Furrion eROVE FCR45DCAPA-GL User manual

TM
50Q Electric Cooler
User Manual Model: FCR45DCAPA-GL
This full manual is full online use only.
* Product picture is for reference only.
* This full manual is full online use only.

English
2
Thank you for purchasing this Furrion® product. Before operating your new appliance, please read these instructions carefully.
This user manual contains information for safe use, installation and maintenance of the appliance.
Please keep this user manual in a safe place for future reference. This will ensure safe use and reduce the risk of injury. Be sure
to pass on this manual to new owners of this appliance.
The manufacturer does not accept responsibility for any damages due to not observing these instructions.
Table of Contents
Table of Contents...........................................................................................................................................................................2
Explanation of Symbols ................................................................................................................................................................3
Important Safety Instructions......................................................................................................................................................3
Before Use.......................................................................................................................................................................................4
Introduction ..................................................................................................................................................................................................................................4
What’s in the Box........................................................................................................................................................................................................................4
Parts and Features....................................................................................................................................................................................................................4
Accessories Sold Separately...............................................................................................................................................................................................5
Shared ECO System Components....................................................................................................................................................................................5
Installation ......................................................................................................................................................................................5
Location .........................................................................................................................................................................................................................................5
Wiring ..............................................................................................................................................................................................................................................5
Storing & Transporting ............................................................................................................................................................................................................5
Operation.........................................................................................................................................................................................8
Getting Started ...........................................................................................................................................................................................................................8
Expanded Function *ePodTM Battery Only* ...................................................................................................................................................................9
Navigating Your Cooler ...........................................................................................................................................................................................................10
ePodTM Battery & Dry Storage Compartment...............................................................................................................................................................10
Care & Maintenance ......................................................................................................................................................................12
Troubleshooting ............................................................................................................................................................................13
Error Code ....................................................................................................................................................................................................................................13
Specification ..................................................................................................................................................................................14

English
3
Explanation of Symbols
This manual has safety information and instructions to help
you eliminate or reduce the risk of accidents and injuries.
Always respect all safety warnings identified with these
symbols. A signal word will identify safety messages and
property damage messages, and will indicate the degree or
level of hazard seriousness.
DANGER
Indicates an imminently hazardous situation which, if not
avoided, will result in death or serious injury.
WARNING
Indicates a potentially hazardous situation which, if not
avoided, could result in death or serious injury.
CAUTION
Indicates a potentially hazardous situation which, if not
avoided, may result in minor or moderate personal injury, or
property damage.
Important Safety Instructions
DANGER
●DO NOT use or modify the appliance for anything other
than it's intended purpose.
●DO NOT use damaged electrical components, or touch
exposed areas of wiring.
●DO NOT store explosive substances, such as aerosol
cans, in the appliance.
●NEVER Immerse the cooler or electrical adaptors in
water, shield from rain fall.
●DO NOT let children or incapable persons to play with
or use the appliance, supervise usage or store out of
reach.
●NEVER attempt to service the product without
contacting Furrion.
●DO NOT lift beyond your capabilities, use additional
help if necessary.
●ONLY use Furrion approved accessories.
●NEVER disconnect power, or handle the battery with
wet hands.
●DO NOT use your cooler if it is damaged or
malfunctions in any manner.
●This appliance is not intended for use by persons
(including children) with reduced physical, sensory
or mental capabilities, or lack of experience and
knowledge, unless they have been given supervision or
instruction concerning use of the appliance by a person
responsible for their safety.
Failure to follow instruction will result in serious injury,
property damage or death.
WARNING
●If the SUPPLY CORD is damaged, it must be replaced by
the manufacturer, its service agent or similarly qualified
persons in order to avoid a hazard.
●The repair and maintenance of the cooler should be
conducted by the manufacturer, local dealer or qualified
personnel. Do not attempt to repair your cooler by
yourself, this will void the warranty.
●Do not let the cord hang over the edge of a table or
counter or touch hot surfaces.
●Do not unplug by pulling the cord, always grasp the plug
head.
WARNING
●Do not attempt to move your cooler while it is still
plugged. To move your cooler safely, it should be
unplugged from power supply.
●Do not use mechanical devices or other means to
accelerate the defrosting process, other than those
recommended by the manufacturer.
●Do not damage the refrigerant circuit.
●Do not use electrical appliances inside the food storage
compartments of the appliance, unless they are of the
type recommended by the manufacturer.
HEALTH HAZARD
●Food may only be stored in its original packaging or in suitable
containers.
●Opening the lid for long periods can cause significant increase
of the temperature in the compartments of the device.
●Clean regularly surfaces that can come in contact with food
and accessible drainage systems.
●Store raw meat and fish in suitable containers in the device, so
that it is not in contact with or can drip onto other food.
●If the device is left empty for long periods:
−Switch off the device.
−Defrost the device.
−Clean and dry the device.
−Leave the lid open to prevent mould developing within the
device.
CAUTION
●Unplug your cooler when not in use or before cleaning.
●Always keep lids closed before use.
●It is recommended to operate the unit on a flat surface.
Maximum operation angle is 30°. During transportation,
its slope should be less than 30° and should be handled
carefully.
●When not in use, unplug the adapter or solar panel, take
out the ePodTM Battery and empty the compartment.
Then allow the cooler to air dry.
●The cooler should not be placed inverted.
●Do not use abrasive powders or scouring pads since
they may scratch the exterior and interior surfaces of
your cooler. Use only mild soap and water and allow to
air dry.

