Fusion 30117 User manual

SOLAR MONARCH
BUTTERFLY STICK LIGHT
Assembly Instructions
IMPORTANT: Please read this manual carefully
before beginning assembly of this product.
Keep this manual for future reference.
Overview
This product is designed to the highest technical specifications and standards. It will supply years of maintenance-free use. Please
read these instructions thoroughly prior to installation, then store in a safe place for future reference. If at any time you are unclear
about this product, or require further assistance please do not hesitate to contact our trained professionals operating the customer
support line at 1-877-615-1378 Monday to Friday between the hours 8:00 AM to 4:00 PM Eastern Standard Time or email
[e-mail].
About Your Solar Light
During the day your solar panel will convert the sun’s light and/or UV rays into electrical power that will charge the rechargeable
battery. When it becomes dark, the solar light will turn on using the power stored in the rechargeable battery as it will detect no
daylight. The unit’s light output strength and duration depends on how many hours and how much sunlight and/or UV rays your
panel absorbs throughout the day.
For maximum output place the solar panel in an area where there is direct sunlight for at least 8 hours in a given day. Do not install
your solar light in a shaded area. The selected location should not be near nighttime light sources such as porch lights, street lights
or pool lights, as these may cause the solar light to turn off prematurely.
model no. 30117

2
Getting Started
Please do not throw away any packing material until all parts are
verified as present.
Parts List
IMPORTANT INFORMATION
Important
• Fully charge the battery before first use.
• For best results, locate your solar lamp in a position where it can get direct sunlight on the solar panel and is generally free from
cover and shade.
• Keep your solar lights away from other nighttime light sources, such as streetlights.
• Make sure the solar panels are not covered by dust, snow and debris. Clean it with a soft damp cloth or paper towel periodically.
Avoid the use of abrasive cleaning agents.
• Use only rechargeable batteries for your solar lights. Replace with a new battery of the same size each year for optimum
performance.
Part # Description
AUpper Pole
BMiddle Pole
C Lower Pole
model no. 30117
Figure 1
A
B
C

3
ASSEMBLY & OPERATIONBATTERY REPLACEMENT
Battery Replacement
Note: The battery in your solar light is preinstalled from the factory.
Step 1: Push the switch to the OFF position.
Step 2: Remove the screws from the battery compartment cover.
Step 3: Carefully lift the cover to access the battery compartment, being sure not to detach any of
the connected wires.
Step 4: Replace the battery with an equivalent new solar rechargeable battery; ensuring the
correct polarity is observed.
Step 5: Reassemble the unit by reversing the above procedure.
Step 6: Fully charge the battery before first use. Charge under direct sunlight in the ON position for
2 days. Your solar light will automatically turn on once it gets dark.
CAUTION: Rechargeable batteries contain nickel-cadmium or nickel-metal hydride and
must be recylced or disposed of properly. Do not mix old and new batteries. Do not mix
alkaline, standard (carbon-zinc), or rechargeable batteries. Do not dispose of batteries in
fire. Batteries may explode or leak.
model no. 30117
Assembly & Operation (Figure 1).
For First Time Use:
Step 1: Assemble lower pole section(s) to upper pole by threading together in a clockwise
direction until secure.
Step 2: Insert the spiked end of the lower pole into the ground until the spike is fully
submerged.
Step 3: Fully charge the battery before first use. Charge under direct sunlight in the ON
position for 2 days. Your solar light will automatically turn on once it gets dark.

Care Information
1. Clean any dirt and debris from the solar panel. The panel cannot recharge if the light is obstructed. Use a soft cloth to clean the
panel. Do not use abrasives or chemicals that might scratch or damage the UV coating.
2. In a region where snow and ice are likely and the light assembly is covered with snow for an extended period of time the
batteries will require a recharge for at least 8 hours.
3. To prolong the life of the product, it is recommended to store the product indoors during the winter months. Remove the batteries
and store in a dry location.
MAINTENANCE
WARRANTY
4
Troubleshooting Tips
If your solar light does not come on at dusl despite following all instructions please try the following steps:
1. Make sure that the solar light is not affected by any other light source.
2. Ensure the solar light does not stand in the shade all day.
3. Check to see if the batteries are installed correctly.
4. Battery may need to be replaced.
model no. 30117
1-Year Limited Product Warranty
This product is covered under a one year limited warranty. Fusion Products Ltd. warrants to the original purchaser that this product
is free from defects in materials and workmanship for the period of one year from date of purchase.
For Technical Support and/or Warranty inquiries please contact:
Fusion Products Ltd.
Monday to Friday
8:00-4:00 PM EST
5 Cherry Blossom Road, Unit 7
Cambridge, Ontario N3H 4R7
Tel: [phone] Fax: [phone]
Email: [email protected]
Website: www.fusionproducts.ca
