through the keyboard
[Key symbol] indicates keys according to their representation on the
keyboard
If capital letters are to be entered explicitly, then the
Shift key is shown, e.g. [SHIFT] - [A] for A.
If two keys need to be pressed at the same time, then
this is shown by placing a hyphen between the two key
symbols.
“quotation marks” indicates names and terms that are being empha-
sized.
Êindicates an operation that to be performed
VCAUTION! indicates warnings, which, if ignored, will endanger
your health, destroy the system or lead to the loss of
data.
Iindicates additional information, notes and tips
Table 1: Notational conventions

A26361-D1919-Z120-1-7419 3
2 Important notes
In this chapter you will find essential information regarding safety when working
with your server.
VCAUTION!
With the system board installed you must open the system to access the
system board. How to dismantle and reassemble the system is described
in the service manual accompanying your system.
When installing the system board, refer to the specific installation infor-
mation in the operating and/or service manual for the receiving server.
2.1 Notes on safety
VCAUTION!
●The actions described in these instructions should only be performed
by authorized, qualified personnel. Equipment repairs should only be
performed by qualified staff. Any failure to observe the guidelines in
this manual, and any unauthorized openings and improper repairs
could expose the user to risks (electric shock, fire hazards) and could
also damage the equipment. Please note that any unauthorized
openings of the device will result in the invalidation of the warranty
and exclusion from all liability.
●Transport the device only in the antistatic original packaging or in
packaging that protects it from knocks and jolts.
●Only install expansions that are allowed for the system board. If you
install other expansions, you may damage the requirements and rules
governing safety and electromagnetic compatibility or your system.
Information on which system expansions are suitable can be
obtained from the customer service centre or your sales outlet.
●The warranty expires if the device is damaged during the installation
or replacement of system expansions.

4 A26361-D1919-Z120-1-7419
Notes on safety Important notes
V●Components can become very hot during operation. Ensure you do
not touch components when making extensions to the system board.
There is a danger of burns!.
●Transmisson lines to peripheral devices must be adequately shielded.
●To the LAN wiring the requirements apply in accordance with the
standards EN 50173 and EN 50174-1/2. As minimum requirement
the use of a protected LAN line of category 5 for 10/100 MBps
Ethernet, and/or of category 5e for Gigabit Ethernet is considered.
The requirements of the specification ISO/IEC 11801 are to be
considered.
●Never connect or disconnect data transmission lines during a storm
(lightning hazard).
Batteries
VCAUTION!
●Incorrect replacement of lithium battery may lead to a risk of
explosion. The batteries may only be replaced with identical batteries
or with a type recommended by the manufacturer.
It is essential to observe the instructions on page 37.
●Do not throw batteries into the trash can. They must be disposed of
in accordance with local regulations concerning special waste.
●The battery must be disposed of in accordance with local regulations
concerning special waste.
●All batteries containing pollutants are marked with a symbol (a
crossed-out garbage can). In addition, the marking is provided with
the chemical symbol of the heavy metal decisive for the classification
as a pollutant:
Cd Cadmium
Hg Mercury
Pb Lead

A26361-D1919-Z120-1-7419 5
Important notes Notes on safety
Modules with electrostatic-sensitive components
Systems and components that might be damaged by electrostatic discharge
(ESD) are marked with the following label:
Figure 1: ESD label
When you handle components fitted with ESDs, you must observe the following
points under all circumstances:
●You must always discharge yourself of static charges (e.g. by touching a
grounded object) before working.
●The equipment and tools you use must be free of static charges.
●Remove the power plug from the power socket before inserting or removing
boards containing ESDs.
●Always hold boards with ESDs by their edges.
●Never touch pins or conductors on boards fitted with ESDs.
●Use a grounding cable designed for this purpose to connect yourself to the
system unit as you install/deinstall the board.
●Place all components on a static-safe base.
IYou will find a detailed description for handling ESD components in the
relevant European or international standards (EN 61340-5-1,
ANSI/ESD S20.20).

6 A26361-D1919-Z120-1-7419
CE Certificate Important notes
Notes about boards
●During installation/deinstallation of the system board, observe the specific
instructions described in the service manual for the server.
●Remove the plug from the mains outlet so that system and system board are
totally disconnected from the mains voltage.
●To prevent damage to the system board, the components and conductors on
it, please take great care when you insert or remove boards. Take great care
to ensure that extension boards are slotted in straight, without damaging
components or conductors on the system board, or any other components,
for example EMI spring contacts
●Be careful with the locking mechanisms (catches, centring pins etc.) when
you replace the system board or components on it, for example memory
modules or processors.
●Never use sharp objects (screwdrivers) for leverage.
2.2 CE Certificate
The shipped version of this board complies with the requirements
of the EEC directive 89/336/EEC "Electromagnetic compatibility".
Compliance was tested in a typical PRIMERGY configuration.

