Full Spectrum Laser FSL100 User manual
1
1. ProductOverview
This high quality fume extractor is designed for capturing dust particles
and removing odors when cutting or engraving with the Full Spectrum
Laser line of laser cutters. Use only OEM replacement filters from Full
Spectrum Laser in this machine to maintain top performance and
warranty.
2. UnpackingInspection
Please check carefully to ensure that the following listed parts are
included. If there are any missing or damaged items, please contact
customerservice.
NameofParts
Qty
Remarks
MainUnit
1
PowerCord
1
4”Hose
1
TopCotton
PreFilter
5
Oneinstalled,4spares
included.
HEPAMiddleFilter
1
Installedinmainunit
ActivatedCarbon
LowerFilter
1
Installedinmainunit
FullSpectrumLaserFSL100UserManual,2016,Rev.A
2
3. UnitComponents
4. Specifications
ModelFSL100Specifications
AirInletSize
4”duct
InputVoltage
AC110V
MaximumPower
200W
Noise
＜
60dB
TypicalFlowRate
210CFM
Dimensions
17”x10”x16”
Weight
31lbs
FullSpectrumLaserFSL100UserManual,2016,Rev.A
3
5. Installation&UseInstructions
5.1 FilteringCoreInstallation
Open the top cover and correctly install the Activated Carbon
filter, HEPA filter and Cotton prefilter in that order. Press the
twobucklestolockdownthelid.
5.2 SuctionDuctHoseInstallation
Remove the hose from the package, and attach one end of the
4” duct flange on the top cover of the machine and the other
endtoyourFullSpectrumLasermachine’soutletduct.
Donotintroduceabendradiusofmorethan10”onthehose.
5.3 MachineOperatingInstructions
Pluginandcheckifthepowerplugisproperlyfitintothesocket.
Turnonthepowerswitch.
FullSpectrumLaserFSL100UserManual,2016,Rev.A
4
5.4 ControlPanelButtonFunctions
On/OffButton
Pressing the On/Off button on the control panel should cause the
machine to start running and the orange light on the machine control
panel should turn ON. Pressing the power button again should cause
the machine to stop running and the orange indicator light on the
machinecontrolpanelshouldturnOFF.
Flow+Button
Press this button when the machine is running to increase the fan
speed, the number on digital display increases in multiples of 10, the
maximum number is 100 which means the machine is running in full
speed.
FlowButton
Press this button when the machine is running, the number on digital
displaydecreasesinmultiplesof10.
ProperFanSpeed
Thefanspeedshouldbesetaccordingtotheactualrequirementsto
removeallsmokewithoutcreatingtoomuchofavacuum.Duringlaser
cutting,thelasermachineshouldnotfillupwithsmoke.Ifthereis
lingeringsmokeduringcuttingincreasethefanspeed.Toohigha
settingmaycausetheworkpiecetoliftupandbepulledtowardthe
vacuumcreated.Inaddition,toohighafanspeed
increasesthepowerconsumptionaswellasthenoiselevel.
TimeSetButton
FullSpectrumLaserFSL100UserManual,2016,Rev.A
5
While the machine is running, press the Timer Set button, the digital
display will show HXXX. Then press the Flow+/Flow buttons to adjust
the shutdown timing. XXX represents the timer countdown in hours
with a maximum of 300 hours and minimum of 1 hour. After you are
satisfied with the setting, press the Timer Set button again and the
digital display will show HXXX and start the countdown timer. For
example, H005 represents that the machine will shut down
automatically in 5 hours. This function is useful at the end of the day
when you turn the laser off but still want to keep cleaning any smell
residuesthatmayremaininsidethemachine.
Ok/SettingButton
If the machine is in alarm status and buzzer sounds, press the
Ok/Setting button to turn OFF the alarm. If the machine is not in alarm
status, press the Confirm/Set button to check the total working hours of
themachine.
FullSpectrumLaserFSL100UserManual,2016,Rev.A
6
6. Troubleshooting
Makesurethepowerisswitchedoffandunpluggedbefore
inspectingorrepairingthemachine!
Problem1: Themachinestillworks,buttheairflowisveryweak
andsuctionpowerisgreatlyreduced.
Cause: AirInletisblockedorforeignbodyexistsinsidetheduct.
