Fytech FY-6D User manual

Instruction Manual
FY-6D
Our equipment is approved by the following car manufacturers (China)

1. Precautions
2. Specifications
3. Installation
4. Controls
5. Operation
6. Troubleshooting
1) Troubleshooting
2) Lamp Tube Replacement
7. Exploded View
8. Circuit Diagram
1
2
3
4
5
7
8
9
10
CONTENTS

Page 1
1. PRECAUTION
1. Read this manual carefully before installing or using this equipment.
2. This equipment is designed for paint drying applications. Adjust to the correct
temperature and check minimum safe distance from the heat source when using.
Improper use may cause paint surface damage.
3. Installation and servicing must be performed by a qualified installer or service agency.
4. The system has been designed for easy installation, low operating costs and minimal
maintenance. The warranty does not cover lamp tube defects resulting from misuse or
improper operation.
5. Disconnect power source when the equipment is not in use for a long time.
6. The light tube should not be perpendicular to the ground when the equipment is in
operation. Otherwise, it will shorten the useful life of the light tube.
7. Make sure the cassette plug is tightly connected before using to prevent it from burning.

Model
Input Voltage
Input Power
Curing Area
Temperature
Time Setting
Light Intensity
FY-6D
380V / 1-ph / 50-60Hz
6 × 1000W
1800 × 1000mm
35°C - 80°C
0min - 99mins adjustable
10% - 100%
2. SPECIFICATIONS
Page 2

3. INSTALLATION
Page 3
1. Temperature & distance sensor
2. Cassette
3. Pull rod
4. Lifter
5. Column
6. Lifter switch
7. Power switch
8. Overcurrent protection switch
9. Base
10. Caster
3
5
87
10
1
9
2
6
4
Attention!
Check that plugs
are connected.
The shortwave infrared curing lamp is divided into 3 parts (a base, a column and a cassette).
1) Installation of the base.
a. Open the packing of the base.
b. Install the four wheels on the base respectively and tighten up the screws. Usually, the
wheels with brakes should be mounted on the rear of the base.
2) Installation of the column.
a. Open the packing of the column.
b. Put the column vertically on the top of the base, directly engage the screw holes and
tighten up using the screws.
c. Connect the support arm with the column for supporting cassette.
d. Connect the lifter with the column to control the up and down movement of cassette.
3) Installation of the cassette.
a. Open the packing of the cassette.
b. Connect cassette with support arm and tighten up with the screws.
c. Connect control wires and adjust the angle of cassette.

4. CONTROLS
Page 4
Pull-up this handle
for cassette moving
up and down.
Pull-up this handle
for cassette moving
up and down.
Pull-up this handle
for cassette moving
up and down.
Pull-up this handle
for cassette moving
up and down.
Pull-up this handle
for cassette moving
up and down.
Pull-up this handle
for cassette moving
up and down.
3 s
①
②
③
AUT O
1
2
3
5
6
7
8
4
1. LCD display
2. Lamp selector (each lamp can be controlled
separately)
3. Power adjustment
4. Time adjustment
5. Setting:
- Press the button once, it will enter into
"Routine" mode when the lamp is on.
- Press again, it will enter into "Pulse" mode
when the lamp is on.
- Press and hold to enter into curing
parameters setting mode.
6. Auto
7. Start
8. Stop
1. Setting for Distance
Press and hold the "Setting" (Button 5) to enter into setting mode. Set the curing parameters
according to the requirements of different paints. Nearest distance: The equipment will stop
automatically when the distance between the panel and emitter is less than its preset distance.
Farthest distance: The equipment will stop automatically when the distance between the panel
and emitter exceed its preset distance. The equipment works only in the preset distance range.
2. Setting for Temperature
Press "Power adjustment" (Button 3) when the lamp is ready to use to set the temperature.
3. Setting for Automatic Mode
Press "Setting" (Button 5) when the lamp is ready to use to set curing parameters (shown on
LCD display) according to the requirements of different paints to achieve the best effect - see
next page.
C i r c u i t b r e a k e r m u s t b e i n s t a l l e d

