Full Boar FBT-5000 User manual

KNOW YOUR PRODUCT
INSTRUCTION MANUAL
WARNING: Read all safety warnings and all instructions. Failure to follow the
warnings and instructions may result in electric shock, fire and/or serious injury.
Save all warnings and instructions for future reference.
1015
• 50L STAINLESS
STEEL TANK
• 1500W MOTOR
• TRANSPORT
TROLLEY
WET
& DRY
VACUUM

2
SPECIFICATIONS - MODEL NO. FBT-5000
KNOW YOUR PRODUCT
1
2
10 4
18
11
12
15
13
16
21
19
3
5
8
6
7
20
Mains Voltage: 230 – 240V ~ 50Hz
Input Power: 1500W
Power Outlet Max.: 900W
Psum: 2400W
Suction Power Max.: 170 mbar
Tank Capacity: 50 l
IP Rating IP24
Weight: 14.5 kg

6
3
KNOW YOUR PRODUCT (cont.)
1. Main Handle
2. Cable Hook
3. Power Cable
4. Automatic Power
Take Off Outlet
5. Head
6. Carry handle
7. ON/OFF/Automatic
Switch
8. Suction Hose
Connection
9. Flexible Suction Hose
10. Tank
11. Water Drain Outlet
12. Castors (1 braked)
13. Wheels
14. Dual Purpose Nozzle
15. Accessory Compartment
16. Holder for Handle
17. 2-Piece Suction Tube
18. Locking Hook
19. Blow Outlet
20. Filter Cage
21. Safety Float Valve
22. Hose Step Down
Adaptor
23. Crevice Nozzle
24. Pleated Filter (Dry)
25. Foam Filter (Wet)
26. Combination Nozzle
attachment for wet
vacuum cleaning
27. Combination Nozzle
attachment for smooth
oors
28. Combination Nozzle
attachment for carpets
29. Air Regulator
30. 2 x Washers for tting
the wheels
31. 2 x R-clip for tting the
wheels
32. 2 x Covers for tting
the wheels
33. Axle for tting the
wheels
34. 2 x Phillips-Hd screws for
tting the head handle
35. Tank Bag (Dry)
1
2
14
28
22
23
24
35
25
30 3431
29
27
26
9
12
32
13
17
33

4
SPECIFICATIONS....................................................... Page 02
KNOW YOUR PRODUCT........................................... Page 02
INTRODUCTION........................................................ Page 05
SAFETY INSTRUCTIONS........................................... Page 05
ASSEMBLY.................................................................. Page 10
SUCTION NOZZLES................................................... Page 13
OPERATION............................................................... Page 14
MAINTENANCE......................................................... Page 16
DESCRIPTION OF SYMBOLS.....................................Page 17
CONTENTS................................................................ Page 18
WARRANTY................................................................ Page 20
TABLE OF CONTENTS

5
INTRODUCTION
WARNING! When using mains-powered equipment, basic safety precautions,
including the following, should always be followed to reduce risk of re, electric
shock, personal injury and material damage.
SAFETY INSTRUCTIONS
ELECTRICAL SAFETY
Read and understand the manual prior to operating this tool.
Save these instructions and other documents supplied with this tool for future reference.
Congratulations on purchasing a Full Boar Wet and
Dry Vac.
The Full Boar Wet and Dry Vac is designed for wet and
dry vacuuming using the appropriate lter. The appliance
is not suitable for the vacuuming of combustible,
explosive or harmful substances.
The electric motor has been designed for 230V and 240V only. Always check that the power
supply corresponds to the voltage on the rating plate.
Note: The supply of 230V and 240V on Full Boar tools are interchangeable for Australia and
New Zealand.
Note: The power outlet used for the vacuum must be protected by a 30mA residual current
device or earth leakage circuit breaker.
The supply cored assessed as type Y attached by using AS/NZS 60335.1.
If the supply cord is damaged, it must be replaced by an electrician or a power tool repairer
in order to avoid a hazard.
Using an Extension Lead
Always use an approved extension lead suitable for the power input of this tool. Before use,
inspect the extension lead for signs of damage, wear and ageing. Replace the extension lead
if damaged or defective. When using an extension lead on a reel, always unwind the lead
completely. Use of an extension lead not suitable for the power input of the tool or which is
damaged or defective may result in a risk of re and electric shock.

