Fujitsu D2861 User manual

Technical Manual - English
System Board D2861
for BX922 S2
Technical Manual
Edition March 2011

Comments…Suggestions…Corrections…
The User Documentation Department would like to
know your opinion of this manual. Your feedback helps
us optimize our documentation to suit your individual
needs.
Feel free to send us your comments by e-mail to
email: [email protected].
Certified documentation
according to DIN EN ISO 9001:2008
To ensure a consistently high quality standard and
user-friendliness, this documentation was created to
meet the regulations of a quality management system
which complies with the requirements of the standard
DIN EN ISO 9001:2008.
cognitas. Gesellschaft für Technik-Dokumentation mbH
www.cognitas.de
Copyright and Trademarks
© cognitas. Gesellschft für Technik-Dokumentation mbH 2011 Pfad: C:\Programme\FCT\tim_app\tim_local\work\WALTER\OBJ_DOKU-9414-003.fm
Copyright © 2011 Fujitsu Technology Solutions GmbH.
All rights reserved.
Delivery subject to availability; right of technical modifications reserved.
All hardware and software names used are trademarks of their respective manufacturers.
–The contents of this manual may be revised without prior notice.
–Fujitsu assumes no liability for damages to third party copyrights or other rights arising from
the use of any information in this manual.
–No part of this manual may be reproduced in any form without the prior written permission
of Fujitsu.
Microsoft, Windows, Windows Server, and Hyper V are trademarks or registered trademarks of
Microsoft Corporation in the USA and other countries.
Intel and Xeon are trademarks or registered trademarks of Intel Corporation or its subsidiaries
in the USA and other countries.

D2861 (BX922 S2) Technical Manual
Before reading this manual
For your safety
This manual contains important information for safely and correctly using this
product.
Carefully read the manual before using this product. Pay particular attention to
the accompanying manual "Safety Notes and Regulations" and ensure these
safety notes are understood before using the product. Keep this manual and the
manual "Safety Notes and Regulations" in a safe place for easy reference while
using this product.
Radio interference
This product is a "Class A" ITE (Information Technology Equipment). In a
domestic environment this product may cause radio interference, in which case
the user may be required to take appropriate measures. VCCI-A
Aluminum electrolytic capacitors
The aluminum electrolytic capacitors used in the product's printed circuit board
assemblies and in the mouse and keyboard are limited-life components. Use of
these components beyond their operating life may result in electrolyte leakage
or depletion, potentially causing emission of foul odor or smoke.
As a guideline, in a normal office environment (25°C) operating life is not
expected to be reached within the maintenance support period (5 years).
However, operating life may be reached more quickly if, for example, the
product is used in a hot environment. The customer shall bear the cost of
replacing replaceable components which have exceeded their operating life.
Note that these are only guidelines, and do not constitute a guarantee of
trouble-free operation during the maintenance support period.
High safety use
This product has been designed and manufactured to be used in commercial
and/or industrial areas as a server.
When used as visual display workplace, it must not be placed in the direct field
of view to avoid incommoding reflections (applies only to TX server systems).
The device has not been designed or manufactured for uses which demand an
extremely high level of safety and carry a direct and serious risk of life or body
if such safety cannot be assured.

Technical Manual D2861 (BX922 S2)
© cognitas. Gesellschft für Technik-Dokumentation mbH 2011 Pfad: C:\Programme\FCT\tim_app\tim_local\work\WALTER\OBJ_DOKU-9414-003.fm
These uses include control of nuclear reactions in nuclear power plants,
automatic airplane flight control, air traffic control, traffic control in mass
transport systems, medical devices for life support, and missile guidance control
in weapons systems (hereafter, "high safety use"). Customers should not use
this product for high safety use unless measures are in place for ensuring the
level of safety demanded of such use. Please consult the sales staff of Fujitsu if
intending to use this product for high safety use.
Measures against momentary voltage drop
This product may be affected by a momentary voltage drop in the power supply
caused by lightning. To prevent a momentary voltage drop, use of an AC
uninterruptible power supply is recommended.
(This notice follows the guidelines of Voltage Dip Immunity of Personal
Computer issued by JEITA, the Japan Electronics and Information Technology
Industries Association.)
Technology controlled by the Foreign Exchange and Foreign Trade
Control Law of Japan
Documents produced by Fujitsu may contain technology controlled by the
Foreign Exchange and Foreign Trade Control Law of Japan. Documents which
contain such technology should not be exported from Japan or transferred to
non-residents of Japan without first obtaining authorization in accordance with
the above law.
Harmonic Current Standards
This product conforms to harmonic current standard JIS C 61000-3-2.
Only for the Japanese market:
About SATA hard disk drives
The SATA version of this server supports hard disk drives with SATA / BC-SATA
storage interfaces. Please note that the usage and operation conditions differ
depending on the type of hard disk drive used.
Please refer to the following internet address for further information on the
usage and operation conditions of each available type of hard disk drive:
http://primeserver.fujitsu.com/primergy/harddisk/