5. OPERATION
Page 5
1. Automatic Mode
a. Properly assemble the curing system according to the instruction (see page 3).
b. Switch on the power supply. The system is ready to use when the graphic appears on the
display screen as follows:
00:00
POWER:80%
00CM
00℃
Routine
Pulse
d. Press the "Auto" button and then press "Start" to go into the automatic curing mode.
Once the automatic mode is selected, four related cure programs become available to
the user – Program 1-4 (Fig. A). The data of these four programs, time (min) and power
(%), can be set respectively (Fig. B). (The curing time and power should be set according
to the requirements of the paint material).
e. Setting curing time. Press the navigation buttons "time +" or "time -” (Button 4, Page 4)
when the lamp is ready to use to adjust curing time.
f. Protect the lamp against shocks and vibrations when the lamp is in use.
g. After this program is completed, the system is able to carry out other programs. Make
sure to turn off the system when the equipment is not in use and keep the equipment
securely in place.
1.Nearest distance (cm)
2. Farthest distance (cm)
3. Lowest Temperature (°C)
4.Highest Temperature (°C)
5.Routine Time (min)
6.Power (%)
7.Pulse Time (min)
8. Power (%)
9. Routine Time (min)
10.Power (%)
11.Pulse Time (min)
12. Power (%)
1.020cm
2.070cm
3.035°C
4.075°C
5.003min
6.070%
7.002min
8.080%
9.005min
10.070%
11.005min
12.080%
Program 1
Program 2
Program 3
Program 4
Fig.A Fig.B
c. Move the cassette forward or backward from the paint surface to adjust to the best
distance for curing. The distance data will be detected and shown on the display screen
automatically. The measuring range is 20-120cm and beyond it is blind zone. The curing
distance between the cassette and paint surface should be set according to the paint
material and weather conditions (air humidity). Usually, keeping a distance of about
45cm from the paint surface is recommended.

5. OPERATION
Page 6
2. Manual Mode
a. Press the navigation buttons "Power +/- " and "Time +/-" when the lamp is ready to use
to adjust the curing power and time.
b. Press the button "Setting" to set the mode of "Routine" or "Pulse”.
c. Press the button "Start".
d. The curing distance between the cassette and paint surface should be set according to
the paint material and weather(air humidity). Usually, keeping a distance of about 45cm
from the paint surface is recommended.
e. The curing time and power should be set according to the requirements of the paint
material. Usually, "Pulse" is set to 5 mins and "Routine" to 10 mins.
g. Turn off the equipment when the work is completed.
3. Pulse Mode
a. Set power and time. Press the button "Setting" and select "Pulse".
b. Press the "Start" button.
c. The curing distance between the cassette and paint surface should be set according to
the paint material and weather (air humidity). Usually, keeping a distance of about 45cm
from the paint surface is recommended.
d. After this program is completed, the system is able to carry out other programs. Make
sure to turn off the system when the equipment is not in use.
3 s3 s
①①
②②
③③
AUT OAUT O
Setting
Power Adjustment
Start
Auto Stop

1. Troubleshooting
Page 7
6. TROUBLESHOOTING
PROBLEM
Lamp tube does not work
Lamp tube does not turn
off
Digital display is blank or
is incomplete
Temperature and time
cannot be adjusted
CAUSE
a. Lamp tube damaged
b. Lamp is not plugged in
c. Control silicon damaged
a. Control silicon damaged
a. Unplugged flat wire in
circuit board
b. Digital display damaged
a. Switch imbalance
b. Keyboard has exclusion
SOLUTION
a. Check lamp tube
b. Plug in lamp holder
c. Check control silicon
a. Check control silicon
a. Check flat wire
b. Check digital display
a. Check the installation
of switch
b. Check keyboard exclusion

2. Lamp Tube Replacement
(a)
(b)
(c)
(d)
(e)
(f)
a. Prepare cassette for replacement.
b. Remove the grille of cassette.
c. Remove the plates from both ends
of the cassette.
d. Remove the fixed plates from both
ends of the cassette.
e. Loosen fixed screws and cut off
connections, the lamp can be
replaced.
f. Repeat the steps above in reverse
order to replace the lamp.
6. TROUBLESHOOTING
Page 8

Page 9
7. EXPLODED VIEW
NO
1
2
3
4
5
6
7
8
NO
9
10
11
12
13
14
15
16
NO
17
18
19
20
21
22
23
24
NO
25
26
27
28
29
NAME
Upright post
Top cover
Plastic band
Bracket
Connector (left)
Clamping bar
Cassette
Temperature & distance sensor
NAME
Plastic nut
Connecting rod
Connecting axle
Connector (right)
Handle
Lower connecting rod
Upper connecting rod
Lifter
NAME
Lifter switch
Front wheels
U-type base
Back casters
Cover plate (lower)
Flange
Relay
Control silicon
NAME
Handle
Power switch
Transformer
Cover plate (upper)
Circuit board

8. CIRCUIT DIAGRAM
Page 10
OU T
IN
F
L1 L2 L3
Control Silicon
Power Switch
Fan
Transformer
A/C Contactor
PCB for Distance
PCB for Temperature
