Cleaning Instructions for
fi-5750C Scanner
It is recommended that these items be
cleaned EVERY 10,000 SCANS
Consumables Part Number
Consumable Kit CON-3338-008A
Cleaning Kit SC-CLE-LV
Using cleaning paper moistened with F1 Cleaner

Brake Roller
Open the brake roller holder and remove the brake roller before cleaning


Turn the Scanner OFF while cleaning the following locations
ADF Glass Surfaces x 2
Located on the ADF cover and opposite side. Clean lightly.
Pick Roller
Clean lightly taking care not to scratch the surface.
P.T.O.

Plastic Rollers x 4
Clean lightly while rotating with your finger. Take care not to roughen the surface.
BEFORE CLEANING
Open the ADF while pressing
the cover open button
ADF Cover
Paper
Chute
Cover Open
Buttons
Pick Roller




Plastic Rollers
Feed Rollers
Glass
Brake Roller


Eject Rollers
(hidden)
Using cleaning paper
moistened with F1 Cleaner
Cleaning the Flatbed
Open the document cover clean:
Document Holding Pad
Document Bed






Feed Rollers x 2
Clean lightly taking care not to roughen the surface.
For further information please refer to the
fi-5750C Scanner Operators Guide
which can be found on our Website:
http://www.fujitsu.com/emea/products/
January 2010
Using cleaning paper moistened with F1 Cleaner
Turn the Scanner ON while cleaning the following locations
PFU Imaging Solutions Europe Ltd Cleaning Instructions for fi-5750C Scanner

Eject Rollers x 2
Clean lightly taking care not to roughen the surface.
To rotate the Feed and Eject Rollers, press the POWER button while holding down the SCAN
button.
As a guideline, seven presses of the POWER button make the rollers rotate one full turn.




Plastic Rollers
Feed Rollers
Glass
Brake Roller


Eject Rollers
(hidden)
Pick Roller
While holding down the SCAN button 
Press the POWER button 
Each press of the POWER button will cause the
rollers to rotate

