Fujitsu PRIMERGY TX600 User manual

U41057-J17-Z146-1-76 Januar 2004 02–TX600–1
© Siemens Nixdorf Informationssysteme AG 1995 Pfad: P:\02-systemeinheiten\TX600\TX600-e\TX600-e.ivz
02
TX600
PRIMERGY TX600
You will find updates and new components in the chapter ’Updates’ positioned
after the index.
Contents
General information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 02-TX600-5
Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 02-TX600-5
Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 02-TX600-6
Options . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 02-TX600-11
Function . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 02-TX600-12
Product designations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 02-TX600-13
System allocation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 02-TX600-17
Service . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 02-TX600-18
Technical data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 02-TX600-19
Installation and initial operation . . . . . . . . . . . . . . . . . . . . . . . . 02-TX600-21
Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 02-TX600-21
Preparation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 02-TX600-21
Preparing the keyboard . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 02-TX600-22
Connecting devices to the server . . . . . . . . . . . . . . . . . . . . . . 02-TX600-22
Connecting the server to the mains . . . . . . . . . . . . . . . . . . . . 02-TX600-24
Initial operation and operating . . . . . . . . . . . . . . . . . . . . . . . . . . . 02-TX600-25
Locking and unlocking the floor-standing server . . . . . . . . . . 02-TX600-25
Controls and indicators on the front panel . . . . . . . . . . . . . . . 02-TX600-28
Indicators on the rear . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 02-TX600-35
– Indicators on the external connector panel . . . . . . . . . . . . 02-TX600-35
– Indicators on hot-plug PCI slots . . . . . . . . . . . . . . . . . . . . 02-TX600-36
– Status indicators on the hot-plug power supply modules . 02-TX600-38
Indicators on the fan . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 02-TX600-39
Switching the server ON and OFF . . . . . . . . . . . . . . . . . . . . . 02-TX600-40
Starting up hot-plug PCI slots . . . . . . . . . . . . . . . . . . . . . . . . . 02-TX600-41
Configuration of the server . . . . . . . . . . . . . . . . . . . . . . . . . . . 02-TX600-42
Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 02-TX600-43
System board D1411 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 02-TX600-43
– Interfaces and connectors . . . . . . . . . . . . . . . . . . . . . . . . . 02-TX600-43
– Temperature / system monitoring . . . . . . . . . . . . . . . . . . . 02-TX600-44
– LAN connectors A and B . . . . . . . . . . . . . . . . . . . . . . . . . . 02-TX600-46

02–TX600–2 Januar2004 U41057-J17-Z146-1-76
Contents
– LAN connectors of the Remote Management controller . 02-TX600-46
– Slot sequence . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 02-TX600-48
– ISA bus resources . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 02-TX600-48
– PCI bus resources . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 02-TX600-49
– Supported screen resolutions . . . . . . . . . . . . . . . . . . . . . 02-TX600-51
– Settings with switches . . . . . . . . . . . . . . . . . . . . . . . . . . . 02-TX600-51
RemoteView chipDISK . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 02-TX600-53
Operating panel board . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 02-TX600-54
SCSI backplane . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 02-TX600-55
Power backplane . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 02-TX600-56
Fan backplane . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 02-TX600-57
Hot-plug panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 02-TX600-58
Tape SCA2 adapter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 02-TX600-58
Internal cabling . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 02-TX600-59
Basic cabling . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 02-TX600-59
Cabling of power backplane . . . . . . . . . . . . . . . . . . . . . . . . . 02-TX600-60
Addresses for SCSI devices . . . . . . . . . . . . . . . . . . . . . . . . . . . . 02-TX600-61
Overview of cables . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 02-TX600-62
Diagnostics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 02-TX600-65
LocalView module . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 02-TX600-65
Numbering of the components in ServerView . . . . . . . . . . . . . . 02-TX600-66
PRIMERGY diagnostic LEDs . . . . . . . . . . . . . . . . . . . . . . . . . . . 02-TX600-68
Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 02-TX600-70
Removal/installation routines . . . . . . . . . . . . . . . . . . . . . . . . . 02-TX600-75
Preparation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 02-TX600-75
Opening/closing the server . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 02-TX600-75
Floor-standing model . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 02-TX600-75
– Removing/installing the front cover . . . . . . . . . . . . . . . . . 02-TX600-76
– Removing/installing the right side cover . . . . . . . . . . . . . . 02-TX600-77
Rack model . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 02-TX600-78
– Removing/installing the rack model . . . . . . . . . . . . . . . . . 02-TX600-78
– Removing the front panel of the rack . . . . . . . . . . . . . . . . 02-TX600-80
Removing/installing the main cover . . . . . . . . . . . . . . . . . . . . 02-TX600-81
Removing/installing the peripheral cover . . . . . . . . . . . . . . . . 02-TX600-82
SCSI hard disk subsystem . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 02-TX600-83
Components and indicators of the hard disk module . . . . . . 02-TX600-84
Installing/removing a SCSI hard disk module . . . . . . . . . . . . 02-TX600-85

