Furinno 13234 User manual

Assembly Instruction
Customer Service
Tel/Fax: [phone]
Toll Free: 773.299.8111 (Mon - Fri 9am - 5pm)
Email: [email protected]
WARNING:
>This unit has been designed to support the
maximum loads shown. Exceeding these
load limits could cause sagging, instability,
product collapse, and/or serious injury.
>DO NOT allow children to climb on unit.
>Put heavier items on lower shelves.
its Space. its Budget
www.furinno.com
5.1 Upright the unit.
5.2 Unfold Bin(7) and slide it into the unit.
5.3 Cover Round Sticker(6)on top of screw.
STEP 5
Recommended Maximum Weight
Furinno Simplistic 3-Tier Organizer
with Bin Drawers
1323420140717
MODEL : 13234
22.4”(W) x 36”(H) x 11.2”(D)DIMENSION :
*Unit in Pound(lbs)
15
15
15
Tool RequiredTool RequiredNo Tools Required
Recomm. 1 PersonRecomm. 2 Person
Approx. 5 minutesApprox. 10 minutesApprox. 15 minutesApprox. 20 minutesApprox. 30 minutes

STEP 3
Attach Panel(D)to assembled unit with
Screw(2).
STEP 4
Attach Panel(A)to assembled unit and
tighten Cam-Lock Nut(3).
STEP 2
Attach Panel(C)to Panel(B)with Screw(2).
STEP 1
1.1 Install Dowel(1)& Nail Leg(5)into Panel(C)&(D), as shown.
1.2 Insert Cam-Lock Nut(3)into the pre-drilled holes on Panel(C)&(D).
1.3 Insert Cam-Lock Screw(4)into the pre-drilled holes on Panel(A).
USEFUL HINTS BEFORE YOU START:
1. Read each step carefully before starting.
2. It is important that each step is performed in correct order to avoid difficulties.
3. Identify, sort and count the parts before assembly.
4. Assemble your furniture on packaging cardboard to prevent scratch or damage.
5. Clean the product with mild cleanser using soft damped cloth. Do not use harsh or abrasive cleanser.
6. Using uncompatible hardware might cause damage to product.
1
2
3
8pcs
24pcs
4pcs
A 1pcs
Top Panel
Cam-Lock Nut
No Hardware List Qty No QtyParts List
M6x20mm Dowel
M4x32mm Screw
4
5
6
4pcs
4pcs
4pcs
Round Sticker
7 2pcs
Non-Wooven Bin
Cam-Lock Screw
Nail Leg
B
C
3pcs
2pcs
Side Leg
Shelf Panel
D 2pcs
Back Leg
Arrow towards hole