English
4
Before Use
What’s in the Box
Make sure the unit and the accessories are in the box. If
anything is damaged or missing, contact your dealer.
●Furrion eRove™ Electric Cooler x 1
●DC (Cigarette Lighter) Cable x 1
●AC/DC Adapter x 1
●Serving Tray x 1
●Dual Cup Holder x 1
●Umbrella Holder x 1
●Basket x 1 (in the cooling compartment)
●Bottle Opener x 1 (installed )
●Screw Plug x 2
●Quick Start Guide x 1
●Warranty Manual x 1
Parts and Features
2
1
4
5
3
8
7
10 11
13
12
16
17
15
14
6
9
Item Part Name
1Lid Latch
2Cooling Compartment
3Serving Tray
4Retractable Handle
5Drainage Cap
6AC/DC Adapter
7Dry Storage & ePodTM Compartment
8USB Ports
9Handle
10 Solar Panel Input
11 DC Input
12 Control Panel
13 Bottle Opener
14 Wireless Charging Pad
15 DC (Cigarette Lighter) Cable
16 Vent
17 Accessory Rail
Introduction
This appliance is designed and manufactured for beverage
and food preservation. Common uses may include:
●RV Indoor refrigerator/freezer
●Portable Camping Cooler
●Emergency Cold Storage
●Cold Grocery Preservation
●Cooler mounted in the vehicle to keep food & beverages
cold
Refrigerant
The refrigerant of the cooler is R134a, a natural gas with a
high level of environmental compatibility and inflammable in
the air.
●During transportation and installation of the cooler, be
certain that none of the components of the refrigerant
circuit become damaged.
●If the refrigerant circuit should become damaged:
−Avoid open flames and sources of ignition;
−Thoroughly ventilate the room in which the appliance is
situated.
Save these instructions for future reference!