6
GENERAL POWER TOOL SAFETY WARNINGS
WARNING! Read all safety warnings and instructions. Failure to follow all
instructions listed below may result in electric shock, re and/or serious injury. The
term “Power Tool” in all of the warnings listed below refers to your mains operated
(corded) power tool or battery operated (cordless) power tool.
SAVE THESE INSTRUCTIONS
1. Work area safety
a. Keep work area clean and well lit. Cluttered or dark areas invite accidents.
b. Do not operate power tools in explosive atmospheres, such as in the presence of
ammable liquids, gases or dust. Power tools create sparks which may ignite the dust
or fumes.
c. Keep children and bystanders away while operating a power tool.
Distractions can cause you to lose control.
2. Electrical safety
a. Power tool plugs must match the outlet. Never modify the plug in any way. Do not
use any adapter plugs with earthed (grounded) power tools. Unmodied plugs and
matching outlets will reduce risk of electric shock.
b. Avoid body contact with earthed or grounded surfaces, such as pipes, radiators,
ranges and refrigerators. There is an increased risk of electric shock if your body is
earthed or grounded.
c. Do not expose power tools to rain or wet conditions. Water entering a power tool
will increase the risk of electric shock.
d. Do not abuse the cord. Never use the cord for carrying, pulling or unplugging the
power tool. Keep cord away from heat, oil, sharp edges or moving parts. Damaged
or entangled cords increase the risk of electric shock.
e. When operating a power tool outdoors, use an extension cord suitable for outdoor
use. Use of a cord suitable for outdoor use reduces the risk of electric shock.
f. If operating a power tool in a damp location is unavoidable, use a residual current
device (RCD) protected supply. Use of an RCD reduces the risk of electric shock.
3. Personal safety
a. Stay alert, watch what you are doing and use common sense when operating a
power tool. Do not use a power tool while you are tired or under the inuence of
drugs, alcohol or medication. A moment of inattention while operating power tools
may result in serious personal injury.
b. Use personal protective equipment. Always wear eye protection. Protective
equipment such as dust mask, non-skid safety shoes, hard hat, or hearing protection
used for appropriate conditions will reduce personal injuries.
c. Prevent unintentional starting. Ensure the switch is in the off-position before
connecting to power source and/or battery pack, picking up or carrying the tool.
Carrying power tools with your nger on the switch or energising power tools that have
the switch on invites accidents.

7
GENERAL POWER TOOL SAFETY WARNINGS (cont.)
d. Remove any adjusting key or wrench before turning the power tool on. A wrench or
a key left attached to a rotating part of the power tool may result in personal injury.
e. Do not overreach. Keep proper footing and balance at all times. This enables better
control of the power tool in unexpected situations.
f. Dress properly. Do not wear loose clothing or jewellery. Keep your hair, clothing
and gloves away from moving parts. Loose clothes, jewellery or long hair can be
caught in moving parts.
g. If devices are provided for the connection of dust extraction and collection
facilities, ensure these are connected and properly used. Use of dust collection can
reduce dust-related hazards.
4. Power tool use and care
a. Do not force the power tool. Use the correct power tool for your application. The
correct power tool will do the job better and safer at the rate for which it was designed.
b. Do not use the power tool if the switch does not turn it on and off. Any power tool
that cannot be controlled with the switch is dangerous and must be repaired.
c. Disconnect the plug from the power source and/or the battery pack from the
power tool before making any adjustments, changing accessories, or storing
power tools. Such preventive safety measures reduce the risk of starting the power tool
accidentally.
d. Store idle power tools out of the reach of children and do not allow persons
unfamiliar with the power tool or these instructions to operate the power tool.
Power tools are dangerous in the hands of untrained users.
e. Maintain power tools. Check for misalignment or binding of moving parts,
breakage of parts and any other condition that may affect the power tool’s
operation. If damaged, have the power tool repaired before use. Many accidents
are caused by poorly maintained power tools.
f. Keep cutting tools sharp and clean. Properly maintained cutting tools with sharp
cutting edges are less likely to bind and are easier to control.
g. Use the power tool, accessories and tool bits etc. in accordance with these
instructions, taking into account the working conditions and the work to be
performed. Use of the power tool for operations different from those intended could
result in a hazardous situation.
5. Service
a. Have your power tool serviced by a qualied repair person using only identical
replacement parts. This will ensure that the safety of the power tool is maintained.
b. If the supply cord is damaged, it must be replaced by an electrician or a power tool
repairer in order to avoid a hazard.

