Furinno 14151R1 User manual

Assembly Instruction
its Space. its Budget
Furinno 3 Tier Shelf Bookcase
14151R120151110
MODEL : 14151R1
24.5”(W) x 40.3”(H) x 9.5”(D)DIMENSION :
Tool RequiredTool Required
Recomm. 2 Person
Approx. 20 minutes
USEFUL HINTS BEFORE YOU START:
1. Read each step carefully before starting.
2. It is important that each step is performed in correct order to avoid difficulties.
3. Identify, sort and count the parts before assembly.
4. Assemble your furniture on packaging cardboard to prevent scratch or damage.
5. Clean the product with mild cleanser using soft damped cloth. Do not use harsh or abrasive cleanser.
6. Using uncompatible hardware might cause damage to product.
1
2
4pcs
8pcs
A 1pc
Top Panel
No Hardware List Qty No QtyParts List
Small Screw
Mini Fix Cam B
C
1pc
2pcs
Shelf Panel
Bottom Panel
D
E
F
1pc
1pc
1pc
Right Side Panel
Bottom Bar
Left Side Panel
G 1set
Back Panel
3 8pcs
Mini Fix Bolt
4 1set
Wall Mounting Set
5
6
8pcs
2pcs
L Bracket
Shelving Support
7 28pcs
Power Pin
STEP 2
2.1 Install L Bracket (6) to Bar (D) with Small Screw (1).
2.2 Attach assembled unit to Panel (B) with Small Screw (1).
STEP 1
Insert Mini Fix Cam (2) to Panel (A&B), as shown.
STEP 4
Attach Panel (A) to Panel (F), as shown.
3.1 Insert Mini Fix Bolt (3) into Panel (F) using screwdriver.
3.2 Attach Panel (F) to assembled unit in Step 2, as shown.
STEP 3
Customer Support
NEED HELP? For help with assembly, or if you are missing a
part, please call Furinno Customer Service, 1-773-299-8111
from Mon-Fri, 9am-5pm (CST) or email: [email protected]
www.furinno.com

STEP 6
Attach Panel (G) to the back of the assembled unit using Power Pin (7).
Attach Panel (E) to Panel (A&B), as shown.
STEP 5
WARNING:
>This unit has been designed to support the
maximum loads shown. Exceeding these
load limits could cause sagging, instability,
product collapse, and/or serious injury.
>DO NOT allow children to climb on unit.
>Put heavier items on lower shelves.
7.1 Insert Shelving Support (5) to the pre-drilled holes on Panel (E&F).
7.2 Insert Shelf Panel (C) to the unit, as shown.
7.3 Fix the unit to the wall using Wall Mounting Set (4) to prevent unit from falling.
STEP 7
Recommended Maximum Weight
*NOTE: Please use wall
plug to prevent unit
from falling.