English
5
Accessories Sold Separately
Wheel Kit
(C-FCR00DCAPA-01) Furrion ePodTM Battery
(FBN12C33A1)
Solar Panel
(FSPK10MWN-BL)
NOTE: For the wheel kit, Furrion ePodTM battery and solar
panel, please refer to their own manuals separately for
instructions.
Shared ECO System Components
ePodTM Battery
Provided with the ePodTM, sold separately with the
eRoveTM cooler.
Solar Panel
Sold separately for both the eRoveTM cooler and the
ePodTM, but can be shared.
DC (Cigarette Lighter) Plug & AC/DC Adapter
Shared between both the eRoveTM cooler and the ePodTM,
and provided with each.
ePodTM Battery
DC (Cigarette Lighter) Plug AC/DC Adapter
Solar Panel
(FSPK10MWT-BL)
Furrion eRove™
FCR45DCAPA-GL
Furrion Powerstation™
FIVSPB40A-BL
ePodTM Battery
Installation
NOTE: 12V Wiring Installation
●Provide a dedicated circuit to prevent light flicker and
other 12V appliance interference.
●Ensure proper wire gauges are used per the following:
AWG Gauge Max Length* 12V DC
(ft.) (m)
14 0 - 6 0 - 1.8
12 6 - 10 1.8 - 3
10 10 -20 3 - 6
820 - 30 6 - 9.1
●Protect circuit with a 15A delayed or slow blow fuse.
Storing & Transporting
WARNING
EXCESSIVE WEIGHT HAZARD
In case of back or other injuries
to be caused while moving the
cooler, two or more persons
should be utilized to move and
install the cooler.
●Store the Cooler at the temperature range of
-27°F ~ 122°F (-33°C ~ 50°C).
CAUTION
Leaving loose objects inside the cooler compartments
while inside a vehicle on the move can damage the cooler
unit. Always make sure the stored objects are secured.
Location
●This appliance is designed to be free standing only, and
should not be recessed or built in a cabinet.
●NEVER block the air vents during operation and make
certain at least 1" (25.4mm) clearance exists to the air
vents for good circulation.
●Ensure 20'' (508mm) of clearance is above the cooler to
open the lids for accessing the compartments if needed.
●It is recommended to operate the unit on a flat surface, or
the surface with slope of no more than 30°.
●The unit must be placed in a dry and ventilated place far
away from heat sources (such as stove, flue), place the
unit in a well shaded area. (Prevent exposure to direct
sunlight.)
●When the cooler is attached on the prep kit, make sure
there is 20'' (508mm) of clearance on top of the cooler so
that its lids can be opened without blocking.
Wiring
The cooler can be powered from the following auxiliary
sources:
1. Via power adaptor, plugged into a standard fused NEMA
5-15R AC outlet (GFCI not required, as the cooler only
uses a NEMA 1-15P plug, which has no protective ground
terminal). Ensure the outlet can provide at least 3A of
current. The power adaptor is only to be used indoors.
2. Via by-packed cigarette lighter harness, plugged into
a standard 12V cigarette outlet. Ensure the outlet can
provide a continuous current of 10A, with short peaks up
to 15A. The outlet shall be fused as per applicable local
legislation.

English
6
Tie Downs
Restrain the cooler over the top with tie down straps (not
provided) when transporting to prevent tipping over, sliding,
or other hazards. (Fig. 1)
Protection Foam
(not provided)
Fig. 1
NOTE: Do not use the handle or accessory rail as a
restraining point. Always include a protection foam over the
control panel in case of scratching while strapping the cooler.
Wheel Kit
A wheel kit base is available that can be attached securely
to the cooler and used for easy mobility. The wheel kit can
remain secured to the cooler when transported in your
vehicle if tied down properly.
1. See the separate quick start guide of the wheel kit to
assemble it.
2. Place the Furrion eRoveTM Cooler on the wheel kit
following the instruction of direction markings on the
wheel kit. (Fig. 2)
Direction Marking
Fig. 2
3. To lock the eRoveTM Cooler, flip up the latches until they
click into place. (Fig. 3)
Fig. 3
4. To unlock the eRoveTM Cooler, flip up the latches and pull
outwards at the same time until they are unlocked. (Fig. 4)
Fig. 4
5. When the cooler with wheel kit is located in a moving
vehicle, tie down the cooler securely to prevent it from
tipping over, sliding or other hazards. (Fig. 5)
Protection Foam
(not provided)
Fig. 5
NOTE: Do not use the handle or accessory rail as a
restraining point.
Mounting Base
Protection Foam
(not provided)
●The cooler is designed to be fixed to a structure with the
prep kit.
●Before mounting the base, have the prep kit separated
from the wheel kit by removing the wheels (if assembled)
and feet.