U41057-J17-Z146-1-76 Januar 2004 02–TX600–3
Contents
© Siemens Nixdorf Informationssysteme AG 1995 Pfad: P:\02-systemeinheiten\TX600\TX600-e\TX600-e.ivz
– Removing the dummy cover . . . . . . . . . . . . . . . . . . . . . . . 02-TX600-86
– Installing the dummy cover . . . . . . . . . . . . . . . . . . . . . . . . 02-TX600-86
– Installing a SCSI hard disk module . . . . . . . . . . . . . . . . . . 02-TX600-87
– Removing a SCSI hard disk module . . . . . . . . . . . . . . . . . 02-TX600-89
– Replacing a SCSI hard disk module during operation . . . 02-TX600-89
Changing the SCSI hard disk drive in the hard disk carrier . . 02-TX600-90
Installing/removing a hot-swap magnetic tape drive . . . . . . . . 02-TX600-91
Changing the tape drive in the drive carrier . . . . . . . . . . . . . . 02-TX600-93
Replacing the SCSI backplane . . . . . . . . . . . . . . . . . . . . . . . . 02-TX600-95
Accessible drives and operating panel . . . . . . . . . . . . . . . . . . . . . 02-TX600-97
Installing/removing the peripheral cage . . . . . . . . . . . . . . . . . 02-TX600-97
Installing/removing an accessible 5.25 inch drive . . . . . . . . . . 02-TX600-99
– Removing/installing the dummy cover . . . . . . . . . . . . . . . 02-TX600-100
– Installing an accessible 5.25 inch drive . . . . . . . . . . . . . . 02-TX600-101
Installing/removing a floppy disk drive . . . . . . . . . . . . . . . . . 02-TX600-102
Replacing a DVD-ROM drive . . . . . . . . . . . . . . . . . . . . . . . . 02-TX600-103
Replacing the operating panel board . . . . . . . . . . . . . . . . . . 02-TX600-104
LocalView module . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 02-TX600-106
Replacing a LocalView module . . . . . . . . . . . . . . . . . . . . . . 02-TX600-106
Power Supply . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 02-TX600-108
Replacing a hot-plug power supply module . . . . . . . . . . . . . 02-TX600-108
Removing/installing the power backplane . . . . . . . . . . . . . . 02-TX600-110
System fans . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 02-TX600-112
Replacing a redundant system fan . . . . . . . . . . . . . . . . . . . . 02-TX600-113
Removing/installing a fan backplane . . . . . . . . . . . . . . . . . . 02-TX600-115
Installing/removing the fan box holder . . . . . . . . . . . . . . . . . 02-TX600-117
External SCSI interface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 02-TX600-118
Upgrading an external SCSI interface . . . . . . . . . . . . . . . . . 02-TX600-118
RemoteView medium . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 02-TX600-120
Installing/removing the chipDISK . . . . . . . . . . . . . . . . . . . . . 02-TX600-120
Configuring the chipDISK . . . . . . . . . . . . . . . . . . . . . . . . . . . 02-TX600-122
Boards in PCI slots . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 02-TX600-123
Replacing a (hot-plug) PCI board . . . . . . . . . . . . . . . . . . . . . 02-TX600-123
Installing an additional PCI board . . . . . . . . . . . . . . . . . . . . . 02-TX600-131
Installing a PCI RAID controller . . . . . . . . . . . . . . . . . . . . . . 02-TX600-134
System board . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 02-TX600-137
Ventilation duct . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 02-TX600-137
– Removing/installing the ventilation duct . . . . . . . . . . . . . 02-TX600-137
Main memory . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 02-TX600-139