D2861 (BX922 S2) Technical Manual
Only for the Japanese market:
IAlthough described in this manual, some sections do not apply to the
Japanese market. These options and routines include:
– USB Flash Module (UFM)
– CSS (Customer Self Service)
– Replacing the lithium battery

Technical Manual D2861 (BX922 S2)
© cognitas. Gesellschft für Technik-Dokumentation mbH 2011 Pfad: C:\Programme\FCT\tim_app\tim_local\work\WALTER\OBJ_DOKU-9414-003.fm

D2861 (BX922 S2) Technical Manual
Contents
1 Preface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
2 Important notes . . . . . . . . . . . . . . . . . . . . . . . . . 11
2.1 Safety instructions . . . . . . . . . . . . . . . . . . . . . . . 11
2.2 CE Conformity . . . . . . . . . . . . . . . . . . . . . . . . . 14
2.3 Environmental protection . . . . . . . . . . . . . . . . . . . 15
3 Performance features . . . . . . . . . . . . . . . . . . . . . 17
3.1 Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
3.2 Main memory . . . . . . . . . . . . . . . . . . . . . . . . . . 22
3.2.1 Memory speed . . . . . . . . . . . . . . . . . . . . . . . . . . 29
3.3 Supported screen resolutions . . . . . . . . . . . . . . . . . 30
3.4 Temperature and system monitoring . . . . . . . . . . . . . 30
3.5 LED indicators . . . . . . . . . . . . . . . . . . . . . . . . . 32
3.5.1 Internal LEDs . . . . . . . . . . . . . . . . . . . . . . . . . . 32
3.5.2 External LEDs . . . . . . . . . . . . . . . . . . . . . . . . . . 33
3.6 Ports, switch and plugged connectors . . . . . . . . . . . . 34
3.7 Settings with switches and jumpers . . . . . . . . . . . . . 36
4 Replacing the lithium battery . . . . . . . . . . . . . . . . . 39

Technical Manual D2861 (BX922 S2)
Contents
© cognitas. Gesellschft für Technik-Dokumentation mbH 2011 Pfad: C:\Programme\FCT\tim_app\tim_local\work\WALTER\OBJ_DOKU-9415-003.fm

D2861 (BX922 S2) Technical Manual 9
1 Preface
This technical manual describes the D2861 system board, which can be
equipped with two processors.
For additional driver information (if available), refer to the Readme files located
on the server hard disk and on the supplied DVDs (see Installation DVD of
ServerView Suite - ServerView Software Products).
You will find further information about the BIOS setup in the "D2861 BIOS Setup
Utility for PRIMERGY BX922 S2 Server Blade" manual.
IPRIMERGY manuals are available in PDF format on the ServerView
Suite DVD 2. The ServerView Suite DVD 2 is part of the ServerView Suite
supplied with every server.
PRIMERGY Abbreviations and Glossary can also be found on the ServerView
Suite DVD 2.
Notational conventions
The meanings of the symbols and fonts used in this manual are as follows:
Italics Indicates commands, menu options or software
programs.
"Quotation marks" Indicate names of chapters and terms that are being
emphasized.
ÊDescribes work steps that must be performed.
VCAUTION! Indicates instructions which, if not followed, may result
in personal injury, damage to the system or a threat to
your data.
IIndicates additional information, notes and tips
Table 1: Notational conventions