The filter becomes saturated and hence gets blocked
and gives an alarm. Usually only the prefilter gets
clogged quickly with large particles and needs to be
vacuumedorreplaced.
Solution: Turnoffthepowerandopenthetopcover.Checkif
there is any foreign objects blocking the air inlet. Then
check if the air vent is blocked or not. If the suction
power of the emptyloaded machine is normal, it means
thefilterneedstobereplaced.
Problem2: Themachineshutsdownautomaticallyafteritisjust
started. Even if you restart the machine, the same
problemhappensagain.
Cause: Theairflowthroughthemachineisobstructed.Asa
result, the starting current of the fan becomes very high,
hence the machine shuts down automatically for self
protection.
Solution: Turnoffthepowerandopenthetopcover.Checkif
thereisanyobstructionsintheairinletorreplacefilters.
Problem3: PowerswitchisON,butmachinedoesnotrunandthe
powerindicatordoesnotlightup.
Cause: Thefusemightbebad.
Solution: The fuse needs to be replaced. Pop the fuse out from
the power socket using a flat head screwdriver and
replace.
FullSpectrumLaserFSL100UserManual,2016,Rev.A
7
If the problem remains after these inspections and maintenance
areperformed,pleasecontactcustomerservice.
FullSpectrumLaserFSL100UserManual,2016,Rev.A
8
7. FilterUse&Maintenance
This product uses disposable filtering elements. When these elements
have been used to a certain extent, they need to be cleaned or
replacedinordertoguaranteethegoodpurifyingeffectofthemachine.
1. CottonPrefilter
AirFlowDirection
Place the Prefilter on top of Middle HEPA Filter. The front side (rough
side) is facing upwards (air inlet direction). When the accumulated dust
on the Prefilter is over 70% coverage and cannot be cleaned anymore,
itmustbereplacedwithanewone.
2. MiddleHEPAFilter
AirFlowDirection
With the handle side facing up, put the Middle HEPA Filter on top of the
the Lower Activated Carbon Filter. It should be immediately cleaned off
by vacuuming when any accumulated dust affects the suction power.
When cleaning does not help replace the Middle HEPA Filter with a
newone.
FullSpectrumLaserFSL100UserManual,2016,Rev.A
9
3. LowerActivatedCarbonMainFilter
AirFlowDirection
With the handle side facing up, place the Lower Activated Carbon Filter
at the bottom inside the machine. This filter is responsible for removing
smells. If there is good airflow but the odors are not removed, the
ActivatedCarbonFilterisconsumedandmustbereplaced.
FullSpectrumLaserFSL100UserManual,2016,Rev.A
10
8. ReplacementParts
Name
Remarks
Pictures
TopCottonPrefilter
Mainlyfilteringlarge
particles.Replaceor
cleanweekly.
MiddleHEPAFilter
Usedforfilteringsmall
particles.
ActivatedCarbon
LowerFilter
Removesodors.
9. ImportantUseConsiderations
Whileusingthemachine,theambienttemperaturerangeofthe
gas and the dust which is sucked into the air inlet should be
within the range 1560ºC. Never use the machine when the
temperatureishigherorlowerthanthistemperaturerange.
Whenusingthemachine，thehumidityofthegasandthedust
sucked into the air inlet should be between the range of
40%80%. If the humidity is excessively high, the activated
carbon filter element will become rapidly saturated with water
andconsumed.
Donotusethismachinewithoutallfilterelements
because the fumes or the dust particles may be sucked into the
air blower and the control system causing damage. Any
operation without all filter elements installed is not covered
under warranty. Use only OEM replacement filter elements
fromFullSpectrumLaser.
FullSpectrumLaserFSL100UserManual,2016,Rev.A
11
Do not continue to use the machine when the HEPA filter
element or the Cotton prefilter is clogged as this will increase
motor wear and shorten the service life of the machine. Please
clean and/or replace the filter elements regularly to ensure
propermachineoperation.
The warranty will not cover any losses or damage that may be
incurredbytheuserifinstructionsarenotfollowed.
10. ContactInformation
FullSpectrumLaserLLC
6216SSandhillRd,LasVegas,NV89120
Tel:(702)8023100
Fax:(702)9870150
http://fslaser.com/Support
FullSpectrumLaserFSL100UserManual,2016,Rev.A