02–TX600–4 Januar2004 U41057-J17-Z146-1-76
Contents
Processors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 02-TX600-141
– Installing/removing processors . . . . . . . . . . . . . . . . . . . 02-TX600-141
– Changing the processor heat sink . . . . . . . . . . . . . . . . . 02-TX600-145
Changing DC/DC converters and VRMs . . . . . . . . . . . . . . . 02-TX600-145
Lithium battery . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 02-TX600-146
– Replacing the lithium battery . . . . . . . . . . . . . . . . . . . . . 02-TX600-146
Removing/installing the PCI slot insulation plate . . . . . . . . . 02-TX600-148
Changing the system board . . . . . . . . . . . . . . . . . . . . . . . . 02-TX600-150
– Removing the system board . . . . . . . . . . . . . . . . . . . . . 02-TX600-150
– Installing the system board . . . . . . . . . . . . . . . . . . . . . . 02-TX600-155
IDTEMP combo . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 02-TX600-157
Replacing the IDTEMP combo . . . . . . . . . . . . . . . . . . . . . . 02-TX600-157
Intrusion detection switch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 02-TX600-159
Replacing the intrusion detection switch . . . . . . . . . . . . . . . 02-TX600-159
– Removing the intrusion detection switch . . . . . . . . . . . . 02-TX600-160
Changing the housing variant . . . . . . . . . . . . . . . . . . . . . . . . . . 02-TX600-161
Converting from floor-standing model to rack model . . . . . . 02-TX600-161
Installing/removing the rack model . . . . . . . . . . . . . . . . . . . . . . 02-TX600-170
Mounting in the PRIMECENTER rack . . . . . . . . . . . . . . . . . 02-TX600-171
– Procedure for telescopic rails type 1 . . . . . . . . . . . . . . . 02-TX600-171
– Procedure for telescopic rails type 2 . . . . . . . . . . . . . . . 02-TX600-174
Mounting in the DataCenter rack . . . . . . . . . . . . . . . . . . . . . 02-TX600-176
Mounting in the Classic rack . . . . . . . . . . . . . . . . . . . . . . . . 02-TX600-179
Mounting in third-party racks . . . . . . . . . . . . . . . . . . . . . . . . 02-TX600-184
Installing the server . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 02-TX600-185
– Procedure for telescopic rails type 1 . . . . . . . . . . . . . . . 02-TX600-185
– Procedure for telescopic rails type 2 . . . . . . . . . . . . . . . 02-TX600-187
– Fastening the server in the rack . . . . . . . . . . . . . . . . . . . 02-TX600-188
Overviews, lists . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 02-TX600-189
Spare parts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 02-TX600-189
Glossary . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 02-TX600-189
Index . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 02-TX600-193
Updates . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 02-TX600-199

U41057-J16-Z146-1-76 October 2003 02–TX600–5
© Siemens Nixdorf Informationssysteme AG 1995 Pfad: P:\02-systemeinheiten\TX600\TX600-e\TX600-e.k01
02
TX600
General information
Description
The PRIMERGY TX600 server is an Intel-based server for mid-size networks
and large companies. The server is suitable for use as a file server as well as
an application, information, or internet server. It is available as a floor-standing
or rack model. The floor-standing model can be converted into a rack model
using an optional conversion kit.
The PRIMERGY TX600 server offers a high level of reliability and availability
through highly developed hardware and software components. These include
hot-swap hard disk drive modules, redundant system fans and power supply
units, and hot-plug PCI slots, the ServerView server management software,
"Prefailure Detection and Analyzing" (PDA), and "Automatic Server Reconfigu-
ration and Restart" (ASR&R).
The term hot-swap refers to the online replacement of a component (e.g. a
failed hard disk drive, which is configured as a member of a disk array (RAID)).
The term hot-plug refers to the replacement of components while the power is
switched on. In the special case of hot-plug PCI boards it is ensured that the
corresponding PCI slot is powered off before the board is removed.
Security functions in the BIOS Setup and on the system board protect the data
on the server against manipulation. Additional security is provided by the
intrusion detection and the lockable drive cover on the floor-standing model
and/or the lockable rack door.