10 Technical Manual D2861 (BX922 S2)
Preface
© cognitas. Gesellschft für Technik-Dokumentation mbH 2011 Pfad: C:\Programme\FCT\tim_app\tim_local\work\WALTER\OBJ_DOKU-9416-003.fm

D2861 (BX922 S2) Technical Manual 11
2 Important notes
This chapter provides safety instructions which you must observe when
handling the system board.
VCAUTION!
With the system board installed you must open the system to access the
system board. How to access the system board of your system is
described in the appropriate service supplement (except for the
Japanese market).
When handling the system board, refer to the specific notes on safety in
the operating manual and/or service supplement for the respective
server.
2.1 Safety instructions
VCAUTION!
●The actions described in this manual may only be performed by
personnel with the appropriate technical training. System board
repairs must be performed by qualified staff. Failure to comply with
the guidelines in this manual or any attempt at repair by untrained
personnel can endanger the user (electric shock, fire hazard) and/or
may cause material damage to the board or device; such actions will
also void the warranty and exempt the manufacturer from all liability.
●Only transport the board in the original antistatic packaging or in
packaging that protects it from shock and impact.
●Only install expansions that have been approved for the system
board. Installing other expansions may result in non-compliance with
the specifications and regulations regarding electromagnetic
compatibility, or may damage the system. You can find out which
expansions are suitable from the customer service center or your
sales outlet.
●If you cause a defect on the device by installing or exchanging
expansions, the warranty will be invalidated.

12 Technical Manual D2861 (BX922 S2)
Safety instructions Important notes
© cognitas. Gesellschft für Technik-Dokumentation mbH 2011 Pfad: C:\Programme\FCT\tim_app\tim_local\work\WALTER\OBJ_DOKU-9417-003.fm
VCAUTION!
●When adding expansions to the system board, note that components
can become very hot during operation. Operators may be burned!
●Connection cables to peripheral devices must be adequately
shielded.
●Standards EN 50173 and EN 50174-1/2 apply for LAN cabling. The
minimum requirement is the use of a category 5 shielded LAN cable
for 10/100 Mbit/s Ethernet, or a category 5e cable for Gigabit
Ethernet. The requirements of the specification ISO/IEC 11801 must
also be taken into account.
●Do not connect or disconnect any data transmission cables during a
thunderstorm (lightning hazard).
Batteries
VCAUTION!
●If the lithium battery is replaced incorrectly, there is a risk of explosion.
Batteries must only be replaced with types that are identical or that
are recommended by the manufacturer.
Please observe the information in chapter "Replacing the lithium
battery".

D2861 (BX922 S2) Technical Manual 13
Important notes Safety instructions
Notes on electrostatically sensitive components:
Components with electrostatic-sensitive devices (ESD) may be identified by the
following sticker:
Figure 1: ESD label
When you handle components fitted with ESDs, it is essential that you observe
the following:
●Always discharge static build-up (e.g. by touching a grounded object) before
working with the components.
●The equipment and tools you use must be free of static charge.
●Remove the device power plug before inserting or removing boards.
●Always hold boards by their edges.
●Do not touch any connector pins or conductors on the component.
●When installing or removing components on the board, use a suitable
grounding cable.
●Place all components on a static-proof base.
IFor a detailed description of how to handle ESD components, see the
relevant European or international standards (EN 61340-5-1, ANSI/ESD
S20.20).

14 Technical Manual D2861 (BX922 S2)
CE Conformity Important notes
© cognitas. Gesellschft für Technik-Dokumentation mbH 2011 Pfad: C:\Programme\FCT\tim_app\tim_local\work\WALTER\OBJ_DOKU-9417-003.fm
Instructions for handling boards
●The specific instructions in the service article for the respective end device
must be observed when installing and removing the board.
●Disconnect the device plug from the shock-proof socket before carrying out
any work on an installed board.
●Exercise extreme care when installing and removing all boards.
Take care not to tilt boards; they must be installed perfectly straight.
If they are incorrectly handled, the boards and the components on them, or
the other components (e.g. EMI spring contacts) and conductors can be
damaged.
●Handle all locking mechanisms (engaging lugs and centering pins) carefully
when installing/removing the board or components (e.g. memory modules,
processors).
●Never use sharp objects (screwdrivers) as levers.
2.2 CE Conformity
The shipped version of this board complies with the requirements
of the EC directives 2004/108/EC "Electromagnetic
Compatibility" and 2006/95/EC "Low Voltage Directive". The
board therefore qualifies for the CE marking (CE=Communauté
Européenne).
Conformity has been tested in a typical configuration of a
PRIMERGY server.