English
7
1. Choose a desired location to fix the prep kit. (Fig. 6)
NOTE: Keep min. 5'' (127mm) clearance around the prep
kit for easy hand locking and releasing the cooler.
5” (127mm) 5” (127mm)
5” (127mm)5” (127mm)
Floor
Fig. 6
2. Set the prep kit on the desired location and use 4 screws
(with washers) that are appropriate for the weight of
cooler and its load to fix through the prep kit holes to the
floor. (Fig. 7)
Fig. 7
3. Place the Furrion eRoveTM Cooler on the prep kit following
the markings on the prep kit. (Fig. 8)
Direction Marking
Fig. 8
4. To lock the eRoveTM Cooler, flip up the latches until they
click into place. (Fig. 9)
Fig. 9
5. To unlock the eRoveTM Cooler, pull up the latches and flip
outwards until they are unlocked. (Fig. 10)
Fig. 10
6. When the vehicle is in motion, tie down the cooler securely
with band on the RV floor for additional restraint. (Fig. 11)
Protection Foam
(not provided)
Fig. 11
NOTE: Do not use the handle or accessory rail as a
restraining point.
Mounting the Cooler on Sliding Platform
A sliding platform can be fabricated to support the cooler for
easy storage and usage. Plan for a minimum 200lb (90kg)
cooler weight when considering loading scenario's for the
platform.
1. Use bolts, washers and nuts (not provided) for securing
the prep kit to the tray. Ensure the mounting location on
the prep kit aligns with a supporting member of the sliding
platform.
2. Extend sliding platform out entirely and check the
following:
−Proper load support.
−Clearance for opening and closing cold and dry
storage lids.
−Wiring lengths and connection strains.
−Access to locking latches.
3. Fix the cooler in RV sliding platform. (Fig. 12)
Fix with Wheel Kit Fix with Mounting Base
Fig. 12

English
8
2. Insert the plug of the appropriate adapter into the DC
input socket for power supply. (Fig. 14)
Fig. 14
ePodTM Battery
1. Open the battery compartment lid by pulling the latch
upwards.
2. Remove the terminal cap at the bottom of the battery
compartment by unscrewing the 2 fastening screws.
(Fig. 15)
Fig. 15
3. Block the screw holes with 2 screw plugs (provided).
(Fig. 16)
Fig. 16
4. Insert fully the ePodTM battery into the battery
compartment with the icons on the battery and cooler
aligned. Close the lid afterwards. (Fig. 17)
Fig. 17
It is recommended to clean the cooler before first use. For
detail cleaning instructions, please refer to section Cleaning
Instruction.
Getting Started
Power Input
Select the appropriate power source:
NOTE:
The 400Wh ePodTM battery is purchased separately and
can be used as a standalone power source. The solar panel
is also purchased separately but can not be used as a
standalone power source, it must be used in combination
with the 400Wh portable ePodTM battery.
1AC/DC
Adaptor
Converts 120VAC
from the wall to DC to
power the cooler.
2
Cigarette
Lighter
Plug
Connect directly to
DC power from the
Car or RV to power
the cooler..
3
400WH
Portable
ePodTM
Battery
Power the cooler.
Can be charged by
AC/DC Adaptor,
Cigarette Lighter Plug
or Solar Panel.
4Solar
Panel
Using the 100W solar
panel to charge the
ePodTM battery.
NOTE:
The AC/DC adapter is for indoor use only. Do not use it
outdoors.
Power Input Connection
AC/DC Adapter, DC (Cigarette Lighter) Plug
1. Open the DC input socket cover. (Fig. 13)
DC Input Socket
Fig. 13
Operation

