FURNITURE VILLAGE 5687-2 User manual

Self Assembly
Instructions

Page: 1
IW-17-5687-01-2-0
Pre-assemblypreparation
Pleaseensureinstructionsareread in full beforeattemptingtoassemblethis product.
Stocknumber:5687-2
Thankyou for purchasingthis product.Pleasereadtheinstructionscarefullybeforeusetoensuresafeand
satisfactoryoperation ofthis product.
4-6 DINING EXTENSION TABLE
Pleasecheckthepackcontentsbeforeattemptingtoassemblethis product.A full checklist ofcomponentsis
given in this leaflet.Ifanycomponentsaremissing,pleasecontact theretailerfromwhomyou bought this
product.
This product takesapproximately 30MINUTES toassemblewith 2PEOPLE.
All assemblyshould beperformed on aflat,stable,clean and soft surface.
This product is HEAVY,it should beassembled asnearaspossibletothepoint ofuse. TAKECARE
WHENLIFTING toavoid personalinjuryand (or)damagetotheproduct
Thefittingpackcontains SMALL ITEMS which should be KEPTAWAYFROMYOUNGCHILDREN.
IMPORTANT: Retain theseinstructionsforfuturereference.
Necessary Tools: (Included )

Page :2
1
Fittings and parts checklist
x 1
Tabletop
Item Description Qty. Item Description Qty.
2Leg x 4
A D
B
C
E
F
Cross dowel
Threaded bolt
Flat washer
x 4
x 8
x 8
Lock washer
Hex nut
Spanner
x 8
x 8
x 1
1
2x4
IW-17-5687-01-2-PD#23319

Page :3
StepByStepAssemblyInstructions
Step1
Fitting
1.1: Lay all partson aflat,stable,clean and soft surface.
1.2: Insert 4x cross dowels (A)intotheholeson top oflegs(2)asshown.Ensurethehorizontal
markingon each fitting(A)isfacingasshown.
1.3: Screw8x threaded bolts(B)intofitting(A)that arealreadyconcealed in legs(2)asshown.
Continuetotighten until fittings(B)aresecurelyfastened.
Ax 4
Bx 8
2x4
A
2x4
Step 1.2
Step 1.3
B
B
IW-17-5687-01-2-0

Page :4
StepByStepAssemblyInstructions
Step2 2.1:Attach each leg(2)intoplacebyinsertingbolts(B)intothepre-drilled holesofeach
wooden corners asshown.
2.2 :Insert flat washers (C),lockwashers (D)and hex nuts(E)ontothreaded bolts(B)on leg
(2)and in orderasshown (C)followed by(D)followed by(E).
2.3 :Tighten hex nuts(E)usingspanner(F) asshown.Continuetore-tighten hex nuts(E)
until theyaresecurelyfastened.
Repeat aboveprocedureswith theremaininglegs(2).
2.4 :Stand thetableupright.
Fitting
C x 8
Dx 8
Ex 8
Fx 1
BC
D
E
F
Step 2.1
Step 2.2&2.3
Step 2.4
IW-17-5687-01-2-PD#23319

StepByStepAssemblyInstructions
Step3 3.1:Extend theleavesundertop byslidingtheleavesall theway out asshown.
3.2 :Lift up and push endsofleavesinwardsuntil nogap is visible.
Ensurethecross dowels on support rail is seated in theslot ofapron
Note: Toclosetable,reversetheprocedure.
Page :5
IW-17-5687-01-2-0
Step 3.1
Step 3.1
Step 3.2
Step 3.2

Page :6
IW-17-5687-01-2-0
PLEASE KEEP THESE INSTRUCTIONSFORFUTUREREFERENCE
CareandMaintenance
WoodFurniture
Wood displaysdifferent grain patternsdependingon which way theyarecut -for example,the'medullaryray' which
can appearon oakfurnitureis amarkofgood qualitytimber-thesearejust characteristicsofthenaturalbeautyof
thewood.
Somefurnitureis also deliberatelyaged and rustic.
Wood veneers also allow distinctivepatternstobecreated on somesurfaces, such astabletopsand drawer
frontsbytheway slivers arearranged.
All timberand veneersurfaceswill changecolourand mellow overtime.Newfurniturewill initiallyvaryin shade
fromitemsthat havebeen previouslypurchased.
Howtocareforyourwoodfurniture
Dust with aclean,damp,lint free cloth.Frequent dustingwill removeabrasivebuild up,which can damagethe
finish overtime.
Donot useaverywet cloth or allow anyliquid tocontact with theveneers for alongperiod oftimeasthis can
permanentlydamagethesurface.Wipeup spills immediately.
Donot useanyabrasivecleaneror harsh detergent asthis can damagethesurfaceofthe furniture.
Spray polishesarebest avoided astheycontain siliconeswhich may spoil thefurniture'ssurfacewhen buildingup
overtime.
Make sureall surfacesareprotected fromheat and liquidsbymatsand coasters.
Ensurethat amat or pad is placed underpaperwhenyou arewritingon thefurnituresurface.
Donot placerubber, cork,vinylor plasticmaterials on thewood finish aschemicals within may react with thefinish
ifleft in contact for an extended period oftime.
Ourfurniturewill enduremost temperaturesin thehomebut it is best toavoid placingfurniturenext toheat
sourcessuch asradiators or fires.Beparticularlycarefulwith solid wood asthelackofhumiditycaused byhome
heatingcan causedamagesuch aswarping,crackingor splitting.
Excessiveexposuretosunlight can causefadingofyourfurniture.
Avoid exposingyourfurnituretoanyliquids. All liquidsshould bewiped up immediatelywith asoft,slightlydamp
cloth in thedirection ofthewood grain.If stickyliquid residuesdooccur, theymay beremoved with adilute
solution ofwarmsoapywaterfollowed byaclean,damp sponge.Theareashould then bewiped immediatelyin the
direction ofthewood grain with aclean,soft whitecloth until completelydry.
Nail polish remover, hairspray,perfume,potpourri &anyotherproductsthat containssolventscan damagewood
upholsteryfinishes.
SafetyInstructions:
Neverdrag furniturewhen movingit.Alwayslift it.
Periodicallycheckall fixingstoensurenonehavecomeloose.Re-tighten when necessary.
Pleasetake carewhen handlingor movingthefurnitureascareless handlingmay causedamageor injury.
Furniturecan bedangerousifincorrectlyassembled.Assemblyshould becarried out byacompetent person.
Noliabilitywill beaccepted for damageor injurycaused byincorrectlyinstalled or assembled furniture.
Heavy itemwarning:
It is recommended toseek assistancewhen movingaheavy object.Take carewhen liftingtoavoid personal
injuryand (or)damagetotheproduct.
It is recommended that beforemovingaheavy object toanewlocation it is completelydis-assembled to
avoid personalinjuryor damagetothefurniture.Pleasebecarefultoretain all fittingswhen doingthis.
Extendabletablewarning:
Extendablediningtablesshould beleft extended for thefirst fewmonthstoavoid an uneven appearance.
Likewise,lampsand ornamentsshouldalso bemoved regularly.