02–TX600–6 October2003 U41057-J16-Z146-1-76
Description General information
Features
System board D1411
– ServerWorks GC LE chipset
– 4 processor sockets for Gallatin processors with 2.0 GHz and higher, socket
603, with 400MHz front-side bus and quad-pumped data bus
– 512 Kbyte second-level cache, and 1 or 2MB TLC
– 8 slots for main memory. PC2100 modules (registered DDR DIMM memory
modules with 266 MHz and ECC) for 1-16 Gbyte main memory
– 4x 64-bit hot-plug PCI-X slots with 3x 133MHz, 1x100 MHz
– 1x 64-bit PCI-X slot with 100 MHz (prepared for ZCR)
– 1x 64-bit PCI slot with 33 MHz (long design possible)
– SCSI controller AIC7902 Ultra 320 capable, two-channel; board supports
Zero Channel RAID (with Host RAID function)
– Screen controller ATI Rage XL VGA onboard with 230 MHz RAMDAC and
8 Mbyte SDRAM memory
– Ethernet LAN-Controller Broadcom BCM 5704 with 2x 1 Gbit
– Onboard Remote Management controller (RMC) with a own COM and LAN
interface and an optional battery backup unit
– 2 IDE interfaces ATA100 capable, support PIO mode 0-4
– Floppy port (34-pin classical)
– 1 external parallel interface (ECP- and EPP-compatible)
– 2 external serial ports (COM1 and COM2)
– 1 external serial interface for Remote Management
– 3 external and 2 internal USB1.1 ports
– 2 external RJ45 LAN ports
– 1 external RJ45 LAN port for Remote Management
– 2 external PS/2 interfaces for keyboard and mouse
– 1external port for the optional battery backup unit of the RMC
– System monitoring
Hot-plug PCI slots
As well as standard PCI slots, the server also has four hot-plug PCI slots that
allow boards to be installed and removed online, assuming the operating
system supports this functionality.

U41057-J16-Z146-1-76 October 2003 02–TX600–7
General information Description
© Siemens Nixdorf Informationssysteme AG 1995 Pfad: P:\02-systemeinheiten\TX600\TX600-e\TX600-e.k01
LocalView module (alphanumeric system display)
The LocalView module providesan alphanumeric display of system information
and hardware errors. It is an intelligent module with a micro controller and its
own memory that can run independently of the attached server system.
The LocalView module includes the LCD panel and the toggle switch, both of
which are integrated in a peripheral bay. The mechanism used allows the
module to be pulled out and opened with ease. The LocalView module is
installed in a free 5.25 inch server slot.
A description of the indicators and how to use LocalView can be found in the
"Diagnostics" module of the Service Manual.
Hard disk drives
The server has two drive cages, each of which can accommodate up to six
ULTRA320-SCSI hard disk slide-in modules. Each hard disk module can
accommodate a SCSI hard disk drive with an SCA (Single Connector
Attachment) interface and a maximum height of 1. The module is connected to
the SCSI backplane without cables via the SCA interface. This allows hard disk
modules to be simply plugged in or pulled out.
The hard disk drive system is designed for Ultra3 SCSI and can be configured
as a dual-channel system with three hard disk drives each or as a single-
channel system with six hard disk drives. The hard disk drives can be controlled
by the onboard controller or by a plug-in RAID controller.
If the server has a RAID controller and a corresponding RAID configuration,
defective hard disk modules can be exchanged online (hot-swap).
Accessible drives
Various mounting slots are available:
– Two 5.25 inch half-height (1.6 inch) slots for accessible drives (e.g. magnetic
tape drives)
Alternatively, these slots can be used to install a 3.2-inch-high accessible
drive.
– One slot for a 3.5 inch slimline floppy disk drive (1.44 MB) and one slot for a
slimline DVD-ROM drive.
The accessible drives integrated in the 5.25 inch slots cannot be
replaced online.
i

02–TX600–8 October2003 U41057-J16-Z146-1-76
Description General information
Power supply
In its basic configuration, the server has two hot-swap wide-range power supply
units which adjust automatically to any power voltage in the range of 100 V to
240 V. If one power supply unit fails, the second ensures that operation can
continue uninterrupted. The defective power supply unit can be replaced online.
Ventilation
The server is cooled by means of the power supply unit fans and eight system
fans (redundant configuration).
If one fan in a redundant pair fails, the other fan ensures that operation can
continue uninterrupted. A defective system fan can be replaced online.
Every CPU has its own heat sink with fan.
High availability and data security
When memory data is accessed, 1-bit errors in the main memory are recog-
nized and automatically corrected with the ECC (Error Correcting Code)
method. The patented memory-scrubbing function regularly starts up the EDC
mechanism and thus ensures continuous data integrity.
The memory modules used support Chipkill™ technology, which in addition
increases the effectiveness of the monitoring and correction of memory errors.
Support is likewise provided for hot-spare memory technology, in which a
memory bank is used like a replacement bank. If a memory module fails, the
bank with the defective memory is automatically deactivated and the
replacement bank is activated in its place (assuming it has been configured
appropriatelyintheBIOS).Thedeactivatedmemorybankisnolongerusedand
the faulty memory module can be replaced at the next opportunity. For the hot-
spare memory function to be used, all occupied memory banks must have an
identical memory configuration.
ASR&R (Automatic Server Reconfiguration and Restart) restarts the system in
the case of an error and automatically "hides" the defective system compo-
nents.
The PDA (Prefailure Detection and Analyzing) technology from Fujitsu Siemens
Computers analyzesandmonitors allcomponentsthat areimportant for system
reliability.
Optional RAID controllers support RAID levels 0, 1, 5 and 10 and increase
system availability.

