Full Support PortaCount 8040 User manual

PortaCount® Pre Fit Test Checklist
For more information call 01933 672180 email: [email protected]
www.fullsupportgroup.com
© Copyright 2019 FSI-0141-B
•Set up PortaCount®machine and run daily check,
making sure ambient particle count is over 3000 pcm3
for testing half-face respirators and is over 10000 pcm3
for full-face respirators.
•Ask if the individual has smoked or vaped in the last
60 minutes or eaten in the last 15 minutes.
•Ask if they are medically t to take the test – it will
involve gentle continuous exercise for around 8 minutes.
•Check that the individual is clean shaven and ensure
they are aware that they must always be clean shaven
when wearing RPE at work.
•Ask if other PPE is worn during work (glasses, hearing
aids, visors etc). Any required PPE must be worn during
the Fit Test.
•Explain why you are conducting a Fit Test.
•Briey explain the test exercises and reiterate that the
subject will be stepping/cycling/pacing throughout the
test in addition to these.
•Probe the respirator and attach tubing.
•Ensure a P3 or P3 combination lter is attached of a
similar size/weight/shape to what will be worn in the
work environment.
•Instruct the subject how to don and do the mask.
•Visually check that their mask is tted correctly, checking
that no hair is trapped in the face seal.
•Fill out details for the individual and the make/model of
the respirator they are Fit Testing into the PortaCount®.

For more information call 01933 672180 email: [e-mail]
www.fullsupportgroup.com
Insert the wick, making sure it has been sitting
in alcohol for at least 2 minutes.
Connect to the power supply
Connect the tubing – blue to blue, clear to clear.
Connect to computer with preinstalled
PortaCount®software, FitPro Ultra.
Turn on.
Perform a ‘Daily Check’ and address any errors, paying
particular attention to the ambient particle count.
© Copyright 2019 FSI-0138-A
Setting up your
PortaCount® 8040 machine
NOTE: To Fit Test an FFP1 or FFP2 respirator, you will need a PortaCount®8048 with n95 technology enabled.
NOTE: When Fit Testing single-use or half-face respirators, the Ambient Particle Count should be in excess of
3000 pcm3. When Fit Testing full-face respirators, the Ambient Particle Count should be in excess of 10000 pcm3.

For more information call 01933 672180 email: [e-mail]
www.fullsupportgroup.com
Fill Salt Solution Reservoir container with water to the ll line and add one salt tablet.
Attach container to machine, screwing anti-clockwise.
Connect to the power supply and turn on.
The machine should buzz and produce a mist from the top.
© Copyright 2019 FSI-0139-A
Setting up a Particle Generator
NOTE: When Fit Testing single-use or half-face respirators, the Ambient Particle Count should be in excess of
3000 pcm3. When Fit Testing full-face respirators, the Ambient Particle Count should be in excess of 10000 pcm3.

For more information call 01933 672180 email: [e-mail]
www.fullsupportgroup.com
Slide sampling probe onto piercing
tool and push nut onto anvil tool.
Push the piercing tool through the mask,
from the inside of the respirator.
Firmly push the tools together and remove. Attach clear tubing to probe and don the respirator.
© Copyright 2019 FSI-0140-A
Probing a single-use
FFP3 respirator
NOTE:
Disposable and reusable respirators are probed in different ways.
Please ensure your respirator is a disposable model before starting.
NOTE: If tted correctly, the probe should not swivel or move.
CAUTION: Probed respirators are for Quantitative Fit Testing only and should be discarded after use.
NOTE: The probe should be inserted centrally around the breathing zone - avoiding seams, folds and valves.
CAUTION:
The piercing tool is very sharp – watch your hands!

