Thankyouforpurchasingthisqualityproduct.Besuretocheckallpacking material carefullyfor
small partsthatmaycomelooseinsidethe cartonduringshipment.
BEFORE USING THISPRODUCT PLEASEREAD, UNDERSTAND, AND FOLLOWTHESEINSTRUCTIONS.
Save these instructionsforfuture reference. FORINDOORUSEONLY
aspenhome
RASSEMBLYINSTRUCTIONS
MADEINVIETNAM
TOOLSREQUIRED (NOTPROVIDED)
PHILLIPSSCREWDRIVER
FUNCTIONALITYINSTRUCTION
LiftMechanism
Assemblyinstructions forthe Lift
Mechanism areinthe Lift
Mechanism package. Follow the
below instructionswhen attaching
desktop tothe LiftMechanism.
LeveleronBase
Adjusttheleveler
whennecessary
Press here torelease
Hook latch
Metalplate
Flipdownkeyboard
tray
2ACoutlet/2USB
powerpack
HARDWARELIST:
1PC
No.
B
C
D
E
Description Sketch Quantity
Bolt 5/16" x3/4"
Lock Washer5/16"
FlatWasher5/16"
Allen Wrench
8PCS
PlasticWireClip
Wood ScrewM4*5/8"
F
G6PCS
10 PCS
COMPONENTSLIST:
1Set
No.
1Description Sketch Quantity
DeskTop
Liftmechanism
(IUAB-301-1)
ITEMNO:IHP-360T-FSL/KHA60"Adj.LiftDeskTop(forIUAB-301-1)
8PCS
8PCS
LiftMechanism PowerBox
LiftMechanism Handset
02-15-2022

STEP1:Putthe desktop face downon a softsurface.
STEP2:Place LiftMechanism IUAB-301-1on desktop and adjusttoalign withthreaded inserts. Follow Step 3 from
the IUAB-301-1assemblyinstructionsforadjusting widthofLiftMechanism.
STEP3:Secure LiftMechanism IUAB-301-1todesktop by using 8bolts(B), 4wood screws (G), 8lock washers(C)
and 8 flatwashers(D). Then use an allen wrench totighten all the bolts.
Page2/2
aspenhome
RASSEMBLYINSTRUCTIONS
MADEINVIETNAM
DeskBack
DeskBack
Screw
G
F
Wire
Threadedinsert
D
C
B
E
G
ACoutlet
Note:RefertoLiftMechanism assemblyinstructions forHandsetoperation.
LiftMechanism
PowerBox
LiftMechanism
PowerBox
LiftMechanism
Handset
LiftMechanism
Handset
STEP4:Tighten boltsthatwere loosened inStep 3 fromthe IUAB-301-1assemblyinstructions.
STEP5:Attach LiftMechanism PowerBox and Handset (“5”and “6”on the componentlistforliftdesk
mechanism)tothe desired positionswithscrews(“A”on the hardware bag forliftdeskmechanism).
STEP6:Follow Step 5 from the IUAB-301-1assemblyinstructins.
STEP7:Clipthe wire intothe plastic wire clip, Attach the plastic wire clips(E) tothe rightposition withscrews(F).
STEP8:Turnthe assembled desktothe uprightposition.
STEP9:Connectthe appropriate wiresleading from the motorand Handsettothe LiftMechanism PowerBox.
STEP10:Plug inthe PowerBox toanACoutlet.
STEP11:If disassemblyisrequired, lowerthe LiftMechanism tothe lowestpoint.
ITEMNO:IHP-360T-FSL/KHA60"Adj.LiftDeskTop(forIUAB-301-1)
02-15-2022