U41057-J16-Z146-1-76 October 2003 02–TX600–9
General information Description
© Siemens Nixdorf Informationssysteme AG 1995 Pfad: P:\02-systemeinheiten\TX600\TX600-e\TX600-e.k01
Server management
ServermanagementisimplementedusingthesuppliedServerView software and
PDA (Prefailure Detection and Analyzing) technology from Fujitsu Siemens
Computers. PDA reports the threat of a system error or overloading early on, so
that preventive measures can be taken.
ServerView allows the management of all PRIMERGY servers in the network via
a central console. The following are some of the key features supported by
ServerView in this context.
– Remote power-on (Wake On LAN)
– Intrusion detection in the floor-standing model
– Temperature monitoring of the CPU and surrounding area
– Monitoring of the utilization of the PCI buses
– Detailed status and error reports for bus systems, processors and main
memory
– Watchdog timer for Automatic Server Reconfiguration and Restart (ASR&R)
if memory modules or processors fail
– Power monitoring
– Early detection of a defective fan
– Watchdog timer for operating system monitoring and application monitoring
with ASR&R
Further information on the ServerView server management is provided in the
associated documentation.
ServerStart
You can configure the PRIMERGY server quickly and purposefully with the
ServerStart softwareprovided. User-guided menusare available for installing the
server operating systems.
Service and support
PRIMERGY servers are service-friendly and modular, thus enabling quick and
simple maintenance.
The handles and locks (touch points) of the different hot-plug/hot-swap compo-
nents are colored green to allow quicker recognition. Also colored green are the
elements of all other components that can be handled without tools.
PRIMERGY diagnostic LEDs arranged on the system board identify the
component (memory module, CPU, VRMs) on the board that is not functioning
correctly.

02–TX600–10 October2003 U41057-J16-Z146-1-76
Description General information
The flash EPROM program supplied with the Fujitsu Siemens Computers
utilities supports a fast BIOS update.
The optional RemoteView remote testing and diagnostics system allows the
PRIMERGY TX300 server to be maintained from remote locations. Remote
diagnostics can therefore be performed for system analysis, remote configu-
ration and remote restart should the operating system or hardware fail.
RemoteView
RemoteView is the remote management solution from Fujitsu Siemens
Computers for Intel-based PRIMERGY systems. RemoteView 3.0 and the
relevant hardware components integrated on the system board allow remote
monitoringandmaintenanceaswellasfastrestorationofoperabilityintheevent
of errors.
Remote monitoring and maintenance avoids time-consuming and costly on-site
repairs and reduces service costs. This leads to a reduction in the total cost of
ownership and an excellent return on investment for the remote management
solution.
RemoteView helps to:
– switch the system ON/OFF remotely
– monitor systems and analyze the cause of faults
– prepare error resolution or have this process initiated independently if pos-
sible
– identify potential sources of error
– configure the system
– adjust system settings and initiate system restarts from a remote location.

U41057-J16-Z146-1-76 October 2003 02–TX600–11
General information Description
© Siemens Nixdorf Informationssysteme AG 1995 Pfad: P:\02-systemeinheiten\TX600\TX600-e\TX600-e.k01
Options
Converting from a floor-standing model to a rack model
The floor-standing model can be optionally converted to allow the server to be
mounted in any typical rack system.
Additional hot-swap tape drive
A hot-swap tape drive can be installed optionally in the hard disk drive cage. As
a result, two slots will be occupied in the drive cage which are then no longer
available for HDD modules.
Additional RemoteView
RemoteView is a feature-rich remote testing and diagnostics package. The
testing and diagnostics software is stored on a chipDISK. The chipDISK is a
memory module with an IDE interface and is located on the system board. In
the event of an error the testing and diagnostics software is automatically
loaded from the chipDISK and then executed.
ZCR (Zero Channel RAID) -Controller
The ZCR controller, together with the onboard controller, offers RAID function-
ality. It is used for the internal hard disk drives as well as for the accessible
drives.
Additional external SCSI interface
If the internal HDD modules are connected via a RAID controller, a channel of
the onboard controller can also be made available via an external SCSI
interface for connecting storage subsystems.

