• Your heater is produced to run on natural gas and LPG.
• It your fires your fuel by high efficiency and blue flame.
• Heater can be run very easily thanks to its deluxe gas control system.
• Batary igniter has ignition system and pilot flame.
• Unless the pilot flame fires gas never goes to combustion chamber.
• It has the magnet ventil safety system which cuts the gas passing authomaticlly in case the
flame dies. It provides a copmlete safety.
• It is determined from tests that the heater is influenced from out door atmphere conditions
like wind, storm back fire etc. less than its rivals thanks to its special chimney equipments.
• Chimney equipments set that are given with your heater should asseble to a 300 mm thick
wall.
• Your air tight heater doesn't use the oxygen of your room. It takes the oxygen that is needed
to fire from outside thanks to its spezial design and gives the tail gas to outside again thanks
to its tight body.
• It can be used safely in all living areas such as bedroom, nursery, sitting room and living
room etc.
• It has thermostated safety valve, maximum and minimum combustion setting and it provides
conrolled heat and prevents waste consumption.
• Its sheet of combustion chamber is thicker (1.0) than its rivals and it is provided to be
durable long-lived by covering inside and outside of it with gloss.
• Burner is produced by stainless steel thus it is long-lived and it burns the gas with blue
flame.
• This air thight heater is produced in accordance with european standarts and EN 613
standarts.
• It has the pressure balance, its systems aren't influenced by pressure changes.
We are proud of presenting such a excellent air tight heater that you can use every space of your
home , work place or colosed area thanks to its economic, modern and elegant lines, practical
dimensions and which provides you to profit from natural gas or LPG comforts by safety of Ersel
and which also has lower expenses but higher efficiency in comparision with its rivals.
We present you this assembly and user guide to help you to use your heater without any
problem for long years.
We recommend you to read this guide before assembly and use. Have a good use...
DISTINGUISHED USER
SUPERIOR FEATURES

FHS 4000 E - FHS 5000 E
FHS 9000 E - FHS 12000 E
-3-
ASSEMBLY INSTRUCTION
1. For Natural Gas:
– Before doing the natural gas connection please refer to the local natural distribution company
and have them prepare and approve the natural gas installation project.
– There has to be a system gate between heat and installation according to the present norms for
natural gas.
– The heat is set according to natural gas (METHANE) please don't use any other gas.
– For gas entrance please use metallic pipe or flexible hose which is clamped by clips and
appropirate to CE norms.
NOTE: All heaters are shipped ready for use with natural gas.When the chainged the gas to the
LPG please call the authorised service
2- For LPG:
– It is prefered to be used 300 mmSS regulator. (2 kg) Never use industrial regulator. PVC hose
which is used between gas cylinder and heater shouldn't be longer than 125 cm. Please tighten hose
connection ends with metal clips. Never use the gas cylinder horizantally or reversing.
– Please don't use destroyed gas cylinder change by a new one
– Expenses that are caused by assebmly and installation are belong to user.
– Before installation, ensure that the local distribution conditions (identification of the type of
gas and pressure) and the adjustment of the appliance are compatible.
– Natural gas heater should be assembled by authorized people appropriate to assemby
instructions and instructions of gas distribution company, municipality and CE.
– For natural gas measure the installatin gas pressure before the assembly. TEST PRESSURE
shouldn't be over 50 mbar for the safety of gas valve.
– Natural gas – LPG or LPG - natural gas convertion should be done by authorized sevice or
people. Otherwise the heater is accepted out of guarantee. Don't let natural gas convertion to do
this work, it is ithout responsibility on our part.
– POINTS THAT YOU HAVE TO BE CAREFUL WHEN YOU CHOSE THE PALCE TO
INSTALL YOUR HEATER.
– Your heater should be taken avoid over-heating of the floor, shelf, walls, or else a statement
to use non-combustible materials for the floor, shelf or wall close to the appliance.
– Don't install the your heater near the dampy or flowly area.
– This appliances shall be installed in accordance with current regulations and only used in a
well-ventilated space.Refer to the instructions before installing and using the appliance.
– Use only Fujiyama specified vents and vent caps when installing your Heater insert All vent
pipe sections must be tight and leak proof.
GAS CONNECTION