D2861 (BX922 S2) Technical Manual 15
Important notes Environmental protection
2.3 Environmental protection
Environmentally-friendly product design and development
This product has been designed in accordance with standards for
"environmentally friendly product design and development". This means that
key factors such as durability, selection and labeling of materials, emissions,
packaging, ease of dismantling and recycling have been taken into account.
This saves resources and thus reduces the harm done to the environment.
Further information can be found at:
–http://ts.fujitsu.com/products/standard_servers/index.html (for the EMEA market)
–http://primeserver.fujitsu.com/primergy/concept/ (for the Japanese market)
Energy-saving information
Devices that do not need to be constantly switched on should be switched off
until they are needed as well as during long breaks and after completion of work.
IThe On/Off button does not disconnect the device from the mains. To
disconnect from the mains completely, remove the power plug(s).
Packaging information
This packaging information does not apply to the Japanese market.
Do not throw away the packaging. You may need it later for transporting the
system. If possible, the equipment should only be transported in its original
packaging.
Information on handling consumables
Please dispose of printer consumables and batteries in accordance with the
applicable national regulations.
In accordance with EU directives, batteries must not be disposed of with
unsorted domestic waste. They can be returned free of charge to the
manufacturer, dealer or an authorized agent for recycling or disposal.

16 Technical Manual D2861 (BX922 S2)
Environmental protection Important notes
© cognitas. Gesellschft für Technik-Dokumentation mbH 2011 Pfad: C:\Programme\FCT\tim_app\tim_local\work\WALTER\OBJ_DOKU-9417-003.fm
All batteries containing pollutants are marked with a symbol (a crossed-out
garbage can). They are also marked with the chemical symbol for the heavy
metal that causes them to be categorized as containing pollutants:
Cd Cadmium
Hg Mercury
Pb Lead
Labels on plastic casing parts
Please avoid sticking your own labels on plastic parts wherever possible, since
this makes it difficult to recycle them.
Returns, recycling and disposal
Details regarding the return and recycling of devices and consumables within
Europe can also be found in the "Returning used devices" manual, via your local
Fujitsu Technology Solutions branch or from our recycling center in Paderborn:
Fujitsu Technology Solutions
Recycling Center
D-33106 PaderbornGermany
Tel. [phone]
Fax [phone]
The device must not be disposed of with domestic waste. This
device is labeled in compliance with European directive
2002/96/EG on waste electrical and electronic equipment (WEEE).
This directive sets the framework for returning and recycling used
equipment and is valid across the EU.
When returning your used device, please use the return and
collection systems available to you. Further information can be
found at http//ts.fujitsu.com/recycling.

D2861 (BX922 S2) Technical Manual 17
3 Performance features
3.1 Overview
Processors
– 1 or 2 Intel®Xeon®processors of the 5500 or 5600 series
– 2 LGA1366 processor sockets for Intel®Xeon®processors
– Integrated memory controller (DDR3)
– 32 KB L1 cache (on-die data cache for each processor core)
– 256 KB mid-level cache per processor core
– Up to 12 MB on-chip shared L2 cache (shared by all processor cores)
– 2x Intel®QuickPath Interconnect connections with up to 6.4 GT/s in each
direction
Main memory
– 12 slots for DDR3 memory modules (DIMMs) with 800/1066/1333 MHz and
a capacity of 2 GB, 4 GB, 8 GB and 16 GB
– Both unbuffered ("UDIMM", up to 2 GB) and buffered ("RDIMM", up to
16 GB) memory modules are supported, mix of memory is not permitted
– Maximum 192 GB memory, minimum 2 GB (1 memory module)
– Maximum 32 Gbit/s bandwidth (DDR3)
– Both CPUs have 2 DIMM slots for memory per channel
– ECC error detection and error correction
– Memory Scrubbing function
– Single Device Data Correction (SDDC) function (Chipkill™) only for RDIMM
Chips on the system board
– Intel®5500 Chipset
– Intel®ICH10R Base
– Intel®IOH24D
– 2x dual-port Gigabit Ethernet controllers Intel®82576EB
– TPM 1.2 Infineon SLB9635 TT1.2 (optional)
– iRMC S2 (integrated Remote Management Controller) with integrated
graphics controller
– 2 MB Flash ROM
– 32Mx16 DDR2 667 SRAM for iRMC S2
– ADT7462 temperature/system monitoring controller