02–TX600–12 October2003 U41057-J16-Z146-1-76
Function General information
Function
Configuration diagram
Hot-plug power supply (redundant)
The highest assembled bank
is the hot-spare bank
(if the feature is enabled)
Processors must be plugged
in order according the picture
3
4
2
2
1
0
6
5
4
3
2
1
Font view
System unit
Memory
Bank 4 (2 modules) Bank 3 (2 modules) Bank 2 (2 modules) Bank 1 (2 modules)
Processor
Xeon MP (4)
Xeon MP (1)
Extension slots
SCSI controller
Disk-Array
Communication/Network
PCI bus
Slot
PCI-X 64 bit / 100 MHz, long (hot-plug)
(slot for Zero-Channel RAID controller)
PCI-X 64 bit / 133 MHz, long (hot-plug)
PCI-X 64 bit / 100 MHz, long (hot-plug)
PCI-X 64 bit / 100 MHz, long (hot-plug)
PCI-X 64 bit / 100 MHz, long (hot-plug)
PCI 64 bit / 33 MHz, long
1. PSU 2. PSU
Operating panel
5.25" x 0.5" DVD-ROM
3.5" x 0.5" floppy disk
Local View module
5.25" x 1.6" SCSI drive
5.25" x 1.6" SCSI drive
Accessible drives
Hard disk drives
hot-plug
3.5"x1" ID 5
3.5"x1" ID 4
3.5"x1" ID 3
3.5"x1" ID 2
3.5"x1" ID 1
3.5"x1" ID 0
3.5"x1" ID 5
3.5"x1" ID 4
3.5"x1" ID 3
3.5"x1" ID 2
3.5"x1" ID 1
3.5"x1" ID 0
Hot-plug
tape
optional
Top view
Xeon MP (3)
Xeon MP (4)
Rear view

U41057-J16-Z146-1-76 October 2003 02–TX600–13
General information Product designations
© Siemens Nixdorf Informationssysteme AG 1995 Pfad: P:\02-systemeinheiten\TX600\TX600-e\TX600-e.k01
Product designations
The sales information contained in this service manual is provided to
help the service technicians and should not be used as sales documen-
tation. Some of the products in the overview may no longer be available
to order.
Product Base units
PRIMERGY TX600 floor-standing model with 1x XEON MP
processor, 1or 2 MB TLC with 400MHz front-side bus
(maximum 4 processors) max. 16 GB main memory)
2-channel Ultra 320 SCSI onboard controller (Adaptec 7902)
2x Gbit Ethernet LAN onboard
Graphics controller ATI Rage XL 8MB onboard
3.5" drive bay with:
– Floppy disk drive 1.44 MB + DVD-ROM drive (IDE)
each 0.5" high
8 hot-plug fans (4 fans are redundant)
2 hot-plug power supplies (2 modules)
PS/2 mouse
ServerView, ServerStart (incl. MS-DOS) on CD
S26361-K901-V300 Floor-standing model 2.0GHz/1 MB TLC
S26361-K901-V301 Floor-standing model 2.5GHz/1 MB TLC
S26361-K901-V302 Floor-standing model 2.8GHz/2 MB TLC
PRIMERGY TX600 rack model with
1x XEON MP processor, 1 or 2 MB TLC with 400MHz front-
side bus (maximum 4 processors), max. 16 GB main memory
2-channel Ultra 320 SCSI onboard controller (Adaptec 7902)
2x Gbit Ethernet LAN onboard
Graphics controller ATI Rage XL 8MB onboard
3.5" drive bay with:
– Floppy disk drive1.44 MB + DVD-ROM drive (IDE)
each 0.5" high
8 hot-plug fans (4 fans are redundant)
2 hot-plug power supplies, 2 modules
(PS/2 mouse
ServerView, ServerStart (incl. MS-DOS) on CD
S26361-K901V400 Rack model 2.0 GHz/1 MB TLC
S26361-K901V401 Rack model 2.5GHz/1 MB TLC
S26361-K901V402 Rack model 2.8GHz/2 MB TLC
i