For more information call 01933 672180 email: [e-mail]
www.fullsupportgroup.com
© Copyright 2019 FSI-0136-C
Performing a Pre-use
wearer-seal check
1. Prepare 2. Don 3. Check
Fully open respirator. Pull bottom
strap downwards so top strap
runs parallel with nose band on
outside of the respirator.
Pull bottom strap over the head so it rests
at back of the neck and below the ears.
Place bottom of respirator onto the chin
and top of respirator onto bridge of the
nose. Pull upper strap and place it on
crown of head above the ears.
Pull respirator down under
chin and ensure the respirator
sits centrally on the face.
5. Dispose4. Fit Check
Perform a t check by cupping both hands
over the respirator. Unvalved respirators,
exhale sharply. Valved respirators, inhale
sharply. If air leaks around the nose adjust
nose area. If air leaks around the edge of
respirator adjust straps to eliminate leakage,
then repeat process.
Remove the mask by holding the
straps and lifting them over your head,
then dispose of the mask. Do not touch
the mask – it may be contaminated.
Fit testing should be carried out by a trained competent t tester.
Your department t tester is:
Additional supplies of Easimask can be ordered via NHSSC
Order Codes: FSM18 (unvalved) FSM17 (valved).
Closest depart stocking this product:
Custom Fit Unvalved FSM18 Custom Fit Valved FSM17
Please ensure that you follow these six steps to t your respirator correctly:
Please be
aware that our
t testing is
mask and brand
specic. Ensure
you are wearing
the Easimask®
for which
you received
t testing.

For more information call 01933 672180 email: [e-mail]
www.fullsupportgroup.com
NOTE:
Disposable and reusable respirators are probed
in different ways. Please ensure your respirator is
a reusable model before starting.
Attach a short (1-2 inch) offcut of tubing onto
the central shaft of the probing attachment.
Remove a lter from the respirator.
Screw the probing attachment onto the mask with the
tubing inserted into the hole and attach the lter on top.
Firmly push suction pad to side of mask around
the breathing zone, avoiding valves and seams.
Attach metal clip onto the inner tubing
and slot suction pad onto clip.
Attach clear tubing from PortaCount®machine to outer
shaft of the probing attachment and don the respirator.
CAUTION:
Probing attachments vary. Please ensure
your attachment is correct for the respirator
you are Fit Testing.
© Copyright 2019 FSI-0137-B
Probing a reusable respirator
NOTE: You must use a P3 of combination P3 lter of a similar size/weight/shape during the Fit Test.

For more information call 01933 672180 email: [e-mail]
www.fullsupportgroup.com
© Copyright 2019 FSI-0143-A
Performing a Pre-use
wearer-seal check
1. Don 2. Secure 3. Press
Hold the mask against your face
and place harness over your head.
Connect straps behind your head
and tighten securely.
Press the front and back of both
lters covers together and inhale.
The body of the respirator should
collapse against your face,
indicating a good t.
5. Remove4. Repeat
Repeat the press check process
looking up, down, left and right to
ensure a suitable seal is formed.
Unclip the straps behind your head
and bring the harness over your head,
in front of your face. Do not touch the
mask – it may be contaminated.
Fit testing should be carried out by a trained competent t tester.
Your department t tester is:
Additional supplies of Series 8 Half-
Masks can be ordered directly.
Order Codes: IND-110-2289 (small),
IND-110-0051 (medium), IND-110-2290 (large)
Closest department stocking this product:
Series 8
Please ensure that you follow the following ve steps to t your respirator correctly every time
you put it on. A Pre-Use Wearer-Seal Check does not replace the need for a Fit Test.
Please be
aware that you
should have
passed a face
Fit Test before
wearing this
respirator. Face
Fit Testing is
mask and brand
specic.

For more information call 01933 672180 email: [e-mail]
www.fullsupportgroup.com
Fit Test Exercises Protocol
Prepare the equipment
• Ensure the PortaCount®machine has been set up, daily checks run, the ambient particle count of the room is over
3000 pcm3 (single-use/half-face) or 10000 pcm3 (full-face) accordingly and that all respirators are probed.
Prepare the subject
• Ask the subject whether they have smoked or vaped in the past 60 minutes, eaten in the past 15 minutes, if they are
 medicallytandwhethertheyhavecleanshaveninthepast8hours.
Don the respirator
• Instructthesubjecttodontheirrespiratorandperformatcheck.Iftheyareunfamiliarwiththerespirator,please
refer to the respirator’s manufacturer’s instructions.
• Visuallycheckthattherespiratorhasbeenttedcorrectly,andcheckthatnohairistrappedalongthefaceseal.
• If Personal Protective Equipment (PPE) is usually worn during the course of work (including spectacles and hearing
aids) it should also be worn for the Fit Test.
CAUTION
If PPE interferes with the Quantitative Fit Test process
you may need to wear an alternative form of RPE.
The exercises
• Ensure the subject is continually cycling on an exercise bike / walking on a treadmill / stepping on a stepper
throughout the test - with the exception of the bending exercise (step 6)
• Follow on-screen instructions and timings.