18 Technical Manual D2861 (BX922 S2)
Overview Performance features
© cognitas. Gesellschft für Technik-Dokumentation mbH 2011 Pfad: C:\Programme\FCT\tim_app\tim_local\work\WALTER\OBJ_DOKU-9419-003.fm
Graphics
– Integrated VGA controller with PCIe x1 interface (PILOT II)
– 16 MB graphics memory onboard
Ethernet LAN controllers
– 2x Intel®Dual Port 10/100/1000 MBit/s Base-T Ethernet controllers
– 1x BCM5221 for iRMC S2
Storage devices
– 2x SSD (Solid State Disk) or 2x SATA HDD
– UFM (USB Flash Module)
External connections (via Y cables)
– 4x USB 2.0 ports at the front
– 1x serial port on the front
–1xVGA
internal connectors
– 1x VGA port on the front
– 1x USB port for 4 USB ports on the front
– 1x UFM port (USB Flash Module port) for USB Flash ROM
– 12x ports for DDR3 memory modules
– Power supply (12V and 5V auxiliary voltage)
iRMC S2 server management controller
– Basic features: Temperature monitoring, System Event Log and ASR&R
(Automatic Server Reconfiguration and Restart)
–PDA
– Global Error/CSS/ID indicator
– Prefailure warranty for memory
– HD/SSD LED support (SAS, SATA)
– Inventory Identification Control
– CSS functionality
– Energy consumption control
– Console redirection (text console)
– Graphic console redirection (Advanced Video Redirection - AVR)
– Provision of remote memory media (Remote Storage)

D2861 (BX922 S2) Technical Manual 19
Performance features Overvie
w
Security features
– Password protection for system and BIOS
– BIOS restore support
– Virus protection through Flash Write Protection
Energy saving functions
– ACPI (States S0, S1, S4, S5)
– On/Off/Idle state/Reactivate via power switch
– Switch on and off via software
– Reactivate the server from standby via RTC, external serial ports, LAN, PCIe
controller and iRMC S2
– Switch on the server via the power switch, external serial ports, LAN, PCIe
controller and iRMC S2
BIOS features
–AMI
– SMBIOS 2.5 (DMI)
– MultiProcessor Specification
– Server Hardware Design Guide
–WfM
– ACPI support
– LSI SAS/RAID BIOS
– USB keyboard/mouse
– Boot capabilities from:
– Hard disk (SSD, SATA, SAS, SCSI, USB)
– USB stick
– CD/DVD (USB)
–LAN
– Console Redirection support
– OEM logo
– CPU, memory deactivation
– Mirroring and spare memory support
Environmental protection
Battery in holder for recycling

20 Technical Manual D2861 (BX922 S2)
Overview Performance features
© cognitas. Gesellschft für Technik-Dokumentation mbH 2011 Pfad: C:\Programme\FCT\tim_app\tim_local\work\WALTER\OBJ_DOKU-9419-003.fm
Form factor, slot compatibility list
– 491mm x 200mm
– ACPI 2.0, OnNow, PCI-Express 2.0, LPC 1.1, WfM 2.0,
SHDG 3.0, MPS 1.4, IPMI 1.5, PCI SHPC 1.0 and PCI Express Card
Electromechanical Specification Rev. 1.0, USB2.0, SATAII 2.0
CSS (Customer Self Service)
IThis feature is not available for the japanese market.
This system board supports the CSS functionality. You can find a description of
this in the operating manual for your server.
UFM (optional)
IThis feature is not available for the japanese market.
By the manufacturer the system board is equipped with a slot for a UFM
(USB Flash Module). The module can be used as optional memory for software
(e.g. VMware) or as a software dongle.