02–TX600–14 October2003 U41057-J16-Z146-1-76
Product designations General information
Product Rack mounting kits
S26361-F2734-L36 Mounting kit for mounting rack server in:
– 19" racks (DataCenter and PRIMECENTER rack)
– all other server racks conforming to EIA standard EIA-
310-D
Contents:
– 1 pair of telescopic rails
– 1 pair of carrier rails
– 1 bracket PC rack
– 1 cable management PC rack
S26361-F1927-L210 Conversion kit (for later conversion), floor-standing model
into rack model
Product Upgradings/Conversions
T26139-Y3882-E101 External SCSI connection
Product Processors
PRIMERGY TX600 with 4 CPU slots.
For a CPU extension the additional CPU must be of
identical type, cache size and clock rate.
S26361-F2817-E201 XEON 2.0 GHz/400 MHz FSB with 1 MB TLC on chip,
incl. heat sink; maximum 3
S26361-F2817-E251 XEON 2.5 GHz/400 MHz FSB with 1 MB TLC on chip,
incl. heat sink; maximum 3
S26361-F2817-E282 XEON 2.8GHz/400 MHz FSB with 2 MB TLC on chip,
incl. heat sink; maximum 3
i

U41057-J16-Z146-1-76 October 2003 02–TX600–15
General information Product designations
© Siemens Nixdorf Informationssysteme AG 1995 Pfad: P:\02-systemeinheiten\TX600\TX600-e\TX600-e.k01
Product Main memory
– There are 8 slots divided into 4 banks with 2 memory
modules each.
– These take 1 GB, 2GB or 4GB PC 2100 DDR-RAM mod-
ules.
– The maximum main memory capacity is 16 GB!
– Mixing of modules within one bank is not allowed.
– Standard for TX600:
ECC with memory scrubbing and chipkill
S26261-F2762-E524 Main memory 1 GB (2 modules), PC21000 registered
DDR RAM, occupies one bank, maximum 2/system
S26261-F2762-E525 Main memory 2 GB (2 modules), PC21000 registered
DDR RAM, occupies one bank, maximum 2/system
S26261-F2762-E526 Main memory 4 GB (2 modules), PC21000 registered
DDR RAM, occupies one bank, maximum 2/system
Product Accessible drives
– The system unit has 2 x 5.25 inch slots (1.6 inch height)
and slots for mounting the following:
– 1.44 MB floppy disk drive 0.5" and
– DVD-ROM drive 0.5" (IDE)
S26361-F2850-E3 Tape drive SDLT 320, 160GB, 16 MB/s, LVD/U2W,
3.2 x 5.25", maximum 1/system
S26361-F2233-E13 Tape drive DAT DDS4 Autoloader, 6x20 GB, 3 MB/s,
LVD/U2W, 3.2 x 5.25", maximum 1/system
S26361-F2573-E3 Tape drive LTO Ultrium, 100 GB,7.5 MB/s, LVD/U2W,
1.6 x 5.25"maximum 2/system
S26361-F2849-E3 Tape drive VXA 2, 80 GB, 6MB/s, LCD/U2W
1.6 x 5.25", maximum 2/system
S26361-F2233-E3 Tape drive DAT DDS4, 20 GB, 3 MB/s, LVD/U2W
1.6 x 5.25", maximum 1/system
S26361 -F2848-E3 Tape drive DAT DDS5, 36GB, 3MB/s, U2W SCSI
1.6 x 5.25", maximum 1/system
Option: Hot-plug backup drive
An optional hot-plug backup drive can be configured:
– occupies 2 x 1" HDD bays
– requires a RAID controller
S26361-F2233-E6 Tape drive DAT DDS4, hot-plug, 20 GB, 3 MB/s, LVD/U2W
1.6 x 3.5", maximum 1/system

02–TX600–16 October2003 U41057-J16-Z146-1-76
Product designations General information
Product Hard disk drives
– The system unit has 12 slots
– The 80-pin SCA hard disk drives are plugged into a cas-
cadable 2-channel SCSI backplane
– Hot replacement is possible with DAC and RAID setup
S26361-F2764-E136 36 GB, 10000 rpm, U320 SCSI (320 MB/s),
maximum 12/system
S26361-F2764-E173 73 GB, 10000 rpm, U320 SCSI (320 MB/s),
maximum 12/system
S26361-F2764-E114 146 GB, 10000 rpm, U320 SCSI (320 MB/s),
maximum 12/system
S26361-F2764-E518 18 GB, 15000 rpm, U320 SCSI (320 MB/s),
maximum 12/system
S26361-F2764-E536 36 GB, 15000 rpm, U320 SCSI (320 MB/s),
maximum 12/system
S26361-F2764-E573 73 GB, 15000 rpm, U320 SCSI (320 MB/s),
maximum 12/system
Product Miscellaneous
S26361-F2116-E9 RemoteView for remote maintenance with IDE chipDISK,
maximum 1/system
S26361-F2425-E300 RemoteView external power supply

U41057-J16-Z146-1-76 October 2003 02–TX600–17
General information System allocation
© Siemens Nixdorf Informationssysteme AG 1995 Pfad: P:\02-systemeinheiten\TX600\TX600-e\TX600-e.k01
System allocation
The PRIMERGY TX600 server is supported with at least the following software
and firmware versions:
Alarm Service 2.20.07
DDM LINUX SuSE SLES7 2.01.19
DDM and Multipath W2K, W2003 3.00.09
Duplex Write NT4.0 2.01
Easy Mirror for NT and Windows 2000 2.01.05
Easy Mirror Linux Red Hat and SuSE planned
Global Flash Agent NT / W2K 4.01.01
Global Flash Manager 4.01.03
Linux Red Hat ServerView Agent 3.01-06
Linux SuSE ServerView Agent 3.01-06
Multipath LINUX SuSE SLES7/SLES8 2.01.07
Multipath LINUX RedHat Advanced Server 2.1 with
Update to 2.4.9-e.12 2.01.07
Multipath NT4.0 2.01
NetWare ServerView Agent Novell NetWare not yet released
NT / W2K / W2003 ServerView Agent 3.01.05
Open Unix 8 Agent not yet available
RemoteView 3.10.17
ServerStart 5.309
ServerSupport 5.309
ServerView Frontend 3.50.04
ServerView Web extension 2.34.04

02–TX600–18 October2003 U41057-J16-Z146-1-76
Service General information
Operating systems
Service
The model rating plate is located:
– On the floor-standing model on the top cover next to the rear
– On the rack model on the left side of the server.
The system serial number is written on the type label. You will need this in the
event of a hardware error.
Manufacturer Operating system State
Microsoft Windows NT 4.0 Server ok
Windows NT 4.0 Server Enter-
prise Edition ok
Windows NT 4.0 Terminal Server
Edition ok
Windows 2000 Server ok
Windows 2000 Advanced Server ok
Windows 2003 Enterprise Edition ok
Windows 2003 Standard Edition ok
Caldera Open Unix 8 -
Novell Netware 6 planning
SCO UNixWare 7.1.3 ok
Linux SuSE Linux Professional -
SuSE SLES 8 ok
Red Hat Linux Professional -
Red Hat Advanced Server 2.1 planning

U41057-J16-Z146-1-76 October 2003 02–TX600–19
General information Technical data
© Siemens Nixdorf Informationssysteme AG 1995 Pfad: P:\02-systemeinheiten\TX600\TX600-e\TX600-e.k01
Technical data
Electrical data (hot-swap power supply unit)
Standards observed
Type Wide range power supply unit
Rated voltage range 100 - 240 V
Rated frequency 47 - 63 Hz
Rated current in basic configuration 6 - 2.5 A
Maximum rated current 11 - 4.5 A
Active power 1100 W
Apparent power 1100 VA
Heat emission 3960 kJ/h
Building fuse 16 A
Protection class I
Product safety and ergonomics IEC 60950 / EN 60950 / UL 1950,
CSA 22.2 No. 950
Electromagnetic compatibility FCC class A
VCCI class A
AS / NZS 3548 class A
BSMI class A (CNS13438)
Emitted interference EN 55022
Harmonic current EN 61000-3-2 JEIDA
Flicker EN 61000-3-3
RFI suppression EN 55024
CE label
according to EU directives Low-Voltage Directive 73/23/EEC Electromagnetic Compatibility 89/336/EEC

02–TX600–20 October2003 U41057-J16-Z146-1-76
Technical data General information
Dimensions
Weight
Approx. 55 kg (depending on the configuration)
Ventilation clearance
At least 200 mm at the front and at the rear
Maintenance area for the floor-standing model
1.2 m² on the left side. The maintenance area may also be used, but must be
quickly accessible.
Environmental conditions
Condensation during operation must be avoided!
Noise level
Dimensions Floor-standing model Rack model
Width 286 mm (with feet) 444 mm (without front panel)
Depth 743 mm 743mm (without handles)
Height 473 mm (with feet) 177 mm or 5 HU
Environment class 3K2
Environment class 2K2 DIN IEC 721 part 3-3 DIN IEC 721 part 3-2
Temperature:
–Operating(3K2)
– Transport (2K2) 10 °C.... 35 °C -25 °C.... 60 °C
Humidity 10%... 85%
Sound power level LWAd (ISO 9296): ≤6.5 B (standby)
≤6.7 B (operation)
Sound pressure level at bystander position
LpAm (ISO 9296) ≤50 dB(A) (standby)
≤52 dB(A) (operation)
i
