Furrion DV1100 User manual

4
Fig.1 Fig.2 Fig.3
A
B
+ side up

28
HUE
It is for adjusting the hue of the video output.
SATURATION
It is for adjusting the saturation of the video output.
SHARPNESS
It is for adjusting the sharpness of the video output.
5.17.5 SPEAKER SETUP
DOWNMIX
It is for selecting your desired sound effect when there is no center speaker
and subwoofer. There are 3 modes: LT/RT, STEREO, VSS.
LT/RT: When playing a disc with PRO LOGIC Dolby stereo effect, choose the
item, so it will output audio signal with vivid theatre effect.
STEREO: If you choose the item, when outputting audio signal with 5.1 channels,
it will output the left and right channels of signal ; when outputting audio signal
with 2 channels, it will output the common 2 channels of stereo signal.
VSS: If you choose the item, when playing a disc recorded with 5.1 channels,
the main channel speakers can output audio signal with VSS effect.
5.l7.6 OUTPUT SETUP
DYNAMIC RANGE
After selecting the compression mode of LINE OUT, set the item, so you can
adjust the linear compression ratio. If you set it to be FULL, the Peak-to-Peak
value of the audio signal is the minimum; if you set it to be OFF, the Peak-to-
Peak value is the maximum.
DUAL MONO
It is for selecting a desired audio output mode for the left and right ways of signal.
It is mainly for Karaoke of Ac3. There are 4 modes in all as follows:
STEREO, MONO L, MONO R, MIX MONO.
CONTRAST
It is for adjusting the contrast of the video output

27

26
For the DVD System Menu, there are 6 setup pages in all. They display as follows:
5.17.1 SYSTEM SETUP
TV TYPE
The setup item is for matching TV screen size.
4:3 PS: Choose the item when connecting a TV set with 4:3 screen. When playing
the pictures with 16:9 size, the left and right parts of the video will be cut out,
and display in full screen.
4:3 LB: Choose the item when connecting a TV set with 4:3 screen. When playing
the pictures with 16:9 size, the top and bottom parts of the TV screen will be
turned into a black square respectively.
16:9: Choose the item when connecting a TV set with 16:9 wide screen.
PASSWORD
This setup item is for locking or unlocking the rating level of the Parental Control.
The defaulted state is locked. The defaulted password is 0000.
You can set a new password that you like: Select the PASSWORD item and then
press the > button to enter it, then input the original password 0000, and then
press the OK button to unlock it. Press the > button to enter it again, then input
a new password that you like and then press the OK button to make it effective.
Before the other persons see the Manual, you should get the password in mind
and cut out the part of PASSWORD in the Manual.
RATING
The item is for setting a new rating level of the Parental Control.
1. Select the PASSWORD item and then press the > button to enter it, then input
the password mentioned above, and then press the OK button to unlock the
setting of the rating level of the Parental Control.
2. Select the RATING item and then press the > button to enter it, then use the
direction buttons to select your desired rating level, then press the OK button
to confirm.
3. Select the PASSWORD item again and then press the > button to enter it, then
input the password, and then press the OK button to lock the new setting of
the rating level of the Parental Control.
DEFAULT
This item is for making all setup items change back to original status.
Press once to pause the playback,press >|| to resume;
press twice to stop playback, then press >|| to start playback
from the beginning of the first chapter/track.
Disc USB Opreation
Insert Disc
Eject CD
Track Select
Fast Forward
and Backward
Pause
Playback
Stop
Playback
Repeat
Random
Title
With the label facing up,insert a disc into the Disc slot.
The disc will automatically begin playback.
Press EJECT toeject the disc
Rotate TRK >>| or TRK|<< to skip to next or previous
track/chapter.
Rotate and hold TRK >>| or TRK |<< to fast forwards or
backwards.
Press >|| to temporarily stop the playback.
Press>|| again to resume playback.
Press RPT to repeat current playing track/chapter.
Press RPT to resume.
Press RDM to play each track in random order.
Press RDM again to resume.
In DVD/VCD mode,press TITLE to display the title list.
BLUETOOTH OPERATION
Dial or
accept call
Reject or
End call
Press to accept, dial or redial a call.
Press to reject or end a call.