FHS 4000 E - FHS 5000 E
FHS 9000 E - FHS 12000 E
-4-
A- Minimum spaces for outside chimney (display by pictures);
– Space to balcony and garage is minimum 600 mm.
– Space to sliding window is 300 mm.
– Space to zinc, plastic, earthen channels, pipes is 600 mm.
– Horizontal Space to chimney outlet is 600 mm vertical space to chimney outlet is 1500 mm.
B- Minimum distances for Indoor;
– Space to the left wall distances 400 mm.
– Space to the right wall distances 200 mm.
– Hight of the heater from floor is min. 40 mm.
– Curtain shouldn't be close the heater from front side, Hight between heater and curtain
should be min 300 mm.
– If the heater will be installed under the shelf which don't pas 150 mm deept, distances
between shelf and heater should be 300 mm.

FHS 4000 E - FHS 5000 E
FHS 9000 E - FHS 12000 E
-5-
A A
MM
GA
EF
G
MB,C B,C
F
F
GG
K
L
K
L

FHS 4000 E - FHS 5000 E
FHS 9000 E - FHS 12000 E
-6-
K
F
D,N
J
H,I
G
POSITION MINIMUM SPACING
ADirectly below an openable window, air vent or any other
ventilation opening 300 mm 12 in.
B Below gutter, drain/ soil pipe 75 mm 3 in.
C Below eaves 200 mm 8 in.
D Below a balcony 200 mm 8 in.
E From vertical drain pipes an soil pipes 75 mm 3 in.
F From intrenal or external corners 300 mm 12 in.
G Above adjacent ground or balcony level 300 mm 12in
H From a surface facing the terminal 600 mm 24 in.
I Facing terminals 1200 mm 48 in.
J From opening (door, window) in carport into dwelling 1200 mm 48 in.
K Vertically from a terminal on the same wall 1500 mm 60 in.
L Horizontally from a terminal on the same wall 300 mm 12 in.
M Adjacent to opening 300 mm 12 in.
N Below carport 600 mm 24 in.

FHS 4000 E - FHS 5000 E
FHS 9000 E - FHS 12000 E
-7-
ASSEMBLY OF THE HEATER
→ Bring out the heater from package carefully.
→ Unsrcew the 2 transport screws that are on the top of the galvanized back sheet in figure 1.
→ Come out the 2 pieced flaps at the bottom of the back sheet taking up the body. (Screws
can't be used after being unscrewed).
Figure-1
Unscrew the transport screws and
lifting body up and pull forward
Back Sheet Transport Screw
Body
– Chimney equipments and connection elements are put
in a different box. Take the chimney equipments from the
box.
– Attach the waste gas discharge tube in chimney
equipment to gas outlet of the holder without taking out
fom the equipment.
– Then screw the chimney equipment assembly holes
(figure 2) in burning air inlet pipe by fiting eachother.
Figure-2
Mounting holes
of smokestack
Hanger Holes

FHS 4000 E - FHS 5000 E
FHS 9000 E - FHS 12000 E
-8-
– Bore a chimney eye to the wall that the heater is assembled appropriate tothe dimensions in
figure 3.
– Put the chimney equipment system assembled into the heater to the hole in the wall.
– Put waste gas safekeeping cage which is ssen in figure 2 as its whole body stays outside
(waste gas safekeeping cage should completely be outside no matter the thickness of the wall.)
Figure-3
Waste gas the protection cage
– Prevent all the tight in the installation.
– Check the tightness in gas test by gas leakage checking device or soap bubble.
– Don't check by flame (match, lighter, etc.)
INSTALLATION CONTROL
C
B
A
I
D
G
F
E
H
min. 100 mm
J
A B C D E F G H I J
FHS 12000 E 1075 655 260 340 560 75 575 980 45 250
FHS 9000 E 800 655 260 310 455 65 555 735 45 200
FHS 5000 E 800 655 215 380 440 65 555 735 45 200
FHS 4000 E 680 655 215 380 400 65 555 610 45 200