8
• Do not leave appliance unattended when plugged in. Unplug from outlet when not in
use and before servicing and cleaning.
• To avoid electric shock, do not expose to rain. Store indoors.
• Never use in the presence of explosive liquids, vapours or explosive dust
– such as coal or grain.
• Never pick up asbestos or asbestos dust.
• Wood dust and chips in a conned area can give rise to re or an explosion. Guard
against possible ignition sources.
• Do not pick up anything that is burning or smouldering – such as metal grinding dust,
cigarette ends, hot coals, matches or similar.
• The appliance is not intended for use by young children or inrm persons without
supervision. Young children should be supervised to ensure they do not play with the
appliance.
• Use only manufacturer’s recommended attachments and consumables.
• Never modify the cleaner in any way - this is dangerous and will invalidate the warranty.
• Do not use cleaner without the lter in place.
• If motor sound becomes higher pitched always check for the following:
- Blocked hose or accessory. - Blocked lter - Full container.
• Never try to move the cleaner by pulling with the mains lead.
• Always check that the lter is clear and not blocked. Keep all openings clear of any
blockages.
•When lifting the unit, always lift it with the handle or under rim of bucket.
Beware of excess weight.
• Always switch the unit off before changing attachments or connecting different
power tools.
• Always disconnect equipment from the appliance when it is not in use.
• If the cordset is damaged have it repaired by an authorised service centre.
WET & DRY VACUUM SAFETY WARNINGS
IMPORTANT! When using the equipment, a few safety precautions must be
observed to avoid injuries and damage. Please read the complete operating manual
with due care. Keep this manual in a safe place so that the information is available at
all times. If you give the equipment to any other person, give them these operating
instructions as well.
The manufacturer cannot accept any liability for damage or accidents which arise
due to a failure to follow these instructions and the safety information.
WARNING! DO NOT connect power tools to outlet when using the vacuum for wet
pick up.

9
WET & DRY VACUUM SAFETY WARNINGS (cont.)
• This appliance is not intended for use by persons (including children) with reduced
physical, sensory or mental capabilities, or lack of experience and knowledge,
unless they have been given supervision or instruction concerning use of the appliance
by a person responsible for their safety.
• Children should be supervised to ensure that they do not play with the appliance.
• The wet and dry vacuum cleaner is designed for wet and dry vacuuming using the
appropriate lter. The appliance is not suitable for the vacuuming of combustible,
explosive or harmful substances.
• The equipment is to be used only for its prescribed purpose. Any other use is
deemed to be a case of misuse. The user / operator and not the manufacturer will be
liable for any damage or injuries of any kind caused as a result of this.