English
9
NOTE:
●Once the ePodTM Battery is plugged in, the LCD display
on it shows white light for 10s. If the ePodTM battery is
charging, the battery icon will flash for a few seconds.
●The dry storage & ePodTM battery compartment should be
closed when not in use.
●If the cooler is not used for a long time, install the terminal
cover back with screws.
Solar Panel
NOTE: Only operate with ePodTM Battery.
1. Open the solar input socket cover.
2. Insert the plug from solar panel into the solar input socket.
(Fig. 18)
Fig. 18
Control Panel Function
Power On/Off
To turn on the cooler, touch and hold "Power" key for 1
second, the buzzer will sound, the control panel will display
the mode and previous temperature setting. USB ports 1,2,3
and wireless charger are activated for charging your device.
NOTE: The LCD screen shows "ECO" for the initial start up of
the cooler.
To turn off the cooler, touch and hold "Power" key again
for 1 second, the buzzer will sound, and the cooler turns off.
The compressor, LCD display, USB and wireless charger will
shut down. However, if ePodTM battery is still inserted and
the cooler still connected to power supply or solar panel, the
device will still charge.
Mode Selection
●Press Mode key to select cooling mode following the
sequence: ECO > Beverage > Freezer > USB.
●Select the ECO, Beverage or Freezer modes, the
temperature settings are automatically set to their default
values.
●Use "/ " to increase/decrease temperature, the
cooler enters in Manual mode and does not turn back
to the ECO, Beverage or Freezer modes even if the
temperature is adjusted to their default values.
●To turn back to the cooling mode (ECO, Beverage or
Freezer), press Mode key to reselect.
●Temperature setting will flash for 2 seconds before
displaying the actual temperature.
Mode Displayed Default Temperature
Range Function
ECO ECO 46°F
(8°C) /Saving Power: Freezer or Beverage
Beverage Beverage 43°F
(6°C) /Cooling Beverages
Freezer Freezer 7°F
(-14°C) /Freezing Items
USB USB
USB ports and Wireless charging function
only, ePodTM battery quick charging activated,
Cooling disabled.
Manual "Not
Displayed" /-8°F ~ 50°F -22°C ~ 10°C Full Range Setting
/
Touch "/ "to cycle through the available temperature
range for the Manual mode. Stop cycling on desired setting
to select temperature. Temperature setting will flash for 2
seconds before displaying the actual temperature.
Touch " " to toggle between Fahrenheit and Celsius. Stop
at the desired setting to select the temperature unit.
Loss of Power Memory Function
If there is a loss of power, the system will resume with the
same settings prior to the interruption as soon as power is
restored.
Expanded Function *ePodTM Battery Only*
Power Level Display
When the ePodTM battery is plugged in the cooler, the battery
icon will indicate the actual battery level.
The battery icon is divided into 4 sections, each of them
indicates 25% of the ePodTM battery capacity.
When there is no ePodTM Battery plugged in or the ePodTM
battery plugged in has no power, the battery icon will not
display.
Deep ECO Mode
A Deep ECO Mode is available to extend the battery run time
when using the ePodTM battery power source.
Deep ECO can be activated only when the device is powered
by the Furrion ePodTM battery. To activate Press “ ” and "
" together for 3 seconds.
The LCD screen displays "d" + "ECO" symbol and lights off
in 5 seconds. The temperature setting range of this mode
is 30°F ~ 46°F (-1°C to +8°C) and the default temperature is
46°F (8°C).
When the cooler is in Deep ECO Mode, only the compressor
is in operation and the “”, “ "and " "keys are active.
The USB or wireless charging function will not be available
and the Mode and Power On/Off keys will be disabled.
To exit this mode, there are two options to choose:
−Remove the ePodTM battery and DC/Solar power input;
−Press “ ” and " "keys at the same time for 3
seconds.