FHS 4000 E - FHS 5000 E
FHS 9000 E - FHS 12000 E
-9-
Burning settings of the heater is done according to natural gas in factory so don't change the
settings. Adjusting of your heater not include other gases which is given in user manuel, don't use
your heater other gases. The table below is given only in order to help the requirement made by
authorised services.
SETTING OF THE HEATER
Pressure test point IN
Pressure test point OUT
“ U" MANOMETER
Turn the knob to position.
Screw the adjustment screw clockwise to increase gas flow.
Gas Type G30 G31 G20
PRODUCTS PRESURE 30mbar 37 mbar 20 mbar
FHS 4000
Injectors 1.1 mm 1.1 mm 1.9 mm
Burner input
Pressure 28 mbar 28 mbar 9.5 mbar
FHS 5000
Injectors 1.2 mm 12 mm 2 mm
Burner input
Pressure 29 mbar 29 mbar 10.5 mbar
FHS 9000
Injectors 1.5 mm 1.5 mm 2.3 mm
Burner input
Pressure 19 mbar 24 mbar 15 mbar
FHS 12000
Injectors 1.74 mm 1.74 mm 2.47 mm
Burner input
Pressure 17 mbar 23 mbar 15 mbar
Figure-4
– Bore a chimney eye to the wall that the heater is
assembled appropriate to the dimensions in figure 4.
– Put the chimney equipment system assembled
into the heater to the hole in the wall.
– Put waste gas safekeeping cage which is ssen in figure
2 as its whole body stays outside (waste gas
safekeeping cage should completely be outside no
matter the thickness of the wall.)
Pressure regulator the adjustment screw

FHS 4000 E - FHS 5000 E
FHS 9000 E - FHS 12000 E
-10-
- 10 -
CONVERSION
– For our heater's operation in all gas groups, it is required that an injector with the appropriate
diameter for the corresponding gas group is used. Depending on the gas type the heater will work
with, the injector is selected from the table and it is attached to heater's burner.
– To change the injector, firstly the body of our heater is removed as shown in Figure-1 First the
input pipe, then the injector is removed in order, as seen in the figure. The injector with the
appropriate diameter for the gas used in the country is selected and attached to our heater's burner.
Then, the burner input pipe is attached to the injector. Following the completion of our heater's
assembly, gas line is checked for any leaks using soapy foam or a gas leak detector device.
Injector
Burner Gas
Inlet Pipe
– The burner must light immediately and the flame must travel promptly and smoothly around
curve and light entire burner. The flame must not "lift" off the burner.
– Never chainge the adjustments.
– Call the authorised service if the gas must be chainged.
– Authorised service could be adjusted the burner inlet gas pressure from the back side
of heater gas entries by reached to the screw of valve adjustment with flat edge - screw driver.
– If the adjustment of the screw is Gas pressure will be.
– If the adjustment screw is turned clock wise the pressure wil be. - If the
adjustment screw is turned clockcross wise the pressure wil be.
– Gas pressure must be measured by manomometer or digital pressure meter.
– Put the hose of manomometer to the valve pressure measuring point.

FHS 4000 E - FHS 5000 E
FHS 9000 E - FHS 12000 E
-11-
IMPORTANT SUBJECTS
– Assembly, control and LPG-natural gas conversion of the heater should be done by
authorized service.
– You heater adjustment is given data plate.
– Be sure that you heater should be adjusted to the gas type of you usage.
– Never use your heater which is not made assembly of flues system.
– Don't to use the your heater if the glass front door or panel has been broken, removed or is
open.
– Don't leave your children alone during the heater running , or put the barrier in the 1.5
meter area to prevent touching the children to the hot surfaces.We are declare that our gas heater
working area is 1.5 mm2 area.
– Curtains should not be positioned above the appliance at a distance less than the minimum 600
mm.
– Don't cover any side of the heater with towel, clothes and blanket etc.
- Don't try to lighten the heater with match. Use the lighten button.
– If you feel any smell in the room or if you have a headache stop the heater completely and
ventilate the room.
– To stop the heater completely turn off the gas gate from system or gas cylinder
– Air in the room where our heater operates should be circulated 2 or 3 times a day to increase
the amount of oxygen
FOR YOUR SAFETY
– Do not use this heater in a space where gasoline or other liquids having flammable vapors are
stored or used.
NOTE: Read and understand all operating and safety warnings and instructions
before using. The operator must retain these instructions for future reference
– These instructions are only valid if the following country code is on the appliance. If this code
is not present on the appliance, it is necessary to refer to the technical instructions which will
provide the necessary information concerning the modification of the appliance to the conditions
of use for the country.
OPERATING INSTRUCTIONS