10
KNOW YOUR PRODUCT
Fitting the wheels (13):
1. Place a R-clip (31) for tting the wheels through the appropriate hole in the axle (33)
(Fig. 1).
2. Fit a washer (30) and a wheel (13) to the axle (33) (Fig. 2).
3. Now slide the axle (33) through the guides provided for it on the underside of the Tank
(10) (Fig. 3).
4. Fit the second wheel (13) to the empty end of the axle (33)
and secure it with the other washer (30) and the R-clip (31).
5. Push the covers (32) on to the outside of the wheels (13)
so that the hooks on the covers (32) clip into the slots in
the wheel (13). (Fig. 4).
Fitting the castors (12):
1. Fit the castors (12) into the appropriate mountings on
the underside of the tank (10). Push the castors (12) rmly
into the mounting until they engage with a clicking noise
(Fig. 5).
Fitting the main handle (1):
1. Place the main handle (1) into the handle holders (16).
Push downwards until the retractable locators on the main
handle (1) click into the holes in the handle holders (16)
(Fig. 6).
ASSEMBLY
Fig. 1 Fig. 2
Fig. 3
WARNING! During assembly ensure the wet and dry vac is switched OFF and
disconnected from the power supply.
Fig. 4
Fig. 5
Fig. 6

11
KNOW YOUR PRODUCT
Fitting the appliance head (5):
1. The appliance head (5) is fastened to the container (10) by the locking hooks (18) (Fig. 7).
2. To remove the appliance head (5), open the locking hooks (18) and lift the appliance
head (5) (Fig. 8).
3. When tting the appliance head (5), make sure that the locking hooks (18) lock
into place correctly (Fig 9).
Fitting the head handle (6):
1. Place the head handle (6) on top of the appliance head (5),
so that it sits securely in the moulded indents. Fix the head
handle in place ( fits one direction only) with the supplied
Phillips head screws (34) (Fig.10).
Fitting the lter
Fitting the foam filter (25) - vacuuming liquid:
1. For wet vacuuming, slip the supplied foam filter (25) over
the filter cage (20) (Fig.11).
Note. The pleated lter (24), already tted upon delivery is
not suitable for wet vacuuming.
Fitting the pleated filter (24) - vacuuming dry matter:
1. For dry vacuum cleaning always use the pleated filter. If it
is not fitted, slip it over the filter cage (20), turn the pleated
filter’s base in a clockwise direction to tighten (Fig. 12). The
pleated filter (24) is suitable for dry-vacuuming only.
Note: Do not use the foam lter (25) when vacuuming dry
mater.
ASSEMBLY (cont.)
Fig. 8 Fig. 9
Fig.11
Fig.10
IMPORTANT! Never use the wet and dry vacuum cleaner without a lter. Check
that the lter is securely tted at all times.
Fig.12
Fig. 7

12
ASSEMBLY (cont.)
Fitting the Tank bag (35) - vacuuming dry matter:
Place the Tank bag (35) inside the Tank, with the elastic
mouth of the bag stretched around the outside of the Tank’s
rim (Fig. 13).
Fitting the suction hose (9):
Connect the suction hose (9) to the corresponding connector
on the wet and dry vacuum cleaner, depending on the
application required.
Vacuuming
Connect the suction hose (9)
to the suction hose connector
(8) (Fig. 14).
Blowing
Connect the suction hose (9)
to the blow connector (19)
(Fig. 15).
To extend the suction hose (9) you can attach one or more of
the elements which make up the 2-part suction tube (17) to
the suction hose (9) (Fig. 16).
Air regulator (29):
The air regulator (29) can be tted between the suction hose
(9) and the suction tube (17)(Fig. 17). The suction power of
the nozzle can be adjusted by twisting the band on the air
regulator (29).
Fig. 14 Fig. 15
Fig. 16
Fig. 17
Fig.13

