Serene S2022 Instruction Manual

12SereneS2022/3
Heating panel Series 2
Serene Heating Panel
Models S2022/3
With 24/7 Electronic LCD Programming
Operating
Instruction Manual
Please read and save the user manual

12SereneS2022/3
Heating panel
Introduction
Serene Heating Panels
Serene Convection panel heaters are available as horizontal models, providing
you with the opportunity to choose a model that will optimise the available wall
space. Our new designs have passed rigorous testing and quality assurance
controls with both style and safety in mind. As a result, they have a slim profile,
operate silently, are double insulated, include auto reset overheat protection and
are supplied with wall mounting brackets for simple installation.
These Serene Model 2022/3 convection heating panels incorporate a fully
programmable real time electronic controller with manual override - which enables
simple easy real time programming and operation 24/7.
The electronic thermostat control with rapid cycling samples the air temperature
every few seconds which ensures that the element is only energized for short
periods which minimises power usage and saves you money.
Safety Information:
When using any electrical appliance, safety precautions should always be
observed. Read these instructions carefully, and retain for future reference.
When used by, or near, young children or infirm persons, supervision is
necessary. Young children should be supervised to ensure that they do not play
with the appliance.
Use this appliance only with the voltage specified on rating label.
Do NOT use this appliance other than for its intended use.
Do NOT touch hot surfaces or moving parts.
Do NOT cover the grilles or place any object or material up against the unit,
as this may block entry or exhaust of airflow.
Do NOT probe any opening to remove fluff. To ensure trouble-free
performance it is recommended that on a regular basis the unit be isolated
from the power supply and a vacuum cleaner used to remove dust and fluff
from the inlet and outlet grilles.

12SereneS2022/3
Heating panel
Caution:
When the heater is operated in auto mode by the programmable control ensure
the heater is not obstructed in any way by furniture or drapes etc. Ensure the
heater can operate safely, should the heater switch on when the ambient
temperature drops, or a timer activates the heater.
Do NOT allow the supply cord to come into contact with heated surfaces during
operation.
Regulations require that electrical work be carried out by authorised persons. For
your own safety and that of others, ensure this is done.
If the supply cord becomes damaged, it must be replaced by a qualified person,
in order to avoid a hazard.
Safety Cutout:
Serene Convection Heating Panels are fitted with a resettable thermal cutout.
This safety device will automatically switch off the elements should the heater reach
an abnormal temperature and turn the heater back on once it has cooled down.
Overheating is normally caused by blockage of the air vents or by the vents being
covered.
NEVER COVER THE HEATING PANNEL OR ANY OF THE VENTS.
To clean the vents use a vacuum cleaner and a damp cloth as necessary .

12SereneS2022/3
Heating panel
Installation:
This appliance must be installed in accordance with the current electrical
wiring rules and regulations. The heater must not be located immediately
below a socket-outlet. A suitable disconnection device (acting in all active
supplies) is required to be incorporated in the fixed supply wiring.
When used as a bathroom, the heater must be installed such that the controls
cannot be touched by a person in the bath or shower.
The minimum required distance from the heater to any floor is 150mm.
The minimum required distance from the heater to any adjacent wall is
200mm.
Connection Details:
The heater is supplied with a flex and 3 pin plug. For single operation the
heater can be plugged directly into a socket outlet or hard wired.
For permanent connection to fixed wiring, the plug must be removed.

12SereneS2022/3
Heating panel
Operation & Functions
Control panel
1:POWER ON/OFF BUTTON
2:MANUAL OVER RIDE
3:SET PROGRAM
4:CONFIRM PROGRAM
5:TEMPERATURE DOWN
6: TEMPERATURE UP
7:ECO
8:POWER INDICATOR
9:DAY OF THE WEEK
10: HEATING INDICATOR
11: LOW POWER
12: HIGH POWER
13: N/A
14: MANUAL INDICATOR
15: AUTO INDICATOR
16: TIMER
17: HOURS
18: MINUTES
19: REAL TIME TEMPERATURE
20: TEMPERATURE (℃)

12SereneS2022/3
Heating panel
Program set up:
Turning the heater Power ON/OFF
When the unit is connected to power there is a short buzz, the blue power
indictor 8lights up and the LCD display will light for 12 seconds.
Pressing the’ Power On’ button 1turns the heater on and the day, time and
room temperature are displayed.
Then select HI or ECO temperature setting 2
Manual or Programmed operation selection 3
Temperature setting
Eco or program mode.
Touch 5 or 6 and the temperature indication will flash.
Touch 5 or 6 again to set the temperature.
To finish temperature setting touch confirm button 4.
When the setting temperature stops flashing the room temperature will
show on the LCD screen.
Time setting
When setting up the program for the first time the actual time needs to be
set up as follows.
Day: With the power on press 3 and 4 at the same time for 3 seconds.
The day 9 will flash.
Touch 5 and 6 to select the day and press 3 to finish.
Hour: The hour indicator 17 will be flashing,
Touch (5 or 6) to set the hour and press 3 to finish.
Minute: The minute indicator 18 will be flashing.
Touch 5 or 6 to set the minute and touch 3 to finish.
Seconds: 19 will be flashing,
Touch 5 or 6 o set the seconds and press 3 to finish.
After setting the seconds the controller will revert back to
the day setting as a cycle.
Touch button 4 to finish time setting.
All time symbols will now stop flashing.