FHS 4000 E - FHS 5000 E
FHS 9000 E - FHS 12000 E
-12-
OPERATING THE HEATER
Thermostat Button
Ignition Button
For Electronic Ignition (Battery) Model
Battery change for electronic ignition (battery) model: Open the cover with the lighter button
by turning it counterclockwise. Remove the old battery and replace it with the new one. 1.5 V -
AA-use alkaline batteries.
WARNING: PLEASE FREQUENTLY CHECK IN CASE THE BATTERY
LEAKS.
Press the
corners to open
the lid.
: Closed
: Ignition
: Min. to heat
: Thermostate perceiving point
: Max. to heat
Knowledge on thermostate button :
Position of button in thermostate 1 2 3 4 5 6 7 Room
temperature ºC (approximately) 13 17 21 25 30 33 38
Fan Button
(Only FHS 12000-FHS 9000)

FHS 4000 E - FHS 5000 E
FHS 9000 E - FHS 12000 E
-13-
LIGHTENING THE PILOT
– Turn on the gas gate from system or gas cylinder.
– Take the thermostat tuning button to firing and pilot position.
– Push the button down and at the same time push the pointed lighter button ( )a few times.
– Keep op this opeartion untill the pinpoint catchs fire.
– You can see the flame of pilot from the front window of heater.
– After the pinpoint lights hold down the thermostat tuning button for 10-15 seconds, the
pilot should go on lighting when you stop holding down the button if it dies down, do the same
operation again.
Note: It catchs the fire late especially in first lightings because of the air inside.
- After the pinpoint catchs the fire light the burner by turning the thermostat tuningbutton to
clockwise.
– You can make the heater burn in the level you wish by turning the thermostat tuning button
to heat level you wish (1-2-3-4-5-6-7) When ambient temparature reachs the level you tune
burner will stop authomatically When ambient temparature falls under the level you tune
burner will start to burn again authomatically. If the heater stop for any reason turn the
thermostat button to “0” position.
Ps: After you light the heater and turn off the thermostat button it including pinpoint
when you wish to start it, do this after waiting 2-3 minutes. If you wish to light it before it
can't burn because the safety system is on. This not a defect it is a feature of system.
– If you don't use the heater for a short time turn the thermostat tuning button to ( ) position
thus burner will die down but pinpoint will keep on burning.
– To burn the burner again it is enough to turn the thermostat button to the position you wish
(such as 3-4-5).
– When you wish to stop the heater take the thermostat button to “0” position by turning it to
counterclockwise. The burner and pinpoint will stop.
– If any flame supervision device actuating flame is extinguished either intentionally or
unintentionally, no attempt should be made to relight the gas until at least 3 min have elapsed.
OPERATION OF FAN (FOR MODELS WITH FAN)
– For operating of the fan take the fan switch ''ON' position. When you don't want to run the
fan , you can close the fan with fan switch.
Note: This is recommended for us.
– But Fan motor energy is 24 watt/h just like dark lamp and It is your advantage by
running the fan. Your heater provides homogens heating of the room.

FHS 4000 E - FHS 5000 E
FHS 9000 E - FHS 12000 E
-14-
- 14 -
MAINTANENCE:
– All maintanence should be done when the heater is extinguished and cold.
– Clean the heater with a soft dry or humid cloth when it is cold.
– Don't use detergent, abrasive cleanser or sprey while cleaning the heater.
– Dust in inside chamber should be cleaned, full maintanence and cleaning of the heater
should be done by authorised service bi yearly (one in two years).
– Burning of the dust can cause a bad smell.
- If the window breaks, make it change
Weekly Maintenance:
– Check the visually your heater flue system ıf there is any quantity of material contained
therein, position of flue, assambly and corrosion of the flue material.
– Make the cleaning tpo your heater with dry cloth.
Yearly Maintanence:
– It is recommended to control following points firstly in every warming season:
• Cleaning of burner and pinpoint
• Cleaning of gas ways, chimney and pipe
• General cleaning of the heater
– All repairs and yearly maintanence should be done by licensed people or services.
CLEANING AND MAINTENANCE