English
10
Seamless Power Interruption
If there is a loss of power, the Furrion ePodTM battery will
automatically maintain the cooler's function seamlessly until
power is restored. No additional setting needs to be selected
to activate the battery.
ePod™ Battery Charging
The ePodTM Battery plugged in the unit can be charged
through an adaptor, cigarette plug or solar panel.
NOTE:
●When ePodTM battery plugged in, connect the AC/DC
adapter, cigarette plug or solar panel to the cooler for
charging the ePodTM battery. The LCD backlight will dim or
turn off if no further operation. Upon touching any key, the
LCD screen will light on again.
●When the cooler is only connected with solar panel and
without the ePodTM battery plugged in, the LCD shows
“SOL” on screen, all functions are disabled.
●When the cooler is with solar panel and with the ePodTM
battery plugged in but the battery voltage is too low, the
battery icon outline will flash, the LCD shows “- -” on
screen, all functions are disabled until the ePodTM battery
is recharged to certain level. And it automatically starts
working when it is recharged.
Navigating Your Cooler
Lid Latch
Pull the lid latch outwards to unlock the lid. Then pull the lid
upward to open the compartments. Close the lid until a "click"
is heard. The lid latch will automatically engage the lock.
Cooling Compartment (Fig. 19)
Retractable Handle
Cooling Compartment
Basket
LED Light
LED Light
Fig. 19
●Open the Cooling compartment lid, and the two LED lights
will illuminate the compartment automatically.
●The translucent basket can be used to store content at
the top and can be removed as necessary.
●Place contents in the cooling compartment that best fits,
avoid exceeding a height of the bottom of the translucent
basket, so that the basket can slide appropriately and the
lid can fully close with a tight seal.
ePodTM Battery & Dry Storage
Compartment
ePod
TM
Battery
Compartment
LED Light
Dry Storage
Compartment
LED Light
●Open the small lid, and the two LED lights will illuminate
the compartments automatically.
●This section is divided into two smaller compartments,
one is the ePodTM battery compartment, the other is the
dry storage compartment.
●Place any content that doesn't require cold storage in the
dry storage compartment. The space is large enough to
store an extra battery if needed.
●If using the battery compartment as additional "dry
storage" make sure the Furrion terminal cap is in
place. Never store metallic/conductive objects in this
compartment.
Retractable Handle
WARNING
●Always use the handles to lift or move the cooler.
●The net weight of the cooler is 61.5lbs(27.9kg). Use
TWO persons to lift the cooler if necessary.
●To lift the cooler, the retractable handle must be in its
retracted position to prevent being broken when the
cooler is heavily loaded.
●To extend the handle, press the Furrion button in on the
handle and pull the handle outward.
●When not in use, press the Furrion button in and push the
handle inward.
Serving Tray
●Use the tray to cut food on or place on it, and to hold
condiments on the three recessed slots.
●The tray is located under the cooling compartment lid for
storage.
●It can be removed from the lid, unfolded and rest on the
retractable handle.
1. Pull out the retractable handle and open the cooling
compartment lid. (Fig. 20)
Fig. 20

English
11
2. Rotate the 4 serving tray locks 90° to release and take out
the Serving Tray. (Fig. 21)
Fig. 21
NOTE: When placing the serving tray back, make sure the
"FURRION" side faces outward. Otherwise the serving tray
will not seat properly.
3. Unfold the Serving Tray to its fully extended position.
(Fig. 22)
Unfold 180°
Fig. 22
4. Place the Serving Tray on the extended handle. (Fig. 23)
Fig. 23
NOTE: Do not place more than 5lbs (2.27kg) weight onto the
serving tray.
Drain Cap (Fig. 24)
Drain Cap
Fig. 24
●Located at the bottom of the cooling compartment side.
●Rotate the cap to take it off, the water in the cooling
compartment can be drained.
Accessory Rail (Fig. 25)
Dual Cup Holder
(3”(76mm) diameter
openings)
Umbrella Holder
(2’’(51mm) diameter
opening)
Bottle Opener
Fig. 25
●Installed on both sides of the cooler.
●Dual cup holder, umbrella holder and other accessories
can be quickly and conveniently attached and detached
from the accessory rail.
Bottle Opener
●The Bottle Opener is installed on the accessory rail.
●Heavy duty construction for durability.
Dual Cup Holder
●Able to be quickly attached to & detached from the
accessory rail.
●Two 3” (76mm) wide openings to fit several beverage
sizes (tumblers, cans, water bottles, 12 oz beer bottles).
Umbrella Holder
●Able to be quickly attached to & detached from cooler
accessory rail.
●Can accept beach umbrella of which handle up to 2''
diameter. The pole should insert into the sand ground for
at least 5'' (127 mm).
●Additional use for fishing poles, flag poles up to 2''
diameter.