For more information call 01933 672180 email: [e-mail]
www.fullsupportgroup.com
© Copyright 2019 FSI-0142-B
Step 2
Deep breathing.
Step 4
Moving head up and down.
Step 1
Normal breathing.
Step 3
Turning head
side to side.
Rainbow Passage
For more information call 01933 672180 email: [e-mail]
www.fullsupportgroup.com
© Copyright 2018 FSH-0082-B
When the sunlight strikes raindrops in the air,
they act like a prism and form a rainbow.
The rainbow is a division of white light
into many beautiful colours
These take the shape of a long round arch,
with its path high above, and its two
ends apparently beyond the horizon.
There is, according to legend,
a boiling pot of gold at one end.
People look, but no one ever nds it.
When a man looks for something beyond
his reach, his friends say he is looking for the
pot of gold at the end of the rainbow.
*To be read continuously for a period of 1 minute, during the Fit Test procedure
Step 6
Bending at the waist.
Step 5
Read the
Rainbow
Passage
on screen.
Step 7
Normal breathing.

Rainbow Passage
For more information call 01933 672180 email: [e-mail]
www.fullsupportgroup.com
© Copyright 2018 FSH-0082-B
When the sunlight strikes raindrops in the air,
they act like a prism and form a rainbow.
The rainbow is a division of white light
into many beautiful colours
These take the shape of a long round arch,
with its path high above, and its two
ends apparently beyond the horizon.
There is, according to legend,
a boiling pot of gold at one end.
People look, but no one ever nds it.
When a man looks for something beyond
his reach, his friends say he is looking for the
pot of gold at the end of the rainbow.
*To be read continuously for a period of 1 minute, during the Fit Test procedure

For more information call 01933 672180 email: [e-mail]
www.fullsupportgroup.com
© Copyright 2019 FSI-0133-B
Quantitative APC Fit Test Report
Employee Name:
Department:
Organisation:
Date of Test:
Is the person clean shaven? Yes No
Is the person medically t? Yes No
Has the person smoked/vaped in the last 60 mins? Yes No
Has the person eaten in the last 15 mins? Yes No
FIT TEST EXERCISES: FIT FACTOR:
Normal breathing
Deep breathing
Turning head side to side
Moving head up and down
Talking out loud - Rainbow Passage
Bending over
Normal breathing
Overall Fit Factor:
Pass level:
Test result Passed 1st time Passed 2nd time Failed 1st time Failed 2nd time
Test conducted using PortaCount®(please circle): 8030 8038 8040 8048
Was n95 enabled? Yes No
Respirator type:
Other facial PPE worn ie: visor/glasses/hearing aids:
Make: Model:
Please identify what was used in your t test:
Tested by: Signature: Date:
Employee Name: Signature Date:

Name Dept/Area of Work Respirator
Make/Model
Pass 1st/
2nd/Fail
Tester
Initials Date
Fit Test Register
Organisation: Date:
Trained Tester/s Name:
For more information call 01933 672180 email: [e-mail]
www.fullsupportgroup.com
© Copyright 2019 FSI-0134-B

For more information call 01933 672180 email: [email protected]
www.fullsupportgroup.com
© Copyright 2018 FSH-0085-D
Evaluation Form
Name: Date:
Job title:
Organisation: Dept:
Address:
Tel: Fax:
Email:
Thank you for completing the delegate evaluation and feedback form. We appreciate the information and look forward to speaking to
you soon. Please return this form to your Trainer. Full Support Healthcare Ltd is committed to high standards of information security,
privacy and transparency. We place high priority on protecting and managing data in accordance with data protection regulations.
Please refer to our Privacy Policy on our website www.fullsupporthealthcare.com/privacy-policy/ for further information.
This Easimask®Fit Tester Training workshop has been independently
reviewed and certied as conforming to universally accepted Continuing
Professional Development (CPD) guidelines.
We really appreciate all feedback, please leave a comment below:
Please rate the following (with 1 = poor and 5 = excellent)
Following this training, do you feel condent to Fit Test your colleagues? (Please circle) Yes No
Do we have permission to publish your comments? (Please circle) Yes No
Were the training room/facilities suitable for Fit Tester training? (Please circle) Yes No
12345
Program achieved the objectives
Quality of course/supporting materials
Presentation style (pace, volume, etc)
Overall satisfaction with the course