FHS 4000 E - FHS 5000 E
FHS 9000 E - FHS 12000 E
-15-
TECHNICAL FEATURES
INFORMATION ABOUT THE PRODUCTS
Model FHS 4000 FHS 5000 FHS 9000 FHS 12000
No Xlimit
Type C11 C11 C11 C11
Catagory II2H3B/P-II2H3P II2H3B/P-II2H3P II2H3B/P-II2H3P II2H3B/P-II2H3P
Gas
Consumption Injectors Setting
Pressure Consumption Injectors Setting Pressure Consumption Injectors Setting Pressure Consumption Injectors Setting Pressure
G30(30) LPG ….. Kg/h 1,1 mm 29 mbar ….. Kg/h 1,2 mm 28 mbar 0,6 Kg/h 1,50 mm 19 mbar 0,70 Kg/h 1,74 mm 17 mbar
G30(37) LPG ….. Kg/h 1,1 mm 29 mbar ….. Kg/h 1,2 mm 28 mbar 0,552 Kg/h 1,50 mm 24 mbar 0,70 Kg/h 1,74 mm 23 mbar
G20(20) NG 0.46 m³/h 1,90 mm 9,5 mbar 0.53 m³/h 2,0 mm 10,5 mbar 0,73 m³/h 2,30 mm 15 mbar 1,05 m³/h 2,8 mm 15 mbar
Heat input Q 4 kW 5 kW 7,5 kW 10,5 kW
Diameter of non burning gas 85 mm 110 mm 110 mm 120 mm
Air input pipe dimentions 205 mm 205 mm 205 mm 250 mm
Weigth 16.50 kg 20 kg 24,9 kg 32,7 kg
Heigth 710 mm 710 mm 710 mm 710 mm
Length 755 mm 885 mm 885 mm 1140 mm
Width 295 mm 295 mm 335 mm 335 mm
Voltage (V ac) - - 220 V 220 V
Power (W) - - 24 w 24 w
Frequency (Hz) - - 50 Hz 50 Hz
Minimum wall tickness 200 mm 200 mm 200 mm 200 mm
Maximum wall tickness 300 mm 300 mm 300 mm 300 mm
Approvals EN 613 :2001
Metal Parts
Metal body : 0.8 mm grey powder painted sheet metal
Back cover metal : 1 mm galvanize plated sheet metal
Housing of heater : 0.8 mm black enamel plated sheet metal
Valve assambly metal : 0.7 mm galvanize plated sheet metal Pilot
and thermic assambly sheet matel 1 mm
Main gas entries pipe is galvenize plated 16 mm pipe
Food metal : 1 mm galvanize plated sheet metal
Burner : 0.4 mm steel
Outher Flue : 0.5 mm galvanize plated sheet metal, dia. 205 mm,length 600 mm
Inner Flue : 0.6 mm galvanize plated sheet metal, dia. 117 mm, length 555 mm
Injektors : material is brass CuZnSn
Naturel gas inlet : Brass material CuZnSn
LPG gas inlet : Aluminyum material
Seramic/Glass
parts Glass : Ceramic glass 4 mm
Plastic Parts Thermostat knob: PP black color
Power cord straigth plastic : PP black color
Pipe Burner aluminium pipe
Pilot aluminium pipe
Component Gas valve : SIT GROUP 630 Eurosit max gas inlet 50 mbar , outlet pressure 0-18
mbar working temperature 0-80 C
Label Name plate marking on the aluminium plate
Thermostat Knob ğ —1234567…
Carton and
straphor
Carton : corrugated cardboardfor costumer
Dimention FHS 5000 : 295x885x710 mm
Dimention FHS 4000 : 295x755x710 mm
Instruction
manuel FUJIYAMA user manuel with English and Turkish

FHS 4000 E - FHS 5000 E
FHS 9000 E - FHS 12000 E
-16-
INTENDED USE OF THE APPLIANCE
Gas valve
Unenviable fuel is prevent by holding
the request room temperature with 7
scale thermostat.
BURNER
Standing of high temperatures and heating
stretch ,stainless steel material. Soundless,
affiance and clear burning with oxygen and gas
mixtures. Long life usage with special design
Pilot Flame-Thermo element Magnet Valve Safety System
When the pilot flame is deflate, it is provided absolute and certain
safety by cutting down gas automaticly