12SereneS2022/3
Heating panel
Automatic (A) mode timer setting 7 days timer
1.Day setting:
Press (2) to choose automatic mode display (A) then press (3) and
the current day on the screen. 9 will be flashing .
Touch 5 or 6 to set the day and 17 and 18 will
display the timer for last setting. Press 3 to finish.
2. Timer setting: 19 will display.
Number 1 indicates that the heater is on the first running time.
17 and 18 will display the last setting time, and 17 will flash.
Touch 5 or 6 to set the desired time.
Touch 3 to finish the first running time. 18 will begin to flash .
To adjust the time touch 5 or 6, then touch 3to finish, and then the
first running time is set. EG 7- 10 am.
Now 19 display will show 2, indicating the second running time.
Repeat your settings for this time frame and so on.
Touch 3 to finish the timer setting.
NOTES:
The setting program will only save after you have touched the 4
button.
The factory pre-setting running time is 07-11;and 13-18 hours.
When in automatic mode 16 will not display.
Your Serene heating panel is fitted with a 24 hour clock.

12SereneS2022/3
Heating panel
3. Setting the running time for one week:
After you have set the first day the following day setting will show
and data will be as the first day settings unless it is changed.
For example: :
1. If the Monday running time is set to 08-12 and 13-17, then the
running time from Monday to Sunday will continue to be 08-12 and
13-17.
2. If the Wednesday running time is changed to 08- 12 and 14-18, then
the running time from Monday to Tuesday is 07-11 and 13-18 and from
Wednesday to Sunday is 08-12 and 14-18 unless further changed.
4. After setting the running program:
Touch 4 to save and the heater will operate in accordance to the
programmed settings.
Manual timer setting for the current day
Touch 2 selects Manual mode.
Touch 3 to set the timer and 7 will flash Then touch 5 or 6 to
adjust the hour.
Touch 3 again to set the minute and touch 4 to confirm.
The timer 16 will light up if the setting time is more than the current
time
NOTE: If 3is touched when setting the minute this will cancel the
setting.
Turning off
To turn the heater off touch the power button 1.
Selecting Eco or High power
Touch 7 to choose high/low power,
If high power is selected, 12 will light up.
If ECO is selected 11 will light up.

12SereneS2022/3
Heating panel
Manual or Programmed mode selection
Touch 2 to select the required mode.
If manual mode is selected M will display and A when in programmed
mode.
Memory function after shut down
The program setting when the unit is turned on again will be as the last
setting.
Electronic locking
When power is on touch 5 and 6 at the same time for 3 seconds and all
control functions will be locked and will be displayed on1 19 as a square for
5 seconds and then change to real temperature display.
Methods to unlock:
①No electric supply to the device
②Timer over
③Touch 5 and 6 at the same time for 3 seconds.
NOTE
The program memory is retained in the event of any power interruption.
Over - heat protection
All Serene heating panels are equipped with a overheat protection switch
that will automatically turn the heater off if for any reason the unit has
overheated.
The heater will automatically come back on when it has cooled down

12SereneS2022/3
Heating panel
Cleaning
The heater requires regular cleaning to ensure trouble free operation.
Isolate the heater from the mains power supply.
Use a damp cloth to clean the exterior of the heater.
Do not use any abrasive cleaners.
Use a vacuum cleaner to remove dust and fluff visible on the heater
inlet and outlet grilles.
Ensure the heater is dry before turning the mains power supply to the
heater back on
Wall Mounting Instructions
The heater is fixed on the wall with the mounting bracket attached to
back of the heater.
To secure mounting bracket to the wall
1. Remove the wall mounting bracket from the back of the heater, by
compressing the fittings at the top and/or sides of the bracket, which
clip into the heater body (see figure 2 below).
2. Place the mounting bracket against the wall, ensuring the bracket is
level and the minimum distance between the heater and the adjacent
surfaces are adhered to .
3 .Mark and drill the fixing holes at the top and bottom of the
mounting bracket, and attached to the wall with suitable screws
and/or wall anchors).
4. Locate the heater over the bottom clips of the wall bracket and then
push the heater securely into the fittings on the top and/or sides of
the bracket.

12SereneS2022/3
Heating panel
To remove heater from the wall
1. By using a cross head screwdriver, remove the 2 locking screws of the
wall mounting bracket.
2. Lift the heater up and away from the wall.
IMPORTANT: When fitted in a bathroom
The heater must NOT be located immediately below a socket outlet.

12SereneS2022/3
Heating panel
Specifications:
Serene S2022/3
Model S 2022Power: 1000W/500W
Dimensions (mm): W 460 D 75 H 400
Model S2023 Power 2000W/1000W
Dimensions (mm): W 830 D 75 H 400
Electrical
Supply 230-240 volts A.C. 50 Hz
Wattage 500W-2000W
Wiring: Permanent connection or by cord set.
Double insulated, no earth required.
Ingress Protection Rating IPX24
Serene Industries Limited reserves the right to alter specifications without notice.
Contact :
NEW ZEALAND
t: [phone]
f: 0800 437 264
e: [e-mail]
w:www.serene-ind.com
PO BOX 33501, Barrington, Christchurch 8024
AUSTRALIA
e: [e-mail]
w :www.serene-ind.com
HONG KONG
t: [phone]
f: [phone]
e: [e-mail]
w:www.serene-ind.com
1010, 10th Floor, Block A, 27 Wing Hong Street, Cheung Sha Wan,
Kowloon
