FURNITURE VILLAGE Uniqa Series User manual

Self Assembly
Instructions

Leg Assembly Instructions - Uniqa
Please read these instructions carefully before fitting the legs to your furniture. It is critical that the legs are correctly fitted
otherwise serious damage could occur and frame warranties may be invalid. Two people are required, cross head
screwdriver and a spanner suitable for an M8 bolt will be needed. The sofa is heavy so should be assembled near as possible to
point of use. Take care when lifting to avoid personal injury (or) damage to the furniture.
No liability will be accepted for damage or injury caused by incorrectly installed furniture.
Bag contents - 3 & 2 Seater, Chair and Cuddler Static
Steps 1 - 5 apply to all Uniqa Models
Step 1
Remove bag by cutting ties and push
remainder of the ties down the back of the
seat (see Fig 1)
Step 2
Remove all seat and back cushions, and put
to one side. Carefully lie the unit onto
its back on a clean surface, this is a two person
operation
Step 3
Unscrew the temporary feet and M8 bolts
using a cross head screwdriver
M8 Bolt
Temporary Foot
Step 4
Correctly place the foot above the
two bolt holes (see fig 5).
Step 5
Securely fasten the two M8 bolts using
a cross head screwdriver.
Repeat Steps 4 and 5
Five more times for the Split Motion Lounger
totalling three feet on each unit (see Fig 6).
Three more times for a Static model (see Fig 7)
Bolt Locations
Fig 1. Bag Containing Feet on seat cushions
Fig 2. Underside of sofa exposing all four t
emporary feet
Fig 5. Wood foot (left) metal foot (right)
with bolts shown in postition
Fig 3. Temporary foot
and locations of M8 Bolts
Fig 6. Shows locations of all three feet.
Fig 7. Shows locations of all four feet.
Fig 4. Sofa on back exposing all four t
emporary feet
Step 6 - 3 SEATER STATIC MODEL ONLY
n the centre of the base is a bolt hole.
This has four staples around the outside to help locate.
Attach the central plastic support leg as illustrated.
FAILURE TO COMPLETE THIS STEP WILL RENDER THE
FRAME GUARANTEE INVALID
x1 Centre foot
and Bracket
(with bolt)
x2 Central
Support Foot x6 Wood or Metal
Feet
x4 Wood or Metal
Feet
x1 Central
Support Foot
Bag contents - 3 & 2 Seater Motion Lounger
Fig 8. location for central support foot
Page 1 0f 2

Step 7
The 3 and 2 seater Split Motion Loungers
will arrive as two seperate units, both with
temporary plastic feet used to transport the
furniture (Fig 9. Circled in red) in the
centre. These feet need to be replaced with the
larger central support feet provided within the bag
(see step 1)
Fig 9. Left hand 3Str Split Motion Lounger unit Fig 10. Plastic central foot replaces
temporary foot
Steps 7 - 11 apply to all Uniqa Models
Step 8
The two seperate units will have to
be attached via the brackets located
on the armless sides (see Fig 11).
There will be two on eitherside,
one at the front and one towards
the back. The right hand unit will need
to be pushed into the left hand unit to
slide the brackets together. Ensure both
brackets are secured before
proceeding
Connect the cables leading off into the transformer
and plug into power supply, then fully extend the motions
using the controls located on the outside of both the arms.
Step 9
13cm
Front of sofa
Step 10
To attach the centre foot, first locate the
bolt hole, situated approximately 13cm away from
the front of the sofa (Fig 15). Once located remove
the bolt from the metal bracket of the
centre foot and align the
hole to the sofa. Feed the bolt through
one side through the units and into the
opposite side of the bracket (Fig 16).
Tightly fasten the nut with a spanner to secure
the foot into place (Fig 17).
Brackets
Step 11
Once all feet have been attached
the sofa will now be ready to turn
onto its feet DO NOT PIVOT
SOFA ON BACK FEET instead lift
weight of sofa off the floor and turn
onto its feet. Once the sofa is
upright and in the desired
position replace all seat and back
cushions.
Fig 11. Shows locations of brackets
Fig 12 . illustrates the right hand
unit being pushed into the left hand unit
Fig 13 . cables fitting
into transformer
Fig 14. Shows the motions fully extended
Fig 15. Location of the bolt hole, approx 13cm from front of sofa
Fig 16. Location of the bolt hole, approx 13cm from front of sofa Fig 17. Shows bolt securely fed through,
connecting both units.
Page 2 0f 2