English
12
Care & Maintenance
Frost can form on the interior of the cooling compartment
when operating in Freezer mode. It is important to defrost
as necessary and often to prevent a decrease in storage
capacity and efficiency of the appliance. Follow the below
steps for defrosting.
1. Turn off the cooler and open the cooling compartment lid.
2. Empty the cooling compartment. If necessary, move the
items to another freezer.
3. Remove the frost by wiping it off or naturally melting
through the bottom drain port.
Cleaning Instructions
WARNING
●Electrical parts should be wiped by dry cloth only!
●Disconnect any power supply before clean the cooler!
1. Turn off the cooler, unplug the power cord and
remove ePod Battery. Empty the cold and dry storage
compartments.
2. Wash the inside surfaces with a warm water and baking
soda solution. The solution should be about 2 tablespoons
of baking soda to a quart of water.
3. Wash the outside surfaces with warm water and mild
liquid detergent. Rinse well and wipe dry with a clean soft
cloth.
4. Rotate the drain cap off to drain water out of the
compartments. And allow the cooler to air dry.
NOTE:
●Do not use steel wool or steel brush on the stainless
steel. These will contaminate the stainless steel with steel
particles and rusting may occur.
●Do not use cleansers containing corrosive and
deliquescent material (such as scouring powder, bleach,
soap powder, alkaline cleansers, benzene, gasoline, acid,
water, etc.) to clean the appearance panels, lid gaskets
and plastic parts.
Correct Disposal of This Product
To prevent possible harm to the environment or human health
from uncontrolled waste disposal, recycle it responsibly to
promote the sustainable reuse of material resources. To
return your used device, please use the return and collection
systems or contact the retailer where the product was
purchased. They can take this product for environmental safe
recycling.
DANGER
RISK OF CHILD ENTRAPMENT
Before you throw away your old refrigerator or freezer:
●Take off the lids.
●Leave the shelves in place so that children may not
easily climb inside.
CAUTION
Failure to unplug the unit could result in electric shock or
personal injury.
ePodTM Battery Care
Care for the battery as described by the instructions
provided with the battery.
Solar Panel Care
Care for the solar panel as described by the instructions
provided with the solar panel.
Power Failure
Most power failures are recovered within a few hours and
should not affect the temperature of your unit if you minimize
the number of times the lid is opened.
Vacation Time
●Short vacations: Leave the unit operating during
vacations of less than three weeks.
●Long vacations: If the appliance will not be used for
several months, remove all food and unplug the power
cord and ePod Battery. Clean and dry the interior
thoroughly. To prevent odor and mold growth, leave the lid
open slightly.
Energy Saving Tips
●The cooler should be located at the coolest area as much
as possible, away from heat producing appliances and out
of the direct sunlight.
●Let hot foods cool down to room temperature before
placing in the unit. Overloading the unit forces the
compressor to run longer.
●Be sure to wrap foods properly, and wipe containers dry
before placing them in the unit. This cuts down on frost
build-up inside the unit.
●Organize and label food to quickly and conveniently
locate items and reduce duration and frequency of lid
openings.
Defrosting the Cooler
CAUTION
●Never use hard or pointed tools to remove ice or to
loosen frozen objects, because which can damage the
inner surfaces of the compartment.
●Do not empty the frost or water in the compartment by
turning the cooler over.

English
13
Troubleshooting
Before contacting the Furrion Customer Service:
1. Try to solve the problem yourself following the points described in the table below.
2. Turn off the appliance and restart it to see if the fault persists.
Trouble Possible Cause
Cooler does not work
The Cooler is not powered on. Refer Power On/Off section in Page 9 for
instructions).
The circuit breaker tripped or fuse blown.
Compressor turns on and off frequently
The lid is open or is frequently opened, or gasket is torn, ripped or
removed.
The temperature is not set correctly.
Cooling compartments are too warm
Temperature control is not set correctly ( see page 9 for setting
compartment temperature).
The lid gasket does not seal properly.
The lid is open or is frequently opened.
The cooler has recently been disconnected for a period of time.
Vibrating or rattling (slight vibration is
normal) The cooler is placed on uneven or weak surface.
Moisture collects inside the cooler The lid is open or is frequently opened.
Moisture forms on the outside of the
cooler This is normal in hot and humid weather.
Bubbling or gurgling sounds (like boiling
water)
This is the normal sound of refrigerant (used to cool cooler) circulating
throughout the system.
Popping or cracking sounds when
compressor comes on
This is normal for metal parts to undergo expansion and contraction, like
hot water pipes.
The lid can't be closed properly.
The gasket is dirty or bent.
The basket is not seated properly.
Storage compartment is too full and items are interfering with the lid.
Lid latch is damaged or obstructed by sand, screes or something else.
Error Code
Codes Possible Causes
E0 Battery is not recognized by the appliance.
Lo Compressor low voltage protection.
E2 Fan over-current cut-out.
Hot Thermal cut-out of electronic unit.
E6 Controller hardware of the compressor failure (controller detects abnormal parameters)
E7 Cold storage NTC short circuit
E8 Cold storage NTC open
- - Gyroscope malfunction does not work or ePodTM Battery is not discovered.

English
14
Specification
Cooling Storage Volume 1.67 cu. ft. (50 Quart) / 47.3 L
Dry Storage Volume 0.2 cu. ft. (6 Quart)/5.7L
Refrigerant Type R134a
Refrigerant Amount 34g/1.2oz
Cooling Setting
ECO Mode Default: 46°F (8°C)
Beverage Mode Default: 43°F (6°C)
Freezer Mode Default: 7°F (-14°C)
Manual Mode -8°F to 50°F (-22°C to +10°C)
Ambient Temperature* 50°F to 109°F (+10°C to +43°C)
Power Supply/Voltage (DC)
AC/DC adaptor 14.5V /6A
Cigarette Plug 13.2V (10V to 16V)
Solar Panel 16V to 24.5V (open circuit) (sold separately)
ePodTM Battery 14.4V (12.8V to 16.8V) (sold separately)
Noise Level 45 dB (A)
USB Port (output)
USB1 port: 5V /2.4A
USB2 port: 5V /2.4A
USB3 port: 5V /3.1A. 15W quick charge
Wireless Charger 10W
Wheel Detachable Wheel Kit (Sold Separately)
Product Dimension (L x W x H) 35⅝" x 20⅛" x 19⁄"
906mm x 512mm x 507mm
eRove™ Net Weight (lbs/kg) 61.5 / 27.9
NOTE: The ambient temperature of the ePod battery is 32°F to 104°F (0°C to 40°C).

Furrion Innovation Center & Institute of Technology
●52567 Independence Ct., Elkhart, IN 46514, USA ●Toll free:1-800-789-3341
●Email: [email protected]
©2007-2020 Furrion Ltd. Furrion®and the Furrion logo are trademarks licensed for use by Furrion Ltd. and registered in the
U.S. and other countries.
AU201913718, EU005949815-0001, AU201914110 and other patents pending
www.furrion.com
IM-FHA00089 V1.0