A26361-D1919-Z120-1-7419 7
Important notes Environmental Protection
2.3 Environmental Protection
Notes on packaging
Please do not throw away the packaging. We recommend that you do not throw
away the original packaging in case you need it later for transporting.
Notes on dealing with consumables
Please dispose batteries in accordance with local government regulations.
Do not throw lithium batteries into the household waste. They must be disposed
of in accordance with local regulations concerning special waste.
Take-back, recycling and disposal
For details on take-back and reuse of devices and consumables within Europe,
contact your Fujitsu Siemens Computers branch office/subsidiary or our
recycling centre in Paderborn:
Fujitsu Siemens Computers
Recycling Center
D-33106 Paderborn
Germany
Tel. [phone]
Fax [phone]

A26361-D1919-Z120-1-7419 9
3 Features
3.1 Overview
Processors
– 1 or 2 x Intel®Xeon™ Processors
– 2 processor sockets mPGA604 for Intel®Xeon™ processor
– 1 MB second level cache (on-die unified, 64 byte cache-line size)
– 24 KB L1 cache (on-die, data)
– 16 KB L1 cache (on-die, instruction)
– VRM 10.1 onboard (EVRD)
Main memory
– 6 slots for main memory DDR/333MHz (registered),
SDRAM memory modules with 256 MB, 512 MB, 1 Gbyte and 2 Gbyte
(single rank)
– maximum 12 Gbyte of memory
– minimum 512 MB (2 memory modules)
– maximum 5,4 Gbyte/s bandwidth
– supports 2 way interleaved memory subsystems (2 identical memory
modules have to installed at the same time)
– ECC multiple bit error detection and single bit error correction
– memory scrubbing function
– Single Device Data Correction (SDDC) function (Chipkill™)
– hotspare memory technology
Chips on the system board
– Intel®E7320 Chipset
– Intel®6700PXH PCI-X Hub for PCI bridge with 2 PCI-X bus interfaces
– GBit LAN controller (Broadcom5721)
– VGA controller (ATI Rage XL) onboard with 8 MB SDRAM memory
– SCSI controller U320 (2 channel LSI 53C1030) with IME function
– Super I/O controller (SMSC LPC47M107)
– Flash EPROM for:
–SCSI-BIOS
–BIOS
–LAN
– server management (SM)

10 A26361-D1919-Z120-1-7419
Overview Features
– server management with BMC (FSC System)
– thermal and system management controller (ADM1026)
internal connectors
– floppy disk connector (34 pin)
– 1 IDE primary
– 1 Compact Flash for RemoteView (IDE primary)
– 1 IDE secondary (CD-ROM)
– 2 SCSI A and B (68pin connector)
– dual USB type C (for USB port on front side)
– main power connector (12V, -12V, 5V, 3.3V and 5V auxiliary)
– 12V (CPU) power connector
– 1 connector (12 pins) for 2 CPU PWM fans
– 2 direct connectors for system PWM fans
– PC98 connector
– IPMB connector (RSB data)
– front panel
– KVM power connector
– SCSI activity connector (HD LED)
– intrusion connector
– connectors for 2 additonal redundant system PWM fans (optional)
external connectors
– 2 serial ports (COM1, COM2)
– 1 parallel port (optional)
– 2 PS/2 interfaces for keyboard and mouse
– 2 USB 2.0 ports with 480 Mbits/s (rear side)
– 1 VGA port
– 1 RJ45 LAN port

A26361-D1919-Z120-1-7419 11
Features Overview
PCI slots
– 2 x PCI-X (64 bit / 100 MHz), 133 MHz only if one of the two slots is
populated.
– 2 x PCI-X (64 bit / 66 MHz)
– 1 x PCI 2.3 (32 bit / 33 MHz)
BIOS features
– Phoenix System-BIOS V 4.06
– Rompilot
– SMBIOS 2.31 (DMI)
– MultiProcessor Specification 1.4
– Server Hardware Design Guide 3.0
– WfM 2.0
– IPMI V1.5
– ACPI 1.0b support
– Adaptec SCSI RAID BIOS
– USB keyboard/mouse
– boot possible from:
– 120 MB floppy disk drive
– CD-ROM
– USB drive
–LAN
– no alert on LAN
– console redirection support
– OEM logo
– CPU, memory disable
– hotspare memory support
Environmental protection
battery in holder
Form factor
292 x 415 mm