13
Dual-purpose nozzle (14):
The dual-purpose nozzle (14) is for vacuuming solids and
liquids over medium to large areas (Fig. 18).
Various attachments can be tted to the dual-purpose nozzle
depending on what sort of work you wish to carry out:
Wet vacuuming
Use the attachment for wet vacuuming (Fig. 19).
Vacuuming smooth ooring
Use the attachment for smooth oors (Fig. 20).
Vacuuming carpets
Use the attachment for carpets (Fig. 21).
Fit the appropriate attachment into the dual-purpose
nozzle (14) from underneath and secure it using the side lugs
(Fig. 22).
Ensure that the attachments are perfectly secure.
Crevice nozzle (23):
The crevice nozzle (23) is designed for vacuuming solids and
liquids in corners, edges and other areas that are difcult to
access (Fig. 23).
Fig. 18
Fig. 19
Fig. 20
Fig. 21
Fig. 22
Fig. 23
SUCTION NOZZLES

14
This vacuum must be used with a residual current device
with a rated residual current of 30mA or less.
ON/OFF switch (7) (Fig. 24)
Switch position 0: Off
Switch position I: Normal operation
Switch position II: Automatic mode
Dry vacuuming
Use the pleated lter (24) for dry vacuuming (see Fitting the
pleated filter).
The Tank bag (35) can also be tted for removal of particularly
heavy dirt (see Fitting the Tank bag).
Always ensure that the lters are perfectly secure.
Wet vacuuming
For wet-vacuuming, use the foam lter (25) (see Fitting the
foam filter).
Check that the lter is securely tted at all times.
Water drain outlet
To make the Tank (10) easier to empty after wet vacuuming, it
is tted with a water drain outlet (11).
Open the water drain outlet (11) by turning it anti-clockwise
(Fig. 28) and drain the liquid.
OPERATION
Fig. 24
Fig. 25
Fig. 26
Fig. 27
Fig. 28
IMPORTANT! When wet vacuuming, the oating safety switch (21) turns off the wet
and dry vacuum cleaner automatically when the maximum level is reached.
IMPORTANT! The wet and dry vacuum cleaner is not suitable for the vacuuming of
combustible liquids. For wet vacuuming, use only the supplied foam lter.

15
Automatic mode (900W max.):
Connect the power cable on your electric
tool to the automatic power take off outlet
(4) and connect the suction hose (9) to the
extractor connector on your electric tool.
Check that the connections are secure and
airtight.
You can use the supplied hose step
down adaptor (22) to connect the suction
hose (9) to the electric tool. To do so,
t it between the suction hose and the
extractor port on the electric tool.
Set the switch (7) on the wet and dry vacuum cleaner to
position II, automatic mode. The moment you switch on the
electric tool, the wet and dry vacuum cleaner switches on as
well. When you switch off the electric tool, the wet and dry
vacuum cleaner switches off as well after a preset delay.
Blowing
Connect the suction hose (9) to the blow connector (19) on
the wet and dry vacuum cleaner.
OPERATION (cont.)
Fig. 29
Fig. 30
Fig. 31

16
Cleaning
Keep all safety devices, air vents and the motor housing free of dirt and dust as far as possible.
We recommend that you clean the appliance immediately after you use it.
Cleaning the appliance head (5)
Clean the appliance regularly with a damp cloth and some soft soap. Do not use cleaning
agents or solvents; these may be aggressive to the plastic parts in the appliance.
Cleaning the Tank (10)
The container can be cleaned with a damp cloth and some soft soap or under running water,
depending on the amount of dirt.
Cleaning the lters
Cleaning the pleated lter (24)
Clean the pleated lter (24) regularly by carefully patting it and cleaning it with a ne brush
or hand brush.
Cleaning the foam lter (25)
Clean the foam lter (25) with a little soft soap under running water and allow it to air-dry.
Maintenance
At regular intervals and before each use, check that the lters in the wet and dry vacuum
cleaner are securely tted.
MAINTENANCE
IMPORTANT! Before cleaning your wet & dry vac or carrying out any maintenance
procedure, make sure that the motor is off and the vac disconnected from the
power supply to prevent accidental starting.