FHS 4000 E - FHS 5000 E
FHS 9000 E - FHS 12000 E
-17-
SAFETY WARNINGS AND POINTS TO BE CAREFUL
BEFORE CALLING THE AUTHORISED SERVICE
1- IF THE PILOT DOESN’T
CATCH FIRE
Regulator of gas cylinder or
natural gas gate can be off
Turn on the regulator or the
gate
Gas can be finished
Change the gas cylinder to a
new one (check the tightness of
gas by soap bubble after the
change if there is gas leakage
solve it and check again)
Natural gas can be cut off Call the gas distribution
company
Gas conrol button can be in off
position
Turn the button to lighter
position, look weather the pilot
catchs the fire or not from pilot
flame watching hole. If it
doesn't catch fire do the same
operation again turning the
button off poisition again
The electronic lighter may be
igniting the pilot.
The electronic igniter's battery
might have run out. Please
check. See page 14 for battery
replacement.
Piezo lighter may not set the
pilot on fire
It may not catch the fire
immediately especially in first
lighting of the heater after
changing gas cylinder because
of the air inside the gas ways.
In that case make it wait at
symbol level until gas comes
from pilot, however if piezo
lighter still doesn't set the pilot
on fire there is a problem in
lighter. Call the service
2- IF THE PILOT DIES
DOWN
Gas control button may not be
stayed in position for enough
time
Make the gas control button
stay on symbol level for 5-10
seconds.
If the pilot dies down with its
burner while the heater is
running
Regulator pressure of LPG can
be high
In the case of LPG usage
pressure of gas cylinder
regulator should be 300 mmSS
(30mbar). If it is different
change it.
Natural gas system pressure can
be high
In the case of natural gas usage
pressure of gas that comes to
the heater should be 200 mmSS
(20mbar).
Waste gas pipe can be blocked
in any reason
Please check the waste gas
pipe.

FHS 4000 E - FHS 5000 E
FHS 9000 E - FHS 12000 E
- 18 -
UYGUNLUK BEYANI
DECLARATION OF CONFORMITY
(Gas Appliances Directive EU 2016/426)
UYGUNLUK DEKLARASYONU
(Gaz Yakan Cihazlar Yönetmeliği EU 2016/426)
Our Company declare that its responsibility that the item of equipment specified below
has been designed, manufactured, inspected and tested as required by the relevant
provisions of the Gas Appliances Directive EU 2016/426.
Aşağıda özellikleri verilen ekipmanın, Gaz Yakan Cihazlar Yönetmeliği EU 2016/426'
ye göre tasarlandığını, imal edildiğini, denetlendiğini ve uygun testlerden geçirildiğini
ve tamamen sorumluluğumuz altında olduğunu beyan ederiz.
PRODUCT DETAILS (ÜRÜN BİLGİLERİ)
Manufacturer (Üretici) : ERSEL ISITMA ENERJİ SİSTEMLERİ VE EKİP. EV VE
BÜRO GER. TİC. SAN. LTD. ŞTİ
Address (Adres) : ORGANİZE SAN. BÖL. 20.CD NO: 66 KAYSERİ/TÜRKİYE
Product (ÜrünCinsi) : CONVECTIONAL STOVES (KONVEKSİYON SOBALARI)
Brand Name (Marka Adı):FUJİYAMA
Type(model) : FHS 12000, FHS 9000, FHS 5000, FHS 4000, FBS 14000,
FHS 11000
Applied Standards (Uygulanan Standartlar) : EU 2016/426.
SIGNED ON BEHALF OF THE MANUFACTURER (İmalatçı adına);
ÖMER FARUK YÜKSELEN
General Manager

Organize Sanayi Bölgesi 20. Cadde No: 66
KAYSERİ / TÜRKİYE
Tel: [phone]
Fax: [phone] Web: http://www.fujiyama.com.tr E-
mail:[email protected]
ÜRETİCİ VE İTHALATÇI FİRMA:
ISITMA ENERJİ SİSTEMLERİ VE EKİPMANLARI EV VE BÜRO GEREÇLERİ SAN. VE TİC. LTD. ŞTİ.
GENEL DAĞITIM:
EVPA
SEVPA SOBA VE EV GEREÇLERİ PAZARLAMA SAN. VE TİC. LTD. ŞTİ.
Eski Üsküdar Yolu Barış sok. No:5/2 İçerenköy
İSTANBUL / TÜRKİYE
Tel: [phone] Fax: [phone]