12 A26361-D1919-Z120-1-7419
Main memory Features
3.2 Main memory
The system board supports up to 12 Gbyte main memory. 6 slots (3 memory
banks with 2 modules) are available for the main memory. Each memory bank
can be populated with two 256, 512 Mbyte, 1 Gbyte or 2 Gbyte registered DDR
333 (PC2700) memory modules.
A memory bank can be configured as hot spare bank (optional).
As in the basic configuration memory bank 2 is populated with 512 MB, 1 Gbyte,
2 Gbyte or 4 Gbyte memory modules, the memory extensions can be
performed up to two times for memory bank 1 and 0.
ECC with memory scrubbing and with the Single Device Data Correction
(SDDC) function is supported.
Module population
Figure 2: Main memory
– The memory modules have to be based on x4 organisierte single ranked
DDR 333 (PC2700) modules and must be populated in pairs.
– Each pair must consist of identical memory modules (2 way interleaved
mode).
– The module capacity between pairs can differ: pair 0A/0B can be populated
with two 512 Mbyte modules and pair 1A/1B with two 1 Gbyte modules.
– Only single ranked modules are permitted.
Memory Bank 0 - Module A
Memory Bank 0 - Module B
Memory Bank 1 - Module A
Memory Bank 1 - Module B
Memory Bank 2 - Module A
Memory Bank 2 - Module B

A26361-D1919-Z120-1-7419 13
Features Main memory
Following table shows the mandatory population order:
module pair 2A/2B module pair 1A/1B module pair 0A/0B
populated empty empty
populated populated empty
populated populated populated

14 A26361-D1919-Z120-1-7419
PCI bus Features
3.3 PCI bus
Figure 3: PCI slots
PCI slots
The following table shows an overview of the PCI slots:
IOOP™ (PCI bus speed optimisation)
The hardware of the system board optimizes the PCI bus speed of the slots 1
and 2, depending on the slots’ population.
– the PCI bus speed is 133 MHz, if only one of the two slots (or no slot) is
populated.
– the PCI bus speed is 100 MHz for all other population variants for slot 1
and 2.
PCI slot 64bit/
32bit
Frequency
in MHz
Description
1 64 bit 100 64-bit PCI bus slots, 133 MHz only if one of the two
slots is populated
2 64 bit 100
3 64 bit 66 64 bit PCI bus slot
4 64 bit 66 64 bit PCI bus slot
5 32 bit 33 32 bit PCI bus slot
1
2
3
4
5

A26361-D1919-Z120-1-7419 15
Features PCI bus
Zero Channel RAID
PCI slot 1 (blue sockel) is prepared for Zero Channel RAID (ZCR). ZCR means
that the SCSI controller is seen as SCSI RAID controller through the inserted
PCI card. The PCI bus then runs with 66 MHz instead of 100 MHz.
3.3.1 ISA bus resources
"IRQ" = interrupt assigned as shipped
"Address" = this address can be used for your particular device
"Address" = this DMA can be used for your particular device
Default settings are shown in bold print
Device IRQ Address DMA
Timer 0 040-043
Keyboard 1 060,064
Serial port COM2 3 3F8-3FF, 2F8-2FF, 3E8-
3EF, 2E8-2EF
Serial port COM1 4 3F8-3FF, 2FB-2FF, 3E8-3EF,
2E8-2EF
free 5
Floppy disk drive controller 6 3F0-3F5, 3F7 2
Parallel interface LPT1 7 278-27B, 378-37B, 3BC-3BF 0, 1, 3
Real-time clock (RTC) 8 070-071
free 9, 10, 11
Mouse controller 12
Numeric processor 13 0F0-0FE
IDE controller (primary) 14 1F0-1F7, 3F6
IDE controller (secondary) 15 170-177, 376

16 A26361-D1919-Z120-1-7419
PCI bus Features
3.3.2 PCI resources
PCI IRQ Line x - Assignment of the PCI interrupts
PCI IRQ Line x defines which ISA interrupts are used for the separate PCI slots.
If you select Auto in the BIOS setup, the interrupts are assigned automatically
and no further settings are required.
Multifunctional PCI boards or boards with an integrated PCI-to-PCI bridge can
use several PCI interrupts (INTA#, INTB#, INTC#, INTD#). Monofunctional PCI
boards (default) only use one PCI interrupt (INTA#) per PCI slot.
The PCI interrupts INTA#, INTB#, INTC# and INTD# are available for each PCI
slot.
The same interrupt can be assigned simultaneously to several PCI boards. You
should avoid this condition due to reduced performance.
If you use a setting other than Auto, the Plug&Play functionality of the system
BIOS for the corresponding PCI boards is deactivated.
Auto The PCI interrupts are assigned automatically in accordance with
the Plug&Play guidelines.
Disabled No ISA interrupt is assigned to the PCI interrupt.
3, 4, 5, 6, 7, 9, 10, 11, 12, 14, 15
The selected ISA interrupt is assigned to the PCI interrupt. You
may not select an ISA interrupt that is used by a component on
the system board (e.g. controller) or an ISA board.
