Fytech FY-1W User manual

1
Shortwave Infrared Paint
Curing System
Instruction Manual
Model No: FY-1W

2
Shortwave Infrared Paint Curing Lamp
INSTRUCTION MANUAL
*Please read this manual carefully before installing or servicing this equipment.
Precaution
1. This equipment is designed for paint curing application. Keep a safe distance
between emitter and panel. Improper servicing can cause paint surface
damage.
2. Installation and service must be performed by a qualified installer or service
agent.
3. The system has been designed for easy installation, low operating costs and
minimal maintenance. The warranty does not cover lamp tube defects
resulting from misuse or improper operation.
4. Disconnect power source when the equipment not in use for long time
5. The lamp tube should not be perpendicular to the ground when the
equipment is operating. Otherwise, it will shorten the life of the lamp tube.
6. Turn off the equipment after using. Place the equipment in a safe place to
avoid damage to the lamp tube.
Technical Parameter
Model
Parameter
FY-1W
Power Supply
220V 50/60Hz Single Phase
Input Power
1100W
Curing Area
800×500mm
Temperature
40°C – 75°C
Timer
0min-60min Adjustable
Light intensity
100%

3
Installation
Able to move upwards, downwards and rotate 360°

4
Controls
ON/OFF TIMER
Operation
1. Set curing time according to the requirement of paint for curing.
2. To achieve the best result, the emitters should be parallel with the paint
surface. Keep a distance of 30-60 cm from the panel.
3. During the process of curing, the paint surface must be clean without water
and impurities.
4. Switch on the power supply and set up the curing time to start curing
process.
5. Turn off the equipment after using. Place the equipment in a safe place to
avoid damage to the lamp.
