FUNGLAN KJG-180C User manual

WATER-WASHED AIR PURIFIER
MODEL NO.: KJG-180C
OPERATION
MANUAL
QINGDAO FUNGLAN
ENVIRONMENTAL & PROTECTION TECHNOLOGY CO., LTD

Qingdao Funglan Environmental Protection & Technology Co., Ltd
Address: No.143, Zhuzhou Rd, High-Tech Ind Zone, Qingdao, China,
266101
Tel: [phone] Fax: [phone]
Website: www.funglan.com
E-mail: [email protected]

COMPANY PROFILE
Qingdao Funglan Environmental Protection &Technology CO.,
Ltd is a high-new technology enterprise, which professionally
engages in the research, development, manufacture and
marketing about series of products in environmental protection of
the purification and sterilization.
The branch offices are equipped under our main corporation that
possesses a professional team which specializes in the design and
manufacture of air-purified equipments for many years, and keep
a long-term cooperation with many distinguished academician
from top-ranking seat of learning and scientific research
organization at home and overseas, therefore we have the
formidable technical strength. Our quality management system
has been awarded this certificate for compliance with the
standard ISO9001:2000.
Since our corporation was founded, we are always insisting on
the managing principle “Honest, Practical, Innovative and
Public Benefit” and strictly executes national and international
technical standard to satisfy the market demand with excellent
products and service.
Qingdao Funglan strives to provide a clean, germfree and
comfortable living space for the customers

I. Control Panel
Power:
When the LED indicator is on, the machine is ready to work.
Airflow:
Switch the knob on the control panel to turn on the machine and
make the airflow run at low, medium, or high speed.
Anion:
When the machine runs, the ionizer starts working as well.

II. Exploded Drawing
III. Installation and attention
Make sure the power if off. Take out the auxiliary water tank and
twist off the cap, fill water into the tank. Twist on the cap and set
it in right place.
Attention: The machine should be connected with a power
supply after two minutes at least since after the full water tank be
placed in the right position. Otherwise, the machine can give a
water alarm.
Auxiliary water tank
Main Body

Drain
Please change the water in time when it hasn’t been used for a
long time or is contaminated. The steps are as below:
ⅰTurn off the power and unplug the machine.
ⅱTake the auxiliary water tank out.
ⅲScrew off and disassemble the upper body from the main
water tank, lean the left upper body towards right side to loosen
the clips which connects these two parts. Then take out water
deflector and its base.
ⅳEmpty the dirty water of the tank, and clean the tank. If
necessary, you could also add some detergent into the water for
cleaning purpose.
ⅴReplace all the cleaned parts back in the right position, then
screw on the screw on the left side.
vi The machine needs cleaning every 3 months only.
IV. Maintenance
The machine should be placed on a water level surface. When
carrying, please hold both sides of the bottom tightly and
steadily.
Make sure nothing heavy above the airflow outlet.
Photo-catalyst filter
Antibacterial filter
Auxiliary water tank
Main water tank
Water deflector
Water suction pipe
Main Body

Make sure no obstruction blocked up any inlet of the three
sides for ventilation purpose.
As the machine has humidifying function, if your room is
already very moist please choose airflow at low speed state, or
stop working of the machine.
Unplug the machine when it doesn’t need working.
For after-service in case of damage, please go to the
appointed agent for maintenance.
Clean or replace the filters: Take out the bodies and drain the
water, take off and replace the filters. No need replacing the
black humidifying sponge, as which can be cleaned by water.
V. Trouble Shooting:
Troubles
Possible Reason
Solution
Stop working
Power off
1. Check power
2. Switch on the knob

VI. Technical Data
Note: please subject to the actual product if the accessories are
changed; the technical data is subjected to the nameplate on the
machine body.
VII. Accessory
ⅰ. Main set (1 pc) ⅱ. Operating manual (1 pc)
WARNING:
This appliance is not intended for use by persons (including
children) with reduced physical, sensory or mental capabilities, or
lack of experience and knowledge, unless they have been given
supervision or instruction concerning use of the appliance by a
person responsible for their safety.
Children should be supervised to ensure that they do not play with
the appliance.
If the supply cord is damaged, it must be replaced by the
manufacturer, its service agent or similarly qualified persons in
order to avoid a hazard.
Prior to cleaning or other maintenance, the appliance must be
disconnected from the supply mains.
Product Name
Air Purifier
Model
KJG-180C
Voltage
220V
Power
21W
Airflow
290m3/h
Noise
≤32dB(A)
Tank Capacity
8L
Dimension
440mmx252mmx438mm
