Furinno 11206 User manual

Assembly Instruction
Customer Service
Tel/Fax: [phone]
Toll Free: 773.299.8111 (Mon - Fri 9am - 5pm)
Email: [email protected]
WARNING:
>This unit has been designed to support the
maximum loads shown. Exceeding these
load limits could cause sagging, instability,
product collapse, and/or serious injury.
>DO NOT allow children to climb on unit.
>Put heavier items on lower shelves.
its Space. its Budget
www.furinno.com
Install Panel(D)to L/R Side Panel(A)using
Screw(1).
STEP 8
Attach Panel(E),(D)to completed unit in
Step 6,as shown:
STEP 7
Attach Back Panel(F)to the assembled
unit using Power Pin(4).
STEP 9
Recommended Maximum Weight
Furinno Pasir 3 Tier Bookcase with
Door w/out Handle
1120620140418
MODEL : 11206
15.8”(W) x 31.5”(H) x 9.4”(D)DIMENSION :
15
*Unit in Pound(lbs)
(1)x 4pcs
(4)x 18pcs
15
15
15
Tools Required
Recomm. 2 Person
Approx. 30 minutes

1
2
3
16pcs
6pcs
3pcs
A 2pcsL/R Side Panel
Magnet/Screw
Screw
Door Support
4 18pcsPower Pin
B
C
1pcs
2pcsShelf Panel
Top Panel
D
E
F
1pcs
3pcs
1pcsBack Panel
Bottom Panel
Door Panel
A
B
E
E
E
D
C
C
No Hardware List Qty No QtyParts List
USEFUL HINTS BEFORE YOU START:
1. Read each step carefully before starting.
2. It is important that each step is performed in correct order to avoid difficulties.
3. Identify, sort and count the parts before assembly.
4. Assemble your furniture on packaging cardboard to prevent scratch or damage.
5. Clean the product with mild cleanser using soft damped cloth. Do not use harsh or abrasive cleanser.
6. Using uncompatible hardware might cause damage to product.
STEP 5
Attach Door Panel(E)and Shelf Panel(C)to
the completed unit in Step 4, as shown:
Attach Shelf Panel(C)to L/R Side Panel(A)
using Screw(1).
STEP 6
STEP 3
Attach Door Panel(E)and Shelf Panel(C)to
the completed unit in Step 2, as shown:
Attach Shelf Panel(C)to L/R Side Panel(A)
using Screw(1).
STEP 4
STEP 1
1.1 Insert Screw(3B)and Door Support(2)
on Panel(E).
1.2 Insert Magnet(3A)on Panel(B),(C).
Attach Top Panel(B)to L/R Side Panel(A)using
Long Screw(1).
STEP 2
(1)x 4pcs
(1)x 4pcs
(2)x6pcs
(3B)x3pcs (3A)x3pcs
(1)x 4pcs
Note: Enlarge pre-drilled hole with Screw
before attach with Magnet(3).