17
KNOW YOUR PRODUCTDESCRIPTION OF SYMBOLS
Power tools that are no longer usable should not be
disposed of with household waste but in an environmentally
friendly way. Please recycle where facilities exist. Check with
your local council authority for recycling advice.
Recycling packaging reduces the need for landll and raw
materials. Reuse of recycled material decreases pollution in the
environment. Please recycle packaging where facilities exist.
Check with your local council authority for recycling advice.
Read instruction manual
Ingress protection from water
Litres
l
lPX4 mbar Pressure rating (millibar)
CARING FOR THE ENVIRONMENT

18
CONTENTS
1 x Wet & Dry Vac
1 x Main handle
1 x Head handle
2 x Wheels
2 x Castors (1 braked)
2 x Wheel covers
2 x Securing split pins for wheels
2 x Washers for tting the wheels
1 x Axle
2 x Screws for tting the head handle
2 x Suction tube
1 x Hose step down adaptor
1 x Crevice nozzle
1 x Air regulator
1 x Dual purpose nozzle
3 x Combination nozzle attachment
1 x Pleated lter
1 x Tank bag
1 x Foam lter
1 x Suction hose
1 x Instruction manual
Distributed by:
Ozito Industries Pty Ltd
AUSTRALIA (Head Ofce)
1-23 Letcon Drive, Bangholme Victoria, Australia, 3175
Telephone: [phone]

19

20
WARRANTY EXCLUSIONS
The following actions will result in the warranty being void.
If the tool has been operated on a supply voltage other than that specified on the tool.•
If the tool shows signs of damage or defects caused by or resulting from abuse, accidents•
or alterations.
Failure to perform maintenance as set out within the instruction manual.•
If the tool is disassembled or tampered with in any way.
The warranty excludes damage resulting from product misuse or product neglect.
•
•
This warranty is given by Ozito Industries Pty Ltd.
ABN: 17 050 731 756
Ph.1800 069 486
Australia/New Zealand (Head Office)
1-23 Letcon Drive, Bangholme, Victoria, Australia 3175
FB1
WARRANTY
TO ENSURE A SPEEDY RESPONSE PLEASE HAVE THE MODEL NUMBER AND DATE OF
PURCHASE AVAILABLE. A CUSTOMER SERVICE REPRESENTATIVE WILL TAKE YOUR CALL
AND ANSWER ANY QUESTIONS YOU MAY HAVE RELATING TO THE WARRANTY POLICY
OR PROCEDURE.
The benefits provided under this warranty are in addition to other rights and remedies which
are available to you under law. The warranty covers manufacturer defects in materials,
workmanship and finish under normal use.
1 YEAR WARRANTY
Your product is guaranteed for a period of 12 months from the original date of purchase.
If a product is defective it will be repaired in accordance with the terms of this warranty.
Warranty excludes consumable parts, for example: wheels, bearings.
Our goods come with guarantees that cannot be excluded under Australian Consumer law &
Consumer Guarantees Act 1993 (NZ). You are entitled to a replacement or refund for a major
failure and to compensation for other reasonably foreseeable loss or damage. You are also
entitled to have the goods repaired and replaced if the goods fail to be of acceptable quality
and the failure does not amount to a major failure.
`Australia 1800 069 486
New Zealand 0508 069 486
YOUR WARRANTY FORM SHOULD BE RETAINED BY YOU AT ALL TIMES. IN ORDER TO MAKE A
CLAIM UNDER THIS WARRANTY YOU MUST RETURN THE PRODUCT TO YOUR NEAREST
BUNNINGS WAREHOUSE (see www.bunnings.com.au or www.bunnings.co.nz for store locations)
WITH YOUR BUNNINGS REGISTER RECEIPT. PRIOR TO RETURNING YOUR PRODUCT FOR
WARRANTY PLEASE TELEPHONE OUR CUSTOMER SERVICE HELPLINE:
